INSTRUCTION
MANUAL
SPECO 960H WDR Series
Speco Technologies is constantly developing product improvements.
We reserve the right to modify product design and specifications without notice and without incurring any obligation.
WDR705H
(Miniature Camera)
- 1 -
Rev. 12/01/2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WDR705H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Speco WDR705H

  • Page 1 INSTRUCTION MANUAL SPECO 960H WDR Series WDR705H (Miniature Camera) Speco Technologies is constantly developing product improvements. We reserve the right to modify product design and specifications without notice and without incurring any obligation. Rev. 12/01/2015 - 1 -...
  • Page 2: Table Of Contents

    Precautions Contents ............1 ◑ Precautions ..........2, 3 ◑ Safety Instructions ........4 ◑ Package Contents ........5 ◑ Camera Installation ........5 ◑ Camera Dimension ........5 ◑ Specifications ..........6 ◑ Features ............7 ◑ OSD Menu Details ........8-31 ◑...
  • Page 3: Precautions

    Precautions Do not install the camera in Do not install the camera under Do not touch the front lens of the extreme temperature conditions. unstable lighting conditions. camera. Only use the camera under conditions Severe lighting change or flicker can This is one of the most important parts of where temperatures are between cause the camera to work improperly.
  • Page 4 CAUTION CAUTION CAUTION RISK OF ELECTRIC SHOCK RISK OF ELECTRIC SHOCK RISK OF ELECTRIC SHOCK DO NOT OPEN DO NOT OPEN DO NOT OPEN CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER(OR BACK).
  • Page 5: Safety Instructions

    Safety Instructions Precautions for use ◑ This camera should be installed by qualified personnel only ◑ There are no user serviceable parts inside ◑ Do not disassemble this camera other than to make initial adjustments ◑ Use a UL approved regulated 24 volt AC or 12 volt DC power supply ◑...
  • Page 6: Package Contents

    Package Contents Please make sure that the following items are included in the Package: WDR705H • 1 Video Test Connector, Power Jack • Set Screw - 2 Tapping Screws M3x10 - 2 Machine Screws M2x3 CAMERA INSTALLATION CONNECT POWER CABLE 1.
  • Page 7: Specifications

    Speco Technologies (Miniature Camera) 0.001Lux 4mm Fixed Board Lens ■ WDR705H 0.001Lux 0.001Lux SPECIFICATIONS WDR705H MODEL Image sensor 1/3 Inch Super HAD CCD Ⅱ (ICX662, ICX663) DSP / AFE SONY CXD4141GG / CXD5148GG Total pixels NTSC : 1028(H) x 508(V)
  • Page 8: Features

    Smart-IR General Features Scene Select Provide the best image automatically for every situation by intelligent scene analysis. Provide Scene Select 2D-DNR the best image by automatic tuning for selected scene manually. 2D-DNR 2D-DNR 2D-DNR 2D.3DNR Filtering Method of Newly Advanced DNR Function 2D-DNR Digital Noise...
  • Page 9: Osd Menu Details

    SETUP MENU Menu items can be selected by using the OSD buttons of the camera 1. Press the Set Up button. * The Set Up menu will be displayed on the monitor. SETUP MENU ← 1 / 2 → SCENE SELECT FULL AUTO PICT ADJUST EZOOM...
  • Page 10: Advanced Menu

    SCENE SELECT Provide the best image automatically for every situation by intelligent scene analysis. Provide the best image by automatic tuning for selected scene manually. SETUP MENU ← 1 / 2 → SCENE SELECT FULL AUTO PICT ADJUST EZOOM PRIVACY MASK MOTION DET SYS SETTING EXIT...
  • Page 11 ◆ SHUTTER/AGC This function is used to select Automatic or Manual shutter speed control. 1. On the Set Up menu screen select SHUTTER/AGC by using the Up or Down button. 2. Select the desired shutter mode by pressing the Left or Right button. ADVANCED MENU ←...
  • Page 12 * MANUAL - SHUTTER : The function is used to control the light exposure. - AGC MAX : The function is to control the brightness of dark lux. * FIX - SHUTTER : The function is used to control the light exposure. - AGC : The brighter image can be displayed by adjusting AGC( Auto gain control) level.
  • Page 13 * ATW : Auto tracking white, normal environment setting under fluorescent lamp or outdoors. - SPEED : Select the start point of auto tracking speed and time by pressing the left or the right button. - DELAY CNT : Select the start point of Auto tracking speed and time by pressing the left or the right button.
  • Page 14 ◆ HLC/BLC ADVANCED MENU ← 1 / 2 → SHUTTER/AGC AUTO WHITE BAL HLC/BLC WDR/ATR-EX DAY/NIGHT IR OPTIMIZER - - - RETURN HLC SETUP CLIP LEVEL RETURN * HLC : HLC, control and mask process for a strong light source. Select 0~255 by pressing the left or the right button.
  • Page 15 ATR-EX SETUP CONTRAST CLEAR FACE RETURN *ATR-EX - CONTRAST : Increase bright illuminance and dark illuminance level over average value and then control the contrast by selecting LOW, MID and high. - CLEAR FACE : The function is to increase the lux when the object is in the back light. WDR SETUP CONTRAST CLEAR FACE...
  • Page 16 ◆ DNR The level of DNR noise removal mode is getting higher, noise removal effect will be good, but ghost effect may be shown up. Select 0~6 by pressing the left or the right button. ADVANCED MENU ← 1 / 2 →...
  • Page 17 ◆ DAY/NIGHT Picture can be displayed in either color of black and white. 1. Select DAY/NIGHT using the Up or Down button on the SETUP menu screen. 2. Select the desired mode using the Left and Right buttons. ADVANCED MENU ←...
  • Page 18 ◆ IR OPTIMIZER ADVANCED MENU ← 1 / 2 → SHUTTER/AGC AUTO WHITE BAL HLC/BLC WDR/ATR-EX DAY/NIGHT IR OPTIMIZER - - - RETURN IR OPTIMIZER SETUP MODE AUTO IR AREA - - - - LEVEL IR LED DAY/NIGHT COLOR NIGHT IR SHADE COMP RETURN - MODE : IR LED saturation is fixed positions or set the areas automatically.
  • Page 19 - LEVEL : The level of IR Optimizer can be controlled by selecting from 0 to 12. - IR LED(OPTION) : IR LED can be select on or off. - COLOR NIGHT : The function is to present the color in the night mode. - IR SHADE COMP →...
  • Page 20 LENS SHADE COMP SETUP PATTERN SET1 POSH POSV RETURN - PATTERN : The function is to increase the brightness of outside of lens. - POSH : Adjust the bright area by left and right . - POSV : Adjust the bright area by up and down. ◆...
  • Page 21 ◆ FLK LESS The function is to prevent flickering automatically. ADVANCED MENU ← 2 / 2 → LENS SHD COMP DEFOG FLK LESS ANTI CR RETURN FLK LESS SETUP MODE GAIN CNTL RETURN ◆ ANTI CR COLOR rolling control. - 20 -...
  • Page 22: Pict Adjust

