TABLE SAW

2000W 254mm

INSTRUCTION MANUAL

SPECIFICATIONS

Motor:
2000W (S6 40%) 1800W (S1)
Input:
230-240V ~ 50Hz
No Load Speed:
4,250/min
Blade:
Ø254mm x Ø30 x 2.8mm
Blade Teeth:
24 TCT
Bevel Angle:
0º-45° left
Blade Height Adj: 0-80mm
Max. Cutting Capacity:
Bevel 90°:
80mm
Bevel 45°:
53mm
Table Size:
638 x 430mm
With Side Ext.:
638 x 730mm
Rear Extension:
390 x 190mm
Dust Port:
Ø36mm
Weight:
19.5kg
ozito.com.au
IN ORDER TO MAKE A CLAIM UNDER THIS
WARRANTY YOU MUST RETURN THE PRODUCT
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO
Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
WARRANTY
The benefits provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer
service helpline above.
3 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from
the original date of purchase. If a product is defective it will
be replaced in accordance with the terms of this warranty.
Warranty excludes consumable parts, for example: blade,push stick,
spanners, bearings & carbon brushes.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other
than that specified on the tool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the
instruction manual.
• If the tool is disassembled or tampered with in any way.
• Professional, industrial or high frequency use.
WHAT'S IN THE BOX
Sliding Mitre
Rip Fence
Gauge
Table Extensions x 3
Cutting Blades x 3
Blade Guard & Riving Knife
Push Stick
Base Frame Components
Assembly Fasteners
TBS-2000
1117

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TBS-2000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ozito TBS-2000

  • Page 1: Table Saw

    Weight: 19.5kg ozito.com.au Base Frame Components Assembly Fasteners TBS-2000 WARRANTY IN ORDER TO MAKE A CLAIM UNDER THIS The benefits provided under this warranty are in addition to other rights and remedies which are available to you at law. WARRANTY YOU MUST RETURN THE PRODUCT...
  • Page 2: Know Your Product

    KNOW YOUR PRODUCT SETUP & PREPARATION TABLE SAW 1. ADJUSTMENTS 1 Side Table Extension 9 Push Stick 2 Sliding Mitre Gauge 10 Table Insert For detailed assembly instructions see Assembly Manual. 3 Rear Table Extension 11 ON/OFF Switch 4 Blade Guard 12 Bevel Lock WARNING! ENSURE THE TOOL IS SWITCHED OFF AND...
  • Page 3: Setting The Rip Fence

    2. SETTING THE RIP FENCE Rip Fence Stop Height 1 Loosen the rip fence lever and The rip fence supplied with the table saw has two different guide faces. insert the fence onto the table 1 for thick material and 1 for thin material. guide rail.
  • Page 4: Operation

    OPERATION 3. SETTING THE MITRE GAUGE 4. USING THE TABLE SAW Using the Sliding Mitre Gauge CAUTION! TO REDUCE THE RISK OF ELECTRICAL The sliding mitre gauge can be fitted into 1 of the 2 grooves in the table SHOCK, THE USE OF A RESIDUAL CURRENT DEVICE and can be used to easily perform mitre angle cuts. (RATED 30mA OR LESS) IS RECOMMENDED.
  • Page 5: Making A Cut

    5 Push the sliding mitre gauge forward until the workpiece is cut all the way through. 6 Switch off the saw again. Do not remove the off-cut until the blade has stopped rotating. TBS-2000...
  • Page 6: Maintenance

    OPERATION MAINTENANCE 6. ADJUSTING THE RIVING KNIFE 7. BLADE REPLACEMENT Setting the Riving Knife Fitting / Replacing the Blade Note: Note: The riving knife helps to prevent kickback and should be checked This product is designed for 254mm saw blades for timber each time the blade is replaced.
  • Page 7: Description Of Symbols

    5 T o fit the replacement table your local Bunnings Warehouse. insert, proceed in reverse For further information, or any parts not listed here, visit order. www.ozito.com.au or contact Ozito Customer Service: Australia 1800 069 486 New Zealand 0508 069 486 E-mail: enquires@ozito.com.au ADDITIONAL INFORMATION Operating mode S6 40%: Continuous operation with idling (cycle time 10 minutes).
  • Page 8: Electrical Safety

    Replace the extension lead if damaged or defective. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the power input of the tool or which is damaged or defective may result in a risk of fire and electric This tool is double insulated therefore no earth wire is required.
