Page 1 DIGITAL LASER MFP SCX-5635 Series SCX-5635FN / SCX-5635HN SERVICE Manual DIGITAL LASER MFP The keynote of Product - Speed : 33 ppm (A4), 35 ppm (LTR) - Print Resolution : 600x600 dpi - Scan Resolution : Enhanced 4800x4800 dpi - Toner cartridge •...
Page 2 GSPN (Global Service Partner Network) North America : service.samsungportal.com Latin America : latin.samsungportal.com CIS : cis.samsungportal.com Europe : europe.samsungportal.com ⓒ Samsung Electronics Co.,Ltd. August. 2008 China : china.samsungportal.com Printed in Korea. Asia : asia.samsungportal.com VERSION NO. : 1.00 CODE : 5635-00000E...
Page 3: Table Of Contents
Contents Precautions 1.1 Safety Warning••••••••••••••••••••••••••••••••••••••••••••••••••••••••1-1 1.2 Caution for safety•••••••••••••••••••••••••••••••••••••••••••••••••••••1-2 1.2.1 Toxic material•••••••••••••••••••••••••••••••••••••••••••••••••••••1-2 1.2.2 Electric Shock and Fire Safety Precautions••••••••••••••••1-2 1.2.3 Handling Precautions•••••••••••••••••••••••••••••••••••••••••••1-3 1.2.4 Assembly / Disassembly Precautions•••••••••••••••••••••••1-3 1.2.5 Disregarding this warning may cause bodily injury•••••••1-4 1.3 ESD Precautions••••••••••••••••••••••••••••••••••••••••••••••••••••••1-5 1.4 Super Capacitor or Lithium Battery Precautions••••••••••••••••1-5 Product spec and feature 2.1 Product Overview ••••••••••••••••••••••••••••••••••••••••••••••••••••2-1 2.1.1 Product Summary•••••••••••••••••••••••••••••••••••••••••••••••2-1...
Page 4 Continued Disassembly and Reassembly 3.1 Disassembly and Reassemblyons on Disassembly• • ••••••••••3-1 3.2 Maintenance Parts••••••••••••••••••••••••••••••••••••••••••••••••••••3-2 3.3 Replacing a Maintenance Parts••••••••••••••••••••••••••••••••••••3-3 3.3.1 Fuser Unit•••••••••••••••••••••••••••••••••••••••••••••••••••••••••3-3 3.3.2 ADF Pick up unit and rubber pad ••••••••••••••••••••••••••••3-3 3.3.3 Pick up roller• • ••••••••••••••••••••••••••••••••••••••••••••••••••••3-4 3.3.4 Transfer roller ••••••••••••••••••••••••••••••••••••••••••••••••••••3-4 3.3.5 Holder-Pad•...
Page 5 Continued 4.2 Troubleshooting••••••••••••••••••••••••••••••••••••••••••••••••••••• 4-44 4.2.1 Procedure of Checking the Symptoms•••••••••••••••••••• 4-44 4.2.2 Solution•••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 4-45 System Diagram 5.1 Block Diagram (Main I/F)••••••••••••••••••••••••••••••••••••••••••••5-1 5.2 Block Diagram (SUB B’d)• • ••••••••••••••••••••••••••••••••••••••••••5-2 5.3 Power Diagram••••••••••••••••••••••••••••••••••••••••••••••••••••••••5-3 Reference Information 6.1 Tool for Troubleshooting•••••••••••••••••••••••••••••••••••••••••••••6-1 6.2 Acronyms and Abbreviations• • ••••••••••••••••••••••••••••••••••••••6-2 6.2.1 Acronyms•...
Page 6 Continued 7. ELA HOU-Scan•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••21 8. ELA HOU-ADF••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••23 9. MEA-Cover Open• • •••••••••••••••••••••••••••••••••••••••••••••••••••••••25 10. MEA Unit-Pick Up•••••••••••••••••••••••••••••••••••••••••••••••••••••••27 11. MEA-ADF Upper••••••••••••••••••••••••••••••••••••••••••••••••••••••••29 12. ELA HOU-ADF Lower••••••••••••••••••••••••••••••••••••••••••••••••••31 13. Drive ADF-Bracket••••••••••••••••••••••••••••••••••••••••••••••••••••••33 14. MEA Unit-Cover Platen••••••••••••••••••••••••••••••••••••••••••••••••35 15. ELA HOU-Platen••••••••••••••••••••••••••••••••••••••••••••••••••••••••37 16. MEA-Scan Upper•••••••••••••••••••••••••••••••••••••••••••••••••••••••39 17. ELA HOU-Scan Lower•••••••••••••••••••••••••••••••••••••••••••••••••41 18.
Page 7: Precautions
High voltages and lasers inside this product are dangerous. This printer should only be serviced by a suitably trained and qualified service engineer. (2) Use only Samsung replacement parts There are no user serviceable parts inside the printer. Do not make any unauthorized changes or additions to the printer, these could cause the printer to malfunction and create electric shock or fire haz- ards.
Page 8: Caution For Safety
Take care not to cut or damage the power cable or plugs when moving the machine. (9) Use caution during thunder or lightening storms. Samsung recommend that this machine be disconnected from the power source when such weather conditions are expected. Do not touch the machine or the power cord if it is still connected to the wall socket in these weather conditions.
Page 9: Handling Precautions
1.2.4 Assembly / Disassembly Precautions Replace parts carefully, always use Samsung parts. Take care to note the exact location of parts and also cable routing before dismantling any part of the machine. Ensure all parts and cables are replaced correctly.
Page 10: Disregarding This Warning May Cause Bodily Injury
- The equipment shall be installed near the socket outlet and shall be accessible. - Be sure to fix and plug in the power cable securely after the installation so that no one trips over it. Service Manual Samsung Electronics...
Page 11: Esd Precautions
2. Be sure to replace the battery with the same or equivalent type recommended by the manufacturer. 3. Super capacitor or Lithium batteries contain toxic substances and should not be opened, crushed, or burned for disposal. 4. Dispose of used batteries according to the manufacture? instructions. Service Manual Samsung Electronics...
Page 12: Product Spec And Feature
- Paper handling : 250 sheets cassette : 50 sheets MP tray : 250 sheets option cassette - Memory : 128 MB (Max. 384 MB) - Duplex printing - N/W, USB 2.0, Wireless option - 4 Line LCD Service Manual Samsung Electronics...
Page 13: Product Specifications
MPBF 30,000 pages MTTR 30 Minutes 33.350 Per million pages Operating 10~32℃ Temperature Non Operating -20~40℃ Environmental Operating 20~80% Humidity Non Operating 10~90% Altitude Max 8,200ft Printing Operation 600Wh Power Sleep Mode 18Wh Consumption Power Switch Service Manual Samsung Electronics...
Page 14: Software And Network
TCP/IP, Ethertalk, SNMP, HTTP 1.1 MS Windows 98/2000/XP/NT/Me, MAC (English only, no status monitor, web download only) Network Linux: Red Hat 8.0~9.0, Fedora Core 1~3, Mandrake Operating System 9.0~10.2, SuSE 8.2~9.2. Windows 2003. Netware 4.x, 5.x ,6.x (TCP/IP only) Service Manual Samsung Electronics...
Page 15: Print Specification
Scan Speed through Gray Approx. 20sec (USB 2.0) Platen Color 75dpi/300dpi Approx. 30sec (USB 2.0) Optical 600*1200dpi Resolution Enhanced 4800dpi*4800dpi Halftone 256level Max. Document Width Max.216mm(8.5") Scan Size Effective Scan Width Max 208mm(8.2inch) Scan-to Scan to Application/Network/Email/USB Key Service Manual Samsung Electronics...
