Operating instructions
PLANETARY MICRO MILL
PULVERISETTE 7 premium line
Valid starting with: 07.5000/00100
Read the instructions prior to performing any task!
Translation of the original operating instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PULVERISETTE 7 premium line and is the answer not in the manual?

Questions and answers

Related Manuals for Fritsch PULVERISETTE 7 premium line

Summary of Contents for Fritsch PULVERISETTE 7 premium line

  • Page 1 Operating instructions PLANETARY MICRO MILL PULVERISETTE 7 premium line Valid starting with: 07.5000/00100 Read the instructions prior to performing any task! Translation of the original operating instructions...
  • Page 2 Fritsch GmbH Milling and Sizing Industriestraße 8 D - 55743 Idar-Oberstein Telephone: +49 (0)6784/ 70-0 Fax: +49 (0)6784/ 70-11 Email: info@fritsch.de Internet: www.fritsch.de Version 10/2013 Index 020...
  • Page 3 Certifications and CE conformity Certification Fritsch GmbH has been certified by the TÜV-Zertifizierungsgemeinschaft e.V. An audit certified that Fritsch GmbH conforms to the requirements of the DIN EN ISO 9001:2008. CE Conformity The enclosed Conformity Declaration lists the guidelines the FRITSCH instrument conforms to, to be able to bear the CE mark.

  • Page 4: Table Of Contents

    Table of contents Table of contents Safety information and use............8 1.1 Requirements for the user............. 8 1.2 Scope of application............... 8 1.2.1 Operating principle............. 9 1.2.2 Drive motor and speed regulation........9 1.3 Obligations of the operator........... 9 1.4 Information on hazards and symbols used in this manual. . 10 1.5 Information on hazards at the device........
  • Page 5 Table of contents 5.1.3 Grinding bowl lid............... 31 5.2 Choice of grinding bowls and grinding balls......31 5.2.1 Useful capacity of the grinding bowls....... 33 5.2.2 Size of the grinding balls........... 33 5.2.3 Number of balls per grinding bowl (independent of the material quantity).............
  • Page 6 Table of contents 6.1.3 Hose adapter for grinding bowl gassing......63 6.1.4 Removing the gassing lid in individual steps..... 64 6.2 Gassing lid with stainless steel, swagelok hose couplings... 66 6.2.1 Scope of delivery / lid design..........67 6.2.2 Fitting the gassing lid on the grinding bowl...... 67 6.2.3 Hose adapter for grinding bowl gassing......
  • Page 7 Table of contents Cleaning..................104 8.1 Grinding elements.............. 104 8.2 Mill..................104 8.2.1 Removing the grinding chamber cover......105 Maintenance................106 Guarantee terms................ 107 Exclusion of liability..............109 Safety logbook................111 Index................... 113 - 7 -...

  • Page 8: Safety Information And Use

    People with health problems or under the influence of medication, drugs, alcohol or exhaustion must not operate this device. The of the PULVERISETTE 7 premium line may only be operated by authorised persons and serviced or repaired by trained specialists. All commissioning, maintenance and repair work may only be carried out by technically qualified personnel.

  • Page 9: Operating Principle

    1.3 Obligations of the operator Before using the of the PULVERISETTE 7 premium line, this manual is to be carefully read and understood. The use of the of the PULVERISETTE 7 premium line requires technical knowledge; only commercial use is per- mitted.

  • Page 10: Information On Hazards And Symbols Used In This Manual

    Neither compliance with this manual nor the conditions and methods used during installation, operation, use and maintenance of the of the PULVERISETTE 7 premium line can be monitored by Fritsch GmbH. Improper execution of the installation can result in property damage and thus endanger persons.
  • Page 11 Safety information and use DANGER! This symbol and keyword combination points out a directly hazardous situation due to electrical current. Ignoring infor- mation with this designation will result in serious or fatal injury. DANGER! This symbol and keyword combination designates contents and instructions for proper use of the machine in explosive areas or with explosive substances.
  • Page 12 Safety information and use Example: Loosen screw. CAUTION! Risk of entrapment at the lid. Close the lid carefully. Tighten screw. Tips and recommendations This symbol emphasises useful tips and recommendations as wells as information for efficient operation without mal‐ function. Further designations To emphasise procedure instructions, results, lists, references and other elements, the following designations are used in this manual:...

