18 RS485 Serial Port
The serial communication port RS485 is available on the Command Terminals.
On this port may be done a network up to 127 REVO M.
Terminal M1
11
12
19 PG Connector
The PG Connector is used to configure the thyristor unit with the configuration software and with the
programming cable.
The programming cable is not included.
CD-Eng-REVO-M-1PH-60-210A-Thyristors-Units
Description
RS485 A
RS485 B
40
