Installation Manual
Alcatel-Lucent
1645 AMC Access
Mutiplexer Compact
Cost-effective and compact
STM-1/4 multiservice metro access
Advertisement
Related Manuals for Alcatel-Lucent 1645 AMC
Summary of Contents for Alcatel-Lucent 1645 AMC
- Page 1 Alcatel-Lucent 1645 AMC Access Mutiplexer Compact Cost-effective and compact STM-1/4 multiservice metro access...
- Page 2 (OPEX). Supporting fiber and copper, the 1645 AMC transports metro and access traffic to the network edge, using both optical and electrical interfaces.
- Page 3 TDM and Ethernet services. With versatile and robust management capabilities, it offers flexible instal- lation options. Enterprises can use the 1645 AMC to build and operate their own optical networks, using leased or owned fiber. Key benefits • Eliminates the need for overlay networks • Enhances revenue-generating capabilities while reducing OPEX...
- Page 4 (VPNs). No overlay networks Available in STM-4 configurations, the 1645 AMC provides a wide range of interfaces, including private-line and switched Ethernet capabilities. It is an economical, multiservice unit that transports metro and access...
- Page 5 LAN-to-LAN communication on campus and through VPNs. The 1645 AMC, an economical, multiservice device, allows next- generation services over a legacy SDH network, leveraging existing service-provider assets. Alcatel-Lucent 1645 AMC Access Mutiplexer Compact...
- Page 6 Figure 1. 1645 AMC supporting a typical metro-access application STM-4 (STM-16/64) 1850 TSS 16XX OMSN 1350 OMS 10/100/1000 E1, E3, DS3, STM-1 Ethernet 1643 AMS 1645 AMC PABX switch Alcatel-Lucent 1645 AMC Access Mutiplexer Compact Cost-effective TDM, IP and Ethernet...
-
Page 7: Installation Flexibility
Extended Ethernet services When deploying the optional Alcatel-Lucent TransLAN Card, the 1645 AMC supports a diverse mix of standar- dized Ethernet services. Depending on the TransLAN Card selected, the 1645 AMC provides the following capabilities: • Full Layer 2 switching functionality: point-to-point and point-to-multipoint • Virtual concatenation (VCAT) and generic framing procedure (GFP) • Institute of Electrical and Electronics Engineers... - Page 8 Either the Alcatel-Lucent 1350 Optical Management System (OMS) or a PC-based, Graphical User Interface (GUI) craft terminal can be used to manage the 1645 AMC. When the OMS is deployed, the 1645 AMC communicates through an embedded communications channel. The PC-based craft interface...
- Page 9 When fiber access is available, the 1645 AMC can be installed directly as CPE. If the last mile to the customer must be bridged through copper, the 1645 AMC provides an SHDSL option card. As a result, E1 over copper or 10/100BASE-T Ethernet access through up to four combined SHDSL copper lines can be served.
- Page 10 • STM-1 L-1.1 (long haul) • STM-1 L-1.2 (long haul) Equipped with 16 2 Mb/s (E1) G.703 tributary interfaces, an optional card can expand the 1645 AMC to a maxi- mum of 32 interfaces. In accordance with G.704 and I.431, support of Integrated Services Digital Network (ISDN) modes is also available.
- Page 11 Alcatel-Lucent facilitates its customers’ service offerings and revenue streams. As the recognized world leader in optical networking, Alcatel-Lucent is in a unique position to help service providers navigate through current market conditions. Alcatel-Lucent, with its global reach and scale,...
- Page 12 Alcatel, Lucent, Alcatel-Lucent and the Alcatel-Lucent logo are trademarks of Alcatel-Lucent. All other trademarks are the property of their respective owners. The information presented is subject to change without notice. Alcatel-Lucent assumes no responsibility for inaccuracies contained herein. © 2008 Alcatel-Lucent. All rights reserved. CAR2468080102 (05)
