- Page 1 Version 1.2 Revision Date: Feb. 23, 2012 User’s Manual OXY5315A 3.5" Single Board Computer User’s Manual www.perfectron.com...
-
Page 2: Safety Information
OXY5315A 3.5” SBC User’s Manual Safety information Electrical safety To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device. Before connecting or removing signal cables from the motherboard, ensure that all power cables are unplugged. Seek professional assistance before using an adapter or extension ... -
Page 3: Revision
OXY5315A 3.5” SBC User’s Manual Revision Revision Date (dd.mm.yyyy) Changes Version 1.0 31.07.2011 Initial release Updated Packing list for Cable kit Version 1.1 05.09.2011 Modified 3P Clear CMOS to 2P Removed JUSB_01 Removed JCOMPWR1‐6 Version 1.2 23.02.2012 Updated SK201 Installation Guide Packing list □ OXY5315A 3.5” SBC □ Driver CD □ Quick Installation Guide □ User’s Manual □ Fanless Thermal Module(Optional) ... -
Page 4: Table Of Contents
OXY5315A 3.5” SBC User’s Manual Table of Contents Safety information ............................. 1 Electrical safety ............................. 1 Operation safety ........................... 1 Statement ............................. 1 Revision .............................. 2 Packing list ............................ 2 Chapter 1: Product Information ........................ 6 1.1 Block Diagram .......................... 6 1.2 Key Features ............................ 7 1.3 Board Placement .......................... 8 ... - Page 5 OXY5315A 3.5” SBC User’s Manual 3.1 Installing System Memory ...................... 20 3.2 Installing the CF card ........................ 20 3.3 Driver Installation ......................... 21 Chapter 4: AMI BIOS UTILITY ........................ 22 4.1 Starting ............................ 22 4.2 Navigation Keys .......................... 22 4.3 Main Menu ........................... 23 SATA 1 Setup .......................... 24 SATA 1 (LBA/Large Mode) ....................... 24 SATA 1 (DMA Mode) ........................ 25 SATA 2 Setup .......................... 26 SATA 2 (LBA/Large Mode) ....................... 26 ...
- Page 6 OXY5315A 3.5” SBC User’s Manual ACPI Function .......................... 49 ACPI Standby State ......................... 50 Repost Video on S3 Resume ...................... 50 Restore on AC Power Loss ...................... 51 Resume From S3 By USB Device ..................... 52 Resume By LAN Device ........................ 52 Resume By RTC Alarm ........................ 53 4.8 Security Setting .......................... 53 Change Supervisor Password ...................... 53 Change User Password ........................ 54 4.9 Exit Setting ............................ 55 Save Changes and Exit ........................ 55 ...
-
Page 7: Chapter 1: Product Information
OXY5315A 3.5” SBC User’s Manual Chapter 1: Product Information 1.1 Block Diagram www.perfectron.com... -
Page 8: Key Features
OXY5315A 3.5” SBC User’s Manual 1.2 Key Features Processor & System CPU Type Intel Atom Pineview‐M N455 CPU onboard (45nm, 1.66GHz, 512KB L2 Cache) Chipset Intel® ICH8M Memory Type DDR3 800 SO DIMM (Max is 2GB) BIOS 8MB SPI Flash Super I/O ITE8781F Watchdog 1‐255 sec. or 1‐255 min. software programmable and can be generate system reset Expansion Slot CF Socket CF Type I/II CF Socket SATA Port 2 x SATAII (3Gb/s) Mini PCIe Socket Supports GPRS/GSM Mini PCIe Devices Display Chipset Integrated Intel® GMA3150 Graphic engine Memory Size Intel® DVMT 4.0 compliant Onboard VGA Yes, Max.: SXGA 2048 x 1536 LVDS 18‐bit single channel LVDS 24‐bit single/dual channel LVDS (By LVDS card) Dual Displays ... -
Page 9: Board Placement
