Ratoc Systems CBS52U User Manual

Ratoc pc card adapter cbs52u user's manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PC Card Adapter
CBS52U
User's Manual
Dec. 2002
Rev.1.0

Advertisement

Table of Contents
loading

Related Manuals for Ratoc Systems CBS52U

Summary of Contents for Ratoc Systems CBS52U

  • Page 1 PC Card Adapter CBS52U User’s Manual Dec. 2002 Rev.1.0...

  • Page 2: Table Of Contents

    (4)Driver Confirmation ...10 (4-1)Driver Confirmation for Windows Me/98SE ...10 (4-2)Driver Confirmation for Windows 2000 ... 11 3. Troubleshooting... 13 4. Registration and Tech-support ... 15 4-1. How to Register ...15 4-2. Software Update and Support ...15 Appendix ... 16 CBS52U...

  • Page 4: Introduction

    Check the package contents: -REX-CBS52 PCI Board -CD-ROM -User’s manual NOTE If any of these items are missing from the CBS52U retail package, contact your supplier immediately. 1-2. System Requirements -PC with an availabe PCI slot -Windows XP/Windows Me/Windows 2000/Windows 98SE 1-3.

  • Page 5: Installation

    2. Installation This chapter describes how to install the CBS52. If you have Windows XP, proceed to 2-1. If you have Windows Me,2000,98SE proceed to 2-3. 2-1. Installing on Windows XP If you install the CBS52 on Windows XP, you don’t need the bundled CD-ROM.

  • Page 6: Confirmation Of The Driver Installation

    2-2. Confirmation of the driver installation Right-click on [My Computer] and select [Properties]. Click the [Hardware] tab and click the [Device Manager] button. Check there are two [Ricoh R/RL/5C476(II) or Compatible CardBus Controller] strings under the [PCMCIA adapters]. Double-click a [Ricoh R/RL/5C476(II) or Compatible CardBus Controller] string.

  • Page 7: Installing On Windows Me/2000/98Se

    2-3. Installing on Windows Me/2000/98SE If you use a 16bit PC Card on Windows Me/2000/98SE, you need to install the driver from the bundled CD-ROM before installing the CBS52 into a PCI slot.If you don’t use a 16bit PC Card, you don’t need to install the driver from the bundled CD-ROM.

  • Page 8: Running [Setup.exe] At The Cd-Rom

    (1)Running [Setup.exe] at the CD-ROM Run [Setup.exe] at the CD-ROM before you install the CBS52. Close other programs running on your PC. Run [Setup.exe]. The installation program will start. Click [Next]. If you agree on the License Agreement, click [Yes]. Confirm the destination of the program, and click [Next].

  • Page 9: Installing The Cbs52 Into An Available Pci Slot

    (2)Installing the CBS52 into an available PCI slot Turn off the PC and install the CBS52 into an available PCI slot. After installing it, turn on the PC. 1. Intall the CBS52 straight into an available PCI slot. 2. Install the CBS52 into the PCI slot until the board seats firmly. 3.

  • Page 10: Windows Me

    (3-1)Windows Me If you start your PC after installing the CBS52, you are requested to restart your PC, as shown.Click [Yes] to restart your PC. Proceed to (4-1)Driver confirmation for Windows Me/98SE. (3-2)Windows 2000 If you start your PC after installing the CBS52, you are requested to restart your PC, as shown.

  • Page 11: Driver Confirmation

    Click [Finish] and restart your PC. Proceed to (4-1)Driver confirmation for Windows Me/98SE. (4)Driver Confirmation (4-1)Driver Confirmation for Windows Me/98SE Right-click on [My Computer] and click the [Device Manage] tab. Check there are two [Ricoh RL5C476 CardBus Controller] strings under the [PCMCIA socket]. Double-click a [Ricoh RL5C476 CardBus Controller] string.

  • Page 12: Driver Confirmation For Windows 2000

    Run [GetDrvVer.exe] at the [GetDrvVer] folder in the CD-ROM. You can know the version of the installed programs. You have now finished the installation. (4-2)Driver Confirmation for Windows 2000 Right-click on [My Computer] and select [Properties]. Click the [Hardware] tab and click the [Device Manager] button.Check there are two [Ricoh R/RL/5C476(II) or Compatible CardBus Controller] strings under the [PCMCIA adapters].
  • Page 13 Run [GetDrvVer.exe] at the [GetDrvVer] folder in the CD-ROM. You can know the version of the installed programs. You have now finished the installation.

  • Page 14: Troubleshooting

    3. Troubleshooting (1) How to uninstall the programs(Windows Me/2000/98SE users only) If you want to delete the programs installed from the bundled CD-ROM, follow the step: Double-click [My Computer]->[Control Panel]->[Add/Remove Programs] and select [Winroute]. Then, delete it. (Windows Me/98SE) (Windows 2000) Click [Yes].
  • Page 15 Click [OK]. Click [OK]. Restart your PC. You have now completed deleting the programs. (2)How to update the programs(Windows Me/2000/98SE users only) If you have a latest program availabe through our web site, follow the steps to update the programs. A )Delete the programs fisrt, as described in step (1) B) Run a latest programs and follow on-screen instructions.

  • Page 16: Registration And Tech-Support

    (http://www.ratocsystems.com/english/) -Technical Support- You can get a Tech support from RATOC at the following. (Open Monday - Friday, 9:30A.M. to 5:00P.M(PST)) RATOC Systems International,Inc. Tech support Address: 1933 O’Toole Avenue Suite A109 SanJose, CA 95131, U.S.A. Phone : (408)955-9400 : (408)955-9402 E-mail : int-support@rexpccard.co.jp...

  • Page 17: Appendix

    Appendix Copyright ©2002 RATOC Systems,Inc. All rights reserved. No part of this publication may be reproduced, store in a retrieval system, or transmitted in any form or by any means(electronic, mechanical, photocopying, recording or otherwise) without the prior written consent of RATOC Systems,Inc.
