Disassembly and Reassembly
5.2 Cover Upper (Left, Right)
1. Open the ADF Ass'y.
ADF Ass'y
2. Apply light pressure to the left side of the Cover Upper
Left and pull it in the direction of arrow, as shown
below.
Cover Upper Left
1
2
Service Manual
5-2
3. Apply light pressure to the right side of the Cover
Upper Right and pull it in the direction of arrow, as
shown below.
Cover Upper Right
1
2
