Knick Portavo 902 COND User Manual

Portable conductivity meter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
Betriebsanleitung
Stratos®Pro
English
Aktuelle Produktinformation: www.knick.de
Latest Product Information: www.knick.de
Stratos Pro A2... pH
Portavo® 902 COND
deutsch
Betriebsanleitung
Aktuelle Produktinformation:
www.knick.de
The Art of Measuring.
A2... PH
II 1G Ex ia IIC T3/T4/T6
14163 Berlin
14163 Berlin
SE 706X/1-NMSN
SE 706X/2-NMS
14163 Berlin
BVS 10 ATEX E0
BVS 10 ATEX E089 X
II 1G Ex ia IIC T
SE 706X/1-NM
II 1G Ex ia IIC T3/T4/T6
BVS 10 ATEX E
14163 Berlin
II 1G Ex ia IIC
SE 706X/2-NMSN
14163 Berlin
SE 706X/2-NM
BVS 10 ATEX E089 X
II 1G Ex ia IIC T3/T4/T6
BVS 10 ATEX E
II 1G Ex ia IIC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Portavo 902 COND and is the answer not in the manual?

Questions and answers

Related Manuals for Knick Portavo 902 COND

Summary of Contents for Knick Portavo 902 COND

  • Page 1 BVS 10 ATEX E II 1G Ex ia IIC User Manual Betriebsanleitung Stratos Pro A2... pH Portavo® 902 COND Stratos®Pro English deutsch A2... PH Betriebsanleitung x ia IIC T3/T4/T6 ATEX E 089 X Aktuelle Produktinformation: Aktuelle Produktinformation: www.knick.de Latest Product Information: www.knick.de www.knick.de...
  • Page 3 Basics Return of products under warranty Please contact our Service Team before returning a defective device. Ship the cleaned device to the address you have been given. If the device has been in contact with process fluids, it must be decontaminated/dis- infected before shipment.

  • Page 4: Table Of Contents

    Table of Contents Package Contents ................5 Documentation ................... 6 Overview of the Portavo 902 COND ..........7 Value-Added Features ....................8 Protective Cover ......................9 Hook ..........................9 Display ......................... 10 Keypad ........................11 Start-Up ..................... 12 Inserting the Batteries ................... 12 Connecting a Sensor ....................

  • Page 5: Package Contents

    Package Contents Check the shipment for transport damage and completeness. The package of the Portavo 902 COND includes: • The Portavo 902 COND incl. 4 AA batteries and premounted quiver • Carrying strap • Quickstart instructions in various languages • Specific test report •...

  • Page 6: Documentation

    • User manuals in different languages • Safety instructions • Quickstart guides Safety Instructions In official EU languages and others. • EC Declarations of Conformity Knick Corporate Design Manual / Bedienungsanleitungen Betriebsanleitung für Sauerstoff-Sensoren der Reihe SE 706-Memosens ® ¡Å ¶ MEMO...

  • Page 7: Overview Of The Portavo 902 Cond

    Overview of the Portavo 902 COND The Portavo 902 COND is a portable conductivity meter. A plain-text line on the high-contrast LCD screen makes operation virtually self-explanatory. The meter stands out by the following features: • Use of digital Memosens sensors •...

  • Page 8: Value-Added Features

    Overview of the Portavo 902 COND Value-Added Features Memosens The Portavo 902 can communicate with Memosens sensors. These digital sensors are auto- matically identified and the meter switches to the appropriate measurement method. When a Memosens sensor is connected to the meter, it is indicated by the logo shown on the right.

  • Page 9: Protective Cover

    Overview of the Portavo 902 COND Protective Cover The front of the meter is protected by a cover, which can be completely flipped over and secured to the back for oper- ation. A label on the inner side of the cover explains the control functions and device messages.

  • Page 10: Display

    Overview of the Portavo 902 COND Display The meter has a three-line display for representing alphanumeric information such as measurement and calibration data, temperatures and date/time. Additional information is provided by means of icons (Sensoface, battery icon, etc.). Some typical displays are shown below:...

  • Page 11: Keypad

    Overview of the Portavo 902 COND Keypad The keys of the membrane keypad have a noticeable pressure point. They have the following functions: on/off Switches the meter on and displays the device and calibration data (see Start-up) meas Switches the meter on /...

