Description of the ICE keypad

1
2
3
4
12
1
2
3
4
5 01/11/15
6 25° C
7
8
o
9
o
10
11
12
13
ICE KEYPAD
13
MICROPHONE - FUTURE USES
LOGO - ACCESS TO NOTIFICATIONS CENTRE
ACCESS IN KEYPAD MODE
ACCESS IN APP MODE
13:09
SYSTEM DATE AND TIME
TEMPERATURE DETECTED BY KEYPAD
LED - FUTURE USES
RED LED - POWER OFF (White) or POWER ON (Red)
GREEN LED - SYSTEM NOT READY (White) or SYSTEM READY (Green)
ACCESS IN QUICK ARM MODE
LOGO - TOY READER
SLOT FOR MICRO SD CARD (FOR INSTALLER)
MINI USB PORT (FOR INSTALLER)
5
01/11/15
- 25 -
6
7
8
9
10
11