    PICT ADJUST Move the cursor to PICT ADJUST press the SET button. SETUP MENU ← 1 / 2 → SCENE SELECT FULL AUTO PICT ADJUST EZOOM PRIVACY MASK MOTION DET SYS SETTING EXIT PICT ADJUST BRIGHTNESS CONTRAST SHARPNESS COLOR GAIN RETURN ◆...
  • Page 23 ◆ COLOR GAIN Adjust the color tone density from 0 to 255. EZOOM SETUP MENU ← 1 / 2 → SCENE SELECT FULL AUTO PICT ADJUST EZOOM PRIVACY MASK MOTION DET SYS SETTING EXIT EZOOM SETUP TILT RETURN - MAG : (x1 ~ x256) Digital Zoom. - PAN : Left and right control level 0~1023.
  • Page 24: Privacy Mask

    Image stabilization SETUP MENU ← 1 / 2 → SCENE SELECT FULL AUTO PICT ADJUST EZOOM PRIVACY MASK MOTION DET SYS SETTING EXIT PRIVACY MASK Hide an area you want to hide on the screen. When the PRIVACY menu screen is displayed, press the Up and Down buttons to set to PRIVACY. SETUP MENU ←...
  • Page 25 PRIVACY MASK SETUP AREA SEL 1/15 DISPLAY POSITION - - - - COLOR - - - - TRANSP - - - - MOSAIC - - - - RETURN ◆ AREA SEL Selects the mask frame to be adjusted. ◆ DISPLAY Display the mask frame.
  • Page 26: Motion Detection

    MOTION DETECTION SETUP MENU ← 1 / 2 → SCENE SELECT FULL AUTO PICT ADJUST EZOOM PRIVACY MASK MOTION DET SYS SETTING EXIT MOTION DETECTION DETECTION SENSE INTERVAL BLOCK DISP MASK AREA MONITOR AREA RETURN * DETECT SENSE : Motion detection strength level 0~127 control. * INTERVAL : Set the interval of Motion sense.
  • Page 27: System Setting

    - LEFT : Sets the left side of the monitoring frame selected by the AREA SEL parameter. - RIGHT : Sets the right side of the monitoring frame selected by the AREA SEL parameter. MONITOR AREA AREA SEL AREA MODE BOTTOM LEFT RIGHT...
  • Page 28 ◆ LENS You can select Manual or Auto mode depending on the lens type. ◆ FLIP Select the image of up and down, left and right and reverse. ◆ LCD/CRT Set the monitor of output ◆ COMMUNICATION(Optional) COMMUNICATION PROTOCOL PELCO-D ADDRESS BAUDRATE 38400...
  • Page 29 ◆ CAMERA ID To select the position where the camera ID should be displayed on the screen. Move the cursor to POS and press the SET button. CAMERA ID SETUP ABCDEFGHIJKLMNOPQRSTUV W X Y Z 0 1 2 3 4 5 6 7 8 9 ! ” # $ % & ’ ( ) _ ` ,¥...
  • Page 30 LANGUAGE Selects the language in which to display the internal OSD menu. The menus can be changed in real time in the selected language. SETUP MENU ← 2 / 2 → LANGUAGE ENGLISH VERSION MAINTENANCE EXIT VERSION This number can check the specifications of the camera. SETUP MENU ←...
  • Page 31 MAINTENANCE SETUP MENU ← 2 / 2 → LANGUAGE ENGLISH VERSION MAINTENANCE EXIT ◆ W.PIX MASK : The function is to control and compensate the white spots. MANUAL COMP REGISTRATION REG. POINT CUSRSOR COLOR WHITE BLINK REG. NUMBER 3 / 64 RETURN *MANUAL - REGISTRATION : Compensate the white spots.
  • Page 32 * AUTO AUTO COMP LEVEL1 LEVEL2 AUTO RETURN ◆ CAMERA RESET This function initializes all the internal OSD menu settings together. - 31 -...
  • Page 33: Trouble Shooting

    Trouble Shooting ● PROBLEM POSSIBLE CAUSE ☞ Check the power cable, power supply output and video Nothing appears on connection between the camera and monitor. the screen. ☞ Are the camera lens or the lens glass dirty? Clean the lens / glass with a soft clean cloth. The image on the ☞...
  • Page 34 - 33 -...
  • Page 35 - MEMO - - 34 -...
  • Page 36 200 New Highway Amityville, NY 11701 631-957-8700 1 800 645 5516 www.specotech.com...