  • Page 13: Information On Hazards At The Device

    Safety information and use 1.5 Information on hazards at the device There is a laser radiation hazard warning on the back of the device. It is explained below. Do not remove the information and warning signs. Caution! Hot surface Caution! Crushing hazard 1.6 Device safety information Only use genuine accessories and genuine spare parts.
  • Page 14 If the planetary micro mill or its components are dam- aged or if its operation is not as described in the oper- ating manual, the device may not be put into service. In such a case, consult your Fritsch GmbH representative or distributor. WARNING! The maximum accepted concentration (MAC) levels of the valid safety regulations must be observed.

  • Page 15: Protective Equipment

    Do not remove the information signs. Unauthorised alteration of the device will void Fritsch's declaration of conformity to European directives and void the guarantee. If, after reading the operating manual, there are still questions or problems, please do not hesitate to contact our specialists.

  • Page 16: Hazardous Points

    Safety information and use 1.8 Hazardous points Crushing hazard when opening and closing the grinding chamber cover (the closing force can be adjusted, consult Fritsch GmbH). Crushing hazard when adjusting the control display. Crushing hazard when using the locking lever.

  • Page 17: Protection Against Restart

    Safety information and use 1.9.2 Protection against restart In the case of a power failure during operation or after turning the device off at the main switch, the grinding chamber cover is locked. When the power supply is restored, the grinding chamber is not opened until the software detects that the drive is stationary.

  • Page 18: Technical Data

    Technical data Technical data 2.1 Dimensions 360 mm x 400 mm x 580 mm (height x width x depth) 2.2 Weight Net: approx. 44 kg Gross: approx. 61 kg 2.3 Operating noise The sound level is approx. 74 dB (A). This value fluctuates significantly, depending on the speed and material to be ground and on the type of grinding bowl and grinding balls.

  • Page 19: Electrical Fuses

    Technical data 2.7 Electrical fuses Fuses on the back of device: 2x10 A T 2.8 Material Maximum feed amount in the case of hard material approx. 5 mm Maximum feed amount 2 x 35 ml 2.9 Final fineness Dry grinding up to d <...

  • Page 20: Installation

    Installation Installation 3.1 Transport The device is delivered on a transport pallet with a wooden cover. We recommend using a forklift or pallet truck for transporting the packed device. DANGER! Do not step under the transport pallet during transport. WARNING! Improper lifting can lead to personal injury or property damage.

  • Page 21: Setting Up

    Please store the transport packaging in order that it can be reused in case you need to return the product. Fritsch GmbH denies all liability for any damage due to improper packaging (non-genuine packaging).

  • Page 22: Ambient Conditions

    Installation 3.4 Ambient conditions WARNING! Mains voltage! – The device may only be operated indoors. – The surrounding air may not carry any electrically con- ductive dust. – Maximum relative humidity 80% for temperatures up to 31°C, linearly decreasing down to 50% relative humidity at 40°C.
  • Page 23 Installation NOTICE! Fritsch mills are speed controlled. The devices are equipped for this with frequency converters. In order to comply with the EMC directive, many measures must be taken to pre- vent operational transient emissions. The possible leakage currents resulting from filtering meas- ures can trigger a conventional residual current circuit breaker in the mains line.

  • Page 24: Initial Start-Up

    Initial start-up Initial start-up Switch on the device only after all work as described in Ä ‘Installation’ on page 20 has been carried out. 4.1 Switching on Connect the device to the power supply using the cable provided (device cable with IEC 320/C13 plug). Turn the device on at the main switch.
  • Page 25 Initial start-up You can make various settings in the next menu. Select the "Parameters" menu item. A sub-menu appears in which you can enter the speed using the input keys. Set the speed to 100. Press the "<" button to save your entry and return to the main menu.

  • Page 26: Switching Off

    Initial start-up The sensors detect that the grinding bowls are not present. Press the ">" button to open the grinding chamber cover and grinding station 1 is moved into the loading position. The device functions are OK. 4.3 Switching off If the device is put out of service for a lengthy period, close the grinding chamber cover using the "Close"...

  • Page 27: Using The Device

    5.1 Safety information DANGER! The PULVERISETTE 7 premium line planetary mill from Fritsch enables speeds of up to 1100 rpm. The application of high energy may result in very high temperatures and high pressures in the grinding bowl. Failure to observe the following safety instructions could...

  • Page 28: General Information

    In such a case, the grinding bowls and the machine are not covered by the Fritsch guarantee. To clean the grinding bowl and its components, follow the operating instructions precisely ( Ä...