OXY5315A 3.5” SBC User’s Manual Parallel port 2x13 Pin header Mechanical and Environment Form Factor 3.5” SBC Power Type ATX 2x2 pin Power connector Voltage +12V single voltage in Dimension 146mm x 102mm Operating Temp. ‐20°C ~ 70°C Storage Temp. ‐20°C ~ 80°C Relative humidity 10% to 90%, non‐condensing *All specifications and photos are subject to change without notice* 1.3 Board Placement www.perfectron.com... -
Page 10: Onboard Connector List
OXY5315A 3.5” SBC User’s Manual 1.4 Onboard Connector List Label Function MPCIE1 Mini PCIe Connector ATX2 Power Input Connector DIO1 Digital Input / Output Pin Header COM2 RS‐232 Port B With Power Wafer COM3 RS‐232 Port C With Power Wafer COM4 RS‐232 Port D With Power Wafer COM5 RS‐232 Port E With Power Wafer COM6 RS‐232 Port F With Power Wafer COM7 RS‐232 Port G With Power Wafer COM8 RS‐232 Port H With Power Wafer LPT1 Parallel Port Pin Header SPDIF1 SPD/IF Output Pin Header AUDIO1 AUDIO OUT Wafer AMP_R1 Audio AMP Right Output Wafer AMP_L1 Audio AMP Left Output Wafer DDR3_1 ... -
Page 11: Mechanical Drawings
OXY5315A 3.5” SBC User’s Manual 1.5 Mechanical Drawings www.perfectron.com... -
Page 12: Jumper Settings
OXY5315A 3.5” SBC User’s Manual Chapter 2: Jumpers and Connectors 2.1 Jumper Settings JCMOS1: Clear CMOS Jumper Setting Jumper Function description Setting 1‐2 Normal Operation 2‐3 Clear CMOS *Default setting is 1‐2* PSON1: ATX/AT mode Selection Jumper Function description Setting 1‐2 AT Mode 2‐3 ATX Mode *Default setting is 2‐3* www.perfectron.com... -
Page 13: Onboard Connector Pin Assignment
OXY5315A 3.5” SBC User’s Manual 2.2 Onboard Connector Pin Assignment MPCIE1 Mini PCIE slots V1.2 Signal Name Pin Pin Signal Name PCIE_WAKE# 1 2 *+3.3VSB NC 3 4 GND NC 5 6 +1.5V NC 7 8 UIM_PWR GND 9 UIM_DATA CLK100_MPCIE1#/2# 11 UIM_CLK CLK100_MPCIE1/2 UIM_RESET GND UIM_VPP NC ... -
Page 14: Digital I/O Pin Header
OXY5315A 3.5” SBC User’s Manual Digital I/O Pin Header Pin Signal Pin Signal 1 Digital Output 0 2 Digital Input 0 3 Digital Output 1 4 Digital Input 1 5 Digital Output 2 6 Digital Input 2 7 Digital Output 3 8 Digital Input 3 9 +5V 10 GND COM2~4 RS‐232 Port (1x10 pin Wafer) Pin Signal 1 DCD, Data carrier detect ... -
Page 15: Lpt1 Parallel Port Pin Header
OXY5315A 3.5” SBC User’s Manual LPT1 Parallel Port Pin Header Signal Pin Signal Line printer strobe 1 2 AutoFeed PD0, parallel data 0 3 4 Error PD1, parallel data 1 5 6 Initialize PD2, parallel data 2 7 8 Select In PD3, parallel data 3 9 10 Ground PD4, parallel data 4 11 12 Ground PD5, parallel data 5 13 14 Ground PD6, parallel data 6 15 ... -
Page 16: Ddr3_1 Ddr3 Memory Dimm Slot
OXY5315A 3.5” SBC User’s Manual DDR3_1 DDR3 Memory DIMM Slot CPU/System FAN Pin Signal 1 GND 2 +12V 3 FAN_RPM www.perfectron.com... -
Page 17: Fd1 Cf Type Ii Connector
OXY5315A 3.5” SBC User’s Manual FD1 CF Type II Connector Signal Name Pin Pin Signal Name GND 1 GND IDE Data 3 2 IDE Data 11 IDE Data 4 3 IDE Data 12 IDE Data 5 4 IDE Data 13 IDE Data 6 5 IDE Data 14 IDE Data 7 6 IDE Data 15 IDE Chip select 1# 7 IDE Chip select 3# GND 8 GND GND 9 IDEIOR# GND ... -
Page 18: Fp2 Front Panel 2 Pin Header
OXY5315A 3.5” SBC User’s Manual FP2 Front Panel 2 Pin Header Pin Signal Pin Signal 1 Speaker + 2 SMBus Clock 3 NC 4 SMBus Data ‐ 5 Internal Speaker‐ 6 GND 7 Speaker ‐ 8 Keyboard Lock SATAI1, SATA2 Serial ATA 2.0 Connector Pin Signal Name 1 GND 2 TX+ 3 TX‐ 4 ... -
Page 19: Jlvds1 18 Bit Lvds Panel Connector
OXY5315A 3.5” SBC User’s Manual JLVDS1 18 bit LVDS Panel Connector Pin Signal Name Pin Signal Name 2 +5V 1 +3.3V 4 +5V 3 +3.3V 6 LVDS_A0‐ 5 LVDS_A1‐ 8 LVDS_A0+ 7 LVDS_A1+ 10 GND 9 GND 12 LVDS_A2‐ LVDS_CLK‐ 14 LVDS_A2+ LVDS_CLK+ 16 GND GND ... -
Page 20: Lan1 , Lan2 10/100/1000 Ethernet Rj-45 Connector
