  • Page 1 Multi-Purpose Device for Retail User’s Manual...
  • Page 2 Datalogic and the Datalogic logo are registered trademarks of Datalogic S.p.A. in many countries, including the U.S.A. and the E.U. JOYA is a trademark of Datalogic S.p.A. or of Datalogic Group companies, reg- istered in many countries, including the U.S. and the E.U.

  • Page 3: Table Of Contents

    Use and Functioning ............21 Getting Started ................21 Taskbar ..................23 Touch Gestures ................24 Data Capture ................25 Imager Data Capture ..............25 Resetting the JOYA TOUCH ............28 Warm Boot ..................28 Cold Boot ..................29 User’s Manual...
  • Page 4 Wireless Communications ............54 Audio Settings ................62 Connecting to other Computers ..........65 Windows Mobile® Device Center ..........65 Datalogic Firmware Utility ............66 Retrieving a Firmware Image Update ......... 66 Installing DFU on the Host PC ............67 Updating the Firmware ..............68 Datalogic Desktop Utility ............69...
  • Page 5 Cleaning the Device ..............109 Ergonomic Recommendations ..........110 Safety and Regulatory Information......111 General Safety Rules ............... 111 Power Supply ................112 Laser Safety ................113 LED Class .................. 121 Marking and European Economic Area (EEA) ...... 121 Statement of Compliance ............122 Radio Technologies and Frequency Bands ......
  • Page 6 NOTES JOYA™ TOUCH...

  • Page 7: Introduction

    Introduction Conventions This manual uses the following conventions: ‘Device’ and 'JOYA TOUCH' refer to the JOYA TOUCH. ‘Dock’ refers to the JOYA TOUCH 3-Slot Cradle. The label artworks may be only a draft. Refer to the product labels for more precise information.

  • Page 8: Product Presentation

    (2D bar code), a wireless charging system and wireless communication capabilities, supporting nearly any application. The Datalogic JOYA TOUCH system architecture is based on the blend of Intel X-Scale series processors coupled with the Windows Embedded Compact operating system and it was developed to meet the most demanding customer needs.

  • Page 9: Available Models

    Introduction Available Models The Datalogic JOYA TOUCH is available in different models depending on the features it is equipped with. All options are listed below: • p/n 911350010 JOYA TOUCH Plus Handheld, FWVGA Full Touch color display 4.3” in diagonal, white-illumination 2D imager engine, Green Spot, radio 802.11 A/B/G/N, 512MB...
  • Page 10 RAM, 512GB Flash, Windows Embedded Compact 7 with dedicated SDK for developing 3rd party applications. Wavelink Avalanche® device management preloaded. Grey/Red/Red colors combination (upper case / trigger / battery cover). For further details about the Datalogic JOYA TOUCH models refer to the web site: www.datalogic.com. JOYA™ TOUCH...

  • Page 11: Out Of The Box

    Introduction Out of the Box The JOYA TOUCH package contains: • JOYA TOUCH (device) • Rechargeable battery • Quick Start Guide • Safety & Regulatory Addendum • EULA Addendum Remove all the components from their packaging; check their integrity and compare them with all the packing documents.

  • Page 12: General View

    Introduction General View Front View Touch Panel Display Home Key JOYA™ TOUCH...

  • Page 13: Back View

    Introduction Back View Laser Safety Label Product Label Cold Boot Button User’s Manual...

  • Page 14: Top View

    Introduction Top View Data Capture Window Side View Pistol Grip Models Handheld Models Micro USB Port Scan Trigger JOYA™ TOUCH...

  • Page 15: Accessories

    Cradle Accessories 91ACC0045 JOYA TOUCH Cradle Unlock Key (5 PCS) 91ACC0048 JOYA TOUCH 3-Slot Cradle Power Supply. Line Cord required (max 2 cradles on standard charge, max 1 cradle on fast charge per power supply) 91ACC0049 JOYA TOUCH Cradle Power Jumper (5 PCS)
  • Page 16 Introduction NOTES JOYA™ TOUCH...

  • Page 17: Battery

    Battery Install the Battery To install the battery pack, follow the steps below: 1. Unscrew the battery cover and remove it: Pistol Grip Models Handheld Models 2. Connect the battery contacts to the battery clip located in the battery slot: Pistol Grip Models Handheld Models User’s Manual...
  • Page 18 3. Insert the battery pack into the slot as shown in the figures below: Handheld Models Pistol Grip Models 4. Insert the battery cover and fix the screws: Pistol Grip Models Handheld Models Required torque of the screws is 35 cNm. NOTE JOYA™ TOUCH...

  • Page 19: Charge The Battery

    Battery Charge the Battery The JOYA TOUCH battery pack is not initially fully charged. After installing the battery, charge it with the 3-slot cradle. The device needs to be inserted head down into the cradle. Charge the battery for a minimum of 7 hours in standard charge and 3 hours in fast charge.

