GLX390 Hood
Instructions Manual
www.rangemaster.co.uk

Advertisement

loading

Related Manuals for Rangemaster GLX390

Summary of Contents for Rangemaster GLX390

  • Page 1 GLX390 Hood Instructions Manual www.rangemaster.co.uk...

  • Page 2: Table Of Contents

    Instructions Manual INDEX RECOMMENDATIONS AND SUGGESTIONS ...3 CHARACTERISTICS...4 INSTALLATION ...6 USE...9 MAINTENANCE...10...

  • Page 3: Recommendations And Suggestions

    RECOMMENDATIONS AND SUGGESTIONS The Instructions for Use apply to several versions of this appliance. Accord- ingly, you may find descriptions of individual features that do not apply to your specific appliance. INSTALLATION • The manufacturer will not be held liable for any damages resulting from incor- rect or improper installation.

  • Page 4: Characteristics

    CHARACTERISTICS Dimensions...
  • Page 5 Components Ref. Q.ty Product Components Hood Body, complete with: Controls, Light, Blower, Filters Upper Section Lower Section Directional Air Outlet grille Flange Adapting ring ø 120-125 mm 14.1 Air Outlet Connection Extension Air Outlet Connection Filter cover Ref. Q.ty Installation Components 7.2.1 Upper Chimney Section Fixing Brackets Air Outlet Connection Support...

  • Page 6: Installation

    INSTALLATION Wall drilling and bracket fixing On the wall, draw • a Vertical line up to the ceiling or upper limit, at the centre of the area in which the Hood is to be fitted; • a Horizontal line at a minimum of (710 mm + A) above the Cooker Top. •...
  • Page 7 Mounting the hood body • Open the ducting panels. • Disconnect the panel from the hood canopy by slid- ing the fixing pin lever.(A) • Remove the metal grease filters by turning the han- dles provided. • Adjust the two screws Vr, on brackets 11a, to a mini- mum.(B) •...
  • Page 8 RECIRCULATION VERSION AIR OUTLET • Insert the connection extension pieces laterally 14.1 in connec- tion 15. • Insert the Connector 15 into the Support bracket 7.3 and fix it with a screw. • Make sure that the outlet of the extension pieces 14.1 is hori- zontally and vertically aligned with the chimney outlets.

  • Page 9: Use

    The hood can be switched on pushing directly onto the requested speed without firstly having to select 0/1 button. 0/1 Light 0/1 Motor on Flashing Speed Flashing Speed Speed Fixed Flashing Fixed Flashing Control Panel FUNCTIONS Turns lighting on and off. First speed.

  • Page 10: Maintenance

    MAINTENANCE REMOTE CONTROL (OPTIONAL) The appliance can be controlled using a remote control powered by a 1.5 V carbon-zinc alkaline batteries of the standard LR03- AAA type. • Do not place the remote control near to heat sources. • Used batteries must be disposed of in the proper manner. Ducting panels •...
  • Page 11 Grease filters CLEANING METAL SELF- SUPPORTING GREASE FILTERS Alarm signal reset • Switch off the lights and extractor motor. • Press button T3 for at least 3 seconds, until the leds start to flash. Cleaning the filters • The filters are washable and must be cleaned when the LED S1 lights up or at least every 2 months of operation, or more fre- quently for particularly heavy usage.
  • Page 12 Activated charcoal filter (Recirculation version) The filter is not washable and cannot be regenerated. It must be replaced when led S1 flashes or at least every 4 months. The alarm signal will only light up when the extractor motor is switched on.
  • Page 16 AGA RANGEMASTER LTD. 436004184_ver1...
