Page 1 Proprietary – Use pursuant to Company instruction Title page 1645 Access Multiplexer Compact AMC Release 8.0 Installation Guide 365-313-103R8.0 CC109642231 Alcatel-Lucent – Internal ISSUE 2 Proprietary – Use pursuant to Company instruction JULY 2009...
Page 2 The information presented is subject to change without notice. Alcatel-Lucent assumes no responsibility for inaccuracies contained herein. Copyright © 2009 Alcatel-Lucent. All rights reserved. Contains proprietary/trade secret information which is the property of Alcatel-Lucent and must not be made available to, or copied or used by anyone outside Alcatel-Lucent without its written authorization.
Page 3 Basic safety aspects ................................... Specific safety areas Overview ....................................... Laser safety ....................................Optical circuit pack specifications 1-11 1-11 ............................ Power supply safety instructions 1-11 1-11 .......................................................................... 365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 4 2-11 2-11 ............................ Sequence of steps 2-12 2-12 ..................................Mechanical installation Overview ....................................... 1645 AMC installation Overview ....................................... Technical data for AMC unit ..............................Installation of an option card ..............................Mounting the EMC bracket ..............................Technical data for fan unit ..............................
Page 5 Aggregate interfaces (Main board) 4-36 4-36 ........................... Powering Overview ....................................... Power initialization Overview ....................................... Switching on and testing supply voltage ........................... Fan unit test ..................................................................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 6 ..........................E1 tributary ports distribution wiring test ......................... Line port connection to optical distribution frame test ....................PDH option card test 7-12 7-12 ..............................................................................Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 7 Power failure ....................................Installing the E software ..............................Parameters for E software installation ........................... Fiber cleaning ..................................... Removing the SFP modules B-10 B-10 ........................................................................... 365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 8 Cable assembly instructions Overview ...................................... SUB-D connector ..................................Coax connector (1.6/5.6) ................................ Mounting 4 × 2.5mm coax (75 Ω) to RJ45 connector ....................Glossary Index ..............................................viii Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 9: Table Of Contents
Pin assignment (SHDSL cables) 4-25 4-25 ........................4-14 Pin assignment (LA cables - E/FE) 4-28 4-28 ....................... 4-15 Pin assignment (LA cable - GE) 4-29 4-29 ....................................................................... 365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 10 List of tables ..............................................4-16 Optical specifications 4-32 4-32 ............................4-17 Components (STM-1e cable) 4-33 4-33 ..........................4-18 Optical SFP specifications 4-35 4-35 ........................................................................Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 11 3-16 ............................3-13 Vertical AMC mounting (with bars) 3-17 3-17 ......................... DC connector ................................DC connection ................................AC connection ................................Fan power connector ........................................................................... 365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 12 4-29 4-29 ......................... 4-31 LA cables 4-30 4-30 ................................4-32 Cable design (STM-1e cable) 4-33 4-33 ..........................4-33 Optical SFP module 4-34 4-34 ........................................................................... Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 13 ........................ SUB-D assembly steps ............................Low frequency cable ............................... IMS assembly procedure ............................Crimp tool and die ..............................RJ45 connector C-11 C-11 ............................................................................365-313-103R8.0 Alcatel-Lucent – Internal xiii Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 15 Intended audience This manual is intended for users who wish to install, configure and cable 1645 AMC units including all accessories. This requires that the installation staff has a basic knowledge of SDH and Ethernet technology.
Page 16 Cross-reference conventions are identical with those used for numbering, i.e. the first number in a reference to a particular page refers to the corresponding chapter..............................................Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 17: Installation Guide
Alcatel-Lucent Development Systems. The code consists of a letter combination followed by a combination of numbers (Example: CC123456789). Related documentation This section briefly describes the documents that are included in the 1645 AMC documentation set. • Installation Guide The 1645 AMC Installation Guide is a step-by-step guide to system installation and setup.
Page 18 • Repair and Replacement (R&R) – technical support services for device repair/return or parts replacement. • Alcatel-Lucent Online Customer Support – online access to information and services that can help resolve technical support requests. ote: Technical Support Services are available 24 hours a day, 7 days a week.
Page 19 ..............................................How to order For all questions concerning ordering of 1645 AMC documentation, for a complete list of the marketable items and their comcodes, and for ordering the equipment please contact your Account Executive or your Alcatel-Lucent local customer team.
Page 21 Part I: Physical and power installation Overview Purpose This part of the 1645 AMC Installation Guide contains the physical installation of the 1645 AMC units including the system cabling and the system powering. Contents This part of the document contains the following chapters: •...
Page 22 Is a multimeter available? Is an ohmmeter available? Contents Chapter 1, Safety Chapter 2, General information Chapter 3, Mechanical installation Chapter 4, System cabling Chapter 5, Powering ..............................................Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 23 Overview Purpose The aim of this chapter on safety is to provide users of 1645 AMC system with the relevant information and safety guidelines to safeguard against personal injury. Furthermore, this chapter may be useful to prevent material damage to the equipment.
Page 24 Basic safety aspects Specific safety areas Laser safety Optical circuit pack specifications 1-11 Power supply safety instructions 1-11 Electrostatic discharge 1-12 Conformity statements 1-13 ..............................................Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 25 Structure of safety statements Overview Safety statements describe the safety risks relevant while performing tasks on Alcatel-Lucent products during deployment and/or use. Failure to avoid the hazards may have serious consequences. General structure Safety statements include the following structural elements:...
Page 26 OTICE Indicates a hazardous situation not related to personal injury. Warning symbols These warning symbols are defined for safety instructions: ..............................................Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 27 Flammable material/Risk of fire Service disruption hazard Laceration hazard Corrosive substance Hazard caused by batteries Hot surface Heavy overload load oxious substance Explosion hazard ..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 28 • Any conversions or changes to the system or parts of the system (including the software) must be carried out by qualified Alcatel-Lucent personnel or by expert personnel authorized by Alcatel-Lucent. All changes carried out by other persons lead to a complete exemption from liability.