  • Page 12: Start-Up

    Start-Up Check the shipment for transport damage and completeness (see Package Contents). NOTICE! Do not operate the device when one of the following conditions applies: • the device shows visible damage • the device fails to perform the intended function •...

  • Page 13: Connecting A Sensor

    Start-Up Connecting a Sensor The Portavo 902 COND provides several connections so that many types of sensors can be used for measurement (see illustration below). Note that only one sensor may be connected to the meter at a time. The meter automatically recognizes a connected Memosens sensor and switches accordingly.

  • Page 14: Switching On The Meter

    Start-Up Switching On the Meter When you have connected the sensor, you can switch the meter on by pressing the on/off or meas key. When the meter is switched on with the on/off key, first a self test is performed and then the calibration data and settings are displayed before the meter switches to measuring mode.

  • Page 15: Configuring

    Configuring Conductivity Configuration Prior to measurement, a configuration should be performed to match the connected sensor and the desired measurement performance. Furthermore, you can select the suitable calibration method. The following table gives you an overview. Factory settings are shown in bold print. Measurement “Setup”...

  • Page 16: Calibrating

    Calibrating CELL CONST Calibration (Calibration by entry of cell constant) The calibration method is selected in the configuration menu. Measurement Calibration method, the number of calibration CELL CONST. points and the buffer set have been selected in the configuration menu. Value blinks to select the value for the cell constant.
  • Page 17 Calibrating 0.1 / 0.01 MOL KCL Calibration (Automatic calibration with KCl solution) The calibration method is selected in the configuration menu. NOTICE! • Make sure that the values of the calibration solutions used correspond exactly to those specified in this manual. If not, the resulting cell constant will be incorrect.
  • Page 18 Calibrating INST. FACTOR Calibration (For inductive conductivity measurement only: input of installation factor) Selected in the configuration menu. Measurement In narrow installation conditions, the conductivity measurement is influ- enced by the sensor’s distance to the wall and the wall material. This effect can be compensated for by the instal- lation factor.
  • Page 19 Calibrating ZERO POINT Calibration (For inductive conductivity measurement only: calibrating the sensor zero point) Calibration method is selected in the configuration menu. Measurement Remove the sensor for calibration and place it in air – then start calibration. The “hourglass” icon blinks Calibration is performed.
  • Page 20 Calibrating TEMP. OFFSET Calibration (Option) Temperature calibration (offset) Selected in the configuration menu. Measurement You can specify an offset for the tem- perature measured by the sensor. After calibration has been activated, the following values are listed in the display: •...
  • Page 21 Calibrating FREE CAL Calibration (Free selection of calibration method) FREE CAL calibration is selected in the configuration menu. Measurement to select the desired calibration CELL CONST. blinks method (CELL CONST., COND, 0.01 MOL KCL or 0.1 MOL KCL, INST. FACTOR*, ZERO POINT*, TEMP.

  • Page 22: Concentration Measurement

    Concentration Measurement Measuring Ranges Substance Concentration ranges NaCl 0-26 wt% (0 °C) 0-26 wt% (100 °C) -01- Configuration 0-18 wt% (-20 °C) 22-39% wt% (-20 °C) 0-18 wt% (50 °C) 22-39% wt% (50 °C) -02- -07- Configuration NaOH 0-13 wt% (0 °C) 15-50 wt% (0 °C) 0-24 wt% (100 °C) 35-50 wt% (100 °C)

  • Page 23: Concentration Curves

    Concentration Curves -01- Sodium chloride solution NaCl -01- c [% by wt] Concentration measurement not possible in this range. Conductivity versus substance concentration and process temperature for sodium chloride solution (NaCl)
  • Page 24 Concentration Curves -02- Hydrochloric acid HCl -07- -02- -07- c [% by wt] Concentration measurement not possible in this range. Conductivity versus substance concentration and process temperature for hydro- chloric acid (HCl) Source: Haase/Sauermann/Dücker; Z. phys. Chem. New Edition, Vol. 47 (1965)
  • Page 25 Concentration Curves -03- Sodium hydroxide solution NaOH -10- -03- -10- c [% by wt] Concentration measurement not possible in this range. Conductivity versus substance concentration and process temperature for sodium hydroxide solution (NaOH)
  • Page 26 Concentration Curves -04- Sulfuric acid H -06- -09- -09- -06- -04- c [% by wt] Concentration measurement not possible in this range. Conductivity versus substance concentration and process temperature for sulfuric acid (H Source: Darling; Journal of Chemical and Engineering Data; Vol.9 No.3, July 1964...
  • Page 27 Concentration Curves -05- Nitric acid HNO -08- -08- -05- c [% by wt] Concentration measurement not possible in this range. Conductivity versus substance concentration and process temperature for nitric acid (HN0 Source: Haase/Sauermann/Dücker; Z. phys. Chem. New Edition, Vol. 47 (1965)

