Page 1: User Manual
SHM-7540LPDN-IO License Plate Capture Day & Night Camera with I/O User Manual Thank you for purchasing our product. Before operating the unit, please read the instructions carefully and keep this manual for future reference. -
Page 2: Safety Warning
Safety Warning 1. Read manual carefully before installing the unit. Please read this manual first for correct installation and operation. 2. Never install the camera on a ceiling that cannot hold its weight. The product may fall down and cause damages. 3. - Page 3 The safety and operating instructions should be retained for future reference. Warranty OKINA USA products are covered under warranty for one year from the date of purchase. The warranty will automatically be voided if any of the following occurs: 1. Camera sticker is removed If the camera sticker is removed, we will not be able to confirm any information regarding when and where the product was purchased.
-
Page 4: Table Of Contents
Table of Contents 1. PRODUCT OVERVIEW..........................5 ............................5 EATURES ........................... 5 ACKAGE ONTENTS ............................5 IMENSIONS 2. PARTS & FUNCTIONS ..........................6 3. CONTROL SWITCH ............................ 8 ......................8 PERATION OF WITCH ........................9 ETTING OF WITCH 4. SPECIFICATIONS ............................. 10 5. -
Page 5: Product Overview
(150km/hr) at night time with external IR LEDs. Dual Power 12V DC / 24V AC 1.2 Package Contents One (1) SHM-7540LPDN-IO Camera One (1) User’s manual * For any returns, please include all components listed above with original packaging in Resalable Condition. -
Page 6: Parts & Functions
2. Parts & Functions S.AGC L.L. VIDEO V.P. ME SHUTTER OFF NORM AGC INT S.AGC L.L. VIDEO V.P. ME SHUTTER OFF NORM AGC INT P.I.C. = Product Item Code Copyright 2011. All Rights Reserved. PAL Version Also Available www.okinausa.com R042011-V07... -
Page 7: Lens Mount
1 Lens Mount sed to install a CS mount lens. CS adaptor ring is required if using a C mount lens. 2 CS Mount Fixing Screw Screw for fixing mount and adjusting back focus if needed. 3 Mount Adaptor Can be attached to either the top or bottom of the unit. 4 Auto Iris Lens Connector (4-pin type) The lens connector supplies the auto-iris lens (not supplied) with DC power and a video signal or DC control signal. -
Page 8: Control Switch
3. Control Switch 3.1 Operation of Mode Switch SW1. BLC (Back Light Compensation) Mode Switch When strong light is present behind the object being photographed, the object will appear dark. In this case, turn on the BLC. S.AGC L.L. V.P. OFF NORM AGC INT S.AGC L.L. -
Page 9: Setting Of Mode Switch
3.2 Setting of Mode Switch For Road Surveillance: Car speed is up to 90 mi/hr (150 km/hr) in the daytime and 90 mi/hr (150 km/hr) at night. FLC S.AGC CAR-DC L.L. VIDEO V.P. ME SHUTTER NORM 1. ME/AES Shutter Control should be set on “2”. (Please refer to the function ○... -
Page 10: Specifications
4. Specifications P.I.C. L-803 Model SHM-7540LPDN-IO SHM-7540LPDN-IOP NTSC TV System 1/3” Sony Super HAD CCD II Image Sensor Sony HQ-1 540 TV Lines Resolution 811(H) x 508(V) 795(H) x 596(V) Total Pixels 1.0Vp-p Composite, 75 Ohms Video Output 0.08 Lux @ F1.0 without IR light... -
Page 11: Related Products
5. Related Products 5.1 Recommended Lens: 3~80mm IR D&N Auto Iris 2.7~12mm IR D&N Auto Iris 5~60mm Auto Iris LEN0380DCIR-J LEN2712DCIR-J LEN0560DC-J • Made in Japan • Made in Japan • Made in Japan • 1/3" Aspherical • 1/3" Aspherical •... - Page 12 www.okinausa.com P.I.C. = Product Item Code Copyright © 2011. All Rights Reserved. Copyright 2011. All Rights Reserved. PAL Version Also Available www.okinausa.com R042011-V07...