Page 29 • software can adversely affect the normal functioning of the system. • Only use tested and virus-free data carriers (floppy disks, streamer tapes, …)..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 30: Laser Safety
Overview Purpose The aspects of “laser safety” and “handling of components sensitive to electrostatic discharge (ESD)” are of vital importance for the 1645 AMC equipment. Therefore, the key safety instructions for these subjects are summarized in the following. Contents Laser safety...
Page 31 (power density) decreases rapidly with distance. The greater the distance, the less energy will enter the eye, and the less potential risk for eye injury. Inadvertently ..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 32 Consult A SI Z136.2 American ational Standard for Safe Use of Lasers in the U.S. or outside the U.S., IEC-60825, Part 2 for guidance on the safe use of optical fiber optic communication systems in the workplace..............................................1-10 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 33 Optical circuit pack specifications 1645 AMC Alcatel-Lucent 1645 AMC comply with FDA/CDRH 21 CFR 1040.10 and 1040.11 as Class I and IEC 60825-1 as a Class 1 Laser Product. All optical interfaces are available as “Small Form-Factor Pluggable Optics” (SFPs). The technical specifications of the optical interfaces are given in chapter 4, section “Specifications”...
Page 34 When inserting option cards, ensure the cover is on before powering on the unit. Protection against short-circuits Important! Ensure that the 1645 AMC units have reached room temperature and are dry before taking them into operation. Electrostatic discharge...
Page 35 EU market from 1 July 2006, with various exemptions, including an exemption for lead solder in network infrastructure equipment. Alcatel-Lucent products shipped to the EU from 1 July 2006 will comply with the RoHS Directive.
Page 37 ETSI 300 019-1-3 Class 3.2. The 1645 AMC units can also act as an SHDSL Line Termination Unit (LTU) when equipped with the SHDSL option card. Several third party etwork Termination Units ( TUs) can be connected to the LTU.
Page 38: Technical Specifications (Ac/Dc Converter)
General information Hardware description ..............................................Powering The 1645 AMC units can be ordered either as DC or as AC powered versions. The power ranges are given in chapter 3. Table 2-1 Technical specifications (AC/DC converter) Item DR-120-48 converter DR-75-48 converter AC input 88 ...
Page 39: Technical Specifications (Fsp12Ams)
• The option to let the battery return floating is available. • The fuses protecting the system cannot be replaced at the field. Replacement must be done at a repair center..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 40 General information Hardware description ..............................................1645 AMC main board assembly The main board has the following characteristics: • Two STM-1 electrical/optical aggregate line interface pairs (transmit/receive) for SFP usage • Two STM-1/ STM-4 optical aggregate line interface pairs (transmit/receive) for SFP usage •...
Page 41 Pluggable SFPs The optical/electrical line interfaces of the 1645 AMC unit can be equipped with various SFPs (Small Form-Factor Pluggable). ote that the GE SFPs are only applicable to the X5IP option cards.
Page 42: Optical Sfp Module
OTES: • Please note that Alcatel-Lucent warranty is contingent upon the use of Alcatel-Lucent specified SFPs for the 1645 AMC. Use of other SFPs is not approved by Alcatel-Lucent and is fully at the customer's own risk. Any warranty obligation of Alcatel-Lucent is extinguished when non-Alcatel-Lucent specified SFPs are used.
Page 43: Dust Plug
Provides six STM-1 interfaces to be used with the AMC main 109642314 board. Each interface is SFP based. The option card supports STM-1 optical or electrical bidirectional interfaces..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 44: Example Of An Option Card
Figure 2-5 Example of an option card Environmental considerations General The 1645 AMC units must have room temperature and must be dry before they can be taken into operation. Environmental conditions The environmental conditions for the 1645 AMC units are as follows: •...
Page 45 • Wear working garment made of 100% cotton to avoid electrostatic charging. • Touch the option cards/SFPs at the edges only. • Ensure that the 1645 AMC units are grounded. • Wear conductively connected wrist straps and connect them to an ESP bonding point.
Page 46 Independent of the requirements listed above the minimum requirements of the operating system must be fulfilled. A CD-ROM containing the ITM-CIT software must be available..............................................2-10 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 47: Required Tools
A 15 dB LBO must be used for optical test loops or for testing the individual ports..............................................365-313-103R8.0 Alcatel-Lucent – Internal 2-11 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 48 Overview This manual is structured according to the sequence of steps that should be observed when installing 1645 AMC units. The table below gives an overview of all needed installation steps which are described in detail in the following chapters.
Page 49 “X12SHDSL-V2 option card test” (p. 7-21) • Link acceptance tests “Connecting the fiber cables” (p. 8-2) • “Remote login test” (p. 8-4) • “BER test” (p. 8-6) • ..............................................365-313-103R8.0 Alcatel-Lucent – Internal 2-13 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 51 M echanical installation Overview Purpose The purpose of this chapter is to explain the hardware installation of 1645 AMC units. This chapter describes the installation procedure for the 1645 AMC . Contents 1645 AMC installation Technical data for AMC unit...
Page 52 Mounting the EMC bracket Technical data for fan unit AMC unit installation 3-10 Technical data for AMC unit Specifications A 1645 AMC unit has the specifications as given in the table below. Table 3-1 Technical specifications Item Quantity/Value AMC-DC ominal power supply –24 V, –48 V and –60 V...
Page 53: Amc Unit Dc Version Front View
70 mm [2.756"] × 448 mm [17.587"] × 204 mm [8.04"] (without mounting brackets) Layout The following figure shows a DC powered 1645 AMC unit. The front view can be different depending on the used option card. The front views of the option cards are shown in Figure 3-2.
Page 54: Amc Unit Ac Version Front View
Mechanical installation 1645 AMC installation Technical data for AMC unit ..............................................Figure 3-2 AMC unit AC version front view ..............................................Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 55 Installation of an option card Overview This section provides a procedure for upgrading the 1645 AMC with one of the option cards. An overview about all available option cards is given in chapter 2, section “Upgrade with option cards” (p.
