1. Association Groups

The lock supports 2 association groups. Per Z-Wave Plus requirements, group 1 is
assigned to the Lifeline group. The Lifeline group supports the following unsolicited
messages:
Group 2 is available for all Notification Reports and can be used to send notifications to
at most 5 other nodes.

2. Configuration Parameters

The Z-Wave door lock module supports the use of the configuration command class to
provide advanced configuration of the door lock over the Z-Wave network. This section
describes the configuration parameters supported by the door lock.
2.1 Configuration Parameters 1 through 30
Configuration parameters 1 through 30 are a one byte field used to set the type of user for
their corresponding user code. The following table shows the valid values for user code
types:
!
" #
$$
Reserved
Owner (Default)
Reserved
Guest (required for Year/Day schedules)
Worker (required for week day schedules)
Reserved
$%
No User Code assigned
Battery Report
Door Lock Operation Report
Notification Report
Device Reset Locally Notification
