Operating Instructions

Radar sensor for continuous level
measurement of bulk solids
VEGAPULS SR 68
Modbus and Levelmaster protocol
Document ID: 41371

Advertisement

Table of Contents
loading

Related Manuals for Vega VEGAPULS SR 68

Summary of Contents for Vega VEGAPULS SR 68

  • Page 1: Operating Instructions

    Operating Instructions Radar sensor for continuous level measurement of bulk solids VEGAPULS SR 68 Modbus and Levelmaster protocol Document ID: 41371...

  • Page 2: Table Of Contents

    Parameter adjustment ....................49 Saving the parameter adjustment data ................51 Diagnosis, asset management and service Maintenance ........................52 Measured value and event memory ................52 Asset Management function ................... 53 Rectify faults ........................57 VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 3 10.7 Dimensions ........................83 Safety instructions for Ex areas Please note the Ex-specific safety information for installation and op- eration in Ex areas. These safety instructions are part of the operating instructions manual and come with the Ex-approved instruments. Editing status: 2014-01-28 VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 4: About This Document

    This arrow indicates a single action. Sequence of actions Numbers set in front indicate successive steps in a procedure. Battery disposal This symbol indicates special information about the disposal of bat- teries and accumulators. VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 5: For Your Safety

    During work on and with the device the required personal protective equipment must always be worn. Appropriate use VEGAPULS SR 68 is a sensor for continuous level measurement. You can find detailed information about the area of application in chapter "Product description". Operational reliability is ensured only if the instrument is properly used according to the specifications in the operating instructions manual as well as possible supplementary instructions.

  • Page 6: Ce Conformity

    FCC/IC. The instrument is in conformity with RSS-210 of the IC regulations. The instrument may only be used in closed vessels made of metal, concrete, or fibre-reinforced plastic. VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 7: Environmental Instructions

    That is why we have introduced an environment management system with the goal of continuously improving company environmental pro- tection. The environment management system is certified according to DIN EN ISO 14001. Please help us fulfill this obligation by observing the environmental instructions in this manual: • Chapter "Packaging, transport and storage" • Chapter "Disposal" VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 8: Product Description

    Operating instructions and quick setup guide at the time of ship- ment (PDF) • Order-specific sensor data for an electronics exchange (XML) • Test certificate (PDF) - optional Go to www.vega.com, "VEGA Tools" and "Instrument search". Enter the serial number. Alternatively, you can access the data via your smartphone: VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 9: Principle Of Operation

    – Ex-specific "Safety instructions" (with Ex versions) – if necessary, further certificates Principle of operation Application area The VEGAPULS SR 68 is a radar sensor for continuous measurement of bulk solids also under difficult process conditions. It is particularly suitable for level measurement in high silos and large bunkers. The instrument is also suitable for applications in liquids.

  • Page 10: Packaging, Transport And Storage

    You can find further information in the operating instructions "Display and adjustment module PLICSCOM" (Document-ID 27835). VEGACONNECT The interface adapter VEGACONNECT enables the connection of communication-capable instruments to the USB interface of a PC. For VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 11 Modbus" (Document-ID 41864). Antenna impedance cone The antenna impedance cone is a replacement part used for optimum transmission of microwaves and for sealing against the process. You find further information in the operating instructions "Antenna impedance cone VEGAPULS 62 and 68" (Document-ID 31381). VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 12: Mounting

    The instrument is also available in versions with an antenna whose diameter is larger than the process fitting (thread, flange). In such cases the antenna must be disconnected from the process fitting before mounting. Proceed as follows: 1. Loosen the hexagon socket screws (3) on the antenna socket with an Allen wrench (size 3) 2. Remove the antenna (4) VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 13: Mounting Preparations - Parabolic Antenna

    4. Loosen compression nut (2) completely with a wrench (width across flats 41 mm) in the direction of the antenna 5. Remove the parabolic antenna (4) axially 6. Mount sensor flange on the adapter flange and fasten it tightly 7. Check if the O-ring seal is present on the connection piece and make sure it is not damaged. VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 14: Mounting Instructions