Page 56: Installation Of An Amc Option Card
Mechanical installation 1645 AMC installation Installation of an option card ..............................................Result Figure 3-3 Installation of an AMC option card ..............................................Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 57 Mechanical installation 1645 AMC installation Mounting the EMC bracket ..............................................Mounting the EMC bracket When to use Mount this EMC bracket after you have installed one of the following option cards: • X16E1-V3 • X16DS1 • X12SHDSL-V2. This bracket must be mounted to comply with the EMC requirements.
Page 58 The usage of a fan unit (CC848949657) is recommended, if sufficient air flow for cooling the 1645 AMC unit cannot be guaranteed. A fan unit provides sufficient air flow to cool the unit in a thermally hostile environment. Proper cooling is ensured as long as one fan is still working.
Page 59 Mechanical installation 1645 AMC installation Technical data for fan unit ..............................................Figure 3-5 Fan unit ..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 60 • Horizontal rack mounting • Vertical rack mounting Table top mounting Before installing the 1645 AMC unit on a table top, it is necessary to fix the four supplied self-adhesive pads below the unit. Wall mounting Proceed as follows to mount the 1645 AMC unit on a flat, vertical surface: ........................................
Page 61: Fixing Wall Mounting Brackets (Amc Unit)
Mechanical installation 1645 AMC installation AMC unit installation ..............................................Results Figure 3-6 Fixing wall mounting brackets (AMC unit) ..............................................365-313-103R8.0 Alcatel-Lucent – Internal 3-11 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 62: Vertical Wall Mounting (Amc Unit)
Mechanical installation 1645 AMC installation AMC unit installation ..............................................Figure 3-7 Vertical wall mounting (AMC unit) ..............................................3-12 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 63: Horizontal Wall Mounting (Amc Unit)
Figure 3-9, “Fixing additional brackets to the AMC unit (if required)” (p. 3-14). Important! This step is not necessary if the 1645 AMC unit is to be mounted into a 19-inch rack........................................Fix both brackets (left and right) with six M3 × 8 screws (three at each side) to the 1645 AMC unit as shown in the figures below.
Page 64: Fixing Additional Brackets To The Amc Unit (If Required)
Mechanical installation 1645 AMC installation AMC unit installation ..............................................Results Figure 3-9 Fixing additional brackets to the AMC unit (if required) Figure 3-10 Mounting position for 19-inch racks ..............................................3-14 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction...
Page 65: Mounting Position For Etsi-2 (Lambdaunite) Racks (Back-To-Back, Depth 600 Mm)
Mechanical installation 1645 AMC installation AMC unit installation ..............................................Figure 3-11 Mounting position for ETSI-2 (LambdaUnite) racks (back-to-back, depth 600 mm) ..............................................365-313-103R8.0 Alcatel-Lucent – Internal 3-15 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 66: Mounted Amc Brackets
“Vertical AMC mounting (with bars)” (p. 3-17). The distance must be 450 mm........................................Fix both brackets (left and right) to the 1645 AMC unit with six M3 × 8 screws (three at each side) as shown in Figure 3-12, “Mounted AMC brackets” (p.
Page 67: Vertical Amc Mounting (With Bars)
Mechanical installation AMC unit installation ..............................................Figure 3-13 Vertical AMC mounting (with bars) ..............................................365-313-103R8.0 Alcatel-Lucent – Internal 3-17 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 69 4-24 SHDSL interfaces (X12SHDSL-V2 card) 4-25 E3/DS3 interfaces (X3E3DS3 card) 4-27 LA interfaces (X8PL, and X5IP cards) 4-28 4-31 Fiber cabling Optical interfaces 4-31 ..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 70 System cabling Overview ..............................................SFP-155E cable 4-33 Optical interfaces (X5IP card) 4-33 Optical interfaces (X6STM1 card) 4-35 Aggregate interfaces (Main board) 4-36 ..............................................Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 71 DC RT (return), feed A –24/–48/–60 VDC, feed B blue DC RT (return), feed B DC common return for feed A+B G D (common ground) yellow/green ..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 72: Dc Connection
If an AC/DC converter is used, the DC side needs to be connected to the 1645 AMC and the AC side needs to be connected to a power outlet. Figure 4-2 DC connection Figure 4-3 AC connection ..............................................Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 73 Important! Ensure that the protective earth is connected to the unit via the power cord..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 74 (p. 5-3)). Connector data The fan power connector located on the fan unit is a 9-pin SUB-D male connector..............................................Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 75: Fan Power Connector
2 meters. Cable connection The fan power cable must be connected as shown in the figure below: ..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 76: Fan Power Cable
FA FAIL return connection to normally open contact of fan failure relay (closes in case of failure) MDO1_LED Cathode for MDO 1 LED MDO2_LED Cathode for MDO 2 LED ..............................................Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 77: Pin Assignment (Fan Alarm Cable)
Cathode for MDO 4 LED Cable connection Please connect the fan alarm cable as shown in the figure below: Figure 4-7 Fan alarm cable ..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 78: Mdi Circuit
General The four Miscellaneous Discrete Inputs (MDIs) are intended for customer usage. The inputs can be used to collect status information from the 1645 AMC itself or from other transmission or non-transmission equipment like power supply systems, intruder detectors or fire detectors. The external remote power supply (FSP) box is managed through this interface.