Page 16: Copy Specification
Yes (15,30,60,180sec, Off) Changeable Default mode Contrast, Image, Reduce/Enlarge, N-up copy 2-up, 4-up (ADF only) Collation Copy Yes (ADF only) Auto Fit Copy Yes(Platen only) Special Copy ID Copy Yes(Platen only) Clone Yes(Platen only) Poster Yes(Platen only) Service Manual Samsung Electronics...
Page 17: Telephone Specification
Yes(On, Off) Sound Control Alarm Volume Yes(On, Off) OHD Volume Speaker Yes(On, Off, Comm.) 2.2.7 Fax Specification Item Description Compatibility ITU-T G3 Communication System PSTN/PABX Modem Speed 33.6Kbps TX Speed 3sec Compression MH/MR/MMR/JPEG/JBIG Color Fax Yes(Sending Only) Service Manual Samsung Electronics...
Page 18 Cover page Delayed fax Fax Forward to Email Yes (Enable / Disable),max 10 locations Addresses Memory RX Voice Request Functions Polling Earth/Recall Auto Reduction F/W Remote upgrade Junk Fax barrier Secure Receive Memory Back-up Yes (Serial Flash) Service Manual Samsung Electronics...
Page 19: Paper Handling
0.075mm – 0.13mm(0.003” – 0.005”) 2.2.9 Consumables Item Life Part Code Description Initial 4Kpages (5% ISO 19752 Test Pattern) Toner Standard: 4Kpages MLT-D208S Sales MLT-D208L High yield: 10K pages * Declared yield value in accordance with ISO/IEC 19752. Service Manual Samsung Electronics...
Page 20: Maintenance Parts
Part Code Life Pickup Roller JC90-00932A 150,000 Pages Pickup Roller (ADF) JC97-01962C 80,000 Pages Pad Unit (Tray) JC97-03439A 150,000 Pages Pad Unit (ADF) JC97-01940B 20,000 Pages Transfer Roller JC66-02017A 70,000 Pages JC91-00929A(110V) Fuser Unit 80,000 Pages JC91-00928A(220V) Service Manual Samsung Electronics...
Page 21: Model Comparison
50 ADF 50 ADF Initial : 4K Initial : 4K Intial : 3K Toner Sales : 4K/ 10K Sales : 4K/ 8K Sales : 7K Max. Monthly Duty 35,000 25,000 15,000 Set life 200,000 250,000 2-10 Service Manual Samsung Electronics...
Page 22: System Overview
Multi-purpose tray handle Multi-purpose tray extension Handle Multi-purpose tray paper width guides Paper level indicator Scanner lid Optional tray 2 Scanner glass Tray 1 Scanner lock switch Multi-purpose tray Handset a. Optional device. b. SCX-5635HN only. 2-11 Service Manual Samsung Electronics...
Page 23 Product spec and feature ■ Rear View Network port Duplex unit USB port Rear door USB host port Power receptacle Optional tray 2 cable connector Power-switch Telephone line socket Control board cover Extension telephone socket (EXT) 2-12 Service Manual Samsung Electronics...
Page 24: Toner Cartridge
Product spec and feature ■ Inner View Roller-Pickup Roller-ADF Roller-Exit Roller-Feed Scanner Part Roller-Exit Roller-Heat Toner Cartridge Roller-REGI Roller-REGI Roller-MP Fuser Roller-Transfer Duplex Duplex Roller-Feed Roller-Pickup Engine Part 2-13 Service Manual Samsung Electronics...
Page 25: Hardware Configuration
1 Board. Scanner part is composed of ADF and Platen and is connected with Main by Harness . Line Interface part is designed to apply TBR21 standard (Domestic, Europe, etc.) OPE PBA HVPS Main PBA Fax board SCF Board Engine Board SMPS 2-14 Service Manual Samsung Electronics...
Page 26 FAX for Journal List, and Memory for One Touch Dial, Speed Dial List. 3) SDRAM : is used as Swath Buffer in Printing, Scan Buffer in Scanning, ECM Buffer in FAX receiving, and System Working Memory Area (DDR2 DIMM) - size : 128Mbyte(Default) / 256Mbyte(Option) 2-15 Service Manual Samsung Electronics...
Page 27 TACT SWITCH 4-LINE LCD MICOM 4-LINE LCD MICOM (S3C828BXZZ) (S3C828BXZZ) LCD Backlit LCD Backlit Conn. Conn. 4-LINE LCD 4-LINE LCD UNIT UNIT DEBUGGING DEBUGGING TOOL TOOL (Not Used.) (Not Used.) Main ó OPE Main Conn. Conn. 2-16 Service Manual Samsung Electronics...
Page 28: Smps Board
DC Output Connector( CN3 ) Description PIN NO PIN ASSIGN PIN NO Description Signal Fuser On +24VS Power Power +24V Ground Power +24V Ground Power +24V Ground Power +24V Ground Power Ground Power Ground Power Power On/Off Signal 2-17 Service Manual Samsung Electronics...
Page 29: Hvps Board
+24VS +24VS Power Power +24VS Power Signal Regi Sensor Feed Sensor Signal Signal Exit Sensor Empty Sensor Signal Signal Duplex1 Sensor Cover-Open Signal Signal THV_Read THV_En Signal Signal PWM_MHV PWM_THV Signal Signal PWM_BIAS PWM_DEV Signal 2-18 Service Manual Samsung Electronics...
Page 30: Engine Board
+5V_SMPS Ground Signal nStand-by Ground Power +3.3V Exit Motor Dir. Signal Signal Exit-Motor_Cur1 Duplex-Fan Signal Signal Main_Fan Exit_Motor_Pha Signal Signal Exit-Motor_Cur2 Exit_Motor_En Signal Signal Exit_Motor_MS1 Duplex_Mot_Sleep Signal Signal Duplex_Mot_En SMPS_Fan Signal Signal Dup_Mot_Pha Fuser_On Signal 2-19 Service Manual Samsung Electronics...
Page 31 SCF Board is included Optional SCF. Main PBA Line SI2435 SI2435 External [ FAX Board ] Main PBA Main PBA Paper Empty Sensor Paper Empty Sensor S3F443FX S3F443FX S3F443FX BLDC BLDC Solenoid Solenoid [ SCF Board ] 2-20 Service Manual Samsung Electronics...
Page 32: Mechanic Configuration
MP tray allows you to print a varity of media type. - Feeding Capacity : 50 sheets - Media size : Letter, Legal, Oficio, Folio, A4, ISO B5, JIS B5, envelope DL, Executive, A5, A6, Envelope Monarch, Envelope COM-10, Envelope C5, Envelope C6 2-21 Service Manual Samsung Electronics...
Page 33 • OPC Cleaning: Rake used toner into waste toner box with cleaning blade • Method of toner supply : Toner is transported to the developing roller by supply roller. • Regulating toner level : SUS Blade (Doctor Blade) 2-22 Service Manual Samsung Electronics...
Page 34: Failure Analysis
LD(Laser Diode) Protector panel Trouble Failure Analysis Polygon Motor Error The Rotation of Polygon Motor can not reach stable Hsync Error Though the rotation of Polygon Motor reach stable, the signal of Hsync is not occurred 2-23 Service Manual Samsung Electronics...
Page 35: Fuser Unit
- 10˚C over than Standby Ref.(170˚C) Over for 3min. Low Heat Error 10˚C below than target Temp. for 15 sec. At Warm up (Fuser Low Error) 20˚C below than target Temp. for 15 sec. At Printing 2-24 Service Manual Samsung Electronics...
Page 36: Transfer Roller
- Main motor ass’y (BLDC) : Paper Pickup, Paper Feeding, Toner Cartridge - Exit motor ass’y (STEP) : Fuser Unit, Letting out paper or Putting back paper - Duplex motor ass’y (STEP) : Paper Transferring for duplex printing Exit Exit Main Duplex Main Duplex 2-25 Service Manual Samsung Electronics...
