Required equipment

Table 57: Required equipment – incoming inspection functional tests
Test equipment
Video test signal generator
75 Ω coaxial cables (2 required)
Precision 75 Ω terminator for Analog
Video
WVR8200 and WVR8300 Specifications and Performance Verification
The following equipment is required to perform the incoming inspection
procedure.
Requirements
1080p 59.94 3Gb/s HD signals (required
for option 3G)
100% color bars
4 CH embedded audio (Group 1)
1080i 59.94 1.5Gb/s HD signals
100% color bars
10-bit shallow ramp matrix
100% sweep 1-15 MHz
4 CH embedded audio (Group 1)
525i 59.94 270 Mb/s SD signals
100% color bars
SMPTE color bars
8 CH embedded audio (Groups 1&2)
A/V Delay test mode
NTSC Composite Analog signals
0% Flat Field or Black Burst
100% color bars
SMPTE color bars
1080i 59.94 SMPTE 372M Dual Link
signals
100% color bars, format YCbCr+A
4:4:4 10-bit
100% color bars, format GBR 4:4:4
10-bit
RG-6 type coaxial cable with male BNC
connectors, 1 to 2 meters long, suitable
for use to 1500 MHz
75 Ω±0.025% to 6 MHz, male BNC
connector
Incoming inspection functional tests
Example
Tektronix TG700 or TG8000 with
HD3G7 module
Tektronix TG700 or TG8000 with
HDVG7 modules
Tektronix TG700 or TG8000 with
DVG7 module
Tektronix TG700 or TG8000 with
AVG7 module
Tektronix TG700 or TG8000 with
HDLG7 module
Belden 8281 or 1694A. Tektronix part
numbers 012-0159-00 or 012-0159-01.
Tektronix part number 011-0102-03.
