Video Control Bar - Ratoc Systems CBFW3 User Manual

4-2-3.Video Control Bar :

You can control a DVCAM from this control bar. The DVCAM have a switch which selects video
mode or camera mode. If you set this switch to camera mode or a DV tape is not inserted, this
control bar will be disabled automatically. Set this switch to video mode to control the DVCAM.
The functions are below:
...Rewind
...Previous frame
...Play
...Next frame
...Pause
...Stop
...Fast forward
...Record
...Pause recording
34
When you click the Capture Now button, you can start to capture
DV data from a DVCAM. The [Capture Now] will change to
[Capture Stop].
When you click the DV Export button, you can export DV data to
a DVCAM.You can see the DV data on the screen of the DVCAM.
1.If you don't want to record DV data onto your DV tape,
don't check "Record on the tape".
2.If you really want to record DV data onto your DV tape,
check "Record on the tape".
,
