Ultra SCSI (FAST-20) CardBus PC Card
CB31U
User's Guide
March 2005
Rev. 4.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CB31U and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ratoc Systems CB31U

Summary of Contents for Ratoc Systems CB31U

  • Page 1 Ultra SCSI (FAST-20) CardBus PC Card CB31U User’s Guide March 2005 Rev. 4.0...

  • Page 2: Table Of Contents

    6-3. Install Windows 2000, using Windows 95/98 startup disk ... 63 7. Linux ...64 7-1. How to install the driver for Linux ... 64 7-2. SCSI Configuration Utility for Linux:asccong ... 67 8. Troubleshooting...70 9. Registration and Tech-Support... 98 10. Options ...99 11. Specifications ...100 CB31U...

  • Page 3: Introduction

    Windows 95B / Windows 95C / Windows 98 / Windows98 SE (Second Edition) Windows Xp / Windows 2000 / Windows Me (Millennium Edition) NOTE If the version of your Windows 95 is 4.00.950 or 4.00.950 A, you can not use the CB31U. 1. Introduction...

  • Page 4: Setup

    You can connect Iomega Zip drive to the CB31U, though the Zip drive can not provide termination power. • You can not boot up system from a SCSI device connected to the CB31U. Do not install Operating System into a SCSI device connected to the CB31U because you can not boot up system from it.

  • Page 5: Windows 95 Setup

    Click the General tab. d. If you can find 4.00.950 B or 4.00.950 C, you can use the CB31U. NOTE If the version of your Windows 95 is 4.00.950 or 4.00.950 A, you can not use the CB31U. 2. Setup...
  • Page 6 2. Setup 2. Check to see if your PCMCIA Controller supports CardBus PC Cards. a. In the System Properties window shown above, click the Device Manager tab. b. Double-click on the PCMCIA socket string and make sure there is a CardBus controller name string without “!”...
  • Page 7 Device status, you can use the CB31U. 3. Grasp the CB31U by the edges with the label facing upward. Insert the CB31U into the slot and push it in until it is firmly seated. If the CB31U can not be firmly seated, check to see if the PC Card slot supports CardBus PC Cards.
  • Page 8 2. Setup 4. When the Update Device Driver Wizard Window Appears a. When the Update Device Driver Wizard window appears, insert the CD-ROM or the floppy disk included in this package and click Next. b. When SCSI CardBus PC Card REX CB31 appears in the window, click Finish.
  • Page 9 CD-ROM drive letter for the source of files and click OK. e. Wait until the PC Card (PCMCIA) icon appears on the Windows taskbar. This icon indicates that the CB31U is recognized. f. Remove the floppy disk or the CD-ROM from the PC.

  • Page 10: Confirming The Installation

    2. Setup 2-1-2. Confirming the Installation 1. Click My Computer with the right button. 2. Select Properties. You will see the System Properties window below. 3. Click the Device Manager tab. 4. Double-click SCSI Controllers in the list. 5. Make sure there is a SCSI CardBus PC Card REX CB31 string without “!” or “X” marks. 6.
  • Page 11 4. When the window saying You may safely remove this device appears, you can remove the CB31U from the PC. 5. Press an eject button of the PC Card slot (1). Grasp the CB31U by the edge and pull it straight out of the PC Card slot (2).

