Capturing A Video From A Dv Tape - Ratoc Systems CBFW3 User Manual

4-5.Capturing a video from a DV tape

When you want to capture a video image from a DV tape, follow steps through.
1. Set a DV tape in a DVCAM and confirm the DVCAM mode is set to video mode.
Video Mode means you can control a video of a DV tape. If your DVCAM is in camera
mode, change mode selection switch from camera mode to video mode slowly as
mentioned 4-4.Capturing a video from a DVCAM in camera mode.
2.Select [DV mode] on the [Application Setting] as shown in 4-3.Application settings.
3.When you click the
to play and a video image of the DV tape will appear in the preview window.
4.Click the
5.Click the
You can also stop capturing by using the
pressing ESC button on the keyboard.
6. If you checked [Rename file name every capture execution] on the [Application Setting],
You will see the window.You can
rename the captured file.
7.The file will be saved in the folder
you set at [Set Folder Name To
Save Capture Files] on the
[Application Setting].
NOTE
1.When you preview, it puts some load on PCs. If data loss happens, don't check
[Capture With Preview] on the [Application Setting]. For more information, please refer
to the Chapter 8-4.A captured file is choppy or jerky.
2.To capture correct DV file, you have to use original DV footages which has
continuous Timecode(recording). If the original DV footage has intermittent Time
code, sometimes it may cause system freeze or may not be captured.
40
DV play button on the Video Control Bar, the DV tape will start
button to start capturing.
button to stop capturing.
stop button on the Video Control Bar or