Page 37: Flatbed Scanner
- Scan Method : color CCD(Charge Coupled Device) - Minimum Scan Line Time: 0.73ms(Color) / 0.365(Mono) - Scan Resolution : Optical 600x1200dpi - Scan Width : 216 mm - CCD Operating part : CCD image sensor uses +5V and Inverter uses +24V. 2-26 Service Manual Samsung Electronics...
Page 38: Disassembly And Reassembly
3. Unplug the power cord. 4. Use a flat and clean surface. 5. Replace only with authorized components. 6. Do not force plastic-material components. 7. Make sure all components are in their proper position. Service Manual Samsung Electronics...
Page 39 3.2 Maintenance Parts Sec_Code Description Life Image JC90-00932A ASF-PICK UP 150K JC66-02017A ROLLER-TRANSFER JC91-00928A(220V) FUSER JC91-00929A (110V) MEA UNIT-PICK UP JC97-01962C (ADF pick up assy) JC97-01940B MEA UNIT-HOLDER ADF MEA UNIT-HOLDER PAD JC97-03439A 150K (Cassette friction pad) Service Manual Samsung Electronics...
Page 47 5. Remove the flat cable from CCDM module.
Page 53: Alignment & Troubleshooting
Power Saver Sends the machine into power saver mode. You can also turn the power on and off with this button. Start Starts a job. Service Manual Samsung Electronics...
Page 54: Understanding The Status Led
• A paper jam has occurred. • The cover is opened. Close the cover. • There is no paper in the tray. Load paper in the tray. • The machine has stopped due to a major error. Service Manual Samsung Electronics...
Page 55: Menu Overview
√Legal √Legal Legal Legal Legal Legal √Legal √Legal 4. Press the OK button to process your selection, save your input or selection. 5. To exit the menu, press the Back button repeatedly, or the Stop button. Service Manual Samsung Electronics...
Page 56 Job Name Fax:| Forward Send Forward Rcv. Forward E-mail Send Forward Rcv. Forward Server Send Forward Rcv. Forward Secure Receive Password [????] Off * Password [????] Print Password [????] Add Page 10:22Am DelayFax Cancel Job 10:22Am DelayFax Service Manual Samsung Electronics...
Page 57 Ring to Answer [1-7]times:1 Stamp Rcv Name Off * Rcv Start Code [0-9]:9 Auto Reduction On * Discard Size [00-30]:20 Junk Fax Setup Off * DRPD Mode Waiting Ring Duplex Print Off * Long Edge Short Edge Service Manual Samsung Electronics...
Page 58 Pulse. Contact your local telephone company if you are not sure which dial mode to use. If you select Pulse, some phone system features might not be available. It can also take longer to dial a fax or phone number. Service Manual Samsung Electronics...
Page 59 In this menu, you can set the machine to recognize which ring patterns to answer. Duplex Print Set this duplex feature to save paper. When the machine prints the received fax data, it prints them on both sides of the paper. Service Manual Samsung Electronics...
Page 60: Change Default
You can select the default contrast mode to fax your originals lighter or darker. Auto Report You can set the machine to print a report with detailed information about the previous 50 communication operations, including time and dates. Service Manual Samsung Electronics...
Page 61 Normal * EXE->LTR(104%) Light Dark Original Type Text * 150% Text/Photo 200% Photo 400% Layout Normal * Darkness Normal * 2-Up Light 4-Up Dark ID copy Original Type Text * Poster Copy Text/Photo Clone Copy Photo Service Manual Samsung Electronics...
Page 62: Changing The Copy Setup Options
Adjusts the brightness level to make a copy that is easier to read, when the original contains faint markings and dark images. Original Type Improves the copy quality by selecting the document type for the current copy job. 4-10 Service Manual Samsung Electronics...
Page 63 Scan Format SINGLE-TIFF SMB Feature MULTI-TIFF Scan Size A4 * JPEG* Letter Legal Executive Folio Oficio Original Type Text * Text/Photo Photo Resolution 100 dpi 200 dpi 300 dpi * Scan Color Color * Gray Mono 4-11 Service Manual Samsung Electronics...
Page 64 200 dpi 200 dpi 300 dpi * 300 dpi * Scan Color Color * Scan Color Color Gray Gray Mono Mono * Scan Format Scan Format SINGLE-TIFF SINGLE-TIFF MULTI-TIFF MULTI-TIFF PDF : MULTI-TIFF* JPEG JPEG* 4-12 Service Manual Samsung Electronics...
Page 65: Changing The Scan Setup Options
Sets the image resolution. Scan Color Sets the color mode. Scan Format Sets the file format in which the image is to be saved. If you select TIFF or PDF, you can select to scan multiple pages. 4-13 Service Manual Samsung Electronics...
Page 66 High 1 Cestina Auto Continue On * Svenska Turkce Auto Tray Switch On * 中國語 한국어 Toner Save Default Mode Copy * Off * Import Setting Address Book Setup Data Export Setting Address Book Setup Data 4-14 Service Manual Samsung Electronics...
Page 67 ENV>DL Paper Source Env>C5 Env>C6 Env>No.10 Env>Post Card>Custom Copy Tray Tray 1 Tray 2 MP Tray Tray1/2 Tray Confirm Auto * Tray 1/2 On * Fax Tray Tray 1 Tray 2 Tray1/2 Auto * 4-15 Service Manual Samsung Electronics...
Page 68 Network Setup Sent Report Phone Book E-mail Address Book Rcv Report Printing? Yes/No Email Fax Rcv Report Printing? Yes/No Sent Report Schedule Jobs Printing? Yes/No Email User Auth List Printing? Yes/No Rcv Report Fax Rcv Report 4-16 Service Manual Samsung Electronics...
Page 69: Clearing Memory
Restores all of the network options to the factory default. Address Book Clears all of the email address entries stored in memory. Sent Report Clears all records of sent faxes and emails. Fax Rcv Report Clears all records of received faxes. 4-17 Service Manual Samsung Electronics...
Page 70: Network Menus
List Authentication WPA Key Error Custom Edit SSID Operation Mode WLAN Default Restore WLAN Signal Excellent Very Good Good Very Low No Signal Clear Settings Clearing? Yes/No Clearing… Network Info. Printing? Yes/No Printing... 4-18 Service Manual Samsung Electronics...
Page 71 Clear Settings Reverts the network settings to the default values. Network Info. This list shows information on your machine’s network connection and configuration. a.This menu only appears when an optional wireless network interface has been installed. 4-19 Service Manual Samsung Electronics...
Page 72: Tech Mode
Report Machine Test Machine Test Pattern Test Pattern Test Shading Test Shading Test NVM Read/Write NVM Read/Write NVM Initial NVM Initial Test Routines Test Routines Test Routines Test Routines 100-Motor 100-Motor 101-Clutch 101-Clutch 102-Sensor 102-Sensor 4-20 Service Manual Samsung Electronics...
Page 73: Tech Mode Menu Map
Rom Test Pattern Test NVM Read/Write NVM Initial Test Routines Shading Test Adjust Shading ? Shading&Print Restart Machine TEST USB HOST Report All Report Protocol Supplies Info Configuration Error Info Usage Page ComponentCheck Service Support 4-21 Service Manual Samsung Electronics...
Page 74 This function resets Total Page Count, Flatbed Scan Count, ADF Scan Count. Engine Footer This function is for monitoring of the engine status. If you perform this function, at printing, the setting value for engine is shown on the bottom of the printed page. 4-22 Service Manual Samsung Electronics...
