WaterLogic WL400 Service Manual page 3

RESETTING THE HOT TANK OVERLOADS ‐ HIGH LIMIT SAFETY
1. Turn off Green Heater/Compressor Switch on rear of unit. O=OFF
2. Unplug the Power Cord from rear of unit.
Remove the Tower Cover Locking Screws and Slide
3.
Locks towards outside of unit to unlock both locks.
4. Slide Top Cover forward and lift in front of Top Cover to open.
Remove the 2 Phillips Screws from Left Side Panel (when standing
5.
behind unit) and remove side panel.
Check and press both Thermal Overload buttons on Hot Tank.
6.
7. Close, lock and replace Top Cover Screws
Turn on Red Power Switch and Green Heater / Compressor
8.
Switch. I=ON
WL400 Manual Page 15 – Revision: 5‐2‐2018
Remove Two Screws
Slide Locks Open
