Planet ENW-9600SX User Manual

1000base-sx pci bus gigabit ethernet adapter

Advertisement

Quick Links

User' s Guide
1000Base-SX PCI Bus Gigabit Ethernet Adapter
ENW-9600SX

Advertisement

loading
Need help?

Need help?

Do you have a question about the ENW-9600SX and is the answer not in the manual?

Questions and answers

Summary of Contents for Planet ENW-9600SX

  • Page 1 User’ s Guide 1000Base-SX PCI Bus Gigabit Ethernet Adapter ENW-9600SX...
  • Page 2 FCC Information The Federal Communication Commission Radio Frequency Interference Statement includes the following paragraph: This equipment has been tested and found to comply with the limits for a Class B Digital Device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 3 Limited Warranty In no event will Planet be liable for any damage, including loss of data or profits, cost of cover, or other incidental, consequential or indirect damages arising from the installation, maintenance, use, performance, failure or interruption of Planet’s products, whatever caused and on...
  • Page 4 CONTENTS INTRODUCTION ................1 PACKAGE CONTENTS..............2 HOW TO USE THIS GIGABIT ETHERNET ADAPTER....2 SPECIFICATION................10...
  • Page 5: Introduction

    INTRODUCTION Thanks for your purchase of this Gigabit Ethernet LAN adapter. It is fully compliant with the IEEE802.3 standard. With the features like 1000Mbps Gigabit Ethernet, full/half duplex mode transmission, it offers users a high performance network. Features • IEEE802.3z and IEEE802.3x Standard Compliant •...
  • Page 6: Package Contents

    PACKAGE CONTENTS PCI 1000Mbps Gigabit Ethernet Adapter USERS MANUAL DRIVER DISKETTE Adapter Driver MANUAL THIS GIGABIT ETHERNET ADAPTER Follow the instructions in this section for installing the Gigabit Ethernet adapter in your system. Make sure your system meets the system requirements. Shut down and power off your system.
  • Page 7 Turn on your system power. In the driver diskette in which is provided by vendor, the file name is “install.txt”, read this file carefully, there are more detail information. Windows NT 4.0 installation procedure Installing the Windows NT 4.0 NDIS4 Device Driver Users’...
  • Page 8 Clicks “Have Disk… ” button to use the driver diskette provided by vendor. Type a correct path for the Gigabit Adapter and click “OK”.
  • Page 9 The system will copy some of files. Users may need to prepare the Windows NT4.0 CD. And the system will successfully install the Gigabit adapter driver. After copy the driver, the screen will show up the Gigabit adapter model name and then click “OK”. 10.
  • Page 10 NetWare 4.11 ODI Device Driver installation After users had plugged the Gigabit adapter into the system, make sure the system match the minim system requirement. Power on system and reboot into NetWare 4.11 console prompt At the NetWare console prompt enter the command “load install” to start the install utility.
  • Page 11 Select the “Configure Network Drivers” menu item and press enter. The Additional Driver Actions dialog box is displayed. Insert the driver diskette that support by vendor and select a driver. Select the Load an additional driver menu item option and press enter. The “Select a driver”...
  • Page 12 Specify the path for the drivers. 10. Press “enter” to select the JT1ODI.LAN from the Select a driver to install dialog box. A message asking if you want to copy the driver is displayed. Select Yes to continue. The device driver is copied. 11.
  • Page 13 12. .Select the Save Parameters and Load Driver option and press enter to continue. 13. .Select No when asked if you want to load additional drivers 14. .On the Additional Driver Actions dialog box, select Return to previous menu and press Enter to continue 15.
  • Page 14: Specification

    LINK DATA * Link up is a *Blinking in green means data packet ON/BLINK green light. being transmitted or received. *Power off. *Power off. *Link down. * No data packet being transmitted or received. Table 1. Status of the indicators SPECIFICATION ITEM DESCRIPTION...