  • Page 12: Windows 98 Setup

    2. Setup 2-2. Windows 98 Setup Here’s how to get started with the CB31U and SCSI devices on Windows 98: 1. Check the restrictions before you install the CB31U. 2. Install the CB31U into the PC. Refer to Chapter 2-2-1.
  • Page 13 Device status, you can use the CB31U. 2. Grasp the CB31U by the edges with the label facing upward. Insert the CB31U into the slot and push it in until it is firmly seated. If the CB31U can not be firmly seated, check to see if the PC Card slot supports CardBus PC Cards.
  • Page 14 2. Setup 3. When the Add New Hardware Wizard Window Appears a. When the Add New Hardware Wizard window appears, insert the floppy disk or the CD-ROM included in this package and click Next. b. When the following window appears, select Search for the best driver for your device (Recommended) and click Next.
  • Page 15 2. Setup c. When the following window appears, check Floppy disk drives or CD-ROM drive and click Next. d. When the following window appears, select The updated driver (Recommended) SCSI CardBus PC Card REX CB31 and click Next. If AdvanSys PCI SCSI Host Adapter appears instead of SCSI CardBus PC Card REX CB31 under The updated driver (Recommended), see When you select One of the other drivers.
  • Page 16 When the following window appears, click Next. f. When the following window appears, click Finish. g. Wait until the PC Card (PCMCIA) icon appears on the Windows taskbar. This icon indicates that the CB31U is recognized. h. Remove the floppy disk from the PC.
  • Page 17 2. Setup When you select one of the other drivers. If AdvanSys PCI SCSI Host Adapter appears instead of SCSI CardBus PC Card REX CB31 under The updated driver (Recommended) at step d. in 3., you have to select one of the other drivers. 1.
  • Page 18 2. Setup 3. SCSI CardBus PC Card REX CB31 will appear. Click Next. 4. You will see the following window. Click Next. 5. You will see the following window. Click Finish.
  • Page 19 2. Setup 2-2-2. Confirming the Installation 1. Click My Computer with the right button. 2. Select Properties. You will see the System Properties window below. 3. Click the Device Manager tab. 4. Double-click SCSI Controllers in the list. 5. Make sure there is a SCSI CardBus PC Card REX CB31 string without “!” or “X” marks. 6.
  • Page 20 4. When the window saying You may safely remove this device appears, you can remove the CB31U from the PC. 5. Press an eject button of the PC Card slot (1). Grasp the CB31U by the edge and pull it straight out of the PC Card slot (2).

  • Page 21: Windows Me Setup

    2-3. Windows Me Setup Here’s how to get started with the CB31U and SCSI devices on Windows Me: 1. Check the restrictions before you install the CB31U. 2. Install the CB31U into the PC. Refer to Chapter 2-3-1. 3. Confirm the installation. Refer to Chapter 2-3-2.
  • Page 22 Device status, you can use the CB31U. 2. Grasp the CB31U by the edges with the label facing upward. Insert the CB31U into the slot and push it in until it is firmly seated. If the CB31U can not be firmly seated, check to see if the PC Card slot supports CardBus PC Cards.
  • Page 23 Automatic search for a better driver(Recommended). Click Next. b. When the following window appears, click Finish. c. Wait until the PC Card (PCMCIA) icon appears on the Windows taskbar. This icon indicates that the CB31U is recognized. d. Remove the floppy disk from the PC.
  • Page 24 2. Setup 2-3-2. Confirming the Installation 1. Click My Computer with the right button. 2. Select Properties. You will see the System Properties window below. 3. Click the Device Manager tab. 4. Double-click SCSI Controllers in the list. 5. Make sure there is a SCSI CardBus PC Card REX CB31 string without “!” or “X” marks. 6.
  • Page 25 4. When the window saying You may safely remove this device appears, you can remove the CB31U from the PC. 5. Press an eject button of the PC Card slot (1). Grasp the CB31U by the edge and pull it straight out of the PC Card slot (2).

