Audio performance tests (Options AD and DPE)
114
5. Press and hold the AUDIO button, select Audio Input, and then select
AES A.
6. Press the AUDIO button to close the menu.
7. Connect the digital audio generator unbalanced (UNBAL) output to the
waveform rasterizer AES A IN 1-2 connector, using a 75 Ω cable.
8. Verify that the numbers 1,2 are visible under the headphone icon, in the audio
tile.
9. Set the headphone output volume to maximum by turning the Horz (Volume)
knob clockwise.
10. Connect the 1/4I male phono connector from the headphone test cable to the
waveform rasterizer headphone jack.
11. Connect the XLR corresponding to the 'Left' channel to the analyzer balanced
(BAL) analog input.
12. Check for 0.25 dBu ±1 dB RMS on the analog analyzer. Record the result
in the test record.
13. Connect the XLR corresponding to the 'Right' channel to the analyzer
balanced (BAL) analog input.
14. Check for 0.25 dBu ±1 dB RMS on the analog analyzer. Record the result
in the test record.
15. Set the digital audio generator as follows:
Control or setting
Sample Frequency
Output Level
Frequency
16. Repeat steps 9 through 12.
17. Set the digital audio generator as follows:
Control or setting
Sample Frequency
Output Level
Frequency
18. Repeat steps 9 through 12.
WVR8200 and WVR8300 Specifications and Performance Verification
Value
48 kHz
–6 dB FS Audio Tone
1 kHz
Value
48 kHz
–6 dB FS Audio Tone
19 kHz