  • Page 20: Standard Charge

    The standard charge connection allows to power two cradles with one power supply. To connect a second cradle use the JOYA TOUCH Cradle Power Jumper, available as optional accessory (P/N 91ACC0049). 1. Connect the first cradle to the second cradle using the power jumper.
  • Page 21 As a safety precaution, the battery may stop charging to avoid overheating. The JOYA TOUCH may get warm during charging; this is normal and does not mean a malfunction. Even if the storage temperature range is wider, it is recommended to store the terminal and the batteries at environmental temperature, in order to achieve the longest battery life.
  • Page 22 Use specified charger only. Risk of explosion if the battery is replaced by an incorrect type. Dispose of CAUTION batteries as required by local authorities. Use only Datalogic approved batteries and accessories for battery charging. Risk of explosion if battery is replaced by an incorrect type.

  • Page 23: Battery Safety Guidelines

    To power the cradle, use only a Datalogic approved power supply. The use of an alternative power supply will void the product warranty, may cause product damage and may cause heat, an explosion, or fire.
  • Page 24 If the contact occurs, immediately wash the affected area with water and consult a doctor. Do not solder directly onto the battery pack. Do not expose the battery pack to liquids. JOYA™ TOUCH...
  • Page 25 Battery Avoid any knocks or excessive vibrations. If the device or the battery is dropped, especially on a hard surface, you should take it to the nearest Authorised Repair Centre for inspection before continuing to use it. WARNING If your device stops working for any reason, do not use its battery on other electronic devices without a prior check and approval by an Authorised Repair Centre.
  • Page 26 Battery NOTES JOYA™ TOUCH...

  • Page 27: Use And Functioning

    Furthermore, Avalanche Enabler is a major utility embedded in the software provided from factory. Getting Started The JOYA TOUCH turns on when a charged battery pack is inserted. User’s Manual...
  • Page 28 POWER applet of the Control Panel. In this mode it can be awakened (resuming operation) pressing the Home key. The mobile computer can also be awakened or turned off by the application program. NOTE JOYA™ TOUCH...

  • Page 29: Taskbar

    Use and Functioning Taskbar The Taskbar provides information about the time, the battery level, the keyboard function, and the decoding status. ICON DESCRIPTION Time Icons It displays the time. Radio Status Icons It indicates if the radio is connected or not with an Access Point. Network Status Icons It displays whether you are connected or not to Wi-Fi or Bluetooth Personal Area Network.

  • Page 30: Touch Gestures

    Do not apply not necessary high pressures on the screen. For applications where an intensive use of the touch screen is foreseen, please consider that touch screen components are subject to progressive wear. JOYA™ TOUCH...

  • Page 31: Data Capture

    Use and Functioning Data Capture To capture data, first of all double-tap Control Panel > Decoding and open the applet. Imager Data Capture The imager uses digital camera technology to take a digital picture of a bar code, the image is stored in memory and software decoding algorithms are executed to extract the data from the image.
  • Page 32 Ensure the entire symbol is within the rectangular area formed by the brackets in the aiming pattern, then either wait for the timeout or release the home key to capture the image. A red beam illuminates the symbol, which is captured and decoded. Linear Bar Code JOYA™ TOUCH...
  • Page 33 Scan symbols with smaller bars or elements (mil size) closer to the unit and those with larger bars or elements (mil size) farther from the unit. Hold the JOYA TOUCH between two and nine inches (depending on symbol density) from the symbol, centering the aiming pattern cross hairs on the symbol.

  • Page 34: Resetting The Joya Touch

    Registry is restored from persistent memory if available or returned to factory default. A ”clean boot” restore the JOYA TOUCH to factory default. Warm Boot A warm boot terminates an unresponsive application and clears the working RAM, but preserves the file system and registry.

  • Page 35: Cold Boot

    Use and Functioning Cold Boot A cold boot is a complete reset of the JOYA TOUCH in which all applications are forcibly closed and RAM is completely cleared. Registry is restored from persistent memory if a saved copy is available (see...
  • Page 36 Before performing a reset, it is recommended to: • Execute a system backup to keep your more important files and applications persistent. CAUTION • Save the registry to non-volatile memory to guarantee the persistence of the Windows configuration. JOYA™ TOUCH...

  • Page 37: Control Panel

    Use and Functioning Control Panel From the home screen, double-tap My Device icon or tap Start >Settings and then double-tap Control Panel icon to open the control panel main window. User’s Manual...

