Page 1: Wide Dynamic Range
Wide Dynamic Range Dome Camera WDR-D3 200 New Highway Amityville, NY 11701 631-957-8700 www.specotech.com Please read this manual thoroughly before operation and keep it handy for further reference. -
Page 3: Warning And Caution
WARNING & CAUTION CAUTION The lighting flash with an arrowhead symbol, within an equilateral triangle is Intended to alert the user to the presence of un-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to The exclamation point within an equilateral triangle is intended to alert the user to the... -
Page 4: Camera Installation
CAMERA INSTALLATION CONNECT POWER CABLE 1. WHEN USING 12 VOLTS DC (constant voltage 600 mA) POWER INPUT:RED CONNECT CENTER:(+) POWER SUPPLY 2. WHEN USING 24 VOLTS AC (40 Volt Amps) POWER RED(+) CONNECT BLACK:(-) POWER SUPPLY 3. CONNECT VIDEO CABLE -CONNECT BNC CABLE TO THE BNC JACK. - Page 5 CHAMELEON DOME INSTALLATION If desired, place the Chameleon Dome over the WDR-D3 Push the Chameleon Dome over the WDR-D3 until it snaps into position. ● Notes : If painting is desired, please do so before installation * Painting method on Chameleon Dome * Spray the Chameleon Dome with your desired color * If necessary apply a second coat...
-
Page 6: Internal Components
INTERNAL COMPONENTS 1. Mechanical (1) DC AUTO-IRIS LENS Adjust between T angle (focal length) Set the focus by adjusting ∞ NOTE: BOTH OF THE ABOVE ADJUSTMENTS GET LOCKED INTO POSITION THROUGH THE USE OF "LOCKING HANDLES". (2) JOY STICK TO SET THE OSD (ON SCREEN DISPLAY) , PRESS THE JOY STICK FOR ONE SECOND AND SET AS DESCRIBED IN THE MANUAL (2) JOY STICK... - Page 7 2. Joy Stick RIGHT LEFT DOWN Push the Joy stick for one second, and the OSD appears on the screen. Move the Joy Stick up, down, left & right to control the OSD functions.
-
Page 8: General Information
1. GENERAL INFORMATION SAFETY PRECAUTION ■ Do not open and modify Do not open the cabinet except during maintenance and installation, as it may be dangerous and cause damage. ■ Do not put objects inside the unit Make sure that no metal objects or flammable substances get inside the camera. It could cause fire, short-circuits or damages. -
Page 9: Camera Features
3. CAMERA FEATURES PRODUCT FEATURE 1. High Resolution It has 540 lines of horizontal resolution and 460 lines of vertical resolution. (540 HTVL equivalent) 2. Superior Wide Dynamic Image Quality It has very Wide Dynamic Range by using Pixim ORCA Chip Set. Film-like colors are described under various Light conditions even in high dynamic range scenes Dynamic Range is greater then 120 dB. -
Page 10: Camera Specification
4. CAMERA SPECIFICATION Signal System Pick-up Device Total of pixels Horizontal Resolution Scanning System Synchronization Video Output Iris Control Sensitivity S/N Ratio Dynamic range Shutter Speed Lens Mount AGC Control OSD Menu Control Supplied Voltage Power Consumption Operating Temperature Storage Temperature Operating Humidity Storage Humidity NTSC / PAL... -
Page 11: Main Menu
5. MENU AND SETTING DETAILS MAIN MENU SET UP ID ID POSITION : UP-LEFT or UP-CENTER or UP-RIGHT DOWN-LEFT or DOWN-CENTER or DOWN-RIGHT LENS WB CONTROL AGC CONTROL LOW LIGHT SLOW SHUTTER(Range OFF~X32) SPECIAL BACK LIGHT(ON/OFF/BACK LIGHT JONE) FLICKER LESS(OFF/ON/FLICKER LESS JONE) EXIT MENU DISPLAY ID:ON or OFF CAMERA ID : 8 CHARACTER... -
Page 12: Osd Menu Control
OSD MENU CONTROL CENTER KEY - Used to access the menu mode, Also used to confirm the setting UP / DOWN KEY - Used to choose the desired menu selection. LEFT / RIGHT KEY - Used to choose the desired menu feature adjustment. OSD MENU ENTER / EXIT A. - Page 13 E. WB CONTROL • ATW (Auto Tracking White Balance) : The camera automatically control the white balance in any environment. • AWB (Auto White Balance) : The white balance is automatically adjusted in a specific environment. • MANUAL : Users can adjust the colors by adding or reducing the WB level. You can adjust the desired WB level from 2K to 11K F.
- Page 14 DIMENSIONS * SIDE VIEW : WDR-D3 * TOP VIEW : WDR-D3...
-
Page 15: Warranty
WARRANTY... - Page 16 200 New Highway Amityville, NY 11701 631-957-8700 www.specotech.com...
