4.4.4.
VCC_MCU Jumper
This jumper connects VCC to the target MCU. This jumper can be replaced with an ampere meter to
measure the current used by the target device. Remeber to mount this jumper or an ampere meter to
make the target MCU work properly.
Atmel SAM4L Xplained Pro [USER GUIDE]
22
Atmel-42074C-SAM4L-Xplained-Pro_User Guide-11/2015