  • Page 26: Windows 2000 Setup

    2. Setup 2-4. Windows 2000 Setup Here’s how to get started with the CB31U and SCSI devices on Windows 2000: 1. Check the restrictions before you install the CB31U. 2. Install the CB31U into the PC. Refer to Chapter 2-4-1.
  • Page 27 d. Click the Device Manager button. e. Double-click on the PCMCIA adapters string and make sure there is a CardBus controller name string without “!” or “X” marks. If you find a Intel PCIC compatible PCMCIA controller string under the PCMCIA adapter, your PC Card slot may not be able to use CardBus PC Card or CardBus setting may be set disable in the BIOS of your PC.
  • Page 28 2.Grasp the CB31U by the edges with the label facing upward. Insert the CB31U into the slot and push it in until it is firmly seated. If the CB31U can not be firmly seated, check to see if the PC Card slot supports CardBus PC Cards.
  • Page 29 4. You will see the screen below.Click Yes to restart. 5. Click My Computer with right but- ton and select Properties.You will see the screen below. Click the HardWare tab. And click on the Device Manager button. 6. Double-click on the SCSI and RAID controllers and find a Advansys SCSI Host Adapter string. Double-click the Advansys SCSI Host Adapter string.
  • Page 30 2. Setup 7. You wll see the screen below. You will find This device is working properly under the Device status. If Device status is error,click the Troubleshooting button. 8. Click Driver tab.You will see the screen below.Click the Update Driver button.
  • Page 31 9.You will see the screen below.Click Next. 10.You will see the screen be- low. Check “Search for a suitable driver for my device(Recommended) ” and click Next. 11.You will see the screen be- low. Insert the floppy disk or the CD-ROM included in this package.
  • Page 32 2. Setup 12.You will see the screen below.Click Next. 13.You will see the screen below. Ignore this message and just click Yes .
  • Page 33 2. Setup 14.You will see the screen below. Remove the floppy disk and click Finish. 15.Click the Driver tab on the SCSI PC Card REX CB31 WIN2000 Properties window. You can find a SCSI PC Card REX CB31 WIN2000 string. After that, click OK.
  • Page 34 16. If you find a SCSI PC Card REX CB31 WIN2000 string under the SCSI and RAID controllers in the Device Manager, the CB31U is recognized. 17. Wait until the PC Card (PCMCIA) icon appears on the Windows taskbar. This icon indicates that the CB31U is recognized.
  • Page 35 2. Setup 2-4-2. Confirming the Installation 1.Click My Computer with right button and select Properties.You will see the screen below. Click the HardWare tab. Click on the Device Manager button. 2.You will see the screen below.Double-click the SCSI PC Card REX CB31 Win2000 string.
  • Page 36 2. Setup 3. You will see the screen below.Click the General tab.Make sure Device status is “This device is working properly. ”. 4.Click Driver tab and Driver details button on the previous window shown at step 3.. You will see the screen below.
  • Page 37 4. When the window saying You may safely remove this device appears, you can remove the CB31U from the PC. 5. Press an eject button of the PC Card slot (1). Grasp the CB31U by the edge and pull it straight out of the PC Card slot (2).

  • Page 38: Windows Xp Setup

    2. Setup 2-5. Windows Xp Setup Here’s how to get started with the CB31U and SCSI devices on Windows Xp: 1. Check the restrictions before you install the CB31U. 2. Install the CB31U into the PC. Refer to Chapter 2-5-1.
  • Page 39 d. Click the Device Manager button. e. Double-click on the PCMCIA adapters string and make sure there is a CardBus con- troller name string without “!” or “X” marks. If you find a Intel PCIC compatible PCMCIA controller string under the PCMCIA adapter, your PC Card slot may not be able to use CardBus PC Card or CardBus setting may be set disable in the BIOS of your PC.
  • Page 40 2.Grasp the CB31U by the edges with the label facing upward. Insert the CB31U into the slot and push it in until it is firmly seated. If the CB31U can not be firmly seated, check to see if the PC Card slot supports CardBus PC Cards.
  • Page 41 2. Setup 4. Click My Computer with right button and select Properties. You will see the screen below. Click the HardWare tab. And click on the Device Manager button. 5. Double-click on the SCSI and RAID controllers and find a Advansys SCSI Host Adapter string. Double-click the Advansys SCSI Host Adapter string.
  • Page 42 2. Setup 6. You will see the screen below. You will find This device is working properly under the Device status. If Device status is error, click the Troubleshooting button. 7. Click Driver tab. You will see the screen below. Click the Update Driver button.
  • Page 43 8. Select Install from a list or spe- cific location and click Next. 9. Select Don’t search. I will choose the driver to install and click Next. 10. Insert the floppy disk or the CD-ROM included in this package. Click Have Disk button.
  • Page 44 2. Setup 11. Type CD-ROM drive letter. (Type A:\, if you insert floppy disk.) and click Next. 12. Click Next. 13. Click Continue Anyway on this screen.
  • Page 45 2. Setup 14. You will see the screen below. Take out the floppy disk or the CD-ROM and click Finish. 15. Click the Driver tab and make sure if SCSI PC Card REX CB31 is shown. Click OK.
  • Page 46 2. Setup 16. If you find a SCSI PC Card REX CB31 under the SCSI and RAID controllers on the Device Manager, the CB31U is recognized.
  • Page 47 2. Setup 2-5-2. Confirming the Installation 1. Click My Computer with right button and select Properties. You will see the screen below. Click the HardWare tab. Click on the Device Manager but- ton. 2. Double click SCSI PC Card REX CB31 under SCSI and RAID Controllers.
  • Page 48 2. Setup 3. Click the General tab. Make sure Device status says “This device is working properly. ”. 4. Click Driver tab and Driver details button. You can find the driver version. Click OK.
  • Page 49 CB31U from the PC. 5. Press an eject button of the PC Card slot (1). Grasp the CB31U by the edge and pull it straight out of the PC Card slot (2).