Page 75 They are NVM Read/Write, NVM initial, Test Routines. Use this function to check the status of the components in the machine. Restart Machine You can reboot the machine by using a key without mechanic rebooting. Test USB HOST 4-23 Service Manual Samsung Electronics...
Page 76 It controls temperature of fuser as 180 degrees. On[Off] 110-LSU 0000-Motor1 Rdy Detects if LSU motor1 runs at normal speed. High[Low] 0060-Motor1 Run LSU Motor1 On/Off On[Off] 0110-LD Power4 LSU LD4 Power On/Off (black) On[Off] 4-24 Service Manual Samsung Electronics...
Page 77 Component Check Component Check Report shows the operation procedure of the machine test in tech mode. Service Support Customer Assistance Report shows the country setting procedure, F/W upgrade procedure, printing a Test pattern page. 4-25 Service Manual Samsung Electronics...
Page 78 Alignment & Troubleshooting Configuration Report 4-26 Service Manual Samsung Electronics...
Page 79 Alignment & Troubleshooting Supplies Information Report 4-27 Service Manual Samsung Electronics...
Page 80: Clearing Paper Jams
(2) JAM-1 : Feed sensor ~ Exit sensor (3) JAM-2 : Exit sensor ~ (4) Duplex Jam-1 : ~ Duplex sensor (5) Duplex Jam-0 : Duplex sensor ~ Feed sensor FEED SENSOR SCAN SENSOR EXIT SENSOR DUPLEX SENSOR PAPER EMPTY SENSOR 4-28 Service Manual Samsung Electronics...
Page 81 Duplex not arrive at registration within Jam 0 a certain time after touching 1. Pull out duplex unit FEED SENSOR Duplex Sensor 2. Remove jammed paper from DUPLEX SENSOR duplex unit FEED SENSOR DUPLEX SENSOR 4-29 Service Manual Samsung Electronics...
Page 82 4. Insert tray 1 back into the machine until it snaps into place. Printing automatically resumes. 5. Insert the trays back into the machine. Printing automatically resumes. 4-30 Service Manual Samsung Electronics...
Page 83 2. Open and close the front door to resume 2. Remove the jammed paper by gently pulling it printing. straight out. 3. Replace the toner cartridge and close the front door. Printing automatically resumes. 4-31 Service Manual Samsung Electronics...
Page 84 Skip to step 9. 7. While pushing the fuser lever to the right, open the fuser door. If you still do not see the paper, go to the next step. 4-32 Service Manual Samsung Electronics...
Page 85 10. Close the rear door. Printing automatically resumes. 2. Remove the jammed paper from the duplex unit. If the paper does not come out with the duplex unit, remove the paper from the bottom of the machine. 4-33 Service Manual Samsung Electronics...
Page 86 5. Pull the jammed paper out. If you still do not see the paper, go to the next step. 6. Fold the duplex guide and close the rear door. 3. Open the rear door. 4. Unfold the duplex guide fully. 4-34 Service Manual Samsung Electronics...
Page 87: Abnormal Image Printing And Defective Roller
Horizontal density band Develop Roller 39mm Horizontal density band Transfer Roller 47.1mm Black side contamination/transfer fault Heat Roller 77.8mm Black spot and fuser ghost Pressure Roller1 62.8mm Black side contamination Pressure Roller2 50.2mm Black side contamination 4-35 Service Manual Samsung Electronics...
Page 88 Print this page. Align the this page and the printed defect image and find the defective roller. Start line Charge Roller Develop Roller Transfer Roller Pressure Roller2 Supply Roller Pressure Roller1 OPC Drum Heat Roller 4-36 Service Manual Samsung Electronics...
Page 89: Error Message
1. Close the door. If the message Close it latched. is not disappeared, check the below steps. 2. Check that the door switch is pushed. 3. Check that the LCD message is changed by door switch action. 4-37 Service Manual Samsung Electronics...
Page 90 Remove the jammed paper. 2. If the paper is removed but message is displayed, check the Regi.sensor on EDC mode. If it is defective replace it. 3. Check the exit sensor. If it is defective, replace it. 4-38 Service Manual Samsung Electronics...
Page 91 Divide your mail or reduce the resolution. Mail exceeds than supported size by SMTP server. server support Mail Size Error Single page data exceeds the Reduce the resolution and try again. One Page is configured mail size. Too Large 4-39 Service Manual Samsung Electronics...
Page 92 4. Measure the resistance value of the than Top temp and for a few thermistor. Is it infinite? Replace the minutes. thermistor. 4. At power save mode, the 5. Replace the fuser unit. temperature keep up the constant for regular time. 4-40 Service Manual Samsung Electronics...
Page 93 Cancel. If you select Cancel , the printing Continue ⊙ Cancel X match the paper you are loading. job will stop. Load the correct paper in the tray. If you select Continue, printing job will continue. 4-41 Service Manual Samsung Electronics...
Page 94 Replace New Toner The toner cartridge has reached Replace the toner cartridge with a Replace with New the end of its lifespan. Samsung-genuine toner cartridge. Toner Scanner door Open Door of scanner is open. Close the scanner door. Door of scanner is open.
Page 95 If you select Continue, the machine keeps printing, but the quality cannot be guaranteed. Toner Not Compatible The toner cartridge you have Install a Samsung-genuine toner Toner cartridge is not installed is not for your machine. cartridge designed for your machine. compatible. Check...
Page 96: Troubleshooting
- Main PBA error - LCD Panel error Refer to Indicate Ready or Error Massage Error Massage Power save < Chapter 4.1.7 > Test Print printing Refer to "Solution Quality is of 4.2.2.3 Print Quality" Nomal? 4-44 Service Manual Samsung Electronics...
Page 97: Solution
• Check the right position of the Scanner Motor, mechanical disturbance. and check the any mechanical dis turbance in the CCD carriaging part. • Check the Motor Driver in Driver • If any driver is defective, replace it. PBA. 4-45 Service Manual Samsung Electronics...
Page 98 • Check the right position of the Scanner Motor, mechanical disturbance. and check the any mechanical dis turbance in the CCD carriaging part. • Check the Motor Driver in Driver • If any driver is defective, replace it. PBA. 4-46 Service Manual Samsung Electronics...
Page 99: Fax/Telephone Precautions
LIU PBA. Replace main PBA. Defective • Is the ring checked? • Replace LIU PBA if it cannot be checked. automatic fax • Refer to ‘Defective Transmission.’ • Refer to ‘Defective Transmission’. reception 4-47 Service Manual Samsung Electronics...
Page 100 Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer 4-48 Service Manual Digital Printer Digital Printer Digital Printer Samsung Electronics Digital Printer Digital Printer Digital Printer...
Page 101: Poor Fusing
3. Re-check after putting the machine in the warm place for certain period. Partial blank image 1. Toner is low? 1. Replace Toner cartridge. (not periodic) 2. The toner cartridge is out of position? 2. Checkand adjust. 4-49 Service Manual Samsung Electronics...
Page 102 1. Unstable high voltage contact 1. Clean each contact and check good 2. Charge roller’s contamination contact 3. Contamination of heat roller 2. Clean charge roller 4. Malfunction of LSU 3. Replace fuser unit 4. Check Main PBA. 4-50 Service Manual Samsung Electronics...
Page 103 Digital Printer Digital Printer Digital Printer Digital Printer The mirror in LSU might be misplaced so the light path to the OPC deviates ->Repair or replace LSU or remove any defective matters in the machine 4-51 Service Manual Samsung Electronics...
Page 104 This could occurs when he power of LSU is low or life the density is low due to the obstacles on the window -> Replace LSU or clean the window Replace the toner cartridge 4-52 Service Manual Samsung Electronics...
Page 105: All Black
Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Is the Hsync signal received Replace LSU in LSU? Charge part's contact is bad -> Repair or replace the drum cartridge 4-53 Service Manual Samsung Electronics...