  • Page 38: Data Capture Configuration

    Data Capture Configuration From the control panel main window, double tap the Decoding icon: There are two sections in the Decoding control panel, each containing additional pages. There are eight general configuration pages and multiple bar code symbology pages. JOYA™ TOUCH...
  • Page 39 Use and Functioning Configure Select the desired configuration from the options shown in the figure below, and the other Decoding Properties figures on the following pages. Select General, 1D or 2D Bar Code, then use the menu or tap the left and right arrow keys to navigate the different pages of the Decoding utility.
  • Page 40 Sets the duration of the notification (green spot, beep or vibration) the scanner emits on a good read. Interval Sets the interval between each notification (green spot, beep or vibration) the scanner emits on a good read. Volume Sets the volume of beep tone. JOYA™ TOUCH...
  • Page 41 Use and Functioning Beep Tone Sets the type of beep tone. Good Read From the Decoding Properties page, tap Configure > General > Good Read. Use it to enable good read notifications (green spot, vibrator) and to set the decoding timeout for decoding labels. Select Automatic good read to enable/disable notifications (main enabler), then select the notification you want to use.
  • Page 42 Label Suffix Select Label suffix to enter the characters you will be using as suffix. Scroll the Add special dropdown menu to select a special character to be added in the current cursor position. JOYA™ TOUCH...
  • Page 43 Use and Functioning General Options From the Decoding Properties page, tap Configure > General > General Options. Label Programming Enable Parameter reserved to Datalogic personnel. User’s Manual...
  • Page 44 When AIM IDs Before is enabled, the AIM ID is inserted at the beginning of the decoded bar code. DL IDs is a Datalogic specific character identifier. User IDs is a user specific character identifier you can set in the related symbology settings menu.
  • Page 45 Use and Functioning Group Separator Replacement The group separator replacement is a non printable data separator character (ASCII code 1D hex). Use the Group separator replacement to select a special character that will be used as GS data separator substituting the standard GS character. Remove Non-printable Characters Select it to remove non-printable characters from a unicode string.
  • Page 46 From the Decoding Properties page, tap Configure > General > Decoding Options. Use it to configure the User ID for symbologies, Redundancy and Aggressive Decoding (if supported by the decoding module). Select a symbology to view or change the available properties settings. JOYA™ TOUCH...
  • Page 47 Use and Functioning Imager Options From the Decoding Properties page, tap Configure > General > Imager Options. Use it to customize the JOYA TOUCH scanning behavior. Enable Illumination If selected, it causes the scanner to turn on the illumination to aid decoding.
  • Page 48 If enabled, when the scan button is pressed, the scanner will project an aiming pattern to assist in centering over the bar code before scanning. Scroll the Target mode dropdown menu to select the desired targeting behavior: No Delay Target mode is disabled. JOYA™ TOUCH...
  • Page 49 Use and Functioning Target Timeout If selected, scanning takes place after a programmable time upon pressing the scan button. Drag the Timeout slider to set the maximum amount of time the scanner attempt to decode after target timeout: Release Scan If selected, scanning takes place after the scan button is released.
  • Page 50 Use and Functioning Multi Scan The JOYA TOUCH scanner allows you to scan multiple bar codes by one scan. From the Decoding Properties page, tap Configure > General > Multi Scan and drag the Labels per good read slider to set the number of bar codes allowed to be read per scan.
  • Page 51 Use and Functioning Keyboard Wedge From the Decoding Properties page, tap Configure > General > Keyboard Wedge. Select Bar code to enable the wedge mode. User’s Manual...
  • Page 52 Scroll the drop-down menus from Configure > 1D Bar Code, or tap the left and right arrow keys to navigate the 1D bar code symbology pages and configure symbology decoding options: JOYA™ TOUCH...
  • Page 53 Use and Functioning Refer to the sample symbology control panels for examples of the types of fields and options you can modify. The sample below shows the settings of a Code 128 bar code symbology: User’s Manual...
  • Page 54 1D bar code symbology pages and configure symbology decoding options: Refer to the sample symbology control panels for examples of the types of fields and options you can modify. The sample below shows the settings of a DataMatrix bar code symbology: JOYA™ TOUCH...
  • Page 55 Use and Functioning Decoding Settings Select from the Decoding Properties Settings menu to restore previous configurations and/or other available default settings. Choose from: • Factory Defaults • Minimum Settings • Maximum Settings • Save • Revert to Saved Settings The settings are saved when you tap ‘Yes’. To permanently save these settings you need to save the registry using the Persistent Registry applet in the Control Panel.

  • Page 56: Dl Buttons

    You can use the DL Buttons tab to associate specific keys with specific applications. From the control panel main window, double tap the DL Buttons icon. As for the Joya Touch, it is possible to program the Home key and the Trigger, if present.
  • Page 57 Use and Functioning Triggers Triggers are special customizable buttons that are mapped by default by DL Buttons. Also, they can be set as wakeup buttons: TRIGGERS AVAILABLE FUNCTIONS Scan Bar Code function activates the scanner. Pistol Trigger User’s Manual...

  • Page 58: Persistent Registry

    To persist the Registry settings between boots, do the following steps: 1. Double-tap the Control Panel icon on the home screen. 2. Double-tap the Persistent Registry icon. 3. Tap the Persist button. 4. Tap OK to exit. JOYA™ TOUCH...
  • Page 59 Use and Functioning To change Persistent Registry timing, do the following steps: 1. Select a time interval from the menu. 2. Tap OK to save and exit. To deselect Persistent Registry timing, do the following steps: 1. Deselect the Persist registry settings check box. 2.