  • Page 50: Using Scsi Devices

    3. Be sure that each SCSI device has a unique SCSI ID, ranging from 0 to 6. The CB31U uses SCSI ID 7. You can usually change a SCSI ID with a switch on the back of the SCSI device. For more information, refer to the SCSI device’s manual.
  • Page 51 DB 25-pin, you can order the cable. Refer to Chapter 10. 6. Turn on all the SCSI devices connected to the CB31U. 7. Wait until ACCESS lights of the SCSI devices are turned off. 8. Turn your PC on and insert the CB31U into your PC.

  • Page 52: Confirming Scsi Device Connection

    2. Make sure the SCSI device name string appears in the Device Manager. The following Device Manager in Windows 2000 shows Iomega Zip drive is connected to the CB31U. 3. Double-click the SCSI device name string. The device properties window will appear.

  • Page 53: Scsi Format Utility

    5. You will see the window below and select the disk you want to format. And click the Select button. NOTE: The drive list shows all the disks connected to USB, SCSI port besides the CB31U. Make sure the disk you have selected is the one connected to the CB31U.
  • Page 54 4. SCSI Format Utility 6.You will see the window below. Select [Initialize/Format media] from the [Edit] menu. 7.You will see the window below. Choose format type. If you want to do Low Level Format simultaneousely, check the Low level format check box. Then click OK.
  • Page 55 If you select FAT32 in [File System], MS-DOS/Windows 3.1, Windows NT can not access to the for FAT32 media. 9. To take efect, restart your computer or take the CB31U out and into the slot. 4. SCSI Format Utility Slider bar...

  • Page 56: Installing Windows 95/98/Me

    2.This MKDISK.EXE does not work on Windows Me. You can use this tool with Windows95, Windows 98 only. To access to a SCSI CD-ROM connected to the CB31U with the startup floppy disk, follow these steps: 1.Insert a floppy disk.
  • Page 57 9.After that, hit any key to make the startup floppy disk. 10.Shut down your PC and insert the CB31U connected to a SCSI CD-ROM into the PC Card slot. 11.Turn on the SCSI CD-ROM and insert the startup floppy disk you have just made.

  • Page 58: Making A Windows 95 Startup Floppy Disk

    MKDISK.EXE does not work. With the startup floppy disk, you can access to the SCSI CD-ROM drive connected to the CB31U and install Windows 95 from the SCSI CD-ROM drive connected to the CB31U. Follow the steps through to make a Windows 95 startup floppy disk 1.Edit Config.sys file in a Windows 95 startup floppy disk...