OXY5315A 3.5” SBC User’s Manual LAN1 , LAN2 10/100/1000 Ethernet RJ‐45 Connector Pin Signal 1 Tx+ 2 Tx‐ 3 Rx+ 4 NC 5 NC 6 Rx‐ 7 NC 8 NC VGA1 DSUB 15 pin Connector Signal Name Pin Pin Signal Name Red 1 2 Green Blue 3 4 ... -
Page 21: Chapter 3: Getting Started
OXY5315A 3.5” SBC User’s Manual Chapter 3: Getting Started This chapter provides information on how to install components to the OXY5315A. Specifically, the installation of memory modules and operating system are explained. 3.1 Installing System Memory The OXY5315A supports DDR3 800 SO‐DIMM. Disconnect all power supplies to the board before installing a memory module to prevent damage to the board and memory module. To install a memory module: Located the memory module slots on the motherboard. Push the socket retaining clips outward to unlock the slots. Align the memory module with the socket to make sure the notch ... -
Page 22: Driver Installation
OXY5315A 3.5” SBC User’s Manual 3.3 Driver Installation The OXY5315A drivers for Windows XP 32‐bit are located in the following directories on the Driver CD or can be downloaded from the Perfectron website (http://www.perfectron.com): Follow the instructions below to install the required OXY5315A drivers: 1. Install the Windows operating system before installing any drivers. Most standard I/O device drivers are installed during Windows installation. 2. Install the chipset driver by running the program X:\OXY5315A Driver\INF\setup.exe. Follow the provided instructions and ... -
Page 23: Chapter 4: Ami Bios Utility
OXY5315A 3.5” SBC User’s Manual Chapter 4: AMI BIOS UTILITY This chapter provides users with detailed descriptions on how to set up a basic system configuration through the AMIBIOS8 BIOS setup utility. 4.1 Starting To enter the setup screens, perform the following steps: Turn on the computer and press the <Del> key immediately. After the <Del> key is pressed, the main BIOS setup menu displays. Other setup screens can be accessed from the main BIOS setup menu, such as the Chipset and Power menus. 4.2 Navigation Keys The BIOS setup/utility uses a key‐based navigation system called hot keys. ... -
Page 24: Main Menu
OXY5315A 3.5” SBC User’s Manual 4.3 Main Menu The Main menu is the screen that first displays when BIOS Setup is entered, unless an error has occurred. You could setup these items on the Main menu: System Time: Select this option to set the system time. System Date: Select this option to set the system date. CF: Select this option to set the parameters. System Information: Select this option to display system information. Use the <Arrow> keys to enter the appropriate time and date. Press the <Tab> key or the <Arrow> keys to move between fields. The date setting ... -
Page 25: Sata 1 Setup
OXY5315A 3.5” SBC User’s Manual SATA 1 Setup BIOS will automatically detect the presence of a SATA HDD. SATA 1 (LBA/Large Mode) In order for LBA to work, it must be supported by the BIOS and operating system, but since it is also a new way of talking to the hard disk, the disk ... -
Page 26: Sata 1 (Dma Mode)
OXY5315A 3.5” SBC User’s Manual A drive using LBA is not subject to the 504 MiB disk size barrier, however there has been a great deal of confusion regarding LBA and what it does. In particular, a lot of people think that it is the LBA addressing that "gets around the 504 MB barrier". LBA from the BIOS doesn't affect newer OSs such as Linux, or NT/2000, ... -
Page 27: Sata 2 Setup
OXY5315A 3.5” SBC User’s Manual SATA 2 Setup BIOS will automatically detect the presence of a SATA HDD SATA 2 (LBA/Large Mode) (The default BIOS setting for LBA/Large Mode is Auto) www.perfectron.com... -
Page 28: S.m.a.r.t For Sata 2