  • Page 60: Wireless Communications

    Status Indicates the current status of the Laird Wi-Fi radio. Connection statuses include: • Down The radio is not recognized by Laird software and therefore is not associated or authenticated. JOYA™ TOUCH...
  • Page 61 Use and Functioning • Disabled The radio is disabled. To enable the radio, check the Wi-Fi check box located on the Configuration window. When the radio is disabled, it does not attempt to make a connection to an access point. •...
  • Page 62 Allows user to change profiles and global configurations, and enables administrative abilities. There are two tabs listed under Manage Profiles: • Wi-Fi - Profile Profile settings are radio and security settings that are stored for each configuration profile. The Profile tab displays the following properties and options: JOYA™ TOUCH...
  • Page 63 Use and Functioning Property and Value table: displays the properties of each profile and its respective value. Profile drop-down menu: displays the current profile and a list of all profiles previously configured or used. New: allows a profile to be added to the list. Delete: deletes a profile from the list.
  • Page 64 Property and Value table: displays various properties and their respective values. Value box: displays the current and avaliable alternative values for the selected property. Commit: saves the changed value. When you tap Commit, a registry flush occurs for all settings. NOTE JOYA™ TOUCH...
  • Page 65 Use and Functioning Scan Opens the scan window to scan the area for available SSIDs. Also displays RSSI and security. Diagnostics Tab The Diagnostics tab enables you to troubleshoot connection issues within LCM. User’s Manual...
  • Page 66 Use and Functioning Wi-Fi Status enabled/disabled About Tap to display LCM information including driver and the LCM version. Advanced Tap to display advanced settings for Wi-Fi, strength percentage, and quality percentage. There are three drop-down options: • Status JOYA™ TOUCH...
  • Page 67 Use and Functioning • Ping Tools • Utilities User’s Manual...

  • Page 68: Audio Settings

    From the control panel main window, double-tap the Audio icon: The audio control panel can be used to independently set the playback or recording volume for different types of audio inputs and outputs, such as a headset, powered mobile dock, or the internal speakers and microphone. JOYA™ TOUCH...
  • Page 69 Use and Functioning User’s Manual...
  • Page 70 Volume & Sounds From the control panel main window, select the Volume & Sounds applet by double tapping the Volume & Sounds icon: The Volume & Sounds applet configures audio features of all speakers and headphones and appears as follows: JOYA™ TOUCH...

  • Page 71: Connecting To Other Computers

    Vista and Windows 7; if you run Windows XP or earlier, you have to download Microsoft ActiveSync. To establish a partnership between the JOYA TOUCH and a host PC, start Windows Mobile® Device Center and follow the steps below: 1. Connect the JOYA TOUCH to the host PC. Windows Mobile®...

  • Page 72: Datalogic Firmware Utility

    Use and Functioning Datalogic Firmware Utility The Datalogic devices are equipped with a field upgradeable firmware mechanism. Firmware updates are available on the Datalogic website: http://www.datalogic.com/eng/support-services/automatic-datac apture/downloads/software-utilities-sw-2.html. After you have downloaded the desired update, there are several ways you can update the firmware on your device.

  • Page 73: Installing Dfu On The Host Pc

    NOTE To install the Datalogic Firmware Utility, complete the following steps on the PC: 1. Go to the Datalogic website and download the most current version of the Datalogic Firmware Utility. Unzip the file, then double-click to run DFU_Setup.exe. 2. Click OK to continue once you have removed previous versions of DFU.

  • Page 74: Updating The Firmware

    ActiveSync or Windows Mobile® Device Center connection between the host computer and the Datalogic device. NOTE 1. Go to Start > Programs > Datalogic > DFU > Datalogic Firmware Utility. 2. Verify that ActiveSync is selected by clicking Communications > WMDC/ActiveSync.

  • Page 75: Datalogic Desktop Utility

    Use Application Selector to replace the desktop with a selection of authorized applications. • Restrict user access in Internet Explorer (and customized error recovery mechanisms). To open DDU, access the Control Panel and double-tap the Datalogic Desktop Utility icon. User’s Manual...

  • Page 76: Administrative Options (Admin Tab)

    Password. Set Defaults to reset the default values of all the Set Defaults functions on all the tabs. After you select this option, you will receive a prompt to verify this selection. JOYA™ TOUCH...
  • Page 77 Use and Functioning Setting a Password To set a password: 1. Enter a password in the field using the virtual keyboard. This allows the user to specify a password when this utility is launched. By default the password is ”blank”. Be sure to record the password for future reference.
  • Page 78 Use and Functioning You must tap Set Password prior to exiting DDU in order to store and activate your new password. It is not necessary to select Enable Datalogic Desktop. NOTE If you tap Set Defaults it will remove all custom settings and restore all the factory default settings, except a previously set password.
  • Page 79 1. Enter blanks in both Password fields. 2. Tap Set Password. Password Request Dialog Box Once the password is set, next time you open the Datalogic Desktop Utility, the DDU Password dialog box opens. This dialog box will only open if a password was defined:...
  • Page 80 1. Type in your password using either the keypad on the unit, or using the stylus on the soft input panel (SIP). If you enter an incorrect password, the system will prompt you to input the correct one. 2. Select/tap OK to verify the password. Or tap X to cancel. JOYA™ TOUCH...

