Page 2: Safety Information
OXY5313A 3.5” SBC User’s Manual Safety information Electrical safety To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. -
Page 3: Revision History
OXY5313A 3.5” SBC User’s Manual Revision History Revision Date (dd.mm.yyyy) Changes Version 1.0 31.07.2011 Initial release Version 1.1 05.09.2011 Updated Packing list for Cable Modified 3P Clear CMOS to 2P Removed JUSB_01 Removed JCOMPWR1-6 Packing list □... -
Page 4: Table Of Contents
OXY5313A 3.5” SBC User’s Manual Table of Contents Safety information ..............................i Electrical safety ............................ii Operation safety ............................ii Statement ..............................ii Revision History ............................iii Packing list ..............................iii Chapter 1: Product Information ........................ 7 1.1 Block Diagram ............................ 7 1.2 Key Features ............................ - Page 5 OXY5313A 3.5” SBC User’s Manual SATA 1(LBA/Large Mode) ........................25 SATA 1(DMA Mode) ..........................26 SATA 2 Setup ............................27 SATA 2(LBA/Large Mode) ........................27 SATA 2(LBA/Large Mode) ........................28 S.M.A.R.T for SATA 2..........................28 CF Setup ..............................29 CF setup(LBA/Large Mode) ........................29 CF (DMA Mode) ............................
- Page 6 OXY5313A 3.5” SBC User’s Manual 4.9 Exit Setting ............................57 Save Changes and Exit .......................... 57 Discard Changes and Exit ........................59 Discard Changes ............................ 60 Load Optimal Defaults ..........................61 Load Failsafe Defaults ..........................62 APPENDIX A Watchdog Timer Setting ......................63...
-
Page 7: Chapter 1: Product Information
OXY5313A 3.5” SBC User’s Manual Chapter 1: Product Information 1.1 Block Diagram... -
Page 8: Key Features
OXY5313A 3.5” SBC User’s Manual 1.2 Key Features Processor & System CPU Type Intel Atom Pineview D D525 CPU onboard (45nm,1.8Ghz , 1M L2 Cache) Chipset Intel® ICH8M Memory Type DDR3 800 SO-DIMM(Max is 2GB) BIOS 8MB SPI Flash Super I/O... -
Page 9: Board Placement
OXY5313A 3.5” SBC User’s Manual COM1 belongs to D-Sub 9pin and supports RS- 232/422/485) COM2~COM8 belongs to 10pin Wafer connector and supports RS232 only SPDIF 1x5 Pin header Digital I/O 2x5 Pin header (4in and 4 out) Parallel port 2x13 Pin Box header... -
Page 10: Onboard Connector List
OXY5313A 3.5” SBC User’s Manual 1.4 Onboard Connector List Label Function MPCIE1 Mini PCIe Connector ATX2 Power Input Connector DIO1 Digital Input / Output Pin Header COM2 RS-232 Port B With Power Wafer COM3 RS-232 Port C With Power Wafer... -
Page 11: Mechanical Drawings
OXY5313A 3.5” SBC User’s Manual 1.5 Mechanical Drawings... -
Page 12: Jumper Settings
OXY5313A 3.5” SBC User’s Manual Chapter 2: Jumpers and Connectors 2.1 Jumper Settings JCMOS1: Clear CMOS Jumper Setting Jumper Function description Setting Normal Operation Clear CMOS *Default setting is 1-2* PSON1: ATX/AT mode Selection Jumper Function description Setting AT Mode... -