  • Page 29: Overpressure Relief Of The Grinding Bowls

    Using the device 5.1.2 Overpressure relief of the grinding bowls The grinding bowl seals have a sealing effect but are also for overpres- sure relief. If the pressure increases gradually during grinding, the special seals open at a certain pressure and release the overpressure in a defined manner.
  • Page 30 Using the device Be extremely careful if solvents are used. 60 ml isopropanol in an 80 ml grinding bowl results in the development of the following pressure and temperature: Temperature of grinding bowl Pressure in the grinding bowl wall [°C] [bar] 10.5 The overpressure limit for fluororubber flat seals is reached at 120 °C...

  • Page 31: Grinding Bowl Lid

    Using the device 5.1.3 Grinding bowl lid The grinding bowl lids seal the grinding bowl gastight after manual pre- tensioning (see also Ä ‘Safety measures against an excessively high pres‐ sure’ on page 40). The locking hooks are designed to withstand an internal grinding bowl pressure of up to 40 bar.
  • Page 32 Using the device CAUTION! The grinding element is subject to normal wear during use. Before every grinding operation, check the wall thickness of the grinding bowls. In the event of severe wear, replace the grinding bowl. If this is not done, the prevailing high centri- fugal forces during grinding may cause the grinding balls to penetrate the bowl's wall and damage the mill.

  • Page 33: Useful Capacity Of The Grinding Bowls

    Using the device Exception: Tungsten carbide balls (<20 mm) may be temporarily (a few minutes) combined with grinding bowls made of hardened steel. 5.2.1 Useful capacity of the grinding bowls Grinding bowl 20 ml 45 ml 80 ml Useful capacity 1-9 ml 3-20 ml 10-30 ml...

  • Page 34: Number Of Balls Per Grinding Bowl (Independent Of The Material Quantity)

    Using the device 5.2.3 Number of balls per grinding bowl (independent of the material quantity) A higher number of balls will reduce the grinding duration and the grinding results will be within a smaller grain size range. The number of balls should be complied with to avoid unnecessary wear. Ball diameter (mm) Grinding bowl volume (ml)

  • Page 35: Calculated Weight Of A Ball

    Using the device 5.2.4 Calculated weight of a ball Ball diameter in mm Material Density Calculated weight of a ball in g in g/cm Agate 2,65 0,17 1,39 4,68 11,1 Silicon nitride 3,25 0,20 1,16 5,48 12,99 Sintered 0,25 1,99 6,72 15,92 corundum...

  • Page 36: Filling Quantities Of Grinding Bowls

    Using the device The large surface of many small balls results in high thermal stress due to the friction effect. It can already be measured after 5 minutes of grinding above 100 °C by a surface sensor on the surface of the lid. Inside the grinding bowl, the temperature is then much higher.

  • Page 37: Filling The Grinding Bowl

    Using the device 5.5 Filling the grinding bowl Do not fail to comply with the following sequence: Place the grinding balls in the empty bowl. Fill material to be ground over the balls. CAUTION! Never operate the device without material to be ground, otherwise the grinding balls and grinding bowl will be dam- aged.

  • Page 38: Number And Size Of The Balls

    Using the device 5.6.4 Number and size of the balls Pre-grind course, hard material with large balls: reduced percentage of fine material! Many small balls increase the percentage of fine material during extended running time. 5.6.5 Weight of the balls (type of material) A higher mass (specific weight) of the grinding balls accelerates grinding.

  • Page 39: The Effect Of High Temperature

    Using the device During the transition to grinding in suspension, you can add a liquid aux- iliary agent with high boiling point and low vapour pressure, e.g. water, white spirits (boiling point 100 - 140°C), or alcohols with a high boiling point (e.g.

  • Page 40: Safety Measures Against An Excessively High Pressure

    Using the device NOTICE! If the permissible maximum temperature in the bowl is exceeded during grinding, then the device must not be switched off with the lid closed. That could lead to heat accumulation in the machine, which could cause damage to the device.

  • Page 41: Handling The Grinding Bowl

    Using the device 5.9 Handling the grinding bowl 5.9.1 Design Compl. bowl Compl. lid Flat seal Locking hook Compl. handle Valve plug Press-on sleeve Actuating pin Lid insert 5.9.2 Opening the grinding bowl after a grinding operation Allow the bowl (1) to cool down. Release the pressure by turning the press-on sleeve (7) to open it.