    Locknut Parabolic antenna Mounting instructions Polarisation The emitted radar impulses of the radar sensor are electromagnetic waves. The polarisation is the direction of the electrical wave compo- nent. By turning the instrument in the connection flange or mounting boss, the polarisation can be used to reduce the effects of false echoes. The position of the polarisation is marked on the process fitting of the instrument. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 15 In such a case, it is recommended to repeat the false signal storage at a later date with existing buildup. Inflowing medium Mounting should not be too close to the inflowing material as the microwave signal will be interferred. The optimum mounting position is on the opposite of the filling. To avoid strong pollution, the distance to the filter or dust extraction must be as big as possible. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 16 4 Mounting Fig. 7: Mounting of the radar sensor with inflowing medium With bulk solids silos with lateral pneumatic filling, mounting should not be in the filling stream as the microwave signal will be interferred. The optimum mounting position is next to the filling. To avoid strong pollution, the distance to the filter or dust extraction must be as big as possible. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 17 4 Mounting Fig. 8: Mounting of the radar sensor with inflowing medium Socket The socket piece should be dimensioned in such a way that the antenna end protrudes slightly out of the socket. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 18 When using a swivelling holder, keep in mind that the distance between antenna and socket gets smaller as the inclination of the sensor increases. Additional false reflections may be generated which can influence the measuring result at close range. Fig. 11: Distance between antenna and socket with horn antenna VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 19 The antenna length can be selected (either ex works or later) to allow the antenna to protrude slightly out of the end of the mounting socket. Due to the antenna extension however, disturbing reflections are generated in the close-up range. This can lead to an increase in the VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 20 If mounting in the centre of the silo is not possible, the sensor can be directed to the vessel center by using the optional swivelling holder. The following description shows a simple way to determine the required angle of inclination. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 21 In a vessel 20 m high, the installation position of the sensor is 1.4 m from the vessel centre. The necessary angle of inclination of 4° can be read out from this chart. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 22 Small, inclined sheet metal baffles above the installations scatter the radar signals and prevent direct interfering reflections. Fig. 16: Cover smooth profiles with deflectors Agitators If there are agitators in the vessel, a false signal suppression should be carried out with the agitators in motion. This ensures that the interfering reflections from the agitators are saved with the blades in different positions. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 23 Fig. 18: Radar sensors on traverse crane Information: Keep in mind that for these applications, the sensors are designed for relatively slow level changes. When using VEGAPULS SR 68 on a movable bracket, the max. measuring rate must be observed (see chapter "Technical data").
  • Page 24 This can be avoided by using a sensor with aluminium or stainless steel housing. Mounting in multiple The silo walls of multiple chamber silos are often made of profile chamber silo walls, such as e.g. profile sheeting, to ensure the required stability. If the radar sensor is mounted very close to a heavily structured vessel wall, considerable false reflections can be generated. Hence the sen- VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 25 Fig. 21: Mounting of VEGAPULS SR 68 in multiple chamber silos Fig. 22: Orientation of VEGAPULS SR 68 for emptying in the silo center Dust layers To avoid strong buildup and dust in the antenna system, the sensor should not be mounted directly at the dust extraction of the vessel. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 26 Fig. 23: Purging air connection with horn antenna Fig. 24: Purging air connection with parabolic antenna The practice has shown that a pressure of approx. 0.2 … 1 bar provides a sufficient air flow (see diagram in chapter "Technical data", "Purging air connection". VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 27: Connecting To Power Supply And Bus System

    (e.g. 1 nF, 1500 V). The low frequency potential equalisation currents are thus suppressed, but the protective effect against high frequency interference signals remains. Connection Connection technology The voltage supply and signal output are connected via the spring- loaded terminals in the housing. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 28 8. Connect the lead cable for power supply in the same way accord- ing to the wiring plan, in addition connect the ground conductor to the inner ground terminal when powered with mains voltage. VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 29: Wiring Plan, Double Chamber Housing