  • Page 81: Locked Web Browser Options (Lockedweb Tab)

    Use and Functioning Locked Web Browser Options (LockedWeb tab) Tap the LockedWeb tab to access the Locked Web Browser Configuration. For additional information about Locked Web Browser commands and metatags, see Locked Web Browser on page Error Page Redirection Use the Error Redirection option to provide customized recovery from common errors.
  • Page 82 Web Browser can exit. This password is different than the DDU exit password, with a default value of “0000”. Browser Home This sets the Internet Explorer home page, regardless of the Page enable state of the Locked Web Browser. JOYA™ TOUCH...

  • Page 83: Status Icons Options (Status Tab)

    Use and Functioning Status Icons Options (Status Tab) Tap the Status tab to access the Status Icons option. You can configure the view of some status icons that are used in LockedWeb and in Application Selector to display the status of Wi-Fi radio and battery.

  • Page 84: Windows Control

    This option is only available when the Show Taskbar is checked. Start Menu Enabled to specify whether the Start Start Menu Enabled Menu is displayed or not. This option works only when Task Bar Enabled is checked. AutoSIP Enabled Enables the AutoSIP Windows feature. JOYA™ TOUCH...

  • Page 85: Windows Controls

    Use and Functioning WIndows Controls This control only takes effect in Locked Web Browser. When checked, displays horizontal and vertical scroll bars Scroll Bars Enabled to help view large web pages which do not fit the screen. When unchecked, scroll bars will not be present. Widows CE Desktop When selected, CE Desktop is disabled, so application Enabled...

  • Page 86: Appselector Options (Appselect Tab)

    This is a list of applications that the user can access. Applications Application Selector Commands to create a new application entry. Edit Edit to edit the selected entry. This is a list of applications that the user can access. Up/Down to delete the selected entry. JOYA™ TOUCH...
  • Page 87 Use and Functioning Add Applications The Add Application dialog opens when you tap either New or Edit. From the Add Application dialog the administrator can configure and/or add/change a new application entry in the list. Applications with the Run Application at Startup option enabled will start automatically when the Application Selector starts up.
  • Page 88 Enter a delay duration in seconds in the combo box. This Delay option delays auto start of application(s) to allow drivers to load prior to starting applications. to add/save changes. X Select/tap to cancel the creation of this entry. JOYA™ TOUCH...

  • Page 89: Locked Web Browser

    Use and Functioning Locked Web Browser The Locked Web Browser is a browser helper object for Internet Explorer. It allows an administrator to define a restricted internet usage environment. Once in the restricted environment, a password is required to exit. This means users can only access web applications and websites set by the administrator.

  • Page 90: Flashdisk Directory File Management

    However, since file system persistence is performed after the “\FlashDisk\Startup” folder execution, for those programs which depends upon DLLs resources copied from “\FlashDisk\Windows” to “\Windows” during the cold-boot, the “\FlashDisk\Windows\dl_startup” folder is to be preferred to execute programs and applications, since the execution follows the JOYA™ TOUCH...
  • Page 91 Reinstall?". This message blocks the boot process. Press the [Enter] key to continue the system initialization. In a specific JOYA TOUCH version, a 4GB DS type card is available as permanent general purposes storage device (path = \Storage Card).
  • Page 92 Use and Functioning NOTES JOYA™ TOUCH...

  • Page 93: Connections

    Connections USB Connection USB Direct Connection You can use any standard micro USB cable to directly connect the Datalogic JOYA TOUCH to a host computer to transfer data through the USB interface. Host Computer JOYA TOUCH Standard Micro USB cable type USB A –...

  • Page 94: Wi-Fi Connection

    Connections Wi-Fi Connection The JOYA TOUCH Wi-Fi 802.11 a/b/g/n radio models can communicate with the host using the on-board radio frequency component and an Access Point connected to the host computer. To launch this utility you can tap the specific icon if it' s visible on the taskbar or you can open Connections folder or Control Panel from desktop.
  • Page 95 Connections Suspending the terminal powers off the 802.11 a/b/g/n radio and drops the radio connection. When the terminal resumes, depending on the radio power mode and security protocol selected, it may take up to 30 seconds NOTE for the 802.11 a/b/g/n radio driver to re-associate the radio to the network.

  • Page 96: Bluetooth® Serial Connection

    Connections Bluetooth® Serial Connection JOYA TOUCH models can communicate with a Bluetooth® printer, using the on-board Bluetooth® module. Bluetooth® is only available in Joya Touch plus models. NOTE In order to extend battery life, the Bluetooth® module is off by default. If you need to have Bluetooth® working, the module must be powered on.
  • Page 97 Connections Area coverage and Bluetooth® radio performance may vary, due to environmental conditions or interference caused by other devices (microwave ovens, radio NOTE transmitters, etc.). User’s Manual...