  • Page 42: Closing The Grinding Bowl

    Using the device If the lid insert (9) is sticking on the flat seal (3), apply a screw- driver to the actuating pin (8) to remove the lid insert (9) from the flat seal (3). Open the lid (2). 5.9.3 Closing the grinding bowl Insert the flat seal (3) in such a way that the recess is near a locking hook (4).
  • Page 43 Using the device The lid (2) is now lying on the small lug (a) of the locking hook (4) on the edge of the bowl. (a) Lug Turn the lid (2) on the bowl until the small lugs (a) of the locking hooks (4) engage in the recesses on the edge of the bowl.
  • Page 44 Using the device Make sure that the locking hooks engage exactly in the middle of the recess. Only then can the bowl be closed properly and inserted in the device. + Make sure that the distances are the same. Turn the handle (5) down firmly; the press-on sleeve (7) must be released for air to escape from the bowl.

  • Page 45: Inserting The Grinding Bowl In The Grinding Bowl Holder

    Using the device 5.9.4 Inserting the grinding bowl in the grinding bowl holder Carry out the following checks before inserting the grinding bowls: Are the grinding bowls clean on the outside? à remove any coarse dirt. Is the grinding bowl adapter clean on the inside? à remove any coarse dirt.

  • Page 46: Removing The Grinding Bowl

    Using the device Push the locking element (11) down on the bowl holder. à the grinding bowl is lowered within the mounting device. Apply vertical pressure to the grinding bowl handle (5) to lock the grinding bowl in place in its adapter. The grinding bowl is locked correctly if the locking element (11) on the mounting device moves back up into its initial position.
  • Page 47 Using the device Push the locking element (11) down on the bowl holder. The grinding bowl is unlocked and moves up a few millimetres. Now, the grinding bowl can be removed (upwards) from its holder. (Hold the grinding bowl preferably at the handle (5) provided for this purpose).

  • Page 48: Mass Balance

    Using the device Push the clamping brackets (10) down until they engage in the bracket guides (12) provided and can not be moved down any fur- ther. The loading position can only be changed if the locking elements (11) and clamping brackets (10) that are not in their initial posi- tions and block the milling mechanism reach their initial positions again correctly.

  • Page 49: Grinding Duration

    100°C. The pressure must also be released when the grinding bowl has cooled down. The PULVERISETTE 7 premium line is not suitable for grinding with steel or tungsten carbide grinding bowls in water suspensions. The application of extremely high energy results in abrasion wear in the nano range.

  • Page 50: Program Sequence After Switching On

    Using the device Initially, a grinding duration of 5 minutes should be set and the tempera- ture measured on the actuating pin using a surface thermometer. If it is below 80 °C, grinding can be continued until a temperature of 90 °C is reached.
  • Page 51 Using the device Grinding station 1 is moved into the loading position. The grinding chamber cover opens automatically. Insert the grinding bowl ( Ä ‘Filling the grinding bowl’ on page 37), loaded with the sample ( Ä ‘Handling the grinding bowl’ on page 41) and closed correctly, in the grinding bowl holder ( Ä...
  • Page 52 Using the device The field coloured in black is active. When you start to enter a number, the previous one is deleted, or press the C button to delete the current parameter. Maximum possible entries are: Speed = 1100 rpm, time = 999 min, pause = 99 min, cycles = 99.

  • Page 53: Starting Grinding At High Speed

    Using the device If the sensors detect insufficient safety, the starting procedure is interrupted and the cause is displayed. Press the > button to open the grinding chamber and move grinding station 1 into the loading position. When the error is corrected, grinding can be continued. 5.12.2 Starting grinding at high speed If the speed exceeds 600 rpm, the correct ball size must be selected.

  • Page 54: Overload

    Using the device 5.12.3 Overload If the planetary micro mill is overloaded, the speed is reduced. The reduced speed flashes on the display. 5.12.4 "Program" menu item Grinding cycles can be programmed, saved and selected here. Press the "Menu" button in the main menu. Then press the "Program"...

  • Page 55: Saving The Current Data

    Using the device 5.12.5 Saving the current data First select the program section that is free or to be overwritten. Then, press the Save button to save the current parameters to the selected program section. After saving them successfully, the new parameters are now dis- played in the "Program"...

  • Page 56: Setting The Time Control

    Using the device Press the "<" button to return to the main menu. The program is disabled by manual input e.g. of the speed (see Ä ‘Program sequence after switching on’ on page 50). 5.12.7 Setting the time control Select Menu. Select Clock.