  • Page 59: Making A Windows 98 Startup Floppy Disk

    MKDISK.EXE does not work. With the startup floppy disk, you can access to the SCSI CD-ROM drive connected to the CB31U and install Windows 98 from the SCSI CD-ROM drive connected to the CB31U. Follow the steps through to make a Windows 98 startup floppy disk 1.Edit Config.sys file in a Windows 98 startup floppy disk...
  • Page 60 [IO] Set IO port address used by the CB31U. If you don’t set anything to this parameter, 1300h is set as IO port address. If this doesn’t work, you have to set IO port address from among IO port address which any devices don’t use.
  • Page 61 Pause. When you set this /P parameter, pause the screen and you can check the result of the execution. [/V] View. When you set this /V parameter, the CB31U displays information including IO port address, IRQ,and the SCSI device connected to the CB31U as shown below.
  • Page 62 [/ScanID:id + id + …… ] If you don’t set anything to this parameter, REXCD.SYS search SCSI ID from 0 to 6 to find the SCSI CD-ROM connected to the CB31U. But, if you set this parameter like /ScanID:0+1,REXCD.SYS skip searching SCSI ID from 2 to 6.
  • Page 63 [/ScanID:id + id + …… ] If you don’t set anything to this parameter, REXDISK.SYS searchs SCSI ID from 0 to 6 to find the Hard Drive/MO connnected to the CB31U. But, if you set this parameter like /ScanID:0+1, REXDISK.SYS skips searching SCSI ID from 2 to 6.

  • Page 64: Installing Windows 2000

    6. How to install Windows 2000 6. Installing Windows 2000 This chapter explains how to install Windows 2000 from a SCSI CD-ROM connected to the CB31U. If you upgrade Windows 98, Windows NT to Windows 2000 , refer to Chapter 6-1.

  • Page 65: Install A New Copy Of Windows 2000

    Follow these steps through: 1.Format the HDD where you want to install Windows2000 first. 2.Start setup program of Windows2000 from the SCSI CD-ROM connected to the CB31U. 3.When setup starts,you can see two ways to install Windows2000 on the screen:...

  • Page 66: Linux

    7-1. How to install the driver for Linux This chapter explains how to install the CB31U driver for Linux. To install the driver, development module is required for your Linux. If you do not know how to set up development module, ask the distributor of your Linux.
  • Page 67 3.Make driver module (1)Copy the driver source file (cb31_cb.c) Copy the driver source file named cb31_cb.c to the directory which includes PCMCIA Client Driver source.(The directory normally means pcmcia clients directory) If there is the extracted driver source file named cb31_cb.c in the directory /root/cb31, type the command as written below.
  • Page 68 You have now completed the installation. 5.Confirm the installation When you insert the CB31U while pcmcia module is running, you will hear a recognition sound and see the following message. scsi0: AdvanSys SCSI 3.2M : PCI Ultra 16 CDB: IO E400/F, IRQ10...

  • Page 69: Scsi Configuration Utility For Linux:asccong

    7-2. SCSI Configuration Utility for Linux:ascconf This section explains the instructions to set up the CB31U SCSI Configuration Utility on RedHat 6.1. Log in as root before setting up the CB31U SCSI Configuration Utility. * Instructions for making CB31U SCSI Configuration Utility(ascconf).
  • Page 70 7. Linux * Restriction To execute ascconf To execute ascconf, the driver modules of the CB31U need to be loaded. If the modules are not loaded , error message shows up like below. Not found host adapter Sometimes, you might see following messages.
  • Page 71 --disc5=off : disable Disconnect only with SCSI-ID 5 --sync_all=<20 | 10 | 5 | async> To set Transfer rate for all SCSI ID (for example) --sync_all=10 : 10MB/sec for all SCSI-ID --sync_all=async : Async. transfer for all SCSI-ID --sync<n>=<20 | 10 | 5 | async> To set Transfer rate for spesific SCSI ID (for example) --sync3=10 : 10MB/sec only for SCSI-ID 3...