Page 79: Mdi Implementation
In case of accidental wrong usage of a non floating MDI, the system can withstand without damage a permanent high input voltage between input and ground of; -72V to +72V..............................................365-313-103R8.0 Alcatel-Lucent – Internal 4-11 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 80: Pin Assignment (Mdi/Mdo Cable)
MDO 2 return Miscellaneous Discrete Output 2 return, contact normally closed MDO 1 return Miscellaneous Discrete Output 1 return, contact normally closed ..............................................4-12 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 81 MDIO cable (FSP12AMS) can be used. Cable data Preferably stranded 24 AWG (0.20 mm²) to 20 AWG (0.51 mm²) wires with proper insulation should be used..............................................365-313-103R8.0 Alcatel-Lucent – Internal 4-13 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 82: Return Loss Of 30 Channel Market Station Clock Inputs
Table 4-5 Return loss of 30 channel market station clock inputs Input type Frequency Return loss 2 MHz 2048 kHz 15 dB ..............................................4-14 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 83: Jitter Tolerance At 30 Channel Market Station Clock Inputs
Signal name (120 , symmetrical) (75 , coaxial) RX positive (a-wire) Braid of RX coaxial RX negative (b-wire) Inner conductor of RX coaxial ..............................................365-313-103R8.0 Alcatel-Lucent – Internal 4-15 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 84 Preferably a MiniCoax 75Ω 2.5 mm cable should be used. Cable connection Please connect the timing cable as shown in the figure below: ..............................................4-16 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 85: Timing Cable
The -LA connector is an 8-pin RJ45 connector with metal shell for grounding. Figure 4-15 Q-LAN connector Table 4-8 Pin assignment (Q-LAN cable) Point on connector Signal name Description TX P Transmit-data positive Transmit-data negative ..............................................365-313-103R8.0 Alcatel-Lucent – Internal 4-17 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 86 The routing of the -LA cable should be in accordance with the recommended practices of the cable selected. The cable should be strain relieved to prevent any force from being exerted on the connectors..............................................4-18 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 87: Itm-Cit Cable
Request To Send Data Terminal Ready ot connected Cable connection Please connect the ITM-CIT cable as shown in the figure below. Figure 4-18 ITM-CIT cable ..............................................365-313-103R8.0 Alcatel-Lucent – Internal 4-19 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 88: Itm-Cit Cable Connection
EOW interfaces Purpose An Engineering Order Wire (EOW) can be connected to these interfaces. ote: The EOW interfaces are only available on 1645 AMC units. Connector data The 1 × E1/E2/F1 EOW connectors are 15-pin SUB-D male connectors (hot shrinked, tailed).
Page 89: Eow Cables
The routing of the EOW cables should be in accordance with the recommended practices of the cable selected. The cables should be strain relieved to prevent any force from being exerted on the connectors..............................................365-313-103R8.0 Alcatel-Lucent – Internal 4-21 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 90 Option card cable installation Overview ..............................................Option card cable installation Overview Purpose This section provides information about the cabling of the option cards for 1645 AMC. Contents E1 interfaces (Main board/X16E1-V3 card) 4-22 DS1 interfaces (Main board/X16DS1 card) 4-24 SHDSL interfaces (X12SHDSL-V2 card)
Page 91: E1 Cables
Braid of Tx-coaxial Tinned copper braid Cable connection Please connect the E1 cables as shown in the figure below: Figure 4-23 E1 cables ..............................................365-313-103R8.0 Alcatel-Lucent – Internal 4-23 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 92 Table 4-12 Pin assignment (DS1 cables) Point on connector Signal name TX positive (a-wire) TX negative (b-wire) RX positive (a-wire) RX negative (b-wire) ..............................................4-24 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 93 Preferably shielded twisted pair cables (CAT5) should be used (100 Ω symmetrical). SHDSL interfaces (X12SHDSL-V2 card) Purpose The 1645 AMC unit can act as an SHDSL LTU when it is equipped with the X12SHDSL-V2 option card. SHDSL tributaries can be connected to these interfaces. Connector data The SHDSL connectors which are located on the X12SHDSL-V2 option card are RJ45 connectors.
Page 94: Shdsl Cables
Belden Wire & Cable B.V. (46556) Cable connection Please connect the SHDSL cables as shown in the figure below: Figure 4-26 SHDSL cables ..............................................4-26 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 95: E3 Cables
(or group of ports) on the LTU, and numerically incrementing port numbers on the TU are connected to numerically incrementing port numbers on the LTU. Typical wiring errors are shown in the “1645 AMC Alarm Messages and Trouble Clearing Guide”. E3/DS3 interfaces (X3E3DS3 card) Purpose 34368 kbit/s E3 and 44736 kbit/s DS3 inputs and outputs can be connected to these interfaces.
Page 96: Ds3 Cables
Signal name Description TX P Transmit-data positive Transmit-data negative RX P Receive-data positive ot connected ot connected Receive-data negative ot connected ot connected ..............................................4-28 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 97 A standard LA cable (CAT5) can be used (100 Ω symmetrical). Cable connection Please connect the LA cables as shown in the figure below: ..............................................365-313-103R8.0 Alcatel-Lucent – Internal 4-29 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 98 The routing of the LA cables should be in accordance with the recommended practices of the cable selected. The cable should be strain relieved to prevent any force from being exerted on the connectors..............................................4-30 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 99 – STM-4 long haul (L4.2) • Tributary interfaces: – STM-1 short haul (S1.1). – STM-1 middle range (L1.1) – STM-1 long haul (L1.2) ..............................................365-313-103R8.0 Alcatel-Lucent – Internal 4-31 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 100 It is not mandatory to have an LBO (Lightguide Build-Out) between the optical interfaces of the 1645 AMC unit and the connected optical cable. However, in the case of measurements with optical loops and/or connecting power meters an LBO (15 dB) can be required.
Page 101 ..............................................SFP-155E cable Purpose The SFP-155E cable is used for connecting the 155 Mbit/s STM-1 electrical inputs and outputs to the 1645 AMC E. Cable data (75 , coaxial) Figure 4-32 Cable design (STM-1e cable) Table 4-17 Components (STM-1e cable)
Page 102: Optical Sfp Module
OTES: • Please note that Alcatel-Lucent warranty is contingent upon the use of Alcatel-Lucent specified SFPs for 1645 AMC. Use of other SFPs is not approved by Alcatel-Lucent and is fully at the customer's own risk. Any warranty obligation of Alcatel-Lucent is extinguished when non-Alcatel-Lucent specified SFPs are used.
