Key Description
Main Board Assembly
Note
Contact your Emerson Process
Management sales office for Main
Board Assembly FS Numbers.
15 Fasteners
16 Pressure Sensor Seal
35 Main Board with LCD and Pushbuttons
I/P Converter Assembly
25 Fasteners
26 O-Ring
41 I/P Converter
231 Screen O-Ring
July 2009
(2)
Key Description
(3)
Relay Assembly
2 Relay
45 O-Rings
Mounting Frame Assembly
3 Mounting Frame
16 Pressure Sensor Seal
19 Fasteners
45 O-Ring
51 O-Ring
EMI Shield Assembly
11 Fasteners (3 req'd)
29 Conductive Gasket (Shield)
37 Primary Shield
2. All parts included in the I/P Converter Kit
3. All parts included in the Low Pressure or High Pressure Relay Kits
4. All parts included in the Mounting Frame Kit
5. All parts included in the EMI Shield Kit
Parts
(4)
(5)