Page 106: Vertical White Line (Band)
OPC of Check both if the toner cartridge's toner cartridge and LSU prevent the counter is over its guaranty and path -> Remove the obstacles amount of the toner material -> Replace the toner cartridge 4-54 Service Manual Samsung Electronics...
Page 107: Dark Image
Toner over supply due to the Works adjustment fault of metering correctly after blade in toner cartridge replaced LSU? -> Replace toner cartridge The power of LSU is set high or internal problem -> Replace LSU or adjust volume 4-55 Service Manual Samsung Electronics...
Page 108 Check if the LED of PTL in front of the transfer roller is on when it presses the top cover switch on purpose -> If not, replace PTL Internal blade or supplying part of the toner cartridge is defective -> Replace the toner cartridge 4-56 Service Manual Samsung Electronics...
Page 109 There may be a problem in toner temperature is too low or layer control in toner cartridge not recommended -> Replace the toner cartridge paper used? Use the machine with recommended paper and at condition 4-57 Service Manual Samsung Electronics...
Page 110: Black Spot
P/R or H/R in fuser stuck to charge roller onto the paper -> -> Clean it or replace -> Clean the Charge Roller Replace the toner cartridge and then reprint. 4-58 Service Manual Samsung Electronics...
Page 111 (38.3mm) -> Repair/replace HVPS, drum cartridge The OPC is damaged due to the irregular transfer voltage of HVPS -> Repair/replace HVPS -> If the same problem persists, replace the drum cartridge 4-59 Service Manual Samsung Electronics...
Page 112: Irregular Density
(Check the counter -> Replace the toner cartridge area? and replace it) 1. Clean the window of LSU 2. Light distortion due to the mirror ruined or LSU's diffused reflection -> Replace LSU 4-60 Service Manual Samsung Electronics...
Page 113: White Spot
D/R in the toner cartridge surface unit has the defect -> Clean the OPC and -> Replace the toner cartridge machine or replace toner cartridge When putting in/out the drum cartridge, scratch is made -> Replace the drum cartridge 4-61 Service Manual Samsung Electronics...
Page 114: Trembling At The End When Ohp Printing
Other parts are touching the When multi-page OHP printng, fan and prevents it from less than 10 films are revolution guranteed. (Reduce the -> Check and repair number of films and re-insert after paper check LED if off) 4-62 Service Manual Samsung Electronics...
Page 115: Poor Fusing Grade
3 Kg) 3.5mm? Replace the control The paper used is too component on Main thick or contains too much cotton in it -> Re-test with the Check any contact recommended paper problem in thermistor and repair 4-63 Service Manual Samsung Electronics...
Page 116 If not so, check the operation of feed sensor by Engine test mode. 3. Check exit lever operation. Remore jam and check actuator moving by hand. If actuator is too stiff, paper is wrapped around the heat roller. Remove obstacles or replace. 4-64 Service Manual Samsung Electronics...
Page 117 ADF. 2. Check whether the Feed Roller is working or not. Does it curl while coming out? 1. Check the Open Cover whether there are bosses. 2. Check the ADF ass’y is well assemble. 4-65 Service Manual Samsung Electronics...
Page 118: No Power (Lcd No Display Led Off)
-> Replace the boards Detect failure due to the Repair/replace the Remove the shortage board or replace the board board which detects side cover open or switch error -> Replace the board or switch 4-66 Service Manual Samsung Electronics...
Page 119: Fuser Error
Check CN25 of the main board. Re-assemble the connector. Is the conector inserted right ways? Check CN29 of the main board. Re-assemble the connector. Is the conector inserted right ways? Replace the main board. Fuser Error eliminated? 4-67 Service Manual Samsung Electronics...
Page 120: Paper Jam (Mis-Feeding)
Switch them Does the Pull out the Paper end curled? extender pulled out? extender <Recommendation> Use the recommended Use the MPF for the thick and quality paper paper such as envelope and cardstock 4-68 Service Manual Samsung Electronics...
Page 121: Paper Jam (Jam 1)
Adjust the paper guides to fit the or sensitive paper to is grounded Check paper width static electricity? the shutter prevents feeding The force of springs pressing the developer is weak -> Check guide-DEVE Use the recommended paper 4-69 Service Manual Samsung Electronics...
Page 122: The Cause And Solutions Of Bad Environment Of The Software
Turn the PC and printer off, and reboot the system to print again. If not solved, double-click the printer in my computer If the regular fonts are not printed this time again. the cable must be defective so replace the cable with new one. 4-70 Service Manual Samsung Electronics...
Page 123: Abnormal Printing
Before choosing the document, the menu is still inactive. Or put the document out of the list and repeat the routine as in the above or finish the spool manager. 4-71 Service Manual Samsung Electronics...
Page 124: System Diagram
System Diagram 5. System Diagram 5.1 Block Diagram (Main I/F) Service Manual Samsung Electronics...
Page 125: Block Diagram (Sub B
System Diagram 5.2 Block Diagram (SUB B’d) Service Manual Samsung Electronics...
Page 126: Power Diagram
System Diagram 5.3 Power Diagram Service Manual Samsung Electronics...
Page 127: Reference Information
• Spring Hook Standard : For general use • Tweezers Standard : For general home use, small type. • Software (Driver) installation CD ROM • Cotton Swab Standard : For general home use, for medical service. Service Manual Samsung Electronics...
Page 128: Acronyms And Abbreviations
CRU Memory IMAP Internet Message Access Protocol Center Ware Internet Printing Protocols CWDP Center Ware Device Discovery Images Per Minutes Software(Samsung equivalent of Internetwork Packet Exchange Samsung’s SyncThru) Image Quality CWIS Center Ware Internet Services International Telecommunication Union DADF Duplex Auto Document Feeder...
Page 129 PS/3 PostScript Level-3 USDR Un-Shut Down Rate(=NSDR) Printing Video Controller in the XCMI Samsung’s Management Information SPGPm(Graphic Processor for Printer) Base Quality, Cost, and Delivery Warranty Action Remote Control Panel W x D x H Width x Depth x Height...
Page 130: Service Parts
ELA=Electrical Assembly, HOU =Housing MEA UNIT-COVER PA EXIT ASS’Y MEA= Mechanical Assembly, PA=Paper PMO-TRAY EXTENTION MP NE PMO= Processing Mold MP=Multi-Purpose(Bypass) tray NE=for NEC (common as Samsung Halk printer) MEC-CASSETTE ASS’Y(LETTER) MEC = Mechanic Combined unit COVER-M-FRONT M=Mold MPR-NAME/PLATE MPR= Machinery Press,...
Page 131 PMO-GUIDE DP SIDE DP=Duplex RING-CS CS= Compress GEAR-MP/DUP DRV MP =Multi-Purpose (Bypass) tray DUP DRV = Duplex Driver IPR-BRKT G DUPI PR=Iron Press BRKT=BRACKET G= Ground UP=Duplex PMO-BUSHING TX(B4) TX=Transmit PMO-TRAY CASE, MP MP=Multi-Purpose tray(Bypass tray) Service Manual Samsung Electronics...
Page 132 PBA SUB-MP-SEN =>Sub Printed circuit Board Assembly for the MP-SEN(= Multi-Purpose (Bypass) tray-Sensor) A/S MATERAL-PICKUP,MP FOOT-ML80 HOLDER CATCH CST MC2 MC2=>McKInley2 (Samsung Project code name) IPR-GROUND PLATE A(OPC) OPC=Organic Photo-Conductive ELA M/M-AUD SPEAKER ELA M/M => Electrical Assembly M/M AUD=Audio...