  • Page 57: Imbalance Check

    Using the device Press the "<" button to confirm your entry Enter the time offset. By entering a time offset, grinding is only started after this delay in time. This function is displayed as active in the main menu. Press the "<" button to confirm your entries ð...
  • Page 58 Using the device To tolerate this imbalance within specific limits, you can set the shut- down threshold. Touch the adjustment bar or move it back and forth by applying slight pressure. Press the "<" button to confirm your entries Small setting values make the measuring system more sen‐ sitive, and high values make it less sensitive.

  • Page 59: Switching Off

    Using the device 5.12.9 Switching off NOTICE! If the permissible maximum temperature in the bowl is exceeded during grinding, then the device must not be switched off with the lid closed. That could lead to heat accumulation in the machine, which could cause damage to the device.

  • Page 60: Accessories

    Accessories Accessories 6.1 Standard gassing lid for grinding with inert gas NOTICE! Our workers perform a water bath test on all gassing lids. The part to be tested is sealed, a pressure of 5.5 bar is applied and it is immersed in a water bath. If there is a leak, bubbles will develop.

  • Page 61: Fitting The Gassing Lid On The Grinding Bowl

    Accessories 6.1.2 Fitting the gassing lid on the grinding bowl Place the silicone flat seal (2) on the edge of the bowl insert. (9) Gassing lid handle The central handle (9) must be removed as illustrated. Hold the lid at the hook. Push the hook up and place the lid on the bowl.
  • Page 62 Accessories After releasing the hooks, they must be immersed completely in the recesses on the outer diameter of the bowl fitting and be exactly vertical. Push the central handle (9) down by hand until the resistance increases. Use the hexagon socket wrench (1) to tighten it with maximum manual force.

  • Page 63: Hose Adapter For Grinding Bowl Gassing

    Accessories This is what the closed grinding bowl looks like. 6.1.3 Hose adapter for grinding bowl gassing Push the locking lever (11) of the connection on the hose inwards. (11) Locking lever Push the hose connection onto the valve (8) and down onto the inner seal.

  • Page 64: Removing The Gassing Lid In Individual Steps

    Accessories For flushing, the second valve can be opened with a pen, e.g. the tip of a ballpoint pen. NOTICE! The gas must be supplied very slowly to avoid any turbu- lence in the grinding bowl or of the material to be ground when it is inserted.
  • Page 65 Accessories (10) Actuating pin Unscrew the two actuating pins (10) with a broad slotted screw- driver (tightening torque approx. 4-5Nm = maximum manual force). Unscrew the two valves (8) using the socket wrench (1) (tightening torque approx. 3.5-4Nm = maximum manual force). Remove the flat seals (4) under the valves.

  • Page 66: Gassing Lid With Stainless Steel, Swagelok Hose Couplings

    Accessories (5) Valve insert Turn the two valve inserts out of the valves using the valve key (6). (Tightening torque approx. 1.5-2Nm = average manual force). The valve is held in place using the socket wrench (1), and the valve insert (5) is removed using the valve key (6).

  • Page 67: Scope Of Delivery / Lid Design

    Accessories 6.2.1 Scope of delivery / lid design Compl. gassing lid handle Actuating pin Compl. gassing lid fitting Gassing lid insert Gassing valve connecting plug Flat seal, 57.5x48x2, silicone Gassing valve quick-release coupling 10 Hexagon socket wrench size 13 Sealing ring 8x12x1mm, vulcanised fibre 11 Single head wrench, size 11 Flat seal 6.2.2 Fitting the gassing lid on the grinding bowl...
  • Page 68 Accessories Place the gassing lid insert (8) with the seal gassing valves (3 and 4) and actuating pins (7) on the flat seal (9) in the bowl. Hold the lid (2) at the hooks. Push the hooks outwards and place the lid (2) on the bowl above the gassing lid insert (8).

  • Page 69: Hose Adapter For Grinding Bowl Gassing

    Accessories Push the central handle (1) down by hand until the resistance increases. Use the hexagon socket wrench (10) to tighten it with maximum manual force. The maximum manual force is equivalent to a torque of approx. 3.5-4Nm. This is what the closed grinding bowl looks like. 6.2.3 Hose adapter for grinding bowl gassing Quick-release coupling structure with screwed pipe fitting...

  • Page 70: Removing The Gassing Lid In Individual Steps

    Accessories These parts are not included in the scope of delivery. They are only one example of how gassing hoses can be connected to the hose couplings. Fixed 2.8 mm polyamide hoses are connected here by a threaded hose connection. 6.2.4 Removing the gassing lid in individual steps Turn the central handle (1) and remove it by hand.
  • Page 71 Accessories Unscrew the two valves (3 and 4) using the size 11 single-head wrench (11) (tightening torque approx. 3.5-4Nm = maximum manual force) Gassing valve quick-release coupling Sealing ring 8x12x1mm, vulcanised fibre Flat seal Gassing lid insert Remove the seals (5 and 6) from under the valves. The seals are deformed by the contact pressure.

