Incoming inspection functional tests
74
Preset recall test.
4. Restore the Factory Preset. (See page 59, Restore the factory presets.)
NOTE.
This test overwrites presets A1 through A4. Save any existing presets to
USB flash memory before doing this procedure.
5. Set the waveform rasterizer to display a picture in tile 1 and a waveform
in the remaining tiles:
a. Press the Display Select 1 button and then press the PICT button.
b. Press the Display Select 2 button and then press the WFM button.
c. Press the Display Select 3 button and then press the WFM button.
d. Press the Display Select 4 button and then press the WFM button.
6. Save the current settings as preset A1:
a. Press and hold the PRESET button to display the Preset Menu.
b. Select Save Preset > Select Group A > Save A1.
c. Press SEL to save the preset.
d. Briefly press the PRESET button to close the Preset menu.
You can also press and hold 1 (Preset) button to save the current settings
to Preset 1.
7. Repeat steps 5 and 6 to create a preset with picture in tile 2 and waveform in
tiles 1, 3, and 4. Save as Preset A2.
8. Repeat steps 5 and 6 to create a preset with picture in tile 3 and waveform in
tiles 1, 2, and 4. Save as Preset A3.
9. Repeat steps 5 and 6 to create a preset with picture in tile 4 and waveform in
tiles 1, 2, and 3. Save as Preset A4.
10. Repeat steps 5 and 6 to create a preset with picture in tiles 1 and 4 and
waveform in tiles 2 and 3. Save as Preset A5.
11. Repeat steps 5 and 6 to create a preset with picture in tiles 2 and 4 and
waveform in tiles 1 and 3. Save as Preset A6.
12. Set the waveform rasterizer to the factory presets. (See page 59, Restore the
factory presets.)
13. Short pins 1 and 10 together on the remote cable.
14. Preset A1 should be restored so that a picture is displayed in tile 1.
15. Short pins 1 and 11 together on the remote cable.