    Internal connection to the connection compartment For display and adjustment module or interface adapter Information: The connection of an external display and adjustment unit is not pos- sible with this double chamber housing. VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 30: Double Chamber Housing With Dis-Adapt

    Function ground with installa- tion according to CSA Double chamber housing with DIS-ADAPT Electronics compartment Fig. 29: View to the electronics compartment 1 DIS-ADAPT Internal plug connection Plug connector M12 x 1 VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 31: Switch-On Phase

    Pin 3 Blue Pin 4 Black Switch-on phase After VEGAPULS SR 68 is connected to the bus system, the instru- ment carries out a self-test for approx. 30 seconds. The following steps are carried out: • Internal check of the electronics •...

  • Page 32: Set Up The Sensor With The Display And Adjustment Module

    The display and adjustment module is powered by the sensor, an ad- ditional connection is not necessary. Fig. 31: Insertion of the display and adjustment module Note: If you intend to retrofit the instrument with a display and adjustment module for continuous measured value indication, a higher cover with an inspection glass is required. VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 33: Adjustment System

    60 minutes after the last pressing of a key, an automatic reset to measured value indication is triggered. Any values not confirmed with [OK] will not be saved. Parameter adjustment The instrument is adapted to the application conditions via the pa- rameter adjustment. The parameter adjustment is carried out with an adjustment menu. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 34 To adapt the sensor to these different measuring conditions, the selection "Liquid" or "Bulk solid" should be made in this menu item. Through this selection, the sensor is adapted perfectly to the product and measurement reliability, particularly in products with poor reflec- tive properties, is considerably increased. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 35 Installations: small laterally mounted or large top mounted stirrer • Process/measurement conditions: – Relatively smooth product surface – High requirements to the measurement accuracy – Condensation – Slight foam generation – Overfilling possible • Properties, sensor: VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 36 Process/measurement conditions: – Condensation, buildup on the antenna – Foam generation • Properties, sensor: – Measurement speed optimized by virtually no averaging – Sporadic false echoes are suppressed – False signal suppression recommended Standpipe: • Product speed: very fast filling and emptying • Vessel: VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 37 – False signals outside the vessel are not taken into consideration – False signal suppression recommended Transportable plastic tank: • Vessel: – Material and thickness different – Measurement through the vessel top • Process/measurement conditions: – Measured value jump with vessel change • Properties, sensor: VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 38 – Sensor accepts all measured value changes within the measur- ing range immediately – High sensitivity against interferences, because virtually no averaging Caution: If a separation of liquids with different dielectric constant occurs in the vessel, for example through condensation, the radar sensor can VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 39 – Large angles of repose • Properties, sensor: – Lower averaging – Very high measured value jumps are accepted Heap: • Sensor mounting on movable conveyor belts • Detection of the heap profile • Height detection during filling • Process/measurement conditions: VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 40 [OK] and jump to the next menu item with the [ESC] and the [->] key. Setup - Vessel form Also the vessel form can influence the measurement apart from the medium and the application. To adapt the sensor to these measure- VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 41 These settings can be made ahead of time without the instrument having to be installed. Setup - Min. adjustment Proceed as follows: VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 42 4. Enter the appropriate distance value in m (corresponding to the percentage value) for the full vessel. Keep in mind that the max. level must lie below the min. distance to the antenna edge. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 43 Management functions it is absolutely necessary. If possible, the curve should be saved with a low level in the vessel. With the adjustment software PACTware and the PC, the high resolu- tion echo curve can be displayed and used to recognize signal VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 44 2. Confirm again with [OK]. 3. Confirm again with [OK]. 4. Confirm again with [OK] and enter the actual distance from the sensor to the product surface. 5. All interfering signals in this section are detected by the sensor and stored after confirming with [OK]. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 45 If a linearization curve is selected, the measuring signal is no longer necessarily linear to the filling height. This must be considered by the user especially when adjusting the switching point on the limit signal transmitter. Additional adjustments With a reset, certain parameter adjustments carried out by the user - Reset are reset. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 46 "Technical data" in the supplement Max. adjustment 0,000 m(d) Damping 0.0 s Current output 4 … 20 mA, < 3.6 mA mode Current output Min. current 3.8 mA, max. current Min./Max. 20.5 mA Block adjustment Released VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 47: Saving The Parameter Adjustment Data

