OPERATIONAL MANUAL
Please read the Operational Manual before attempting to use this product.
Wide Dynamic Range Dome Camera
This is a high resolution, multi-functional and super low illuminated WDR dome camera.
It adopts the new WDR DSP and can display the foreground and background with clarity
even under high-contrast circumstances.
with OSD Multi-function
WDSDX-M56AI
WDSDX-M56AIP
1/3" Sony Vertical Double-density Interline CCD
3D DNR Function
Advertisement
Related Manuals for Okina WDSDX-M56AI
Summary of Contents for Okina WDSDX-M56AI
- Page 1 OPERATIONAL MANUAL Please read the Operational Manual before attempting to use this product. Wide Dynamic Range Dome Camera with OSD Multi-function WDSDX-M56AI WDSDX-M56AIP 1/3” Sony Vertical Double-density Interline CCD 3D DNR Function This is a high resolution, multi-functional and super low illuminated WDR dome camera.
-
Page 2: Table Of Contents
CONTENTS Features ………………………………………………….…….………….…… 2 Dimension ……………………………………………………………………… 2 WDR Function …………………………………………………….…………… 3 Installation …………………………………………………………….…..…… 4 Menu Operation ………………………………………………………….…… 5-8 Specification ………………………………………………………….……..… 9 Package Contents …….…………………………………………...………… 10 Caution ………………………………………………………………………… 10-11 Warranty ……………………………………………………………….……… 11 1. FEATURES 1/3” Sony Vertical Double-density Interline CCD 560 TV Lines – Color / 620 TV Lines – B&W 3.7mm~12.0mm Aspherical Vari-focal Auto Iris Lens / F1.4 Made by Tamron IR Cut Filter... -
Page 3: Wdr Function
3. WDR FUNCION 12V DC Power Input Video Output Port OSD Control WDR FUNCTION SETTINGS Enter the menu (EXPOSURE→ALC→WDR SETUP) WDR → SETUP LONG 0……｜……PRESS "LEFT" OR "RIGHT" FOR OPTION 0~+100 SHORT 0……｜……PRESS "LEFT" OR "RIGHT" FOR OPTION 0~+100 EXIT /END Copyright 2010. -
Page 4: Installation
LONG (Adjust to enhance brightness in dark area) SHORT (Adjust to reduce brightness in high light area) Displayed image can reach its best effect through adjusting WDR menu options according to various circumstances. 4. INSTALLATION Step 2: Pull the cable through the center Step 1: Fix the ceiling plate to the ceiling hole on the installation board. -
Page 5: Menu Operation
5. MENU OPERATION CAMERA ID PRESS "LEFT" OR "RIGHT" FOR OPTION 1~255 ID EXPOSURE PRESS "LEFT" OR "RIGHT" FOR OPTION ALC & ELC WHITE BAL PRESS "LEFT" OR "RIGHT" FOR OPTION AWC & MANUAL DAY/NIGHT AUTO PRESS "LEFT" OR "RIGHT" FOR OPTION EXT&DAY&NIGHT MOTION DET PRESS "LEFT"... - Page 6 EXPOSURE-WDR/BLC/HSBLC LONG 0……｜……PRESS "LEFT" OR "RIGHT" FOR OPTION 0~+100 SHORT 0……｜……PRESS "LEFT" OR "RIGHT" FOR OPTION 0~+100 LIMIT PRESS "LEFT" OR "RIGHT" FOR OPTION HIGH&LOW&MIDDLE HSBLC AREA SETTING GRAY SCALE GRAY PRESS "LEFT" OR "RIGHT" FOR OPTION D.GRAY&BLACK USE SCALE 0……｜……...
- Page 7 EXIT /END MOTION DET ZONE NUMER AREA1 PRESS "LEFT" OR "RIGHT" FOR OPTION AREA2/AREA3/AREA4 ZONE STATE PRESS "LEFT" OR "RIGHT" FOR OPTION ON HEIGHT 40……｜…… PRESS "LEFT" OR "RIGHT" FOR OPTION 12~100 WIDTH 40……｜…… PRESS "LEFT" OR "RIGHT" FOR OPTION 16~100 MOVE Y 50……｜……...
- Page 8 LANGUAGE PRESS "LEFT" OR "RIGHT" FOR OPTION ENG/中文 EXIT /END SPECIAL → DIGITAL ZOOM ZOOM x1.1……｜…… PRESS "LEFT" OR "RIGHT" FOR OPTION x1.1~x8.0 0……｜…… PRESS "LEFT" OR "RIGHT" FOR OPTION -100~+100 TILT 0……｜…… PRESS "LEFT" OR "RIGHT" FOR OPTION -100~+100 EXIT /END SPECIAL →...
-
Page 9: Specification
6. SPECIFICATION Model WDSDX-M56AI WDSDX-M56AIP Sensor 1/3” Sony Vertical Double-density Interline CCD Resolution 560 TV Lines – Color / 620 TV Lines – B&W, signal enhancement Line Scan Frequency 15.734 kHz 15.625 kHz Filed Scan 59.95 Hz 50 Hz Frequency... -
Page 10: Package Contents
5.43”(D) x 3.94”(H) / 138mm(D) x 100mm(H) Weight 0.79 lbs / 360g *Specifications are subject to change without notice. 7. PACKAGE CONTENTS One (1) WDSDX-M56AI or One (1) Mounting Plate Four (4) Mounting Screws WDSDX-M56AIP Camera Copyright 2010. All Rights Reserved. P = PAL version. REV081010. -
Page 11: Caution
Four (4) Wall Anchors One (1) Mounting Sticker One (1) Operational Template Manual * For any returns, please include all components listed above with original packaging in Resalable Condition. Absolutely No Returns will be accepted if any component is missing/damaged or if any cable is cut or tampered with. 8. -
Page 12: Warranty
When the video product exhibits a distinct change in performance. 9. WARRANTY OKINA USA products are covered under warranty for one year from the date of purchase. The warranty will automatically be voided if any of the following occurs: 1. -
Page 13: Www.okinausa.com Wdsdx-M56Ai_D
Copyright 2010. All Rights Reserved. P = PAL version. REV081010. www.okinausa.com WDSDX-M56AI_D-224...