  • Page 98: Wireless And Radio Frequencies Warnings

    WARNING Most modern electronic equipment is shielded from RF signals. However, certain electronic equipment may not be shielded against the RF signals generated by JOYA TOUCH. Datalogic recommends persons with pacemakers or other medical...
  • Page 99 Connections Turn this device OFF in health care facilities when any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may use equipment that could be sensitive to external RF energy. WARNING RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles.
  • Page 100 Areas with a potentially explosive atmosphere are often, but not always, clearly marked or shown. Sparks in such areas could cause an explosion or fire, resulting in injury or even death. JOYA™ TOUCH...

  • Page 101: Technical Features

    Technical Features Technical Data Physical Characteristics Handheld: 14.5 x 7.67 x 3.38 cm / 5.7 x 3 x 1.33 in Dimensions Pistol Grip: 14.5 x 7.67 x 11.6 cm / 5.7 x 3 x 4.56 in Handheld: 275 g / 9.7 oz Weight (with battery) Pistol Grip: 310 g / 10.9 oz Colors (standard)
  • Page 102 4.3 to 35.0 cm / 1.7 to 13.8 in, depending on bar code Depth of Field density Minimum Resolution Linear codes at 4 mils; 2D codes at 5 mils Loudspeaker (Polyphonic audio codec); buzzer; Reading Indicators Datalogic’s patented ‘Green Spot’ technology for good-read feedback JOYA™ TOUCH...
  • Page 103 Technical Features Decoding Capability Auto discriminates all standard 1D codes including 1D / Linear Codes GS1 DataBar™ linear codes Aztec Code, Data Matrix, MaxiCode, QR Code, UPU 2D Codes FICS, USPS Intelligent Mail, Optional Digimarc® bar code Australian Post, Japan Post, KIX Code, Postal Codes PLANET,POSTNET, Royal Mail Code (RM4SCC) Micro-PDF417, PDF417, GS1 DataBar Composites,...
  • Page 104 Technical Features Software Datalogic Configuration Utility (DCU) Configuration and Datalogic Firmware Utility (DFU) Maintenance Datalogic Desktop Utility (DDU) Development SDK Suite available upon request System Joya Touch Basic: System RAM: 512 MB; System Flash: 512 MB Flash Disk Memory Joya Touch Plus: System RAM: 512 MB;...

  • Page 105: Decode Distances

    Technical Features Decode Distances Far Guaranteed Depth of Field Working Ranges 4.72 in Code 39 12 cm 8.27 in Code 39 21 cm 6.69 in 17 cm 14.57 in EAN13 37 cm 9.25 in Datamatrix 23.50 cm 19.29 in Code 39 49 cm User’s Manual...
  • Page 106 Technical Features NOTES JOYA™ TOUCH...

  • Page 107: Test Codes

    Test Codes High Density Codes - 0.25 mm (10 mils) Code 39 17162 Interleaved 2/5 $P,HA13,P 0123456784 Code 128 test User’s Manual...
  • Page 108 Test Codes High Density Codes (continued) - 0.25 mm (10 mils) EAN 13 EAN 8 JOYA™ TOUCH...
  • Page 109 Test Codes Medium Density Codes - 0.38 mm (15 mils) Code 39 17162 Interleaved 2/5 0123456784 Code 128 test User’s Manual...
  • Page 110 Test Codes Medium Density Codes (continued) - 0.38 mm (15 mils) 100% EAN 13 100% EAN 8 JOYA™ TOUCH...
  • Page 111 Test Codes Low Density Codes - 0.50 mm (20 mils) Code 39 17162 Interleaved 2/5 0123456784 Code 128 test User’s Manual...
  • Page 112 Test Codes Low Density Codes (continued) - 0.50 mm (20 mils) 120% EAN 13 120% EAN 8 JOYA™ TOUCH...
  • Page 113 Test Codes 2D Codes Datamatrix ECC200 Example Inverse Datamatrix ECC200 Example User’s Manual...
  • Page 114 Test Codes NOTES JOYA™ TOUCH...

  • Page 115: Maintenance

    Maintenance Cleaning the Device Periodically clean the JOYA TOUCH device and the JOYA TOUCH 3-Slot Cradle using a soft cloth slightly dampened with only water or Isopropyl Alcohol (70%). Do not use any other cleaning agents (e.g. different alcohol, abrasive or corrosive products, solvents) or abrasive pads to clean the device.

  • Page 116: Ergonomic Recommendations

    Keep objects that are used frequently within easy reach • Perform tasks at correct heights • Reduce or eliminate vibration • Reduce or eliminate direct pressure • Provide adjustable workstations • Provide adequate clearance • Provide a suitable working environment • Improve work procedures. JOYA™ TOUCH...

  • Page 117: Safety And Regulatory Information

    Use only the components and accessories supplied by the manufacturer for the specific JOYA TOUCH being used. • Do not attempt to disassemble the JOYA TOUCH, as it does not contain parts that can be repaired by the user. Any tampering will invalidate the warranty.

  • Page 118: Power Supply

    Power Unit LPS/SELV rating 12V, min 5A power source which supplies power via the power connector of the cable. Any changes or modifications to equipment, not expressly approved by Datalogic could void the user's authority to operate the equipment. JOYA™ TOUCH...