    If it is necessary to exchange a sensor, the display and adjustment module is inserted into the replacement instrument and the data are likewise written into the sensor via the menu item "Copy sensor data". VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 48: Setting Up Sensor And Modbus Interface With Pactware

    Sensor To the Modbus electron- The connection of the PC to the Modbus electronics is carried out via a USB cable. Scope of the parameter adjustment: • Sensor electronics • Modbus electronics VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 49: Parameter Adjustment

    FDT standard are required. The up-to-date PACTware version as well as all available DTMs are compiled in a DTM Collec- tion. The DTMs can also be integrated into other frame applications according to FDT standard. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 50 The standard version is available as a download under www.vega.com/downloads and "Software". The full version is avail- able on CD from the agency serving you. VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 51: Saving The Parameter Adjustment Data

    7 Setting up sensor and Modbus interface with PACTware Saving the parameter adjustment data We recommend documenting or saving the parameter adjustment data via PACTware. That way the data are available for multiple use or service purposes. VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 52: Diagnosis, Asset Management And Service

    Echo curve of the setup: This is used as reference echo curve for the measurement conditions during setup. Changes in the measure- ment conditions during operation or buildup on the sensor can thus be recognized. The echo curve of the setup is stored via: VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 53: Asset Management Function

    PACTware/DTM or EDD. Out of specification: The measured value is unstable because the instrument specification is exceeded (e.g. electronics temperature). This status message is inactive by default. It can be activated by the user via PACTware/DTM or EDD. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 54 Bit 6 in the start phase, the switch-on phase Determine measured value could – Duration depending measured not yet be determined on the version and value parameter adjustment up to approximately 3 min. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 55 Simulation ac- after 60 mins. tive Out of specification The following table shows the error codes and text messages in the status message "Out of specification" and provides information on causes as well as corrective measures. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 56 – Change polarisation direc- tion – Use instrument with higher sensitivity M504 – Hardware defect – Check connections – Exchanging the electronics Error on an device inter- – Send instrument for repair face VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 57: Rectify Faults

    "Hold value" • In case of a too low level indication, the reason could be a line resistance that is too high VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 58 100 % during filling signal suppression with con- densation/contamination in the close range by editing time – With bulk solids use radar sen- sor with purging air connection or flexible antenna cover VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 59: Exchanging The Electronics Module

    24 hour service hotline Should these measures not be successful, please call in urgent cases the VEGA service hotline under the phone no. +49 1805 858550. The hotline is also available outside normal working hours, seven days a week around the clock.

  • Page 60: Software Update

    • Attach the completed form and, if need be, also a safety data sheet outside on the packaging • Please contact the agency serving you to get the address for the return shipment. You can find the agency on our home page www.vega.com. VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 61: Dismounting

    Pass the instrument directly on to a spe- cialised recycling company and do not use the municipal collecting points. These may be used only for privately used products according to the WEEE directive. VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 62: Supplement

