DVC2000 Digital Valve Controller
Installation
Note
The DVC2000 is not designed to
correct for significant stem rotation on
2
sliding-stem actuators.
Avoid personal injury or property
damage from sudden release of
process pressure or bursting of parts.
Before mounting the DVC2000 digital
valve controller:
D Always wear protective clothing,
gloves, and eyewear when performing
any installation procedures to avoid
personal injury or property damage.
D Do not remove the actuator from
the valve while the valve is still
pressurized.
D Disconnect any operating lines
providing air pressure, electric power,
or a control signal to the actuator. Be
sure the actuator cannot suddenly
open or close the control valve.
D Use bypass valves or completely
shut off the process to isolate the
control valve from process pressure.
Relieve process pressure from both
sides of the control valve.
D Vent the pneumatic actuator
loading pressure and relieve any
actuator spring precompression.
D Use lock-out procedures to be
sure that the above measures stay in
effect while you work on the
equipment.
D Check with your process or
safety engineer for any additional
measures that must be taken to
protect against process media.
2-2
WARNING
Special Instructions for "Safe Use" and
Installations in Hazardous Locations
Certain nameplates may carry more than one
approval, and each approval may have unique
installation/wiring requirements and/or conditions of
"safe use". These special instructions for "safe use"
are in addition to, and may override, the standard
installation procedures. Special instructions are listed
by approval.
WARNING
Failure to follow these conditions of
"safe use" could result in personal
injury or property damage from fire or
explosion, or area re-classification.

CSA

Special Conditions of Safe Use
Intrinsic Safety and Non-Incendive
No special conditions for safe use.
Refer to table 1-3 for approval information, figure C-1
for the CSA loop schematic, and figure C-3 for the
CSA and FM approvals nameplate.
FM
Special Conditions of Safe Use
Intrinsic Safety and Non-Incendive
No special conditions for safe use.
Refer to table 1-4 for approval information, figure C-2
for the FM loop schematic, and figure C-3 for the CSA
and FM approvals nameplate.

ATEX

Special Conditions for Safe Use
Intrinsic Safety
The equipment is an intrinsically safe equipment. It
can be mounted in hazardous area.
The terminal blocks can be only connected to certified
intrinsically safe equipments and these combinations
must be compatible as regard intrinsic safety rules.
The equipment shall be connected in accordance with
with manufacturer's installation instructions (see
drawing GE14685).
The equipment shall not be submitted to mechanical
impacts or frictions.