Page 13: Onboard Connector Pin Assignment
OXY5313A 3.5” SBC User’s Manual 2.2 Onboard Connector Pin Assignment MPCIE1 Mini PCIE slots V1.2 Signal Name Pin Pin Signal Name PCIE_WAKE# *+3.3VSB +1.5V UIM_PWR UIM_DATA CLK100_MPCIE1#/2# 11 UIM_CLK CLK100_MPCIE1/2 UIM_RESET UIM_VPP MPCIE1/2_EN RST_PCIE# PCIE_RX2-/3- +3.3VSB PCIE_RX2+/3+ +1.5V SB_SMB_CLK PCIE_TX2-/3-... -
Page 14: Atx1 Dc Power Input Connector
OXY5313A 3.5” SBC User’s Manual ATX1 DC Power Input Connector Pin Signal Pin Signal +12V +12V 2x2 pin power connector with 90 degrees (Optional feature for OXY5313A/OXY5315A) Digital I/O Pin Header Signal Signal Digital Output 0 Digital Input 0 Digital Output 1... -
Page 15: Com5~8 Rs-232 Port Wafer
OXY5313A 3.5” SBC User’s Manual COM5~8 RS-232 Port Wafer Pin Signal DCD, Data carrier detect DSR, Data set ready RXD, Receive data RTS, Request to send TXD, Transmit data CTS, Clear to send DTR, Data terminal ready RI Ring GND, ground... -
Page 16: Audio1 Audio Output Wafer
OXY5313A 3.5” SBC User’s Manual AUDIO1 Audio Output Wafer Pin Signal LOUT_R LOUT_L LIN_R LIN_L AMP_R1 Audio AMP Right Output Wafer Pin Signal Name Speaker+ Speaker- AMP_L1 Audio AMP Left Output Wafer Pin Signal Name Speaker+ Speaker- DDR3_1 DDR3 Memory DIMM Slot... -
Page 17: Fd1 Cf Type Ii Connector
OXY5313A 3.5” SBC User’s Manual FD1 CF Type II Connector Signal Name Pin Pin Signal Name IDE Data 3 IDE Data 11 IDE Data 4 IDE Data 12 IDE Data 5 IDE Data 13 IDE Data 6 IDE Data 14... -
Page 18: Fp2 Front Panel 2 Pin Header
OXY5313A 3.5” SBC User’s Manual FP2 Front Panel 2 Pin Header Pin Signal Pin Signal Speaker + SMBus Clock SMBus Data - Internal Speaker- 6 Speaker - Keyboard Lock SATAI1, SATA2 Serial ATA 2.0 Connector Pin Signal Name USB2,USB3,USB4 USB2.0 Pin Header... -
Page 19: Jlvds1 18 Bit Lvds Panel Connector
OXY5313A 3.5” SBC User’s Manual JLVDS1 18 bit LVDS Panel Connector Pin Signal Name Pin Signal Name +3.3V +3.3V LVDS_A0- LVDS_A1- LVDS_A0+ LVDS_A1+ LVDS_A2- LVDS_CLK- LVDS_A2+ LVDS_CLK+ DDC_DAT +12V DDC_CLK +12V KBMS1 KB/MS Pin Header Signal Signal KBDAT MSDAT KBCLK... -
Page 20: Lan1 , Lan2 10/100/1000 Ethernet Rj-45 Connector
OXY5313A 3.5” SBC User’s Manual LAN1 , LAN2 10/100/1000 Ethernet RJ-45 Connector Pin Signal VGA1 CRT DB-15 Connector Signal Name Pin Pin Signal Name Green Blue DDC data HSYNC VSYNC DDC clock USB1 2-Stack USB2.0 Type A Connector Pin Signal Name Pin Signal Name... -
Page 21: Chapter 3: Getting Started
OXY5313A 3.5” SBC User’s Manual Chapter 3: Getting Started This chapter provides information on how to install components to the OXY5313A. Specifically, the installation of memory modules and operating system are explained. 3.1 Installing System Memory The OXY5313A supports DDR3 800 SO-DIMM. -
Page 22: Driver Installation
OXY5313A 3.5” SBC User’s Manual 3.3 Driver Installation The OXY5313A drivers for Windows XP 32-bit are located in the following directories on the Driver CD or can be downloaded from the Perfectron website (http://www.perfectron.com): Follow the instructions below to install the required OXY5313A drivers: 1. -
