- Page 1 Pixelfloor P25 Kling-Net ORDERCODE 42280 Highlite International B.V. Vestastraat 2 6468 EX Kerkrade The Netherlands Phone: +31 45-5667700...
- Page 2 For more information: iwant@showtec.info You can get some of the best quality, best priced products on the market from Showtec. So next time, turn to Showtec for more great lighting equipment. Always get the best -- with Showtec ! Thank you!
-
Page 3: Table Of Contents
Showtec Showtec LED Pixelfloor Product Guide ™ Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................4 Rigging .................................... 4 Return Procedure ................................5 Claims ....................................5 Description of the device ..............................6 Overview ..................................6 Backside ..................................7 Installation ................................... -
Page 4: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: • Showtec LED Pixelfloor with clear cover • 1 x AC Power Plug • User manual LED Expected Lifespan LEDs gradually decline in brightness over time. - Page 5 If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
-
Page 6: Operating Determinations
CAUTION ! EYEDAMAGES !. Avoid looking directly into the light source. (meant especially for epileptics) ! Operating Determinations • This device is not designed for permanent operation. Consistent operation breaks will ensure that the device will serve you for a long time without defects. •... -
Page 7: Return Procedure
Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. Call Highlite 0031-455667723 or mail aftersales@highlite.nl and request an RMA prior to shipping the fixture. -
Page 8: Description Of The Device
Description of the device Features The LED Pixelfloor is designed for the more demanding user: Klingnet is developed in collaboration with Arkaos, ensuring powerful tools and state-of-art functionalities in combination with easy set-up. • Plug & Play with Klingnet protocol •... -
Page 9: Backside
Backside Fig. 2 1) Data OUT 2) Data IN 3) Power OUT 4) Power IN 5) Special Powercable Fig. 3... -
Page 10: Installation
Installation Remove all packing materials from the LED Pixelfloor. Check that all foam and plastic padding is removed. Connect all cables. Do not supply power before the whole system is set up and connected properly. Always disconnect from electric mains power supply before cleaning or servicing. Damages caused by non-observance are not subject to warranty. -
Page 11: Level Surface
Level Surface The LED Pixelfloor has 5 adjustable feet, which can help you to make the floor set in level completely. Rigging When rigging is necessary, you may need to remove the adjustable feet and replace them with M10 C- clamp to rig the LED Pixelfloor to the truss. -
Page 12: Maximum And Minimum Height
Maximum and Minimum Height Connecting LED Pixelfloor 1. Install the Arkaos Software or DMT Vision Express on your computer (Windows or Mac). This software already includes the Kling-Net protocol. Computer Fixed IP Address: Example: 192.168.1.0 until 192.168.1.255 Subnet mask: 255.255.255.0 10.0.0.0 until 10.0.0.255 2.0.0.1 until 2.0.0.255 Etc. -
Page 13: Setup Example Combination Of Klingnet Fixtures
Setup example combination of Klingnet fixtures PC or Mac 42275 Pixelbatten P25 42280 Pixelfloor 42280 Pixelfloor 42270 Pixelstrip P25... -
Page 14: How To Make A Data Cable
How to make a Data Cable C-Side A-Side B-Side B-Side Fig. 3 D-Side A Standard ETHERNET CABLE can be used to replace the DATA CABLE required to transmit the data for the LED Pixelfloor. Please follow the following instructions in order to create extra NET CABLE. Take a standard net cable (Cat5/ 5E /6) and connect it to the RJ-45 connector just like displayed on the picture. -
Page 15: Software For Controlling Video Over The Led Pixelfloor (Arkaos Or Dmt)
50228 Arkaos Media Master 3.0: PRO DMX video software for lighting designers Maintenance The Showtec LED Pixelfloor requires almost no maintenance. However, you should keep the unit clean. Otherwise, the fixture’s light-output will be significantly reduced. Disconnect the mains power supply, and then wipe the cover with a damp cloth. -
Page 16: Troubleshooting
2. The LEDs. Return the LED Pixelfloor to your Showtec dealer. 3. The fuse. Since this is an internal fuse, return the device to your Showtec dealer. 4. If all of the above appears to be O.K., plug the unit in again. -
Page 17: Product Specification
Product Specification Model: Showtec LED Pixelfloor (42280) • Plug & Play with Klingnet protocol • Quick setup due to deck brackets • Liquid resistant CAT5 connections • Bright colors • The Pixelfloor P25 is a one square meter LED tile working on the Klingnet-protocol.