Page 133 REGI=Registration PBA SUB-REGI PBA SUB-REGI => Sub Printed circuit Board Assembly for the Registration GROUND-P_SCAN ROLLER GROUND-P =Ground-Press IPR-GUARD C/O S/W C/O = Cover Open S/W= Switch MEA UNIT-TX STACKER TX =Transmit IPR-WASHER SPRING CU CU=Curve Service Manual Samsung Electronics...
Page 134: The Sample Pattern For The Test
The life of the toner cartridge and the printing speed are measured using the pattern shown below. (The image is 70% of the actual A4 size). 6.3.1 A4 ISO 19752 Standard Pattern This test page is reproduced at 70% of the normal A4 size Service Manual Samsung Electronics...
Page 135: Selecting A Location
• Front: 482.6 mm (enough space so that the paper tray can be removed) • Back: 180 mm (enough space for ventilation) • Right: 100 mm (enough space for ventilation) • Left: 100 mm (enough space for ventilation) Service Manual Samsung Electronics...
Page 136 - SCX-5635 Series - Machine Life : 200K or 5 Years - Memory : 128 MB (Max. 384 MB) - Speed : 33 ppm (A4), 35 ppm (LTR) - Print Resolution : 600x600 dpi - Paper handling - Duplex printing - N/W, USB 2.0, EDI, Wireless option - Scan Resolution : Enhanced 4800x4800 dpi : 250 sheets cassette...
Page 137 This Parts Catalog is a property of Samsung Electronics Co.,Ltd. Any unauthorized use of this manual can be punished under applicable International and/or domestic law.
Page 138 History Version Data Description 1.00 11. 11. 08 1.00 release 1.01 11. 28. 08 1.01 release Harness Connection Table, 1.02 12. 04. 08 Used Screw List addition 1.03 02. 12. 09 Parts List, Power Coard 1.04 04.07.09 Handset model addition...
Page 139 ExplodedView and Parts List Ver. 1.04 Contents Power Cord ……………………………………………………………………… 2 17. ELA HOU-Scan Lower ……………………………………………………… 43 Harness Connection Table ……………………………………………………… 3 18. ELA HOU-Scan Motor ……………………………………………………… 45 Used Screw List ………………………………………………………………… 5 19. ELA HOU-OPE ……………………………………………………………… 47 Tumbnail 1 ………………………………………………………………………… 7 20.
Page 140: Power Cord
Power Cord Ver. 1.04 Power Cord differs by countries. Please check your country code. Part Code Part Code Side View Side View Top View Top View Usable Country Code Usable Country Code 3903-000085 3903-000020 XAA / XAX 3903-000133 3903-000042 SEE / STS / XSA / XSG XSS / XEV / XEG 3903-000050 3903-000146...
Page 141: Harness Connection Table
Harness Connection Table Ver. 1.04 Parts Code Description Connection Specification JC39-00869A HARNESS-BLDC Main PBA <-> BLDC Motor S C X - 5 2 3 5 N D , - , U L 1 0 2 7 2 , 1 0 P / 1 0 P, 2 0 0 m m , B L K / G R AY, 2 6 AW G , 1 - 1 7 3 9 7 7 - 0 , 1 - 173977-0,-,-,-,-,-,-,- JC39-00883A HARNESS-FAX Main PBA <->...
Page 142 Harness Connection Table Ver. 1.04 Parts Code Description Connection Specification JC39-00536A CBF HARNESS-ADF UPPER ADF PBA <-> Main PBA SCX-5530FN,-,UL 1061,18P,250±10MM,BLACK/RED,#24,3-179694-1,YDH200-18,-,-,-,-,UL JC39-00887A HARNESS-F_COVER_OPEN Main PBA <-> Flat Cover Sensor SCX-5235ND,-,UL10272,3P/3P,300mm,BLK/GRAY,26AWG,353293-3,173977-3,-,-,-,-,-,-,- JC39-01007A HARNESS-SCAN_MOTOR Main PBA <-> Scan Motor SCX-5535ND,-,UL10272,4P / 4P,200MM,BLK/GRAY,26AWG,173977-4,173977-4,-,-,-,-,-,-,- JC39-01057A HARNESS-CCD_HOME Main PBA <->...
Page 143: Used Screw List
Used Screw List Ver. 1.04 Parts Code Location Specification ELA UNIT-MAIN DRIVE SCREW-MACHINE;BH,+,M3,L6,ZPC(WHT),SWRCH18A,-,- 6001-000130 ELA UNIT-DUPLEX DRIVE SCREW-MACHINE;BH,+,M3,L6,ZPC(WHT),SWRCH18A,-,- ELA HOU-FRAME ETC SCREW-TAPPING;PWH,+,-,2,M3,L8,ZPC(BLK),SWRCH18A,- 6002-000440 ELA HOU-GUIDE_DUP F (ELA HOU-FRAME ETC) SCREW-TAPPING;PWH,+,-,2,M3,L8,ZPC(BLK),SWRCH18A,- HOLDER GLASS + SCAN SCREW-TAPPING;PWH,+,-,2,M3,L8,ZPC(BLK),SWRCH18A,- ELA HOU-MAIN LINE SCREW-TAPTITE;PWH,+,B,M3,L10,NI PLT,SWRCH18A ELA HOU-FRAME SCREW-TAPTITE;PWH,+,B,M3,L10,NI PLT,SWRCH18A FUSER-ROLLER...
Page 144 Used Screw List Ver. 1.04 Parts Code Location Specification ELA UNIT-MAIN DRIVE SCREW-TAPTITE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,- ELA HOU-MAIN LINE SCREW-TAPTITE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,- FUSER-ROLLER SCREW-TAPTITE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,- ELA HOU-FUSER DRIVE SCREW-TAPTITE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,- HVPS+SHIELD HVPS SCREW-TAPTITE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,- 6003-000269 ELA HOU-SMPS_V1 SCREW-TAPTITE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,- COVER CLUTCH + BRAC SCREW-TAPTITE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,- HARNESS GND + ADF M SCREW-TAPTITE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,- MOTOR ADF + BRACKET SCREW-TAPTITE;BH,+,-,S,M3,L6,ZPC(WHT),SWRCH18A,-...
Page 145: Tumbnail 1
Tumbnail 1 Ver. 1.04 3. ELA HOU-Cover Mid 4. MEA-Cover Front 5. MEA-Cover Rear 1. Main 2. ELA HOU-Cover 9. MEA-Cover Open 10. MEA Unit-Pick Up 6. ELA HOU-Cover Side R 7. ELA HOU-Scan 8. ELA HOU-ADF 15. ELA HOU-Platen 11.
Page 146 Tumbnail 2 Ver. 1.04 18. ELA HOU-Scan Motor 19. ELA HOU-OPE 20. ELA Unit-Main Drive 16. MEA-Scan Upper 17. ELA HOU-Scan Lower 24. ELA HOU-Frame Exit 25. ELA HOU-Guide_Dup F 21. ELA Unit-Duplex Drive 22. ELA HOU-Frame 23. ELA HOU-Frame Etc 29.
Page 147 Tumbnail 3 Ver. 1.04 32. MEA Unit-Duplex 33. MEA Unit-Cassette 34. ELA HOU-SCF 31. ELA HOU-SMPS_V1/V2...
Page 148: Main
1. Main Ver. 1.04 15-1 15-2 Only XIL model...
Page 149 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark SCX-5635FN JC92-02060C PBA-FAX CARD P Other SCX-5635HN JC96-05483A ELA UNIT-MAIN JC96-05516A ELA HOU-FRAME 110V JC96-05483B ELA UNIT-MAIN 5635HN/XIL JC96-05517A ELA HOU-FRAME 220V 15-1 JC92-01923A PBA-RAM DIMM...
Page 150: Ela Hou-Cover
2. ELA HOU-Cover Ver. 1.04...
Page 151 2.A COVER SIDE L (Only XIL model) Ver. 1.04...