  • Page 72: Easy Gtm Gas Pressure And Temperature Measuring System

    Accessories 6.3 EASY GTM Gas Pressure and Temperature Measuring System The EASY GTM gas pressure and temperature measuring system is used to control the grinding process and for mechanical alloying. NOTICE! If grinding balls with a diameter of 1 mm or smaller are used, there is a risk of the through holes in the lid getting clogged, which could falsify the pressure and temperature measurement.

  • Page 73: Inserting / Changing The Battery

    Accessories 6.3.2 Inserting / changing the battery Prior to initial start-up, the battery (2) provided must be inserted in the measuring/transmission unit (8) of the system. When inserting it for the first time and during subsequent replacement of the battery, proceed as follows: If not already done, switch off the radio system using the button (A).
  • Page 74 Accessories Undo the two screws (D) of the battery compartment using a hex- agon offset screwdriver, size 2.5mm (6). Lift off the battery compartment lid and place it to the side. The battery compartment can be seen. NOTICE! Please note that the the battery (2) fits exactly in place and may need to be pushed in using a certain amount of force.

  • Page 75: Configuration Of Transmitter Id And Data Transmission Frequency

    Accessories 6.3.3 Configuration of transmitter ID and data transmission frequency The measuring/transmission unit (12) is equipped with four configura- tion switches for setting the transmitter ID and data transmission fre- quency. The switches illustrated are all OFF (actuator cams set to OFF). 6.3.3.1 Adjustment options of the transmitter detection In the delivery condition all switches are set to OFF.

  • Page 76: Installation Of The Transmission Unit On The Easy Gtm Bowl

    Accessories 6.3.3.2 Transmission frequency setting options Transmission every Switch 3 Switch 4 1 second ½ second ¼ second automatic 1-second transmission is the default value. For automatic transmission, the 1 / ½ / ¼ second transmission frequency is switched over in the event of fast changes in pressure or temperature. The data transmission frequency naturally also has an impact on the bat- tery's service life.
  • Page 77 Insert the seal in the bowl! Insert the intermediate lid! NOTICE! Always insert the intermediate lid before grinding with the EasyGTM system! Fritsch assumes no guar- antee for damage caused by grinding without the intermediate lid! Apply the transmitter with seal!

  • Page 78: Installation Of The Receiver Board In The P-7 Premium Line

    Accessories Switch on the transmitter with the On/Off button (A) and insert the bowl as described in Ä ‘Inserting the grinding bowl in the grinding bowl holder’ on page 45! NOTICE! Check the fitting of the transmission unit again after inserting the bowl! NOTICE! During a grinding, during the pauses, the correct...

  • Page 79: Activating Easy Gtm

    Accessories The PKM interfaces board (81.0011.00) is on the rear panel, with the slot (f) for the receiver module 81.0013.00. Insert the receiver module in the corresponding slot. (As illus- trated) Close the rear panel of the housing again and screw it tight. 6.3.6 Activating EASY GTM If the device is protected by SOP mode ( Ä...
  • Page 80 Accessories Select Menu. Select "EasyGTM" sub-menu. Activate EASY GTM. The inverted button indicates the current status. - 80 -...

  • Page 81: Entering The Temperature Limit

    Accessories 6.3.7 Entering the temperature limit Select the maximum temperature input. If the max. temperature is reached, the device stops the grinding process and goes into cooling mode! Depending on the setting of the operating mode, see Ä ‘Selecting the operating mode’ on page 83, the device stops the grinding process and opens the grinding chamber cover or reduces the speed gradu‐...

  • Page 82: Entering The Pressure Limit

    Accessories 6.3.8 Entering the pressure limit Select the maximum pressure input. If the max. pressure is reached, the device stops the grinding process and goes into cooling mode! Depending on the setting of the operating mode, see Ä ‘Selecting the operating mode’ on page 83, the device stops the grinding process and opens the grinding chamber cover or reduces the speed gradu‐...

  • Page 83: Selecting The Operating Mode

    Accessories 6.3.9 Selecting the operating mode You can use the Function menu item to select how the P-7 premium line is to respond to the temperature or pressure limit being reached. rpm: With this setting, the P-7 premium line gradually reduces the speed down to a minimum speed.

