Functions described in this manual

• The functions described in this manual must be enabled by the installer.
• Some of the functions could not be active and visualization might have small variations.
• To identify pushbuttons and LEDs that are explained in various functions, refer to the table
in chapter "Keyboard" of the specific model.

Display lighting

The backlight turns on when any key is pressed (Eg. the [CLR]).

Zone circuit test

The zones open or by-passed are shown directly on the display after entering the User Code;
press [CLR] key to remain in this menù.

Alarm display

The zones that have triggered alarms in the control panel are displayed in sequence in the second
line of the display, while the current date and time are displayed above.

LED signalling A500 - A500 Plus

1. Red Led - System armed (3)
Visualization of this led is linked to the sector to which the keypad is associated and shows the
arming or the occurred alarm.
• If on, the sector/s, associated to keypad, is armed in one of its modes.
• If off, the sector/s, associated to keypad, is disarmed.
• If flashing, the sector/s, associated to keypad, is disarmed.and an alarm has occurred
during the previous arming.
• If flashing quikly, at least one of the sectors associated to keypad, is armed.
2. Yellow Led - Presence of 220Ac mains (4)
• If on, mains voltage is present; the situation is correct.
• If off, there is no mains voltage.
3. Green Led - System ready (14)
This led shows the zone state of the sector associated to the keypad
• If on, all the zones are ready to be enabled.
• If off, at least one of the zones is open.
• If flashing, at least one zone has been by-passed.
4. Red Led - Take care, visualization on display (15)
• If on, it gives information about a visualization on display of keypad
• If off, there is no information to visualize.
Functions of Accessory Leds (1 and 2)
1)
_____________________________
2)
_____________________________
- 9 -