Page 23: Chapter 4: Ami Bios Utility
OXY5313A 3.5” SBC User’s Manual Chapter 4: AMI BIOS UTILITY This chapter provides users with detailed descriptions on how to set up a basic system configuration through the AMIBIOS8 BIOS setup utility. 4.1 Starting To enter the setup screens, perform the following steps: ... -
Page 24: Main Menu
OXY5313A 3.5” SBC User’s Manual 4.3 Main Menu The Main menu is the screen that first displays when BIOS Setup is entered, unless an error has occurred. You could setup these items on the Main menu: System T i m e : S e l e c t t h i s o p t i o n t o s e t t h e s y s t e m t i m e . -
Page 25: Sata 1 Setup
OXY5313A 3.5” SBC User’s Manual SATA 1 Setup BIOS will automatically detect the presence of a SATA HDD. SATA 1(LBA/Large Mode) -
Page 26: Sata 1(Dma Mode)
OXY5313A 3.5” SBC User’s Manual In order for LBA to work, it must be supported by the BIOS and operating system, but since it is also a new way of talking to the hard disk, the disk must support it as well. All newer hard disks do in fact support LBA, and when auto-detected by a BIOS supporting LBA, will be set up to use that mode. -
Page 27: Sata 2 Setup
OXY5313A 3.5” SBC User’s Manual SATA 2 Setup BIOS will automatically detect the presence of a SATA HDD SATA 2(LBA/Large Mode) (The default BIOS setting for LBA/Large Mode is Auto) -
Page 28: Sata 2(Lba/Large Mode)
OXY5313A 3.5” SBC User’s Manual SATA 2(LBA/Large Mode) (The default BIOS setting for DMA mode is Auto) S.M.A.R.T for SATA 2 (The default BIOS setting for S.M.A.R.T is Auto) -
Page 29: Cf Setup
OXY5313A 3.5” SBC User’s Manual CF Setup BIOS will automatically detect the presence of a CF card CF setup(LBA/Large Mode) (The default BIOS setting for LBA/Large mode is Auto) -
Page 30: Cf (Dma Mode)
OXY5313A 3.5” SBC User’s Manual CF (DMA Mode) DMA (Direct memory access) mode is a high performance mode for transferring data to and from devices, The burner devices can function in either DMA or PIO modes. DMA mode allows the processor to transfer large pieces of data with very little software overhead - therefore requiring low CPU utilization. -
Page 31: For Cf
OXY5313A 3.5” SBC User’s Manual S.M.A.R.T for CF S.M.A.R.T. ( Self-Monitoring, Analysis and Reporting Technology; sometimes written as SMART) is a monitoring system for computer hard disk drives to detect and report on various indicators of reliability, in the hope of anticipating failures. -
Page 32: System Information
OXY5313A 3.5” SBC User’s Manual System Information You can review the system information in the BIOS System Information menu. -
Page 33: Advanced Menu
OXY5313A 3.5” SBC User’s Manual *OXY5313A contains an incorporated Intel D525 CPU onboard/OXY5315A contains an incorporated Intel N455 CPU onboard* 4.4 Advanced Menu Onboard I/O Configuration... - Page 34 OXY5313A 3.5” SBC User’s Manual You could setup the IRQ and IRQ address for the OXY5315A. This line of 3.5” SBC supports 8xCOM Ports (COM1 Port belongs to D-Sub 9pin and supports RS232/422/485. COM2~COM8 belongs to the 1x10 pin wafer...
