5.

Appendix

5.1.

Getting Started with IAR

IAR Embedded Workbench
Programming and debugging of Xplained Pro kits are supported in IAR
using the common CMSIS-DAP interface. Some initial settings have to be set up in the project to get the
programming and debugging to work.
The following steps will explain how to get your project ready for programming and debugging:
1. Make sure you have opened the project you want to configure. Open the OPTIONS dialog for the
project.
2. In the category General Options, select the Target tab.
listed, the core of the device.
3. In the category Debugger, select the Setup tab.
4. In the category Debugger, select the Download tab.
option.
5. In the category Debugger > CMSIS DAP, select the Setup tab.
reset method.
6. In the category Debugger > CMSIS DAP, select the JTAG/SWD tab.
and optionally select the SWD speed.
Figure 5-1 Select Target Device
® ®
for ARM is a proprietary high efficiency compiler not based on GCC.
™
Embedded Workbench for ARM
Select the device for the project or, if not
Select CMSIS DAP as the driver.
Check the check box for Use flash loader(s)
Select System (default) as the
Select SWD as the interface
