This symbol is used to alert the user to important
operating or maintenance instructions.
The Lightning bolt triangle is used to alert the user
to the risk of electric shock.
SAFETY:
1. It is important to read these instructions, and to follow them.
2. Keep this instruction manual in an accessible place.
3. Clean only with a dry cloth. Cleaning fluids may affect the equipment.
4. Do not cover or obstruct ventilation of this unit. Install in accordance with the
manufacturer's instructions.
5. Do not install near any heat sources such as radiators, heating vents, or other
apparatus that produces heat.
6. Refer all servicing to qualified personnel. Servicing is required when the
apparatus has been damaged in any way, such as a power supply cord or
plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to any rain or moisture, does not
operate normally or has been dropped.
7. WARNING - To reduce risk of fire or electric shock, do not expose this
apparatus to rain or moisture. The apparatus shall not be exposed to dripping
or splashing and no objects filled with liquids, such as vases, shall be placed
on the apparatus.
ILD100DC HANDBOOK
Box Contents
1 x ILD100DC
1 x Installation & Commissioning
Handbook
1 x Power Cable
1 x Designing Induction Loops Handbook
1 x AC to 12V Power Adapter
1 x A6 Induction Loop Logo
1 x DC PSU Handbook
1 x Drilling Template
DC
Advertisement
Table of Contents
Related Manuals for Ampetronic ILD100DC
Summary of Contents for Ampetronic ILD100DC
- Page 1 ILD100DC HANDBOOK Handbook Contents Box Contents Safety 1 x ILD100DC Introduction 1 x Installation & Commissioning Quick Start Handbook Overview 1 x Power Cable Installation 1 x Designing Induction Loops Handbook Troubleshooting 1 x AC to 12V Power Adapter Accessories...
-
Page 2: Quick Start
TV rooms, nursing homes, private homes, reception and waiting rooms. The ILD100DC can cover areas up to 120m for a square loop and greater than 200m for a rectangular loop configuration. The ILD100DC has two microphone inputs suitable for electret microphones and twin Phono line inputs suitable for direct connection to a TV set via SCART style connection, or connection to a Hi-Fi system. - Page 3 Loop Current Power DRIVE TONE For Mode Switch settings see the Instruction Handbook 100DC INDUCTION LOOP DRIVER Designed and Manufactured in England by AMPETRONIC Ltd. Power 20W max 12V DC LOOP RESISTANCE 0.2 - 0.8 LOOP POWER Š...
- Page 4 OVERVIEW cont’d MICROPHONE inputs: 3.5mm mono jack connectors. LINE input: Twin RCA (Phono) connectors, for stereo connection. VOX MODE SWITCH: Switches 1,2 & 3. ILD100DC Block diagram...
-
Page 5: Installation
The maximum DC resistance of the loop should be greater than 0.2W optimum performance, but should be less than 0.8 W " The cable from the loop to the ILD100DC output terminals MUST be a twisted pair. If this is longer than 10 metres, contact Ampetronic. Tools & Equipment: "... - Page 6 Dynamic microphones cannot normally be used with the equipment because of the much lower signal level, also the DC bias seriously impairs the performance of the microphone. Ampetronic can supply a special adaptor which permits the use of dynamic microphones (and electrets which are affected by the DC bias).
- Page 7 (e.g Ampetronic ILR3), or examine the performance in more detail with a suitable field strength meter. From this point onwards, the DRIVE control will not need re-adjusting, as this only affects the peak field strength. Connect the cable from the audio system to the line input, and re-adjust the input gain control for optimum compression.
- Page 8 Voice Controlled switching (VOX) There are 3 MODE select switches for the VOX switching features of the ILD100DC. These switches are located on the top edge of the unit alongside the input connectors. See Overview. The MODE select switches enable their respective functions when in the 'ON' position (the switch is down, towards the base of the unit).The mode select switches may be used in the...
-
Page 9: Troubleshooting
TROUBLESHOOTING No power LED: Check that power has been connected to the unit and the POWER is switched on (I/0 button pressed in). Check Mains power connector fuse. Check Mains power is available at the socket. No Compression LED: Check that a microphone or signal source is connected and the corresponding input control has been set. - Page 10 3-wire balanced circuits & keep away from loop cables. See also point 1 of Instability. ACCESSORIES Details of all products & services provided by Ampetronic can be found at www.ampetronic.com Desktop Microphone EM195A, or Boundary Microphone Q400, or Tieclip style Microphone EM336, are available if required.
-
Page 11: Technical Specifications
Meets relevant CE, EMC and Twin RCA (phono) inputs. safety standards. Input Impedance: 20kW between each input 60kW single input. Please contact Ampetronic if you Sensitivity: -30dBu (24mV need further assistance. for full output. Overload: >+10dBu (2.45V Compression (AGC): >36dB dynamic range. -
Page 12: Warranty
WARRANTY This product carries a five year parts and labour warranty from date of shipment from Ampetronic. To qualify for the five year warranty, the product must be registered at www.ampetronic.com (products/warranty), without which the warranty will be valid for two years only.