Page 152 ELA HOU-Cover Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC96-05523A ELA HOU-COVER JC63-01464A COVER-FRAME DUP JC97-02420A MEA-COVER FRONT JC63-00934A COVER-M_LEFT UPPER JC97-02419A MEA-COVER MID FRONT JC63-00933A COVER-M_RIGHT UPPER...
Page 153: Ela Hou-Cover Mid
3. ELA HOU-Cover Mid Ver. 1.04...
Page 154 ELA HOU-Cover Mid Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC96-05522A ELA HOU-COVER MID JC63-00927D COVER-M_MIDDLE JC63-00938A COVER-M_REAR UPPER 0604-001095 PHOTO-INTERRUPTER JC63-00944A COVER-M_STACKER RX 6003-000196 SCREW-TAPTITE...
Page 155: Mea-Cover Front
4. MEA-Cover Front Ver. 1.04...
Page 156 MEA-Cover Front Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC97-02420A MEA-COVER FRONT JG66-40003A GEAR-PINION JC63-00447E TRAY-M-ASF_FOLDER JC63-00932A COVER-M_FRONT JC64-00154C KNOB-M_LOCKER JC63-00444A TRAY-M-LINK_MP JC61-00953D HOLDER-M_LOCKER JC63-00446E...
Page 157: Mea-Cover Rear
5. MEA-Cover Rear Ver. 1.04...
Page 158 MEA-Cover Rear Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC97-03555A MEA-COVER REAR JC63-00931F COVER-REAR JC63-00936A COVER-M_FACE UP 6003-000196 SCREW-TAPTITE JC63-02376A COVER-REAR STACKER 6003-001001 SCREW-TAPTITE JC63-01098A...
Page 159: Ela Hou-Cover Side
6. ELA HOU-Cover Side R Ver. 1.04...
Page 160 ELA HOU-Cover Side R Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC96-05518A ELA HOU-COVER SIDE R JC63-00928A COVER-M_SIDE R 6502-000132 CABLE CLAMP JC68-01760A LABEL-INFORMATION JC31-00108A...
Page 161: Ela Hou-Scan
7. ELA HOU-Scan Ver. 1.04...
Page 162 ELA HOU-Scan Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC96-05521A ELA HOU-SCAN JC96-05520A ELA HOU-OPE JC96-05521B ELA HOU-SCAN 5635HN/XIL JC96-05520B ELA HOU-OPE 5635HN/XIL 6003-000196 SCREW-TAPTITE...
Page 163: Ela Hou-Adf
8. ELA HOU-ADF Ver. 1.04...
Page 164 ELA HOU-ADF Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC96-05549A ELA HOU-ADF JC97-01962C MEA UNIT-PICKUP 6003-000196 SCREW-TAPTITE JC97-02410A MEA-ADF UPPER JC63-00998A COVER-M_ADF CONNECTOR JC97-02411A MEA-COVER OPEN JC93-00042A...
Page 165: Mea-Cover Open
9. MEA-Cover Open Ver. 1.04...
Page 166 MEA-Cover Open Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC97-02411A MEA-COVER OPEN JB72-00843A PMO-GUIDE PAPER JC63-00983A COVER-M_ADF OPEN JC66-00738A DAMPER-PAD ADF_R2...
Page 167: Mea Unit-Pick
10. MEA Unit-Pick Up Ver. 1.04...
Page 168 MEA Unit-Pick Up Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC97-01962C MEA UNIT-PICKUP JB61-70904A SPRING ETC-CLUTCH JC72-00734A PMO-COVER ADF JB72-00817A PMO-ADF CLUTCH JB66-00103A GEAR-ADF 38 JB66-00102A...
Page 169: Mea-Adf Upper
11. MEA-ADF Upper Ver. 1.04...
Page 170 MEA-ADF Upper Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC97-02410A MEA-ADF UPPER JC63-00373A SHEET-ADF HOLDER JC63-00985A COVER-M_ADF UPPER JB73-00052A RMO-ADF RUBBER JC97-01940B MEA UNIT-HOLDER ADF JC66-00738A DAMPER-PAD ADF_R2...
Page 171: Ela Hou-Adf Lower
12. ELA HOU-ADF Lower Ver. 1.04...
Page 172 ELA HOU-ADF Lower Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC96-05548A ELA HOU-ADF LOWER JC66-00460A SHAFT-M-FEED GEAR 38 JC63-00982A COVER-M_ADF LOWER JC92-02039A PBA-ADF JC61-00712A GUIDE-STACKER SUB...
Page 173: Drive Adf-Bracket
13. Drive ADF-Bracket Ver. 1.04...
Page 174 ELA HOU-ADF Motor Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC93-00042A DRIVE ADF-BRACKET JC72-01105A PMO-BUSHING FEED MID JC61-01589A BRACKET-P-GEAR H JC66-01175A GEAR-24 JC31-00036A MOTOR STEP-ADF JC66-00662A...
Page 175: Mea Unit-Cover Platen
14. MEA Unit-Cover Platen Ver. 1.04...
Page 176 MEA Unit-Cover Platen Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC97-02416C MEA UNIT-COVER PLATEN JC63-00209A SHEET-WHITE SPONGE JC97-02406A MEA-TX STACKER JC97-02779A MEA UNIT-HINGE JC63-00988A COVER-M_STACKER TX JC61-00011A...
Page 177: Ela Hou-Platen
15. ELA HOU-Platen Ver. 1.04...
Page 178 ELA HOU-Platen Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC96-05551A ELA HOU-PLATEN JC96-05550A ELA HOU-SCAN LOWER 6003-000196 SCREW-TAPTITE JC97-02412A MEA-SCAN UPPER...
Page 179: Mea-Scan Upper
16. MEA-Scan Upper Ver. 1.04...
Page 180 MEA-Scan Upper Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC97-02412A MEA-SCAN UPPER JC63-00152F COVER-M_SCAN DUMMY 0203-001267 TAPE-DOUBLE FACE JC74-00021A MCT-GLASS ADF 6002-000440 SCREW-TAPPING 0203-001266 TAPE-DOUBLE FACE...
Page 181: Ela Hou-Scan Lower
17. ELA HOU-Scan Lower Ver. 1.04...
Page 182 ELA HOU-Scan Lower Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC96-05550A ELA HOU-SCAN LOWER JC39-01002A FLAT CABLE 0604-001095 PHOTO-INTERRUPTER JC39-01007A HARNESS-SCAN_MOTOR 1404-001417 THERMISTOR-NTC ASSY JC39-01057A HARNESS-CCD_HOME...
Page 183: Ela Hou-Scan Motor
18. ELA HOU-Scan Motor Ver. 1.04...
Page 184 ELA HOU-Scan Motor Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC96-04918A ELA HOU-SCAN MOTOR JB72-00764A PMO-HOLDER BELT 6003-000269 SCREW-TAPTITE JC61-00895A BRACKET-SCAN MOTOR R2 6044-000125 RING-E JC66-00530A...
Page 185: Ela Hou-Ope
19. ELA HOU-OPE Ver. 1.04...
Page 186 ELA HOU-OPE Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC96-05520A ELA HOU-OPE JC64-00393C KEY-STOP 6003-000196 SCREW-TAPTITE JC64-00394C KEY-TEL JB64-00114C KEY-POWER JC64-00410B KEY-START JC07-00012A JC64-00443A KEY-POWER_B...
Page 187: Ela Unit-Main Drive
20. ELA Unit-Main Drive Ver. 1.04...
Page 188 ELA Unit-Main Drive Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC96-03761B ELA UNIT-MAIN DRIVE JC61-01593A BRACKET-P-GEAR MAIN 6001-000130 SCREW-MACHINE JC61-01597A BRACKET-P-MOTOR MAIN 6003-000301 SCREW-TAPTITE JC66-01156A...
