3 Install the exterior keypad, mounting plate, and spindle
A B
Install exterior keypad. Route cable through mounting plate.
cable goes
over latch
F
4 Install interior assembly
A
Remove battery cover and battery pack from interior assembly.
a
b
Remove battery cover. Remove
battery
pack.
M
c
Install 4 AA batteries into battery pack.
J
Ensure correct polarity.
For best results, use
K
new, non-rechargeable
alkaline batteries only.
5 Install levers
A
Install interior lever.
Lever handle
faces away
from the latch.
Y1 or Y2
6 Test latch operation
Close door, test latch operation and make adjustments as needed:
The small bolt of the latch should not enter the strike
hole. If it enters the strike hole, reposition strike.
C
Secure mounting plate with
supplied screws.
T (2x)
G
B
Install interior assembly onto mounting plate.
a
K Connect cable.
b
K
Install
battery
pack.
Do not install
battery pack
into interior
assembly yet.
B C
Secure interior lever.
Tighten pre-
installed set
Z
screw.
small bolt in
strike hole
small bolt NOT
in strike hole
2 / 4
D
Install spindle.
keep parallel to
edge of door
rounded edge
faces latch
F2
tighten
screws
evenly
L
c
Push interior assembly onto
mounting plate.
Push excess
cable back into
the door as you
install L.
Turnbutton
may need to
be turned to
install L.
D
Install exterior lever.
Lever handle
faces away
from the latch.
Y1 or Y2
If latch is loose in the strike, adjust the strike tab so it
grips the latch bolt better when the door is closed.
actual
size
T
latch
actual
size
U
Ensure tight cable connection.
d
Secure with
screws.
U (2x)
Secure exterior lever.
Tighten pre-
installed set
Z
screw.
tab
