DVC2000 Digital Valve Controller
The local user interface is available on all DVC2000
digital valve controllers. The interface consists of a
liquid crystal display, four pushbuttons, and a switch
for position transmitter configuration. The DVC2000 is
supplied with one of three different language packs
preinstalled, depending on the firmware revision and
ordering option. Language pack options are shown in
table 3-1. To configure the language, follow the
procedure outlined in the Basic Setup section. The
instrument must be powered with at least 8.5 volts and
3.5 mA to operate the local interface. Certain
procedures require up to 20 mA of current.
3
CAUTION
When accessing the terminals or
pushbuttons, proper means of
electrostatic discharge protection is
required. Failure to provide appropriate
protection can cause the valve to
move, resulting in valve/actuator
instability.

Status Information

The first (home) screen on the LCD that is displayed
TRAVEL = 66.8%
14.6 MA 0.92 BAR
3-2
Only with Optional
Transmitter / Limit Switches
SWITCH 1 = OPEN
A
"
A
SWITCH 2 = CLOSED
Figure 3-1. Home Screen on the LCD
after applying power to the instrument contains basic
status information. On an instrument that is calibrated
and operating properly, the flow chart in figure 3-1
shows the available information by pressing the right
(") arrow key.
TRAVEL=##.#%—Current valve travel in percent of
calibrated travel.
##.# MA—Current input signal applied to the
instrument in mA.
##.## BAR—Current pressure output to the actuator in
the configured units (BAR, PSI or MPA).
SWITCH1—Current status of the optional limit switch
wired to terminals +41 and −42.
SWITCH2—Current status of the optional limit switch
wired to terminals +51 and −52.
FW#—Version of firmware running in the device.
HW#—Version of electronics hardware installed. The
first number (# : #) represents the main board, the
second number (# : #) represents the secondary
electronics.
TUNING = X—Current tuning set parameters
configured in the device.
PROTECTION—Indicates whether the local interface
is protected or not. With protection ON, the instrument
cannot be configured or calibrated with the local
pushbuttons.
FW3:1, HW1:2
A
"
"
TUNING = C
PROTECTION
"OFF
OFF
ON
July 2009