  • Page 84: Cleaning The Easy Gtm System

    Accessories Deactivate EASY GTM. Press the[<] button to confirm your entry and return to the main menu. 6.3.11 Cleaning the EASY GTM system NOTICE! The threaded holes inside the bowl, the passage holes and the Allen screws in the locking ring have to be cleaned thor- oughly after each grinding to allow a safe fastening of the EASY GTM system.
  • Page 85 Accessories socket head screws When inserting the locking ring (11), make sure that the two holes are positioned over the socket head screws (d). The lid normally remains on the bowl (10). If the lid (9) is on the measuring/transmission unit (8), release it by hand before cleaning.

  • Page 86: Battery Arrangement

    (rechargeable) batteries may not be disposed of along with household waste. You can, of course, also return discharged batteries - with sufficient postage - by post to: Fritsch GmbH Milling and Sizing Industriestrasse 8 D-55743 Idar-Oberstein, Germany For information on removing the battery, see Ä...

  • Page 87: Design

    Accessories 6.4.1 Design Syringe pump tip Funnel lid for special emptying device Flat seal, 58x41x2.0 Stainless steel strainer Flat seal, 50.5x41x1.5 Adapter for special emptying device O-ring, 49x4 6.4.2 Handling Remove the bowl with the balls and the suspension from the device after grinding and remove the lid ( Ä...
  • Page 88 Accessories Fit the adapter (6) with stainless steel strainer (4) and seals (2, 5, 7) firmly on the grinding bowl and tension it like a lid ( Ä ‘Closing the grinding bowl’ on page 42). Screw on the funnel lid (2) for holding the syringe on the adapter (6)! Fill the syringe (1) with 10ml air.
  • Page 89 Accessories Shake the bowl with the suspension. Pump 2-5 times with the syringe and then mount the syringe (1). Now, the suspension is in the syringe. Unscrew the syringe (1) from the funnel lid (2). Solvent can again be injected into the bowl using the emptied syringe to extract the last remains of the sample, Repeat the pro- cedure 5 to 10 times.

  • Page 90: Cleaning The Special Emptying Device

    Accessories 6.4.3 Cleaning the special emptying device It is cleaned under running water. To do this, remove all parts to be able to clean the seals properly as well. Then dry the parts with a cloth or a blow-dryer. During installation, pay attention to the correct sequence and position of the seals (see Ä...

  • Page 91: Design

    Accessories 6.5.1 Design Lock nut Rubber washer Counterweights, 25 g each Bowl counterweight 6.5.2 Handling Lock nut Rubber disk Compensating washers, 25g each Counterweight 2-hole face wrench Pipe wrench Determine the weight of the grinding bowl to be used with lid, material to be ground and balls.
  • Page 92 Accessories Make sure that the green rubber disk (2) is lying at the top. Now turn the lock nut (1) onto the threaded spindle. To do this, push the spring back. NOTICE! Before starting the grinding process, ensure that the spring is not bent and that a lock nut, that may be loosening, is held by it in the bowl.

  • Page 93: Planetary Mills - "Millcontrol" Software

    Accessories 6.6 Planetary mills - "MillControl" software The PULVERISETTE 7 premium line planetary mill is con‐ trolled either at the device using the clearly arranged touch display or with the MillControl software. The software pro‐ vides the user with all device controlling options and adds...

  • Page 94: General And Optional Settings

    General and optional settings General and optional settings 7.1 Standard Operation Procedure It is possible to protect this device by applying SOP mode. If this mode is activated by the administrator, only stored programs can be loaded for operation. Parameters can no longer be changed. Some parts of the menu structure can no longer be selected.

  • Page 95: Activating Sop Mode

    General and optional settings 7.1.1 Activating SOP mode Enter a number between 1 and 9999; Then "Save" it; Press the "<" button to return to the main menu. ð SOP mode is displayed in the main menu. 7.1.2 Deactivating SOP mode To disable the restrictions for changing parameters, enter the pin code and press the "ENTER"...

  • Page 96: Deleting Sop Mode

    General and optional settings 7.1.3 Deleting SOP mode Deactivate the mode ( Ä ‘Deactivating SOP mode’ on page 95) Enter pin code 0000 and "Save" it Press the "<" button to return to the main menu. - 96 -...

  • Page 97: Rfid

    If the bowl is damaged, the bowl detection can be deactivated. Because the RFID detection is a safety system that cannot simply be deactivated, it is protected by a pin code. This pin code can only be obtained by consulting Fritsch GmbH. - 97 -...