    Ʋ Aluminium/Stainless steel housing max. 50 Nm (36.88 lbf ft) Input variable Measured variable The measured quantity is the distance between process fitting of the sensor and product surface. The reference plane is the seal surface on the hexagon or the lower side of the flange. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 63 Process reference conditions according to DIN EN 61298-1 Ʋ Temperature +18 … +30 °C (+64 … +86 °F) Ʋ Relative humidity 45 … 75 % Ʋ Air pressure 860 … 1060 mbar/86 … 106 kPa (12.5 … 15.4 psig) VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 64 Time span after a sudden measuring distance change by max. 0.5 m in liquid applications, max 2 m with bulk solids applications, until the output signal has taken for the first time 90 % of the final value (IEC 61298-2). Outside the specified beam angle, the energy of the radar signal has a level which is reduced by 50 % (-3 dB) VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 65 Shock resistance Ʋ Horn antenna 100 g, 6 ms according to EN 60068-2-27 (mechanical shock) Ʋ Parabolic antenna 25 g, 6 ms according to EN 60068-2-27 (mechanical shock) EIRP: Equivalent Isotropic Radiated Power VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 66 Electromechanical data - version IP 66/IP 67 Options of the cable entry Ʋ Cable gland M20 x 1.5 (cable: ø 5 … 9 mm) Ʋ Cable entry ½ NPT Ʋ Blind plug M20 x 1.5; ½ NPT VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 67 Rate deviation max. 10.5 min/year Measurement electronics temerature Resolution 1 °C (1.8 °F) Accuracy ±1 °C (1.8 °F) Voltage supply Operating voltage 8 … 30 V DC Power consumption < 500 mW Interpolation protection Integrated VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 68: Basics Modbus

    Instruments with approvals can have different technical data depending on the version. For that reason the associated approval documents of these instruments have to be carefully noted. They are part of the delivery or can be downloaded under www.vega.com, "VEGA Tools" and "Instrument search" as well as via www.vega.com/downloads and "Approvals". 10.2 Basics Modbus Bus description The Modbus protocol is a communication protocol for the communication between instruments.
  • Page 69 Fig. 50: Bus architecture Modbus Connection resistor Bus participant Voltage supply Protocol description The VEGAPULS SR 68 is suitable for connection to the following RTUs with Modbus RTU or ASCII protocol. Protocol ABB Totalflow Modbus RTU, ASCII Bristol ControlWaveMicro Modbus RTU, ASCII...

  • Page 70: Modbus Register

    (4 bytes) according to IEEE 754 are transmitted with individually selectable order of the data bytes (byte transmission order). This "Byte transmission order" is determined in the parameter "Format Code". Hence the RTU knows the registers of the VEGAPULS SR 68 which must be contacted for the variables and status information.
  • Page 71 Secondary Variable in Byte Order DCBA (Little En- dian) 2106 DWord Third Variable in Byte Order ABCD DCBA (Little En- dian) 2108 DWord Quarternary Variable in Byte Order DCBA (Little En- dian) Status 2200 DWord See Register 100 VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 72: Modbus Rtu Commands

    Length Code/Data Function Code 1 Byte 0x03 Start Address 2 Bytes 0x0000 to 0xFFFF Number of Registers 2 Bytes 1 to 127 (0x7D) Response: Parameter Length Code/Data Function Code 1 Byte 0x03 VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 73 2 Bytes Data Response: Parameter Length Code/Data Function Code 1 Byte 0x04 Start Address 2 Bytes Register Value 2 Bytes Data FC8 Diagnostics With this function code different diagnostic functions can be triggered or diagnostic values read out. Request: Parameter Length Code/Data Function Code 1 Byte 0x08 VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 74 0x0000 to 0xFFFF Data 2 Bytes 0x01 to 0x7B FC17 Report Slave ID With this function code, the Slave ID can be queried. Request: Parameter Length Code/Data Function Code 1 Byte 0x11 VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 75: Levelmaster Commands