Page 103 Optical path penalty < 1 dB < 1 dB < 1 dB Receiver Sensitivity –28 dBm min. –34 dBm min. –34 dBm min..............................................365-313-103R8.0 Alcatel-Lucent – Internal 4-35 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 104 Cable data Single Mode (SM) fibers must be used. Cable connection Please connect the aggregate fiber cables as shown in the figure below: ..............................................4-36 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 105: Aggregate Fiber Cables
1: protection). The ETSI failure of protocol applies. Under this protocol, an alarm-free interworking mode with SO ET defined MSP is supported..............................................365-313-103R8.0 Alcatel-Lucent – Internal 4-37 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 107 P owering Overview Purpose This chapter describes the powering of the 1645 AMC system and some final tests which should be performed to complete the physical installation tasks. Assumption All units/network elements ( Es) must be mounted and cabled correctly (see Chapters 3 and 4).
Page 108 CAUTION Condensation causes malfunctioning. Condensation can occur in the 1645 AMC units during transport, especially on moving from outside to closed rooms; this can cause malfunctioning of the units. Ensure that the units have reached room temperature and are dry before taking them into operation.
Page 109 Switch off the power........................................Connect the power cable between the power interface of the 1645 AMC unit and the BDFB (or PDP). ote: If an AC/DC converter is used, it has to be connected to the DC connector of the 1645 AMC unit first and then to the BDFB (or PDP).
Page 110: Fan Unit
• the fans of the unit are running • the air flow direction is from in to out S T E P S ...................................................................................... Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 111 • the mechanical parts are secured • the optical couplings (or SFPs) are affixed to the optical interfaces • the E is up and running ..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 112: Cable Connections
EMC bracket mounting AMC unit mounting Fan unit mounting AMC unit power cabling Ground cabling Fan power cabling Fan alarm cabling MDI/MDO cabling Timing output cabling ..............................................Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 113 EOW cabling E1 cabling DS1 cabling SHDSL cabling E3 cabling DS3 cabling STM-1e cabling LA cabling Fiber cabling Powering Fan unit test Physical installation check ..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 115 Overview Purpose This part of the 1645 AMC Installation Guide contains the ITM-CIT and E software installation, the E provisioning, and the stand-alone test procedures. Contents This part of the document contains the following chapters: • Chapter 6: ITM-CIT installation and E provisioning •...
Page 116 NE provisioning and stand-alone installation test Overview ..............................................Contents Chapter 6, ITM-CIT installation and E provisioning Chapter 7, Stand-alone test procedures ..............................................II-2 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 117 Overview Purpose This chapter describes the ITM-CIT and E software installation and the initial E provisioning via ITM-CIT. Assumption The person setting up the system is familiar with 1645 AMC, the SDH functionality and ITM-CIT. Contents Software installation Installing ITM-CIT...
Page 118: Software Installation
E login. Contents Installing ITM-CIT Installing the fast download application Fast E software download Connecting the ITM-CIT to the E 6-10 E login procedure 6-12 ..............................................Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 119: Installing Itm-Cit
Installation procedure Complete the following steps to install the ITM-CIT software on your PC: ........................................® desktop, click on Start. On the Windows ..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 120 Help is defined........................................then click Next. you want to install ITM-CIT with default setting English (English The Select Components window appears. Result: Online Help) ..............................................Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 121 WinPcap. Therefore, replace the older version of the Fast Download Tool with the latest version available on the E software CD-ROM..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 122 ITM-CIT installation and NE provisioning Software installation Installing ITM-CIT ..............................................S T E P S ...................................................................................... Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 123: Installing The Fast Download Application
The “Fast download” application permits to download the current software in the equipment in about five minutes. The “Fast download” is realized from a PC connected to the -LA interface of the 1645 AMC unit. The “Fast download” application is installed in the Windows environment using the program supplied.
Page 124: Connection With Crossed Ethernet Cable (Amc Unit)
Ensure that all assumptions listed below are fulfilled before carrying out the fast software download: • The 1645 AMC unit is powered on. • The “Fast download” application is installed on the PC. • An Ethernet cable is installed between the Ethernet access of the PC and the -LA interface (RJ45 connector) of the E.
Page 125: Connection With Crossed Ethernet Cable (Amc Unit)
Select the correct Ethernet Adapter........................................Select the load with the extension to be downloaded to the 1645 AMC unit .ISD or to be downloaded to an external unit like an SHDSL modem. If a “.S3” file is selected for download, then the tool will do a conversion to “.ISD”. Click to the displayed “Attention”...
Page 126 Connecting the ITM-CIT to the NE Overview To perform software tests and provision the system with local configuration parameters, an Integrated Transport Management – Craft Interface Terminal (ITM-CIT) must be connected to the 1645 AMC unit locally..............................................6-10 Alcatel-Lucent – Internal 365-313-103R8.0...
Page 127: Itm-Cit Cable Connection (Amc Unit)
Connecting the ITM-CIT to the NE ..............................................Connecting the ITM-CIT Connect the ITM-CIT to the 1645 AMC unit as shown in the figures below. The provided ITM-CIT cable (CC848069795) should be used. Figure 6-3 ITM-CIT cable connection (AMC unit) ITM-CIT Figure 6-4 ITM-CIT cable connection (AMC unit) ..............................................
Page 128: E Login Procedure
Select the correct Usually, this is COM1. COM port........................................Select to set the correct baudrate. Edit 1645 AMC operates on a baudrate of 115k........................................Select Login The Password Required window appears. Result: ........................................Select the user role from the capability field.
Page 129 ITM-CIT installation and NE provisioning Software installation NE login procedure ..............................................Result: The ITM-CIT is logged into the E. S T E P S ...................................................................................... 365-313-103R8.0 Alcatel-Lucent – Internal 6-13 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 130: Provisioning System Parameters
This section describes all provisioning tasks which should be performed to prepare the system for operation and to be able to perform some tests. Related information An overview about all 1645 AMC related tasks is given in the “1645 AMC User Operations Guide”. Contents...
Page 131 CIT (PC). This information is sent to the E and the time and date are set. Manual set The date and time must be set manually..............................................365-313-103R8.0 Alcatel-Lucent – Internal 6-15 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 132 Provisioning system parameters NE date and time ..............................................Time This field is used to set the time when the manual setting edit mode is chosen..............................................6-16 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 133 For example, a tributary port unit must be assigned before the ports for this unit can be assigned. • For the 1645 AMC , the only slot which may be user assigned is TS2. OTE: Any mistake in provisioning the slots will result in a failure when attempting to create the node.