  • Page 119: Laser Safety

    Safety and Regulatory Information Laser Safety The following information applies to Laser Aiming System, used on JOYA TOUCH Imager. The laser light is visible to the human eye and is emitted from the window indicated in the figure below. LASER LIGHT - DO NOT STARE INTO BEAM...
  • Page 120 ONDA EMITIDA: D' O NDA EMESSA: WELLENLÄNGE: D' O NDE EMISE: 630~680 nm 630~680 nm 630~680 nm 630~680 nm CONFORME A EN CONFORME A EN ENTSPR. EN CONFORME A EN 60825-1 (2007) 60825-1 (2007) 60825-1 60825-1 (2007) (2007) JOYA™ TOUCH...
  • Page 121 Safety and Regulatory Information ENGLISH The following information is provided to comply with the rules imposed by international authorities and refers to the correct use of your device. STANDARD LASER SAFETY REGULATIONS This product conforms to the applicable requirements of both CDRH 21 CFR 1040 and EN 60825-1 at the date of manufacture.
  • Page 122 ATTENZIONE autorizzato, potrebbe violare le norme della sicurezza. Il sistema ottico può essere riparato solamente alla fabbrica. L'utilizzo di procedure o regolazioni differenti da quelle descritte nella documentazione può provocare un'esposizione pericolosa a luce laser visibile. ATTENZIONE JOYA™ TOUCH...
  • Page 123 Safety and Regulatory Information Il prodotto utilizza un diodo laser a bassa potenza. Sebbene non siano noti danni riportati dall’occhio umano in seguito ad una esposizione di breve durata, evitare di fissare il raggio laser così come si eviterebbe qualsiasi altra sorgente di luminosità intensa, ad esempio il sole.
  • Page 124 Sie es, den Laserstrahl weder gegen die Augen eines Beobachters, noch gegen reflektierende Oberflächen zu richten. Die Verwendung von Optiksystemen mit diesem Scanner erhöht die Gefahr einer Augenbeschädigung. Zu optischen Instrumenten gehören unter anderem Ferngläser, Mikroskope, Brillen ACHTUNG Vergrößerungsgläser. JOYA™ TOUCH...
  • Page 125 Safety and Regulatory Information FRANÇAIS Les informations suivantes sont fournies selon les règles fixées par les autorités internationales et se réfèrent à une correcte utilisation du terminal. NORMES DE SECURITE LASER Ce produit est conforme aux normes de sécurité laser en vigueur à sa date de fabrication: CDRH 21 CFR 1040 s et EN 60825-1.
  • Page 126 ATENCIÓN violación a los reglamentos de seguridad. El sistema óptico se puede reparar en la fábrica solamente. La utilización de procedimientos o regulaciones diferentes aquellas describidas documentación puede causar exposición peligrosa a la luz láser visible. ATENCIÓN JOYA™ TOUCH...

  • Page 127: Led Class

    Safety and Regulatory Information El aparato utiliza un diodo láser a baja potencia. No son notorios daños a los ojos humanos a consecuencia de una exposición de corta duración. Eviten de mirar fijo el rayo láser así como evitarían cualquiera otra fuente de luminosidad intensa, por ejemplo el sol. Además, eviten de dirigir el rayo láser hacia los ojos de un observador, también a través de superficies reflectantes como los espejos.

  • Page 128: Statement Of Compliance

    English Directive 1999/5/EC and 2011/65/EU. Por medio de la presente Datalogic S.r.l. declara que el Joya Touch cumple con los requisitos esenciales y cualesquiera otras Español disposiciones aplicables o exigibles de la Directiva 1999/5/CE - [Spanish] 2011/65/EU.
  • Page 129 Datalogic S.r.l. declara que este Joya Touch está conforme com os Português requisitos essenciais e outras disposições da Directiva [Portuguese 1999/5/CE - 2011/65/EU. Datalogic S.r.l. izjavlja, da je ta Joya Touch v skladu z bistvenimi Slovensko zahtevami in ostalimi relevantnimi določili direktive 1999/5/ES - [Slovenian] 2011/65/EU.
  • Page 130 Safety and Regulatory Information Datalogic S.r.l. vakuuttaa täten että Joya Touch tyyppinen laite on Suomi direktiivin 1999/5/EY - 2011/65/EU oleellisten vaatimusten ja [Finnish] sitä koskevien direktiivin muiden ehtojen mukainen. Härmed intygar Datalogic S.r.l. att denna Joya Touch står I överensstämmelse med de väsentliga egenskapskrav och övriga Svenska relevanta bestämmelser som framgår av direktiv 1999/5/EG -...

  • Page 131: Radio Technologies And Frequency Bands

    Safety and Regulatory Information Radio Technologies and Frequency Bands JOYA TOUCH incorporates the following radio technologies and supports the corresponding frequencies, as specified below for Plus and Basic Variants: Plus Basic Variants Variants Radio FCC ID: FCC ID: Frequency Bands...