Page 189: Ela Unit-Duplex Drive
21. ELA Unit-Duplex Drive Ver. 1.04...
Page 190 ELA Unit-Duplex Drive Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC96-03762B ELA UNIT-DUPLEX DRIVE JC61-01599A BRACKET-P-GEAR DUP 6001-000130 SCREW-MACHINE JC66-01159A GEAR DUP RDCN 45/19 JC31-00103A MOTOR STEP...
Page 191: Ela Hou-Frame
22. ELA HOU-Frame Ver. 1.04...
Page 192 ELA HOU-Frame Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC96-05516A ELA HOU-FRAME 110V JC91-00928A FUSER-ROLLER 220V JC96-05517A ELA HOU-FRAME 220V JC96-05515A ELA HOU-FRAME ETC 6003-000196 SCREW-TAPTITE JC96-05621A...
Page 193: Ela Hou-Frame Etc.1
23. ELA HOU-Frame Etc.1 Ver. 1.04...
Page 194: Ela Hou-Frame Etc.2
ELA HOU-Frame Etc.2 Ver. 1.04 72-2 72-3 72-1 72-4 72-5 72-6...
Page 195 ELA HOU-Frame Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC96-05515A ELA HOU-FRAME ETC JC61-01942A GUIDE-TR RIB 6002-000440 SCREW-TAPPING JC61-01943A GUIDE-TR 6003-000196 SCREW-TAPTITE JC61-70932A SPRING ETC-GUIDE DEVE 6003-000282...
Page 196 ELA HOU-Frame Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC72-00983A PMO-LOCKER CST 72-3 JC39-00861A HARNESS-HVPS JC72-00984A PMO-PLATE GUIDE DEVE_L 72-4 JC44-00162A HVPS JC72-00985A PMO-PLATE GUIDE DEVE_R 72-5...
Page 197: Ela Hou-Frame Exit
24. ELA HOU-Frame Exit Ver. 1.04 15-3 14-4 15-2 14-3 15-1 14-2 14-1...
Page 198 ELA HOU-Frame Exit Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC90-00911A EXIT GUIDE JC72-40981A PMO-ROLLER UPPER DP 6003-000282 SCREW-TAPTITE JC92-02007A PBA-DEVE CRUM IF JC39-00886A HARNESS-FUSER_AC JC97-01034A...
Page 199: Ela Hou-Guide_Dup
25. ELA HOU-Guide_Dup F Ver. 1.04 15-3 15-1 15-3 15-2...
Page 200 ELA HOU-Guide_Dup F Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC96-03829B ELA HOU-GUIDE_DUP F JC66-01187A LEVER-ACTUATOR EMPTY 0604-001095 PHOTO-INTERRUPTER JC66-01581A CAM-SHAFT PICK UP 6002-000440 SCREW-TAPPING JC67-00208A...
Page 201: Ela Hou-Mpf
26. ELA HOU-MPF Ver. 1.04 30-6 30-5 30-4 30-3 30-2 29-3 30-1 29-2 29-1...
Page 202 ELA HOU-MPF Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC96-04880A ELA HOU-MPF JC66-00709A GEAR-M-HOLDER_MP 0604-001095 PHOTO-INTERRUPTER JC66-00710A GEAR-M-PICK UP_MP 6003-000196 SCREW-TAPTITE JC66-00720A SHAFT-P-CORE 6003-000196 SCREW-TAPTITE...
Page 203: Ela Hou-Fuser Drive
27. ELA HOU-Fuser Drive Ver. 1.04...
Page 204 ELA HOU-Fuser Drive Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC96-04634A ELA HOU-FUSER DRIVE JC66-00340A GEAR-HUB CLUTCH 6003-000269 SCREW-TAPTITE JC66-00417A GEAR-RDCN FUSER OUT 6044-000125 RING-E JC66-01158A...
Page 205: Ela Unit-Fuser
28. ELA Unit-Fuser Ver. 1.04...
Page 206 ELA Unit-Fuser Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC91-00929A ELA UNIT-FUSER 110V JC67-00254A CAP-LAMP_R JC91-00928A ELA UNIT-FUSER 220V JC66-01593B ROLLER-HEAT JC90-00910A MEA UNIT-DOOR FUSER JC66-01588A GEAR-FUSER...
Page 207: Mea Unit-Bracket Feed
29. MEA Unit-Bracket Feed Ver. 1.04...
Page 208 MEA Unit-Bracket Feed Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC97-02394A MEA UNIT-BRACKET FEED JC66-00484A GEAR-T2 IDEL_Z27 6044-000125 RING-E JC66-01164A GEAR-RETARD 39/19 6044-000231 RING-E JC66-01166A...
Page 209: Mea Unit-Clutch
30. MEA Unit-Clutch Ver. 1.04...
Page 210 MEA Unit-Clutch Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC97-01788A MEA UNIT-CLUTCH JC66-00398A SHAFT-FEED 6107-001171 SPRING-TS JC72-00978A PMO-COLLAR_SPRING JC66-00393A GEAR-FEED 1 JC72-00981A PMO-HUB CLUTCH...
Page 211: Ela Hou-Smps_V1/V2
31. ELA HOU-SMPS_V1/V2 Ver. 1.04...
Page 212 ELA HOU-SMPS_V1/V2 Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC96-05621A ELA HOU-SMPS_V1 110V JC44-00097D SMPS-V1 110V JC96-05622A ELA HOU-SMPS_V2 220V JC44-00090D SMPS-V2C 220V 6003-000269 SCREW-TAPTITE...
Page 213: Mea Unit-Duplex
32. MEA Unit-Duplex Ver. 1.04...
Page 214 MEA Unit-Duplex Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC97-02393A MEA UNIT-DUPLEX 6003-000196 SCREW-TAPTITE JC61-01594A FRAME-M_DUP JC65-00017A TERMINAL-P-GND DUP JC61-01595A GUIDE-M_UPPER DUP JC61-01595A GUIDE-M_UPPER DUP JC61-00665A...
Page 215: Mea Unit-Cassette
33. MEA Unit-Cassette Ver. 1.04...
Page 216 MEA Unit-Cassette Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC97-03554A MEA UNIT-CASSETTE JG61-70531A SPRING ETC-LOCKER,PLATE JC61-00876A FRAME-M_CASSETTE JC70-00300A ADJUST-M-CASSETTE_L JC61-00918B GUIDE-M-EXTENSION L2 JC70-00301A ADJUST-M-CASSETTE_R JC72-00971A...
Page 217: Ela Hou-Scf
34. ELA HOU-SCF Ver. 1.04 23 37 36 50...
Page 218 ELA HOU-SCF Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC96-05180A ELA HOU-SCF JC63-00369A SHEET-COVER SENSOR 3301-001635 CORE-FERRITE JC63-00492C COVER-M_SIMM 6003-000196 SCREW-TAPTITE JC63-00527A SHEET-BRUSH 6501-000004 CABLE TIE...
Page 219 ELA HOU-SCF Parts List Ver. 1.04 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT’y Service Remark Drawer# SEC_Code Description QT’y Service Remark JC97-03554A MEA UNIT-CASSETTE SCF JC63-00940A COVERT-FRONT SCF JC97-02555A MEA-COVER FRONT SCF JC66-00529A ROLLER-M-IDLE FEED 6107-001047 SPRING-ES...

This manual is also suitable for:

Scx-5635fnScx-5635 series

Samsung SCX-5635HN Service Manual

Quick Links

Troubleshooting

Need help?

Questions and answers

Related Manuals for Samsung SCX-5635HN

Summary of Contents for Samsung SCX-5635HN

This manual is also suitable for:

Table of Contents