Page 134 The window ode Creation – Provisioned Slots appears........................................Complete the procedure “Slot provisioning” (p. 6-20). Important! For the 1645 AMC , the only slot which may be user assigned is TS2. Result: The slots of the E are properly assigned........................................Complete the procedure “Confirm/Update the MIB”...
Page 135 ITM-CIT. The procedure “Confirm/Update the MIB” (p. 6-22) gives the steps necessary to confirm the MIB. Once confirmed, the state will become Filled..............................................365-313-103R8.0 Alcatel-Lucent – Internal 6-19 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 136: Slot Provisioning
E is known. This includes the exact types of units to be provisioned and the corresponding slot positions for these units. • For the 1645 AMC , the only slot which may be user assigned is TS2. • The main unit must be assigned before its corresponding interface units are assigned.
Page 137 Automatically assigns the unit to the slot once the E establishes the presence of a unit of the correct type. Until this time, the slot acts as Unassigned..............................................365-313-103R8.0 Alcatel-Lucent – Internal 6-21 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 138: Confirm/Update The Mib
Result: The ode Details window appears. In this window, the MIB state can be viewed. It should now be Filled........................................Click Close ..............................................6-22 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 139: 365-313-103R8.0
Waiting for Upload. When the OMS reassociates with the E and detects this MIB state, a MIB upload is performed, and the state will then become Filled. Management state ..............................................365-313-103R8.0 Alcatel-Lucent – Internal 6-23 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 140 Downloading. EMS connection state Indicates wether an active connection (CMISE association) exist to the element manager (OMS)..............................................6-24 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 141 • The area address must be available to enter into the DC parameters. This is required to get the unit out of the (OSI) isolated state. • The people carrying out the tests are familiar with 1645 AMC , the SDH functionality, the ITM-CIT software and the handling of the test equipment.
Page 142: Test Equipment And Accessories
Two single mode fibers with applicable connectors Optical attenuator, single mode, 1310/1550 nm Cleaning set for optical fibers If the 1645 AMC has an option card installed, then the following test equipment and accessories are required per option card: 1645 AMC with an option card...
Page 143 Stand-alone test procedures Test equipment and accessories ..............................................1645 AMC with an option card Option cards Accessories STM-1 Trans Trans Optical SHDSL X8PL X5IP 2x E1 cables PDH BER test set with E3 option 2x E3 cables PDH BER test set with...
Page 144: Preparation And Test Of The Main Unit
Preparation and test of the main unit ..............................................Preparation and test of the main unit Overview This section describes the preparation and test of a 1645 AMC main unit. Estimated duration 15 minutes Procedure Proceed as follows to perform the main unit test: ........................................
Page 145: E1 Tributary Ports Distribution Wiring Test
• The ITM-CIT must be connected and logged-in to the E. • Test setup as shown in the figure above..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 146 ........................................Display the raised alarm list on the ITM-CIT, and verify that the requirements mentioned in the table below are met. Result: Requirements LEDs on the 1645 AMC : Power: Fault: PDH analyzer: o errors detected Alarms reported on the ITM-CIT: “E12c ES”, 2 Mbit/s ot Expected Input...
Page 147: Issue 2 July 2009 Proprietary - Use Pursuant To Company Instruction
• Reset the alarm reporting settings of E12c ES (2 Mbit/s ot Expected Input Signal) to default ( ot Reported) • Delete all cross-connections..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 148: Line Port Connection To Optical Distribution Frame Test
”. (* stands for “1” or “4”, depending on the port type under test)........................................Install a fiber loop on LP1.1 on the ODF..............................................Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 149 Subtract 0.50 dB per optical connection (for the suggested set-up 1.5 dB (3 connections)) and subtract 0.2 dB per fiber segment (0.4 dB for 2 fiber segments)..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 150 Cleaning up The following tasks must be performed to clean up the system: • Disconnect the PDH analyzer • Disconnect the optical attenuator ..............................................7-10 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 151 Stand-alone test procedures Line port connection to optical distribution frame test ..............................................• Set the STM*c ES to “ ot Reported” • Delete the cross-connection(s)..............................................365-313-103R8.0 Alcatel-Lucent – Internal 7-11 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 152: Pdh Option Card Test
For a long haul laser (L11, L12, L41 or L42) a 10 dB attenuator with applicable connector is required in the loop ..............................................7-12 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 153 ........................................Display the raised alarm list on the ITM-CIT, and verify that the requirements mentioned in the table below are met..............................................365-313-103R8.0 Alcatel-Lucent – Internal 7-13 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 154 Stand-alone test procedures PDH option card test ..............................................Result: Requirement LEDs on the 1645 AMC : Power: Fault: PDH analyzer: o errors detected Alarms reported on the ITM-CIT: “xxc ES”, y Mbit/s ot Expected Input Signal Notes: ot Expected Input Signal alarm refer to Step ........................................
Page 155: Optical Stm-1 Option Card Test
• Test setup as shown in the figure above Procedure Proceed as follows to perform the optical STM-1 option card test: ........................................Assign the installed option card..............................................365-313-103R8.0 Alcatel-Lucent – Internal 7-15 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 156 Monitor the analyzer for correct transmission........................................Display the raised alarm list on the ITM-CIT, and verify that the requirements mentioned in the table below are met. Result: Requirements LEDs on the 1645 AMC: Power: Fault: PDH analyzer: o errors Alarms reported on the ITM-CIT: “STM1c ES”...
Page 157 • Reset the Alarm Reporting/Severity of the STM1c ES (STM-1 ot Expected Input Signal) alarm to default ( ot Reported). • Delete all cross-connections..............................................365-313-103R8.0 Alcatel-Lucent – Internal 7-17 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 158 ........................................Check on the alarm list, and verify that the requirements mentioned in the table below are met. Result: Requirements LEDs on the 1645 AMC : Power LED: Fault LED: Link LEDs of related LA ports: On (green) Alarms reported on the ITM-CIT: “LA c ES”...
