  • Page 1 User’s Manual ENW-9801 ENW-9802 PCI-E Dual / Single Port 10 Gigabit Ethernet Adapter...

  • Page 2: Fcc Caution

    Copyright Copyright  PLANET Technology Corp. 2012. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of PLANET.

  • Page 3: Table Of Contents

    Table of Contents CHAPTER 1 INTRODUCTION ..................... 4 1.1 Package Content..........................4 1.2 Features ............................4 1.3 Gathering Tools and Documentations .................... 4 CHAPTER 2 HARDWARE INSTALLATION ................ 5 2.1 LED Definitions..........................5 2.2 Hardware Installation........................6 CHAPTER 3 DRIVER INSTALLATION ................7 3.1 Installing Driver to Windows Server 2003/2003R2 .................

  • Page 4: Chapter 1 Introduction

    PLANET ENW-9801 / ENW-9802 to connect your servers and workstations guarantees extremely high throughput and excellent signal quality. The ENW-9801 / ENW-9802 is a PCI Express dual / single port 10 Gigabit Ethernet adapter designed to address high-performance system application requirements. With the higher bandwitdh of x8, x4 PCI Express Bus Architecture, ENW-9801 / ENW-9802 can provide better performance than the network cards which base on 32 / 64bit PCI architecture.

  • Page 5: Chapter 2 Hardware Installation

    Chapter 2 Hardware Installation 2.1 LED Definitions The faceplate of ENW-9801 has one LED: Link / ACT. The pictures below have showed the faceplate of ENW-9801. Table 2-1 explains the function and state of the LED. Link / ACT LED...

  • Page 6: Hardware Installation

    Lights to indicate a functional network link through the port. Blinks to indicate data has been sending and receiving via the port. Table 2-1 Descriptions of ENW-9801 / ENW-9802 LED 2.2 Hardware Installation Step 1: Please turn off your PC.

  • Page 7: Chapter 3 Driver Installation

    Chapter 3 Driver Installation A device driver must be installed before your ENW-9801 / ENW-9802 can be used with your computer. This chapter describes how to install the driver for various operating systems. Before you begin the driver installation process, make sure you have the installation disks for your computer’s operation system.
  • Page 8 Win2003R2 will show you this dialog box to prompt you the driver is not digitally signed by Microsoft, please press “ Continue Anyway” to continue.
  • Page 9 Please click “ Finish ” to complete the driver installation.

  • Page 10: Installing Vlan Support Driver To Windows Server 2003/2003R2

    3.2 Installing VLAN Support Driver to Windows Server 2003/2003R2 The following installation uses ENW-9801 and operates under Window2003R2. The ENW-9802 installation procedure is the same with ENW-9801. Open Network Connection properties by Start\Settings\Control Panel\Network Connections then click “ Install ” Button.
  • Page 11 Select "Protocol" and click " Add ” button In "Select Network Protocol" window click " Have Disk ” Button Press “ Browse ” to specify ENW-9801 VLAN driver location to install. (Assume "E" is your CD-ROM drive, you can find ENW-9801 driver in E:\planet_NIC10G\3.23\tools\vlan\W2003).
  • Page 12 In "Select Network Protocol" window select "PLANET 10GbE Server Adapter VLAN Protocol Driver" Win2003R2 will show you this dialog box to prompt you the driver is not digitally signed by Microsoft, Pease press “ Continue Anyway” to continue.
  • Page 13 Wait a moment or more until "Select Network Protocol" window is closed and installation is completed...

  • Page 14: Chapter 4 Specifications

    Chapter 4 Specifications ENW-9801 ENW-9802 Product Hardware Specification PCI Express Host Bus Interface, 8 lanes / 4 lanes Attachment Interface PCI Express Rev 1.1a 1 SFP+ Media Interface 1 SFP+ 1 CX4 Optical Module Options LRM, LR, SR Memory 3Mb internal memory...