    List of Object value 1 Byte Depending on the Object ID 10.5 Levelmaster commands The VEGAPULS SR 68 is also suitable for connection to the following RTUs with Levelmaster proto- col. The Levelmaster protocol is often called "Siemens" "Tank protocol". Protocol ABB Totalflow...
  • Page 76 Level in inches is repeated for sensors with 2 levels. PV value is transmitted as first measured value, SV as second measured value. PV, SV, TV and QV can be adjusted via the sensor DTM. Report Unit Number Request: Parameter Length Code/Data Report Unit Number 5 characters ASCII U**N? VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 77 = 71 Response: Parameter Length Code/Data Set Baud Rate 11 characters ASCII Example: U01B9600E71 Change instrument on address 1 to baudrate 9600, parity even, 7 data bits, 1 stop bit VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 78: Error Codes

    = milliseconds (50 up to 250), default = 127 ms Error codes Error Code Name EE-Error Error While Storing Data in EEPROM FR-Error Erorr in Frame (too short, too long, wrong data) LV-Error Value out of limits VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 79: Configuration Of Typical Modbus Hosts

    The basic number of the input registers is always added to the input register address of VEGAPULS SR 68. Address 1300 must hence be entered as register address for RTU Fisher ROC 809. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 80 The basic number of the input registers is always added to the input register address of VEGAPULS SR 68. Address 1303 must hence be entered as register address for 1302 for RTU ABB Total Flow. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 81 The basic number of the input registers is always added to the input register address of VEGAPULS SR 68. Address 1300 must hence be entered as register address for 1300 for RTU Thermo Electron Auto- pilot. VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 82 The basic number of the input registers is always added to the input register address of VEGAPULS SR 68. Address 1303 must hence be entered as register address for 1302 for RTU Bristol ControlWave Micro. VEGAPULS SR 68 • Modbus and Levelmaster protocol...

  • Page 83: Dimensions

    The basic number of the input registers is always added to the input register address of VEGAPULS SR 68. Address 31303 must hence be entered as register address for 1302 for RTU ScadaPack. 10.7 Dimensions The following dimensional drawings represent only an extract of all possible versions. Detailed VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 84 10 Supplement dimensional drawings can be downloaded at www.vega.com/downloads under "Drawings". Housing ~ 87 mm ~ 84 mm (3.43") ø 84 mm (3.31") ø 79 mm (3.31") (3.11") M16x1,5 M16x1,5 M20x1,5/ M20x1,5/ ½ NPT ½ NPT Fig. 56: Dimensions housing - with integrated display and adjustment module the housing is 9 mm/0.35 in higher...
  • Page 85 10 Supplement VEGAPULS SR 68, horn antenna in threaded version SW 46 mm (1.81") G1½A / 1½ NPT 1½" ø40 2" ø48 3" ø75 4" ø95 inch 3.94" ø1.58" 1½" 4.72" ø1.89" 2" 8.50" ø2.95" 3" 16.93" ø3.74" 4" Fig. 57: VEGAPULS SR 68, horn antenna in threaded version Standard With temperature adapter up to 250 °C...
  • Page 86 10 Supplement VEGAPULS SR 68, horn antenna in flange version inch 3.94" ø1.58" 1½" ø40 1½" 4.72" ø1.89" 2" ø48 2" 8.50" ø2.95" 3" ø75 3" 16.93" ø3.74" 4" ø95 4" Fig. 58: VEGAPULS SR 68, horn antenna in flange version Standard With temperature adapter up to 250 °C VEGAPULS SR 68 • Modbus and Levelmaster protocol...
  • Page 87 10 Supplement VEGAPULS SR 68, horn antenna and swivelling holder 1½" ø 40 2" ø 48 3" ø 75 4" ø 95 inch 3.94" ø 1.58" 1½" 4.72" ø 1.89" 2" 8.50" ø 2.95" 3" 16.93" ø 3.74" 4" Fig. 59: VEGAPULS SR 68, horn antenna and swivelling holder Standard With temperature adapter up to 250 °C...
  • Page 88 10 Supplement VEGAPULS SR 68, parabolic antenna and swivelling holder Fig. 60: VEGAPULS SR 68, parabolic antenna and swivelling holder Standard With temperature adapter up to 200 °C VEGAPULS SR 68 • Modbus and Levelmaster protocol...
