B3
Battery Burnisher
Operator and Parts Manual
EN
MB38904
9008413
Rev. 01 (05-2011)
www.tennantco.com
Home
Find... Go To..

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tennant B3

Summary of Contents for Tennant B3

  • Page 1 Battery Burnisher Operator and Parts Manual MB38904 9008413 Rev. 01 (05-2011) www.tennantco.com Home Find... Go To..

  • Page 2: Table Of Contents

    P.O. Box 6 5400 AA Uden-The Netherlands Customer Service: Europe@tennantco.com www.tennantco.com Specifications and parts are subject to change without notice. Original Instructions. Copyright © 2011 Tennant Company, All rights reserved. Printed in the UK. Tennant B3 (02-11) Home Find... Go To..

  • Page 3: Safety Precautions

    5 amp fuse. If fuse replacement is required, it must be on rear caster. replaced by a 5 amp fuse conforming to BS1362. Do not use charger if fuse cover is missing. Home Find... Go To.. Tennant B3 (02-11)

  • Page 4: Safety Labels

    7. Battery Life Indicator 8. Pad Retainer Tool 9. Battery Charger Power Supply Cord 10. Rear Tilt Caster 11. Battery Charge Indicator Display 12. Dust Collector Container 13. Battery Cover 14. Brush Guard Tennant B3 (02-11) Home Find... Go To..

  • Page 5: Installing Burnishing Pad

    Operate machine in a forward and backward direction. ATTENTION: Do not operate the machine in same spot for a lengthy period. Floor damage may result. Stand machine upright and return pad retainer tool. Release the triggers to stop machine. Home Find... Go To.. Tennant B3 (02-11)

  • Page 6: Spray Buffing (Optional)

    Check battery life indicator. If necessary, recharge the batteries. Only recharge if in red zone. Regularly inspect charger cord for damage or loose connection. Tennant B3 (02-11) Home Find... Go To..

  • Page 7: Recharging Batteries

    ATTENTION – Refer to the Troubleshooting section below if the voltage rating. machine is not functioning properly. Contact a TENNANT The charger is set for GEL batteries only. Authorized service representative if the problem persists or the Do not operate the machine when connected to problem is not listed.

  • Page 8: Storing Machine

    Place pad in correct position. Pad dirty. Clean the pad. Incorrect pad selection. Contact pad supplier. * If the fuse blows repeatedly, the machine should be checked by an Authorized TENNANT service representative. Tennant B3 (02-11) Home Find... Go To..

  • Page 9: Recommended Pads And Spare Parts List

    Pre-Burnish Pad, Pre-burnishing / wet cleaning protected floors. 836464 PAD, 17.0D/432, [PINK, 3M, UHS, 5PC] Eraser Burnish Pad, Dry buffing / spray buffing / cleaning protected floors 833465 DRIVE DISC 836493 STRIP, FELT, DUST COLLECTOR [B3] Home Find... Go To.. Tennant B3 (02-11)

  • Page 10: Parts List

    PARTS LIST MACHINE ASSEMBLY GROUP Tennant B3 (02-11) Home Find... Go To..
  • Page 11 PARTS LIST MACHINE ASSEMBLY GROUP Home Find... Go To.. Tennant B3 (02-11)
  • Page 12 PARTS LIST PAD ASSEMBLY GROUP Tennant B3 (02-11) Home Find... Go To..
  • Page 13 PARTS LIST PAD ASSEMBLY GROUP Home Find... Go To.. Tennant B3 (02-11)
  • Page 14 PARTS LIST PAD MOTOR GROUP Tennant B3 (02-11) Home Find... Go To..
  • Page 15 PARTS LIST PAD MOTOR GROUP Home Find... Go To.. Tennant B3 (02-11)
  • Page 16 PARTS LIST BATTERY CHARGER GROUP Tennant B3 (02-11) Home Find... Go To..
  • Page 17 PARTS LIST BATTERY CHARGER GROUP Home Find... Go To.. Tennant B3 (02-11)
  • Page 18 PARTS LIST PAD GUARD GROUP Tennant B3 (02-11) Home Find... Go To..
  • Page 19 PARTS LIST PAD GUARD GROUP Home Find... Go To.. Tennant B3 (02-11)
  • Page 20 PARTS LIST HANDLE GROUP Tennant B3 (02-11) Home Find... Go To..
  • Page 21 PARTS LIST HANDLE GROUP Home Find... Go To.. Tennant B3 (02-11)
  • Page 22 PARTS LIST CHASSIS GROUP Tennant B3 (02-11) Home Find... Go To..
  • Page 23 PARTS LIST CHASSIS GROUP Home Find... Go To.. Tennant B3 (02-11)
  • Page 24 PARTS LIST MOTOR COVER GROUP Tennant B3 (02-11) Home Find... Go To..
  • Page 25 PARTS LIST MOTOR COVER GROUP Home Find... Go To.. Tennant B3 (02-11)
  • Page 26 PARTS LIST OPTIONAL SPRAY SYSTEM GROUP Tennant B3 (02-11) Home Find... Go To..
  • Page 27 PARTS LIST OPTIONAL SPRAY SYSTEM GROUP Home Find... Go To.. Tennant B3 (02-11)

  • Page 28: Electrical Diagram

    PARTS LIST ELECTRICAL DIAGRAM Tennant B3 (02-11) Home Find... Go To..
  • Page 29 Home Find... Go To.. Tennant B3 (02-11)
  • Page 30 Tennant B3 (02-11) Home Find... Go To..