OXY5315A 3.5” SBC User’s Manual SATA 2 (LBA/Large Mode) (The default BIOS setting for DMA mode is Auto) S.M.A.R.T for SATA 2 (The default BIOS setting for S.M.A.R.T is Auto) www.perfectron.com... -
Page 29: Cf Setup
OXY5315A 3.5” SBC User’s Manual CF Setup BIOS will automatically detect the presence of a CF card CF setup (LBA/Large Mode) (The default BIOS setting for LBA/Large mode is Auto) www.perfectron.com... -
Page 30: Cf (Dma Mode)
OXY5315A 3.5” SBC User’s Manual CF (DMA Mode) DMA (Direct memory access) mode is a high performance mode for transferring data to and from devices, The burner devices can function in either DMA or PIO modes. DMA mode allows the processor to transfer large pieces of data with very little software overhead ‐ therefore requiring low ... -
Page 31: S.m.a.r.t For Cf
OXY5315A 3.5” SBC User’s Manual S.M.A.R.T for CF S.M.A.R.T. (Self‐Monitoring, Analysis and Reporting Technology; sometimes written as SMART) is a monitoring system for computer hard disk drives to detect and report on various indicators of reliability, in the hope of anticipating failures. When a failure is anticipated by S.M.A.R.T., the user may choose to replace the drive to avoid unexpected outage and data loss. The manufacturer may be able to use the S.M.A.R.T. data to discover where faults lie and prevent ... -
Page 32: System Information
OXY5315A 3.5” SBC User’s Manual System Information You can review the system information in the BIOS System Information menu. OXY5315A contains an embedded Intel N455 CPU. www.perfectron.com... -
Page 33: Advanced Menu
OXY5315A 3.5” SBC User’s Manual 4.4 Advanced Menu Onboard I/O Configuration www.perfectron.com... -
Page 34: Onboard Peripherals Configuration
OXY5315A 3.5” SBC User’s Manual You could setup the IRQ and IRQ address for the OXY5315A. This line of 3.5” SBC supports 8xCOM Ports (COM1 Port belongs to D‐Sub 9pin and supports RS232/422/485. COM2~COM8 belongs to the 1x10 pin wafer connector and supports RS232) Onboard Peripherals Configuration www.perfectron.com... -
Page 35: Usb Function
OXY5315A 3.5” SBC User’s Manual USB Function You could enable or disable the onboard USB functions and/or USB 2.0 Controller. USB Device Legacy Support Legacy mode support is inherent to a system and is typically provided by legacy hardware interface emulation. Legacy mode support allows devices to function in an operating environment. www.perfectron.com... -
Page 36: Audio Controller
OXY5315A 3.5” SBC User’s Manual (The default BIOS setting for USB Legacy support is Enabled) Audio Controller This setting enables or disables the onboard Audio Controller. (The default BIOS setting for Audio Controller default is Enabled) Onboard LAN1 Controller This setting enables or disables the OnBoard LAN1 Controller. www.perfectron.com... -
Page 37: Onboard Lan1 Optrom
OXY5315A 3.5” SBC User’s Manual Onboard LAN1 OPTROM This setting enables or disables the Onboard LAN1 OPTROM setting. (The default BIOS setting for Onboard LAN1 OPTROM is Disabled) Onboard LAN2 Controller This setting enables or disables the Onboard LAN2 Controller. www.perfectron.com... -
Page 38: Onboard Lan2 Optrom
OXY5315A 3.5” SBC User’s Manual Onboard LAN2 OPTROM This setting enables or disables the Onboard LAN2 OPTROM. (The default BIOS setting is Disabled) Onboard Mini‐PCIE Controller This setting enables or disables the Onboard Mini‐PCIE Controller. www.perfectron.com... -
Page 39: On-Chip Ata Devices
OXY5315A 3.5” SBC User’s Manual On‐Chip ATA Devices This setting contains two sub‐menus. Press Enter to access the secondary menu. The secondary menu has two settings: ATA/IDE Configuration This setting enables or disables the ATA/IDE Configuration. www.perfectron.com... -