  • Page 98: Language Change

    General and optional settings 7.3 Language change After selecting the national language, all other texts are displayed in the selected language. Press the "<" button to confirm your entry and return to the main menu. - 98 -...

  • Page 99: Screen Brightness

    General and optional settings 7.4 Screen brightness The screen's brightness can be adjusted individually. To do this, touch the adjustment bar or move it back and forth by applying slight pressure. Press the "<" button to save your entry and return to the main menu. - 99 -...

  • Page 100: Information

    General and optional settings 7.5 Information The "INFO" button can be pressed to access system information. operating hours, the firmware version and the bowl materials are displayed here (if they were detected during a START procedure). Press the "<" button to return to the main menu. - 100 -...

  • Page 101: Interfaces

    General and optional settings 7.6 Interfaces In the standard case, the device is equipped with a USB port. An Ethernet or Bluetooth interface can be provided in the future as an option. The interface selection must be switched over accordingly. The optional interfaces have their own installation instructions within the scope of delivery.

  • Page 102: Firmware Update

    General and optional settings 7.7 Firmware update Switch off the device. Install the USB driver software "PL-2303 Driver Installer.exe" on the PC / notebook. Connect the USB cable and only then switch on the device. The USB port is now automatically activated. Start the 'PROGRAMMER.EXE' software and then select the firm- ware file for programming.
  • Page 103 General and optional settings After programming Now, connect the flasher software. Switch off the planetary micro mill (not the computer!) for a few seconds. Switch the device back on again ð Finished!! - 103 -...

  • Page 104: Cleaning

    Cleaning Cleaning 8.1 Grinding elements Clean the grinding bowl and grinding balls each time after using them: e.g. clean them under running water using a brush and a commercially available cleaning agent. Add sand and water until the grinding bowl is about half full and "grind to clean"...

  • Page 105: Removing The Grinding Chamber Cover

    Cleaning 8.2.1 Removing the grinding chamber cover Remove the 4 screws from the side of the housing using a screw- driver. Then, carefully tilt the grinding chamber cover to the right. 3 connectors now need to be released. After doing this, the cover can be lifted off completely and the grinding chamber can be cleaned.

  • Page 106: Maintenance

    Maintenance Maintenance DANGER! Mains voltage! – Maintenance work may only be performed by special- ised personnel. – Before beginning with maintenance work, unplug the mains plug and protect the device against being unin- tentionally switched back on. – Put safety equipment back into operation after mainte- nance work.

  • Page 107: Guarantee Terms

    Guarantee terms Guarantee period As manufacturer, FRITSCH GmbH provides – above and beyond any guar- antee claims against the seller – a guaranty valid for the duration of two years from the date of issue of the guarantee certificate supplied with the device.
  • Page 108 Any servicing done by persons not authorised by us and any use of parts that are not original FRITSCH accessories and spare parts will void the guar- antee.

  • Page 109: Exclusion Of Liability

    FRITSCH GMBH distributor or Fritsch GmbH, Industriestr. 8, D-55743 Idar-Oberstein. FRITSCH GMBH takes the greatest care to ensure that the quality, relia- bility and safety of your products are continuously improved and adapted to the state of the art. The supplied products as well as this operating manual conform to the current state of the art when they leave the sphere of influence of FRITSCH GMBH.
  • Page 110 Exclusion of liability Fritsch GmbH excludes any liability, warranty, or other obligation to com- pensate for damages, regardless of whether this liability, warranty, or other obligation is explicit or implicit, contractual or arising from unlawful acts or prescribed contractually, by law, or otherwise. In no...

  • Page 111: Safety Logbook

    Safety logbook Safety logbook Date Maintenance / Repair Name Signature - 111 -...
  • Page 112 Safety logbook Date Maintenance / Repair Name Signature - 112 -...

  • Page 113: Index

    Index Index Accident prevention ......8 Filling quantities of grinding bowls ... . . 36 Activating EASY GTM .
  • Page 114 Index Selecting the grinding balls ....31 Selecting the grinding bowl ....31 Opening the grinding bowl .

  • Page 116: Industriestraße

    © 2012 Fritsch GmbH Milling and Sizing Industriestraße 8 D - 55743 Idar-Oberstein Telephone: +49 (0)6784/ 70-0 Fax: +49 (0)6784/ 70-11 Email: info@fritsch.de Internet: www.fritsch.de...

Table of Contents
