MP522 Microphone / Line
1. INTRODUCTION
The MP522 preamp was designed for use with Ampetronic Induction Loop
drivers, but can be used in other applications as a separate seven input
pre-amp. The unit is designed to amplify five microphone channels by a
maximum of 46 dB, and two line-level inputs by 6 dB.
Each channel has an electronically balanced input. Microphone channels
use XLR input connectors, with phantom power facility. Balanced line-level
inputs use 6.3 mm jack sockets. A gain control is provided for each channel,
and the combined output signal is electronically balanced.
Power for the preamp is normally obtained from the host Ampetronic
amplifier, but the unit can be powered from a small, separate power supply,
Ampetronic type PS3.
2. INSTALLATION
The unit is designed to be used in a clean and professional environment. If
used with the ILD122 range of loop drivers, the preamp can be installed in
the RM-1U rack mount kit with the correct blanking plate.
3. TECHNICAL SPECIFICATION
Microphone input
Connector: XLR
Channel gain: 31 dB or 46dB, at max gain position.
Rear panel selection.
Frequency response: ±1 dB 20 Hz - 20 KHz.
Input overload: -10 dBu or -25dBu,
gain selection dependent
Input noise level: -127dBu, 200
Input impedance: 5 k .
Phantom power: selectable 0V/15V
Preamplifier
source
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ampetronic MP522
Summary of Contents for Ampetronic MP522
- Page 1 MP522 Microphone / Line Preamplifier 1. INTRODUCTION The MP522 preamp was designed for use with Ampetronic Induction Loop drivers, but can be used in other applications as a separate seven input pre-amp. The unit is designed to amplify five microphone channels by a maximum of 46 dB, and two line-level inputs by 6 dB.
- Page 2 Line-level input Connector: 6.3mm 3-pole jack socket Channel gain: 6 dB at max gain position. Frequency response; ±1 dB 20 Hz - 20 KHz. Input overload: +20dBu Input impedance: each side 1M to common, fully balanced input. Can be used unbalanced. Output Connector: 6.3mm 3-pole jack socket.
-
Page 3: Warranty Information
This product carries a 5 year parts and labour warranty which could be invalidated if these instructions are not followed correctly, or the unit is tampered with in any way. The 5 year warranty is dated from the time the equipment leaves Ampetronic and NOT when it is installed. - Page 4 MP522 Remote Switching Connector Wiring Diagram Pin Number Function Microphone 1 Microphone 2 Microphone 3 Wiring-side view of Microphone 4 8-pin Mini Din Plug Microphone 5 Line Input 1 Line Input 2 Common Selection of Channel A, or B, or both simultaneously as shown below.
