Vega VEGAPULS SR 68 Quick Setup Manual

Radar sensor for continuous level measurement of bulk solids. modbus and levelmaster protocol
Hide thumbs Also See for VEGAPULS SR 68:

Advertisement

Quick Links

Quick setup guide
Radar sensor for continuous level
measurement of bulk solids
VEGAPULS SR 68
Modbus and Levelmaster protocol
Document ID: 47164

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VEGAPULS SR 68 and is the answer not in the manual?

Questions and answers

Summary of Contents for Vega VEGAPULS SR 68

  • Page 1 Quick setup guide Radar sensor for continuous level measurement of bulk solids VEGAPULS SR 68 Modbus and Levelmaster protocol Document ID: 47164...
  • Page 2: Table Of Contents

    Operating Instructions Manual as well as the Safety Manual that comes with instruments with SIL qualification. These manuals are available in the download area of "www.vega.com". Operating instructions VEGAPULS SR 68 - Modbus and Level- master protocol: Document-ID 41371 Editing status of the quick setup guide: 2018-02-16 VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 3: For Your Safety

    During work on and with the device the required personal protective equipment must always be worn. Appropriate use VEGAPULS SR 68 is a sensor for continuous level measurement. You can find detailed information about the area of application in chapter "Product description". Operational reliability is ensured only if the instrument is properly used according to the specifications in the operating instructions manual as well as possible supplementary instructions.
  • Page 4: Eu Conformity

    EN 302372 - Tank Level Probing Radar It is hence approved for use inside closed vessels in countries of the Use is also approved in EFTA countries, provided the respective standards have been implemented. For operation inside of closed vessels, points a to f in annex E of EN 302372 must be fulfilled. Radio license for USA This approval is only valid for USA. Hence the following text is only available in the English language. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 5: Environmental Instructions

    That is why we have introduced an environment management system with the goal of continuously improving company environmental pro- tection. The environment management system is certified according to DIN EN ISO 14001. Please help us fulfil this obligation by observing the environmental instructions in this manual: • Chapter "Packaging, transport and storage" • Chapter "Disposal" VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 6: Product Description

    • Test certificate (PDF) - optional Go to "www.vega.com", "Instrument search (serial number)". Enter the serial number. Alternatively, you can access the data via your smartphone: • Download the VEGA Tools app from the "Apple App Store" or the "Google Play Store" • Scan the Data Matrix code on the type label of the instrument or • Enter the serial number manually in the app...
  • Page 7 2 Product description Scope of this operating This operating instructions manual applies to the following instrument instructions manual versions: • Hardware from 2.1.0 • Software from 4.5.1 VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 8: Mounting

    10. Fasten counter nut (3) with a wrench (width across flats 36), max. torque see chapter "Technical data" Note: On the version with rinsing air connection, make sure that the holes in the antenna and in the process fitting coincide. This ensures a suf- ficient air flow (the air is led through the holes to the feed system. A rinsing of the whole parabolic antenna is not intended). Fig. 2: Dismounting, parabolic antenna Connection piece Compression nut Counter nut Parabolic antenna VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 9: Mounting Preparations

    A secure hold of the antenna is only ensured with the untwist guard. The untwist guards inserted on site must hence be used again. Depending on temperature range and antenna material, these are spring rings according to DIN 217 or wedge lock washers according to DIN 25 201. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 10: Mounting Instructions

    Fig. 4: Dismounting, parabolic antenna Connection piece Compression nut Counter nut Parabolic antenna Mounting instructions Mounting 1. Distance from the vessel wall > 200 mm, the antenna should protrude > 10 mm into the vessel VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 11 Fig. 5: Distance of the antenna to the vessel wall/vessel ceiling 2. Note min. socket diameter depending on the socket length 3. Note the instructions for sealing For further information see chapter "Mounting". VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 12: Connecting To Power Supply And Bus System

    4. Insert the cable into the sensor through the cable entry Fig. 6: Connection steps 5 and 6 5. Insert the wire ends into the terminals according to the wiring plan Information: Solid cores as well as flexible cores with wire end sleeves are insert- ed directly into the terminal openings. In case of flexible cores without end sleeves, press the terminal from above with a small screwdriver, the terminal opening is then free. When the screwdriver is released, the terminal closes again. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 13: Wiring Plan

    (sensor electronics) Terminal compartment Electronics compartment Electronics compartment 4...20mA Fig. 8: Electronics compartment - double chamber housing Internal connection to the terminal compartment For display and adjustment module or interface adapter VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 14 USB interface 2 Slide switch for integrated termination resistor (120 Ω) Modbus signal Voltage supply Terminal Function Polarity Voltage supply Voltage supply Modbus signal D0 Modbus signal D1 Function ground when installing ac- cording to CSA (Canadian Standards Association) VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 15: Set Up The Sensor With The Display And Adjustment Module

    Parameter adjustment Set parameters 1. Go to the menu "Setup" via the display and adjustment module. 2. Select in the menu item "Medium" the medium of your applica- tion, for example "Powder/Dust". VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 16 For indication of the real level, an allocation of the measured distance to the percentage height must be carried out. 100% Fig. 11: Parameterization example Min. level ≙ max. meas. distance Max. level ≙ min. meas. distance For this adjustment, the distance is entered for min. and max. level. If these values are not known, an adjustment with distances, for example, of 10 % and 90 % is also possible. Starting point for these distance specifications is always the seal surface of the thread or flange. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 17 1. Select with [->] the menu item "False signal suppression" and confirm with [OK]. 2. Confirm 3-times with [OK] and enter the actual distance from the sensor to the product surface. 3. All interfering signals in this range are detected by the sensor and stored after being confirmed with [OK]. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 18: Menu Overview

    ≥ 1 bar) Temperature unit °C Position correc- 0.00 bar tion Adjustment Zero/Min. adjust- 0.00 bar ment 0.00 % Span/Max. adjust- Nominal measuring range in bar ment 100.00 % Damping Integration time 1.0 s Linearization Characteristics Linear VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 19 Simulation Pressure Additional adjustments Menu item Parameter Default setting 0000 Date/Time Actual date/Actual time Reset Copy in- strument settings Special pa- rameters Scaling Scaling size Volume in l Scaling format 0 % corresponds to 0 l 100 % corresponds to 0 l VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 20 Current output - Adjustment 0 … 100 °C correspond to 4 … 20 mA Info Menu item Parameter Device name Device name Instrument version Hardware and software version Factory calibration Date date Sensor characteristics Order-specific characteristics VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 21: Supplement

    Ʋ Stranded wire with end sleeve 0.2 … 1.5 mm² (AWG 24 … 16) Voltage supply Operating voltage 8 … 30 V DC Power consumption < 500 mW Reverse voltage protection Integrated VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 22 Notes VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 23 Notes VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 24: Information

    Subject to change without prior notice © VEGA Grieshaber KG, Schiltach/Germany 2018 VEGA Grieshaber KG Phone +49 7836 50-0 Am Hohenstein 113...