Page 159 Disconnect the LA cable from the LA ports. Wait until all LA c ES alarms have cleared........................................Insert a GbE SFP in the SFP slot of the X5IP..............................................365-313-103R8.0 Alcatel-Lucent – Internal 7-19 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 160 S T E P S ........................................Cleaning up Reset the Alarm Reporting/Severity of the LA c ES alarm type to default ( ot Reported)..............................................7-20 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 161: X12Shdsl-V2 Option Card Test
• X12SHDSL-V2 option card is installed. • the ITM-CIT is connected and logged-in to the E ..............................................365-313-103R8.0 Alcatel-Lucent – Internal 7-21 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 162 Assign the installed option card........................................Verify that the requirements mentioned in the table below are met. Result: Requirements LEDs on the 1645 AMC : Power LED: Fault LED: Alarms reported on the ITM-CIT: o alarms Conclusion: If the Fault LED is OFF, then the option card is accepted and the option card software is correctly loaded.
Page 163 Line port connection to optical distribution frame test PDH option card test Optical STM-1 option card test X8PL and X5IP option card test X12SHDSL-V2 option card test ..............................................365-313-103R8.0 Alcatel-Lucent – Internal 7-23 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 165: Alcatel-Lucent - Internal
Part III: Link testing Overview Purpose This part of the 1645 AMC Installation Guide contains the physical network installation and the recommended link test procedures. Contents This part of the document contains the following chapters: • Chapter 8: Link testing •...
Page 167 L ink testing Overview Purpose This chapter describes the link acceptance tests. Contents Connecting the fiber cables Remote login test BER test Link testing exit checklist ..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 168: Connecting The Fiber Cables
Procedure DANGER Laser hazard 1645 AMC systems operate with invisible laser radiation. Laser radiation can cause considerable injuries to the eyes. ever look into the end of an exposed fiber or into an open optical connector as long as the optical source is switched on. Always observe the laser warning instructions (cf.
Page 169 1310 –28 ... –8 L1.1 1310 –34 ... –10 L1.2 1550 –34 ... –8 L4.1 1310 –28 ... –8 L4.2 1550 –28 ... –8 ..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 170: Remote Login Test
(Go to menu: Management, Overlay Comms etwork, DCC, select LP1.1 MS , EDIT) Figure 8-1 Remote login test Remark : ode A is expected to be a 1645 AMC node. Procedure Proceed as follows to test the DCC communication: ........................................With the ITM-CIT login to node A.
Page 171 Successfully logged in to ode B ........................................Repeat this test for node B (B becomes A, X becomes Y and vice versa). S T E P S ...................................................................................... 365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 172: Ber Test
Preparation time: 5 minutes, test duration: 1 hour. Test setup The figure below shows a possible test setup: Figure 8-2 BER test Remark: ode A is expected to be a 1645 AMC node. Procedure Proceed as follows to perform a BER test: ........................................
Page 173: Link Testing Exit Checklist
Verify that applicable procedures have been completed and fill-in the results. If a procedure is not applicable, indicate “ /A”. Procedure Result Initials Notes (Passed, Failed, N/A) Fiber connection Remote login test BER test ..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 175: Alcatel-Lucent - Internal
Contents Power supply measurements Optical output power measurements Final checklist Power supply measurements Measured values Measured voltage ..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 176 Optical output power measurements ..............................................Optical output power measurements Measured values AMC unit Interface type Port Mean launched Receiver sensitivity number number power [dBm] [dBm] ..............................................Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 177 System turn up procedures System provisioning Stand alone test procedures etwork establishment and test If all chapters have been passed successfully, please sign the Completion Form..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 179 • In the case of vertical unit mounting, the power connectors of the units must show always to the bottom due to thermic requirements. Contents AMC units (DC powered) AMC units (AC powered) ..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 180 • A maximum of 10 units (2 blocks - 5 units) can be mounted within one rack. In that case, a heat baffle must be placed in the middle of the rack as shown in the figure below..............................................Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 181: Vertical Mounting (Amc, Ac
Mounting rules AMC units (AC powered) ..............................................Figure A-1 Vertical mounting (AMC, AC) ..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 183 Appendix B: Installation trouble shooting Overview Purpose This chapter provides basic installation troubleshooting information for the 1645 AMC system. Contents Power failure Installing the E software Parameters for E software installation Fiber cleaning Removing the SFP modules B-10 ..............................................365-313-103R8.0 Alcatel-Lucent –...
Page 184: Power Failure
“Switching on and testing supply voltage” (p. 5-3)). Procedure 1 should be used if the “Power” LED does not light up on the 1645 AMC unit. Procedure 2 should be used if the fans in the fan unit are not running. Procedure 1 Follow the steps below if the “Power”...
Page 185 E D OF STEPS S T E P S ...................................................................................... 365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 186: Installing The E Software
E........................................Click Edit. Result: The Edit E Software Configuration window appears........................................Click Download..............................................Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 187 MIB is compatible with the E software. ot retaining the MIB means that the E must be provisioned again with the new settings. Click Switch Result: A confirmation window appears........................................Click ..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 188: Parameters For E Software Installation
Backup store Shows the software load that is now stored in the backup store. The same codes are used as in the active store..............................................Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 189 Store Downloading Code is being downloaded to the memory. Store Inactive Memory contains valid code that is not being executed..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 190: Fiber Cleaning
Fiber cleaning Overview This procedure describes the Alcatel-Lucent recommended method for the cleaning and inspection of optical connectors using specific tools and materials that have been proven to be effective in the assembly and testing of optical transmission equipment. It is critical that the connector end faces are clean and free from particular contamination to assure proper performance and reliability of lightwave systems.