  • Page 72: Troubleshooting

    If you use Windows Xp, refer to Chapter 8-1-3. 8-1-1. Deleting the CB31U driver on Windows 95/98/Me If you failed to install the CB31U driver and want to re-install it from the start, delete it first. Follow the steps through to delete the CB31U driver completely.
  • Page 73 Delete key. The example indicates that VEN_10CD&DEV_1300 is selected. e. If no SCSI Card Bus PC Card REX-CB31 is listed under DeviceDesc line, finish the registry editor. 4. You have now deleted the CB31U driver completely. You can now re-install the CB31U. 8. Troubleshooting...
  • Page 74 Type the drive letter in which Windows 2000 is installed in Look in box. k. Click the Search Now button. l. When appearing, open these files to see the content. If the file is related to the CB31U, select it and press the Delete key.
  • Page 75 If SYSTEM32\DRIVERS\REXCB3x.SYS appears at ImagePath line, select the key and press the Delete key. e. If no SYSTEM32\DRIVERS\REXCB3x.SYS is listed under ImagePath line, finish the registry editor. 4. You have now deleted the CB31U driver completely. You can now re-install the CB31U. 8. Troubleshooting...
  • Page 76 Type the drive letter in which Windows Xp is installed in Look in box. k. Click the Search Now button. l. When appearing, open these files to see the content. If the file is related to the CB31U, select it and press the Delete key.
  • Page 77 If SYSTEM32\DRIVERS\REXCB3x.SYS appears at ImagePath line, select the key and press the Delete key. e. If no SYSTEM32\DRIVERS\REXCB3x.SYS is listed under ImagePath line, finish the registry editor. 4. You have now deleted the CB31U driver completely. You can now re-install the CB31U. 8. Troubleshooting...
  • Page 78 8. Troubleshooting 8-2. Updating the CB31U driver for Windows95/98/Me 1. Download the updated driver from the RATOC web site.(http://www.ratocsystems.com/english/) 2. Make an updated support software floppy disk. a. Download CB31U_xx.exe (tentative name) into an empty folder on the Hard disk drive.
  • Page 79 e. Click on the Properties button, then select the Driver tab. Check the date before updating the driver. g. Click on the Update Driver... button. If your Windows is Windows 95, follow 4. To update the driver for Windows 95 procedure. If your Windows is Windows 98, follow 4.
  • Page 80 8. Troubleshooting 4. To update the driver for Windows 95. a. When the Update Device Driver Wizard window appears, insert the floppy disk made in the step 2. Make an updated support software floppy disk into the PC and select Yes. Then click Next. b.
  • Page 81 8. Troubleshooting c. If a message requesting insertion of a floppy disk appears, click OK. d. When Copying Files... appears, you will see a message prompting you to insert the disk that is already in the floppy drive. Type a:\ for the source of files and click OK. e.
  • Page 82 8. Troubleshooting 4. To update the driver for Windows 98. a. When the Update Device Driver Wizard window appears, click Next. b. When the following window appears, select Search for a better driver than the one your device is using now.(Recommeded) and click Next.
  • Page 83 c. When the following window appears, check Floppy disk drives and insert the floppy disk made in the step 2. Make an updated support software floppy disk into the PC and click Next. d. When the following window appears, check The updated driver (Recommended) SCSI CardBus PC Card REX CB31 and click Next.
  • Page 84 8. Troubleshooting e. When the following window appears, click Next. f. When the following window appears, click Finish. You have finished updating the driver. g. Remove the support floppy disk from the PC.
  • Page 85 4. To update the driver for Windows Me. a. When the Update Device Driver Wizard window appears, select Specify the location of the driver (Advanced) and click Next. b. When the following window appears, select Search for a better driver than the one your device is using now.(Recommended) and check Specify a location.
  • Page 86 8. Troubleshooting c. When the following window appears, select The updated driver(Recommeded) and click Next. d. When the following window appears, click Next.
  • Page 87 8. Troubleshooting e. When the following window appears, click Finish. You have finished updating the driver. f. Remove the support floppy disk from the PC.
  • Page 88 Make sure the date is later than the date you checked in the step 3-f before. c. Click the Driver File Details... button. d. Check the File version of the CB31U driver. You may need to know this version when you want to have a tech-support.
  • Page 89 8-3. If your laptop is made by TOSHIBA I can use 16-bit PC Card with my laptop made by TOSHIBA, but I can not get a CardBus PC Card up and running. 1. Shut down your laptop. 2. Start your computer. 3.
  • Page 90 8. Troubleshooting 8-4-1. SCSI Configuration Utility for Windows 95/98/Me The CD-ROM which comes with the CB31U includes a SCSI configuration utility. This may be required for SCSI devices to change configuration. Before starting this utility, close all other programs running.
  • Page 91 Default is Enable. If you connect the device which does not have parity check function, check Disable. [Host SCSI ID] SCSI ID No. for the CB31U. Default is 7. If you connect the device which can be not assigned other than 7, change the ID. [Disconnect] Default is ON (checked) at all IDs.
  • Page 92 8. Troubleshooting 8-4-2. SCSI Configuration Utility for Windows 2000/Xp The CD-ROM which comes with the CB31U includes a SCSI configuration utility. This may be required for SCSI devices to change configuration. Before starting this utility, close all other programs running.
  • Page 93 Default is Enable. If you connect the device which does not have parity check function, check the Disable button. [Host SCSI ID] SCSI ID No. for the CB31U. Default is 7. If you connect the device which can be not assigned other than 7, change the ID. [Disconnect] Default is ON (checked) at all IDs.