  • Page 28: Measuring

    Measuring Keys for Once you have completed all preparations, you can start with measurement the actual measurement. 1) Connect the desired sensor to the meter. Some sensors require a special preparation. Please proceed according to the operating instructions for the sensor. 2) Switch the meter on using the on/off or meas key.

  • Page 29: Clock

    Clock Press the clock key to access the clock mode. Date and time will be displayed in the format as set in the configuration menu. To set the clock, proceed as follows: Display of time+date Hour display blinks Set value. SET HOUR Minute display blinks Set value.

  • Page 30: Enabling Options / Tan Input

    Options Enabling Options / TAN Input When you have bought “Option 002 Temperature Calibration”, you receive a document with a code (TAN) for enabling this option on your device. Press the set key to access the configuration mode. Use the arrow keys to select the “TAN TEMP CAL” function where you can enter the TAN for enabling the option.

  • Page 31: Option 002 Temperature Calibration

    Options Option 002 Temperature Calibration Selecting the temperature calibration (TEMP. OFFSET) In measuring mode, press the set key. 1) Select CAL (calibration) and confirm by pressing set. 2) Select the TEMP. OFFSET calibration mode and confirm by pressing set. Performing the temperature calibration (TEMP. OFFSET) In measuring mode, press the cal key.

  • Page 32: Error Codes And Device Messages

    Error Codes and Device Messages Error messages are indicated as “ERROR …” on the display. Information on the sensor condition is indicated by the “Sensoface” icon (friendly, neutral, sad) possibly accom- panied by an info message (“INFO …”). Example of an error message: Example of a “Sensoface”...

  • Page 33: Sensoface" Messages

    Error Codes and Device Messages “Sensoface” Messages The “Sensoface” icon provides information on the sensor condition: Sensoface Meaning Sensor is okay Calibrate the sensor soon Calibrate or replace the sensor The “neutral” and “sad” Sensoface icons are accompanied by an “INFO …” message to give a hint to the cause of deterioration.

  • Page 34: Error Messages

    Error Codes and Device Messages Error Messages The following error messages can be shown in the display. Message Cause Remedy Battery empty Replace batteries blinks ERROR 1 Value out of range Check whether the measurement conditions correspond to the Temperature value out of ERROR 3 adjusted measuring range.

  • Page 35: Conductivity Sensors

    Product Line Conductivity Sensors Please visit our website for more information on our product range: www.knick.de Temperature detectors Note: When a Memosens sensor is connected, the temperature detector of the Memosens sensor is used. When no Memosens sensor is connected, the Portavo 902 COND can be used as a temperature meter.

  • Page 36: Conductivity Standards

    Adapter for connecting a conductivity sensor with ZU 0289 2 banana plugs to the Portavo 902 COND Adapter for connecting the ZU 6985 4-electrode sensor to the ZU 0290 Portavo 902 COND Please visit our website for more information on our product range: www.knick.de.

  • Page 37: Specifications

    Specifications Conductivity input, Multi-contact for 2-/4-el. sensors with integrated temp detector analog Measuring ranges SE 202 sensor: 0.01 … 200 μS/cm SE 204 sensor: 0.05 to 500 mS/cm 2-electrode sensors: 0.1 μS * c … 200 mS * c 4-electrode sensors: 0.1 μS * c …...
  • Page 38 Specifications Conductivity input, M8 socket, 4 pins, for Memosens lab cable Memosens Measuring range SE 215 MS sensor: 10 µS/cm … 20 mS/cm Measuring cycle Approx. 1 s Temperature compensation Linear 0 … 20 %/K, reference temperature adjustable Concentration measurement See page 39 Display resolution Conductivity...
  • Page 39 Specifications RoHS conformity According to directive 2011/65/EU Power supply Portavo 902 4 x AA alkaline batteries Operating time Approx. 1000 h (alkaline) Nominal operating conditions Ambient temperature -10 °C ...+55 °C Transport/ -25 °C … +70 °C Storage temperature Relative humidity 0 …...