Page 40: Configure Sata As
OXY5315A 3.5” SBC User’s Manual Configure SATA as This setting allows the most important peripheral equipment. The menu options are: IDE and AHCI *IDE: The function provides the bridge for the IDE to SATA hard disk drive function. *AHCI: This supports a SATA 3GB connection and supports NCQ and e‐SATA. www.perfectron.com... -
Page 41: Hardware Health Configuration
OXY5315A 3.5” SBC User’s Manual Hardware Health Configuration The Hardware Health Configuration setting displays the system hardware details such as CPU Warning Temperature, CPU Temperature, System Temperature, CPU FAN speed, VCORE, +3.3V, +5V and +12V www.perfectron.com... -
Page 42: Boot Setting
OXY5315A 3.5” SBC User’s Manual 4.5 Boot Setting The setting allows you to setup the Boot sequence for a 3.5” SBC. Quick Boot (The default BIOS setting is Enabled) Full Screen Logo Display www.perfectron.com... -
Page 43: Bootup Num-Lock
OXY5315A 3.5” SBC User’s Manual Bootup Num‐lock Wait For ‘F1’ If Error www.perfectron.com... -
Page 44: Hit 'Del' Message Display
OXY5315A 3.5” SBC User’s Manual Hit ‘Del’ Message Display 4.6 Chipset Setting www.perfectron.com... -
Page 45: Initial Graphic Adapter
OXY5315A 3.5” SBC User’s Manual Initial Graphic Adapter When this setting is selected, you should see options for IGD, PCI/IGD, PEG/PCI, PCI/PEG and PEG/IGD. IGD (Integrated Graphic Devices) PEG (PCI express Graphic) Internal Graphic Mode Select www.perfectron.com... -
Page 46: Hyper Threading Technology
OXY5315A 3.5” SBC User’s Manual Hyper Threading Technology Hyper‐threading technology (HTT) is Intel's term for its simultaneous multithreading implementation in some of its CPUs. Hyper‐threading is an Intel‐proprietary technology used to improve performance of multiple tasks running simultaneously. For each processor core that is physically present, the operating system addresses two virtual ... -
Page 47: Video Function Configuration
OXY5315A 3.5” SBC User’s Manual Video Function Configuration www.perfectron.com... -
Page 48: Dvmt Model Select
OXY5315A 3.5” SBC User’s Manual DVMT Model Select DVMT Mode contains the following settings: Fixed Mode, DVMT Mode DVMT/Fixed Memory www.perfectron.com... -
Page 49: Boot Display Device
OXY5315A 3.5” SBC User’s Manual Boot Display Device This setting allows you to setup VGA/LVDS/VGA+LVDS display mode. Flat Panel Type This setting allows you to setup the resolution for an onboard 18‐bit LVDS. www.perfectron.com... -
Page 50: Panel Backlight Voltage
OXY5315A 3.5” SBC User’s Manual Panel Backlight voltage Setup the voltage for Panel 4.7 Power Management Setting ACPI Function This BIOS feature is used to enable or disable the motherboard's APCI (Advanced Configuration and Power Interface) www.perfectron.com... -
Page 51: Acpi Standby State
OXY5315A 3.5” SBC User’s Manual ACPI Standby State Repost Video on S3 Resume This setting controls the state of the system when it receives an ACPI standby signal (OS Independent) S3 = Suspend to RAM ‐ The system powers off while maintaining the active state of the system. S1 = Power ON Standby ‐ The system remains powered on but in a low ... -
Page 52: Restore On Ac Power Loss
OXY5315A 3.5” SBC User’s Manual power state (CPU is idle but powered, usually fans and other modules are still active ‐ hard drives spin down). The S3 setting is preferable, but some people still have to use the S1 setting for various reasons. Either setting should not present problems to any operating system. Restore on AC Power Loss Restore the computer to power up when power is lost. You can set this by entering the computers BIOS setup and configure this setting in the Power ... -
Page 53: Resume From S3 By Usb Device