-
Page 35: Onboard Peripherals Configuration
OXY5313A 3.5” SBC User’s Manual Onboard Peripherals Configuration USB Function You could enable or disable the onboard USB functions and/or USB 2.0 Controller. -
Page 36: Usb Device Legacy Support
OXY5313A 3.5” SBC User’s Manual USB Device Legacy Support Legacy mode support is inherent to a system and is typically provided by legacy hardware interface emulation. Legacy mode support allows devices to function in an operating environment. (The default BIOS setting for USB Legacy support is Enabled) -
Page 37: Onboard Lan1 Controller
OXY5313A 3.5” SBC User’s Manual This setting enables or disables the onboard Audio Controller. (The default BIOS setting for Audio Controller default is Enabled) Onboard LAN1 Controller This setting enables or disables the OnBoard LAN1 Controller. Onboard LAN1 OPTROM... -
Page 38: Onboard Lan2 Controller
OXY5313A 3.5” SBC User’s Manual This setting enables or disables the Onboard LAN1 OPTROM setting. (The default BIOS setting for Onboard LAN1 OPTROM is Disabled) Onboard LAN2 Controller This setting enables or disables the Onboard LAN2 Controller. Onboard LAN2 OPTROM... -
Page 39: Onboard Mini-Pcie Controller
OXY5313A 3.5” SBC User’s Manual This setting enables or disables the Onboard LAN2 OPTROM. (The default BIOS setting is Disabled) Onboard Mini-PCIE Controller This setting enables or disables the Onboard Mini-PCIE Controller. -
Page 40: On-Chip Ata Devices
OXY5313A 3.5” SBC User’s Manual On-Chip ATA Devices This setting contains two sub-menus. Press Enter to access the secondary menu. The secondary menu has two settings: ATA/IDE Configuration This setting enables or disables the ATA/IDE Configuration. -
Page 41: Configure Sata As
OXY5313A 3.5” SBC User’s Manual Configure SATA as This setting allows the most important peripheral equipment. The menu options are: IDE and AHCI *IDE: The function provides the bridge for the IDE to SATA hard disk drive function. *AHCI: This supports a SATA 3GB connection and supports NCQ and e-... -
Page 42: Hardware Health Configuration
OXY5313A 3.5” SBC User’s Manual Hardware Health Configuration The Hardware Health Configuration setting displays the system hardware details such as CPU Warning Temperature, CPU Temperature, System Temperature, CPU FAN speed, VCORE, +3.3V, +5V and +12V... -
Page 43: Boot Setting
OXY5313A 3.5” SBC User’s Manual 4.5 Boot Setting The setting allows you to setup the Boot sequence for a 3.5” SBC. Quick Boot (The default BIOS setting is Enabled) Full Screen Logo Display... -
Page 44: Bootup Num-Lock
OXY5313A 3.5” SBC User’s Manual Bootup Num-lock Wait For ‘F1’ If Error... -
Page 45: Hit 'Del' Message Display
OXY5313A 3.5” SBC User’s Manual Hit ‘Del’ Message Display 4.6 Chipset Setting... -
Page 46: Initial Graphic Adapter
OXY5313A 3.5” SBC User’s Manual Initial Graphic Adapter When this setting is selected, you should see options for IGD, PCI/IGD, PEG/PCI, PCI/PEG and PEG/IGD. IGD (Integrated Graphic Devices) PEG (PCI express Graphic) Internal Graphic Mode Select... -
Page 47: Hyper Threading Technology
OXY5313A 3.5” SBC User’s Manual Hyper Threading Technology Hyper-threading technology (HTT) is Intel's term for its simultaneous multithreading implementation in some of its CPUs. Hyper-threading is an Intel-proprietary technology used to improve performance of multiple tasks running simultaneously. For each processor core that is physically present, the operating system addresses two virtual processors, and divides the workload. -
Page 48: Video Function Configuration
OXY5313A 3.5” SBC User’s Manual Video Function Configuration DVMT Model Select DVMT Mode contains the following settings: Fixed Mode, DVMT Mode... -
Page 49: Dvmt/Fixed Memory