  • Page 132: Information For The User

    Ihres Landes, um zu prüfen ob es Einschränkungen gibt, oder eine Lizenz erforderlich ist. ESPAÑOL Contacta la autoridad competente para la gestión de los dispositivos de radio frecuencia de tu país, para verificar cualesquiera restricciones o licencias posibles requerida. JOYA™ TOUCH...

  • Page 133: Fcc/Ic Labeling

    This device is restricted to indoor use when operated in the 5.15 to 5.25 GHz frequency range. Changes or modifications made to this equipment not expressly approved by Datalogic S.r.l. may void the FCC authorization to operate this equipment. User’s Manual...
  • Page 134 Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. JOYA™ TOUCH...

  • Page 135: Ised Compliance

    Safety and Regulatory Information ISED Compliance NOTICE: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1)this device may not cause harmful interference, and (2)this device must accept any interference received, including interference that may cause undesired operation.
  • Page 136 (ii) les utilisateurs de radars de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu’ils ont la priorité) pour les bandes 5 250-5 350 MHz et 5 650-5 850 MHz et que ces radars pourraient causer du brouillage et/ou des dommages aux dispositifs LAN-EL. JOYA™ TOUCH...

  • Page 137: Radiofrequency Radiation Exposure Information

    More information about the relevant Standards for SAR measurement methods and procedures may be found in the CE DoC included in the product user manual available at www.datalogic.com website and at the FCC public listing www.fcc.gov under the FCC IDs specified in the FCC/IC labeling section.

  • Page 138: Weee Compliance

    For more detailed information about disposal, contact the supplier that provided you with the product in question or consult the dedicated section at the website http://www.datalogic.com. Informazione per gli utenti L’apparecchiatura che riporta il simbolo del bidone barrato deve essere smaltita, alla fine della sua vita utile, separatamente dai rifiuti urbani.
  • Page 139 Am Ende des Gerätelebenszyklus darf das Produkt nicht über den städtischen Hausmüll entsorgt werden. Eine entsprechende Mülltrennung ist erforderlich. Weitere Informationen zu dieser Richtlinie erhalten sie von ihrem Lieferanten über den sie das Produkt erworben haben, oder besuchen sie unsere Hompage unter http://www.datalogic.com. User’s Manual...
  • Page 140 Safety and Regulatory Information NOTES JOYA™ TOUCH...

  • Page 141: Support

    • email form to contact our technical support. Reference Documentation For further information regarding the Joya Touch refer to the SDK Help on-line. Warranty Terms and Conditions The warranty period is 1 year for the device and 90 days for consumables (e.g.
  • Page 142 Support NOTES JOYA™ TOUCH...

  • Page 143: Glossary

    Glossary Access Point A device that provides transparent access between Ethernet wired networks and IEEE 802.11 interoperable radio-equipped mobile units. Hand-held mobile computers, PDAs or other devices equipped with radio cards, communicate with wired networks using Access Points (AP). The mobile unit (mobile computer) may roam among the APs in the same subnet while maintaining a continuous, seamless connection to the wired network.
  • Page 144 Character A pattern of bars and spaces which either directly represents data or indicates a control function, such as a number, letter, punctuation mark, or communications control contained in a message. JOYA™ TOUCH...
  • Page 145 Glossary Decode To recognize a bar code symbology (e.g., Codabar, Code 128, Code 3 of 9, UPC/EAN, etc.) and convert the content of the bar code scanned from a visual pattern into electronic data. Density (Bar Code Density) The number of characters represented per unit of measurement (e.g., characters per inch).
  • Page 146 (Internet Protocol address) The address of a computer attached to an IP network. Every client and server station must have a unique IP address. A 32-bit address used by a computer on a IP network. Client workstations have either a permanent address or one that is JOYA™ TOUCH...
  • Page 147 Glossary dynamically assigned to them each session. IP addresses are written as four sets of numbers separated by periods; for example, 204.171.64.2. Laser Light Amplification by Stimulated Emission of Radiation.The laser is an intense light source. Light from a laser is all the same frequency, unlike the output of an incandescent bulb.
  • Page 148 Signal conditioning circuit - transforms optical detector output into a digitized bar pattern. Software Development Kit. Symbol A scannable unit that encodes data within the conventions of a certain symbology, usually including start/stop characters, quiet zones, data characters and check characters. JOYA™ TOUCH...
  • Page 149 Glossary Symbology The structural rules and conventions for representing data within a particular bar code type (e.g. UPC/EAN, Code 39, PDF417, etc.). Universal Serial Bus. Type of serial bus that allows peripheral devices (disks, modems, printers, digitizers, data gloves, etc.) to be easily connected to a computer.
  • Page 150 ©2016 Datalogic S.r.l. • All rights reserved. Datalogic and the Datalogic logo are registered trademarks of Datalogic S.p.A. in many countries, including the U.S.A. and the E.U. JOYA is a trademark of Datalogic S.p.A. or of Datalogic Group companies, registered in many countries, including the U.S.

Table of Contents