OXY5315A 3.5” SBC User’s Manual Resume From S3 By USB Device Enable or disable this BIOS setting to wake up the computer by USB Devices Resume By LAN Device Enable or disable this BIOS setting to wake up the computer by LAN1/LAN2 Port www.perfectron.com... -
Page 54: Resume By Rtc Alarm
OXY5315A 3.5” SBC User’s Manual Resume By RTC Alarm Enable or disable this BIOS setting to wake up the computer by RTC Alarm 4.8 Security Setting Select this option to set the Security parameters. Select an option to configure. The following settings are available: Change Supervisor Password: Select to set the supervisor password. Change User Password: Select to set the user password. Change Supervisor Password Select this option to set the Supervisor Password parameters. www.perfectron.com... -
Page 55: Change User Password
OXY5315A 3.5” SBC User’s Manual Change User Password Select this option to set the User Password parameters. www.perfectron.com... -
Page 56: Exit Setting
OXY5315A 3.5” SBC User’s Manual 4.9 Exit Setting Save Changes and Exit Select this menu to set the Exit parameters. The following settings are available: Save Changes and Exit: Select to set this parameter. Discard Changes and Exit: Select to set this parameter. Discard Changes: Select to set this parameter. Load Optimal Defaults: Select to set this parameter. Load Failsafe Defaults: Select to set this parameter. www.perfectron.com... -
Page 57: Discard Changes And Exit
OXY5315A 3.5” SBC User’s Manual Select this option to save any changes applied and exit the system. Discard Changes and Exit www.perfectron.com... -
Page 58: Discard Changes
OXY5315A 3.5” SBC User’s Manual Select this option to discard any changes applied and exit the system. Discard Changes www.perfectron.com... -
Page 59: Load Optimal Defaults
OXY5315A 3.5” SBC User’s Manual Select this option to discard any changes applied. Load Optimal Defaults www.perfectron.com... -
Page 60: Load Failsafe Defaults
OXY5315A 3.5” SBC User’s Manual Select this option to load optimal defaults. Load Failsafe Defaults www.perfectron.com... - Page 61 OXY5315A 3.5” SBC User’s Manual Select this option to load failsafe defaults. www.perfectron.com...
-
Page 62: Appendix A Watchdog Timer Setting
OXY5315A 3.5” SBC User’s Manual APPENDIX A Watchdog Timer Setting After the system stops working for a while, it can be auto‐reset by the Watchdog Timer. The integrated Watchdog Timer can be set up in the system reset mode by program. Using the Watchdog Function Start ↓ Un‐Lock WDT ... - Page 63 OXY5315A 3.5” SBC User’s Manual re‐set timer :O 2E F6 O 2F M ; M=00,01,02,…FF(See below table) ↓ IF No re‐set timer :WDT time‐out, generate RESET IF to disable WDT :O 2E 30 O 2F 00 ; Can be disable at any time N=00 M= 00h: Time‐out Disable 01h: Time‐out occurs after 1 second 02h: Time‐out occurs after 2 second 03h: Time‐out occurs after 3 second ………………………........ FFh: Time‐out occurs after 255 second N=08 M= 00h: Time‐out Disable 01h: Time‐out occurs after 1 minute 02h: Time‐out occurs after 2 minutes 03h: Time‐out occurs after 3 minutes ………………………........ FFh: Time‐out occurs after 255 minutes www.perfectron.com...
-
Page 64: Appendix B Digital I/O
OXY5315A 3.5” SBC User’s Manual APPENDIX B DIGITAL I/O Digital I/O Software Programming Program Example: 4IN/4OUT (W83627DHG) GPI GPO O 2E 87 O 2E 87 O 2E 87 O 2E 87 O 2E 07 O 2E 07 O 2F 09 O 2F 09 O 2E 30 O 2E 30 O 2F 02 O 2F F2 O 2E F0 O 2E F0 O 2F F0 O 2F F0 O 2E F1 O 2E F1 I 2F O 2F M(Note) Pin Signal Signal ... - Page 65 OXY5315A 3.5” SBC User’s Manual Note: Digital Output Digital Input Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 DI4 DI3 DI2 DI1 DO4 DO3 DO2 DO1 www.perfectron.com...