OXY5313A 3.5” SBC User’s Manual DVMT/Fixed Memory Boot Display Device This setting allows you to setup VGA/LVDS/VGA+LVDS display mode. -
Page 50: Flat Panel Type
OXY5313A 3.5” SBC User’s Manual Flat Panel Type This setting allows you to setup the resolution for an onboard 18-bit LVDS. Panel Backlight voltage Setup the voltage for Panel... -
Page 51: Power Management Setting
OXY5313A 3.5” SBC User’s Manual 4.7 Power Management Setting ACPI Function This BIOS feature is used to enable or disable the motherboard's APCI (Advanced Configuration and Power Interface) -
Page 52: Acpi Standby State
OXY5313A 3.5” SBC User’s Manual ACPI Standby State Repost Video on S3 Resume This setting controls the state of the system when it receives an ACPI standby signal (OS Independent) -
Page 53: Restore On Ac Power Loss
OXY5313A 3.5” SBC User’s Manual S3 = Suspend to RAM - The system powers off while maintaining the active state of the system. S1 = Power ON Standby - The system remains powered on but in a low power state (CPU is idle but powered, usually fans and other modules are still active - hard drives spin down). -
Page 54: Resume From S3 By Usb Device
OXY5313A 3.5” SBC User’s Manual Resume From S3 By USB Device Enable or disable this BIOS setting to wake up the computer by USB Devices Resume By LAN Device Enable or disable this BIOS setting to wake up the computer by LAN1/LAN2... -
Page 55: Resume By Rtc Alarm
OXY5313A 3.5” SBC User’s Manual Resume By RTC Alarm Enable or disable this BIOS setting to wake up the computer by RTC Alarm 4.8 Security Setting Select this option to set the Security parameters. Select an option to configure. The following settings are available: Change Supervisor Password: Select to set the supervisor password. -
Page 56: Change Supervisor Password
OXY5313A 3.5” SBC User’s Manual Change Supervisor Password Select this option to set the Supervisor Password parameters. Change User Password... -
Page 57: Exit Setting
OXY5313A 3.5” SBC User’s Manual Select this option to set the User Password parameters. 4.9 Exit Setting Save Changes and Exit... - Page 58 OXY5313A 3.5” SBC User’s Manual Select this menu to set the Exit parameters. The following settings are available: Save Changes and Exit: Select to set this parameter. Discard Changes and Exit: Select to set this parameter. Discard Changes: Select to set this parameter.
-
Page 59: Discard Changes And Exit
OXY5313A 3.5” SBC User’s Manual Discard Changes and Exit Select this option to discard any changes applied and exit the system. -
Page 60: Discard Changes
OXY5313A 3.5” SBC User’s Manual Discard Changes Select this option to discard any changes applied. -
Page 61: Load Optimal Defaults
OXY5313A 3.5” SBC User’s Manual Load Optimal Defaults Select this option to load optimal defaults. -
Page 62: Load Failsafe Defaults
OXY5313A 3.5” SBC User’s Manual Load Failsafe Defaults Select this option to load failsafe defaults. -
Page 63: Appendix A Watchdog Timer Setting
OXY5313A 3.5” SBC User’s Manual APPENDIX A Watchdog Timer Setting After the system stops working for a while, it can be auto-reset by the Watchdog Timer. The integrated Watchdog Timer can be set up in the system reset mode by program. - Page 64 OXY5313A 3.5” SBC User’s Manual re-set timer :O 2E F6 O 2F M ; M=00,01,02,…FF(See below table) ↓ IF No re-set timer :WDT time-out, generate RESET IF to disable WDT :O 2E 30 O 2F 00 ; Can be disable at any time...
-
Page 65: Appendix B Digital I/O
OXY5313A 3.5” SBC User’s Manual APPENDIX B DIGITAL I/O Digital I/O Software Programming Program Example: 4IN/4OUT (W83627DHG) O 2E 87 O 2E 87 O 2E 87 O 2E 87 O 2E 07 O 2E 07 O 2F 09 O 2F 09... - Page 66 OXY5313A 3.5” SBC User’s Manual Note: Digital Output Digital Input Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0...