Page 191 Blow purified compressed air through the coupling and visually check for residual impurities by holding it in light. S T E P S ...................................................................................... 365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 192: Removing The Sfp Modules
........................................Grip the SFP transceiver with your fingers and pull it out. S T E P S ...................................................................................... B-10 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 193: Unlocking A Msa Latch (Type 1) Sfp
Press on top of the locking device and pull the SFP out with your fingers (see figure below). S T E P S ...................................................................................... 365-313-103R8.0 Alcatel-Lucent – Internal B-11 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 194: Unlocking A Msa Latch (Type 2) Sfp
Important! Do not pull the bail to get the transceiver out, as it might be torn away from the SFP. S T E P S ...................................................................................... B-12 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 195: Unlocking A Bail Latch (Type 1) Sfp
Important! Do not pull the bail to get the transceiver out, as it might be torn away from the SFP. S T E P S ...................................................................................... 365-313-103R8.0 Alcatel-Lucent – Internal B-13 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 196: Unlocking A Bail Latch (Type 2) Sfp
Installation trouble shooting Removing the SFP modules ..............................................Figure Figure B-4 Unlocking a bail latch (type 2) SFP ..............................................B-14 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 197 Purpose This appendix contains general cable assembly instructions. Contents SUB-D connector Coax connector (1.6/5.6) Mounting 4 × 2.5mm coax (75 Ω) to RJ45 connector ..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 198: Sub-D Connector
Insert the cable with the ferrule into the SUB-D connector........................................Close the connector by tightening the screws. S T E P S ...................................................................................... Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 199: Sub-D Assembly Steps
Turn the stripped end of the ground wire around the braid before soldering the ground wire to the braid. Refer to “Stripping and connecting a low frequency cable” (p. C-4). S T E P S ...................................................................................... 365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 200: Low Frequency Cable
The maximum power of the soldering iron is 50 W. If the temperature is adjustable, it should be adjusted to a maximum of 350°. S T E P S ...................................................................................... Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 201: Coax Connector (1.6/5.6
Crimp the outer ferrule with a hexagon die 4.6 — AGK 3068 by using the Crimp Tool — AGK 2365. S T E P S ...................................................................................... 365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 202: Ims Assembly Procedure
Cable assembly instructions Coax connector (1.6/5.6) ..............................................Result Figure C-3 IMS assembly procedure ..............................................Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 203: Crimp Tool And Die
Coax 1.6/5.6 connector (45°) Crimp tool Figure C-4 Crimp tool and die Legend: Crimp tool — AGK 2365 Hexagon die 4.6 — AGK 3068, or square 1.2 ..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 204: Mounting 4 × 2.5Mm Coax (75 Ω) To Rj45 Connector
Mount the teflon tube under the coax braid........................................Solder wires to the braid and core wire........................................Move the shrink tube over the soldered core wire..............................................Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 205 Position the wires with a liner block........................................Cut the wires to the appropriate length........................................Plug the wire ends into a RJ45 housing..............................................365-313-103R8.0 Alcatel-Lucent – Internal Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 206 S T E P S ........................................RJ45 connector It is recommended to use an RJ45 connector with EMC shield and strain relief as shown below (CC408899888)..............................................C-10 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 207: Rj45 Connector
Cable assembly instructions Mounting 4 × 2.5mm coax (75 ) to RJ45 connector ..............................................Figure C-5 RJ45 connector ..............................................365-313-103R8.0 Alcatel-Lucent – Internal C-11 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 209 Battery Distribution and Fuse Bay Bit Error Ratio (BER) The ratio of bits received in error to bits sent..............................................CATastrophic Cross-Connection, Cross-Connect CCITT See ITU-T..............................................365-313-103R8.0 Alcatel-Lucent – Internal GL-1 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 210 Digital Distribution Frame ..............................................Element Management System (EMS) See Integrated Transport Management Subnetwork Controller. Electromagnetic Compatibility Electromagnetic Interference Engineering Order Wire Electrostatic Discharge ..............................................GL-2 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 211 Local Area etwork Line Build Out - An optical attenuator that guarantees the proper signal level and shape at the receiver input. Light Emitting Diode ..............................................365-313-103R8.0 Alcatel-Lucent – Internal GL-3 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 212 A etwork Element has one or more standard Q-type interfaces. Node A node or network element is defined as all equipment that is controlled by one system controller..............................................GL-4 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 213 Personal Computer Printed Circuit Board ..............................................365-313-103R8.0 Alcatel-Lucent – Internal GL-5 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 214 A signal of a specific rate (2 Mbit/s, 34 Mbit/s, 140 Mbit/s, VC12, VC3, VC4, STM-1 or STM-4) that may be added to or dropped from a line signal..............................................GL-6 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 215: Alcatel-Lucent - Internal
Glossary ............................................................................................Unshielded Twisted Pair ..............................................365-313-103R8.0 Alcatel-Lucent – Internal GL-7 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 217 E provisioning and stand X5IP card), 4-29 DS1 connector (Main board / alone installation test, X16DS1 card), 4-24 MDI/MDO connector, 4-13 physical and power installation, ..............................................365-313-103R8.0 Alcatel-Lucent – Internal IN-1 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...
Page 218 6-20 BER, power failure, E software download, 6-8, cable connections, Power interfaces network cabling, fan unit, AC connector, ode creation, 6-17 remote login, ..............................................IN-2 Alcatel-Lucent – Internal 365-313-103R8.0 Proprietary – Use pursuant to Company instruction Issue 2 July 2009...
Page 219 Index ..............................................supply voltage, transmission stability, test equipment, 2-11 tools, 2-11 troubleshooting fiber cleaning, power failure, software download failure, ............. warning symbols, ..............................................365-313-103R8.0 Alcatel-Lucent – Internal IN-3 Issue 2 July 2009 Proprietary – Use pursuant to Company instruction...

Alcatel-Lucent 1645 AMC Installation Manual

List of Tables

6 6 I Tm-Cit Installation and Ne Provisioning

7 S Tand-Alone Test7 Procedures

8 L Ink Testing8

Appendix B: Installation Trouble Shooting

Appendix C: Cable Assembly Instructions

Quick Links

Chapters

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alcatel-Lucent 1645 AMC

Summary of Contents for Alcatel-Lucent 1645 AMC

Table of Contents