  • Page 94: Pcmcia Card Services Appears

    Hardware wizard will appear. Install the CB31U driver, refering to Chapter 2. 8-7. The CB31U is registered as PCI SCSI BUS Controller The CB31U is registered as PCI SCSI BUS Controller in Other devices in Device Manager window. I have not installed the CB31U driver yet.

  • Page 95: Unknown Device Window Appears

    8-9. Unknown Device Window appears When I connect a SCSI Scanner to the CB31U and start PC, the Add New Hardware Wizard saying [This wizard searches for new drives for Unknown Device] appears and I do not know what to do.
  • Page 96 2. If you can not resolve this issue at the Step 1., change USB resources. a. Start the PC without the CB31U when you can shut down the PC if you remove the CB31U. b. When you can not shut down the PC even if you remove the CB31U, start Safe Mode.
  • Page 97 8. Troubleshooting 6. Select the Resources tab and remove the check mark at the Use automatic settings.And double- click Input/Output Range. 7. Set Value number larger than 1600 by clicking up/down button. 8. Make sure Conflicting device list shows No conflict. 9.
  • Page 98 You need to install ASPI manager for Windows 2000/Xp. To install it, log in as an administrator or same level user. 1. Insert the CD-ROM which comes with the CB31U to PC. 2. Open My Computer and double-click the CD-ROM icon.
  • Page 99 1. If your computer is in a network and all the driver letters are full, the drive icon does not appear in My Computer. To resolve this issue, remove the Network card and install the CB31U driver. 2. If all the drive letters are not full, your CD-ROM drive may be D drive and the drive letter is fixed. In this case, the drive icon does not appear in My Computer.

  • Page 100: Registration And Tech-Support

    You can download the latest version from our web site. (http://www.ratocsystems.com/english/) -Technical Support- You can get a Tech support from RATOC at the following Open 9:30AM-5:00PM(PST) Mon-Fri(except holidays) RATOC Systems, International Tech support 2000 Wyatt drive Suite 9 Santa Clara, CA 95054 Phone: 408-986-9040 FAX: 408-986-9042 E-mail : http://www.ratocsystems.com/english/contact/support.html...

  • Page 101: Options

    -Centronics 50P SCSI-I cable (2 feet) -DB 25P SCSI-I cable (2 feet) -HD 50P female to Centronics 50P male adapter If you have any questions about these options, contact to: RATOC Systems Insternational, TEL : (408)986-9040 FAX: (408)986-9042 E-mail: http://www.ratocsystems.com/english/contact/sales.html...

  • Page 102: Specifications

    11. Specifications 11. Specifications Specifications of the CB31U SCSI Interface •Ultra SCSI (FAST-20) •Single ended SCSI PC Card •PC Card Standard Compliant CardBus (Type II) Data Transfer Rate •Up to 20MB/sec with Ultra SCSI devices (synchronous) •Up to 10MB/sec with SCSI-II devices (synchronous) •Up to 132MB/sec between host and CB31...
  • Page 103 SCSI Cable Connector Pin Assignment The following figure indicates the pin assignment of the CB31U SCSI cable(PC Card side). The connector uses a Hirose NX30TA-25PAA or compatible connector. Do not use any other SCSI cables than the supplied one. SIGNAL...
  • Page 104 Appendix Trademarks -Windows and MS-DOS are registered trademarks of Microsoft Corporation. -AdvanSys is a registered trademark of ConnectCom Solutions, Inc. -BIOS and miniport driver are copyrighted by ConnectCom Solutions, Inc. -Other brand and product names may be registered trademarks or trademarks of their respective holders. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
