- Page 1 Pressure resistant electric water heater 80 - 100 - 120 - 150 Litres ECO CLEVER Operating and Installation Instructions Please forward this on to the user! Id. no.: 242440-7...
- Page 2 Customer Services and Sales Departments for any advice you may require. We hope that you will enjoy your electrical storage system. Did you know that products from Austria Email AG offer outstanding energy efficiency? To find out more, visit www.topprodukte.at...
-
Page 3: Table Of Contents
Safety instructions ....................Function ........................ Hot water requirement ..................Saving Energy ....................... Standby energy consumption ................Operating the ECO CLEVER control system (LCD version) ......Clever mode ........................Manual mode ........................ Legionella protection circuit ..................Child lock ........................Display backlighting ...................... Error codes ........................ -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS General • This storage tank can be used by children eight years old and older as well as by persons with re- duced physical, sensory or mental capabilities or who lack experience and knowledge if they are supervised or if they have been trained with regard to the safe use of the storage tank and under- stand the resulting risks. -
Page 5: Function
FUNCTION The domestic water stored in the enamelled internal boiler is heated up by the electrical heating element. The user can preselect the desired temperature on the operating panel. The heating is independently switched on during heating-up process by the control and switched off again after reaching the desired stored water temperature. -
Page 6: Standby Energy Consumption
STANDBY ENERGY CONSUMPTION If a water heater is heated up and no water is released for a long time after the heating process, a cooling of the stored water via the surface of the device, albeit gradual but continuous, will be the result. The intensity and speed of his cooling off will vary according to the construction type of the device, the size of the device, thickness and quality of the container insulation. - Page 7 When holiday mode is selected, the following image appears in the display. You can set the required days by pressing the [+] or [-] button. Pressing the [+] or [-] button for longer allows quicker selection of the days. The maximum number of days is 99. The controller automatically switches itself to the previously selected mode after the set days have elapsed.
-
Page 8: Clever Mode
Clever mode The different comfort levels can be set by pressing the [+] or [-] button. Comfort level Selection Comfort level Energy saving recommended; standard setting Comfort level “3” complies with the requirements of prEN 15440 and corresponds to 80% of the possible hot water content. -
Page 9: Manual Mode
Manual mode In this mode the hot water temperature is kept constant. The following table provides and overview of the approximate temperatures in the tank: Level Selection Temperature ~57°C ~62°C ~67°C ~72°C ~75°C A flashing shower symbol indicates that the water is being heated-up. Legionella protection circuit This circuit reduces the risk of bacterial growth in the tank. -
Page 10: Error Codes
Error codes If an error occurs, the maintenance and error indicator is visible in the display. The backlighting and the error code flashes. Explanation of codes 1. Dry operation There is no water in the tank 2. Unexpectedly long heating duration There are several possible causes: Defective heating element Defective relay... -
Page 11: Troubleshooting
Troubleshooting Symptoms Measures Error code 1 Attention! Only for specialists! Dry operation Switch the controller to manual Disconnect the tank from the power supply Check whether the tank is filled with water – if not, fill the tank Check the safety temperature limiter and reset it, if required (push button on con- troller) Switch the power back on If the error indication remains, the controller or the display must be replaced... -
Page 12: Control Unit
Control unit The control unit contains the processor, the power connections and the sensors, which are set by the controller. Error indications on the control unit: When the controller reports an error, an LED illuminates on the control unit. Refer to the following table for information: LED indication Description Function... -
Page 13: Operating Requirements
OPERATING REQUIREMENTS The storage tanks must be used exclusively in accordance with the conditions set out on the rating panel. The maximum input pressure should correspond to the nominal pressure stated on the rating panel. In addition to the legally recognised national guidelines and standards, the connection conditions of the local electricity and water works as well as those set out in the operating and assembly instructions must be complied with. - Page 14 f) If a water heater is fitted with covers (cladding) in narrow small spaces or in suspended ceilings and the like, it is crucial to ensure that the connection side of the device (water connections, electrical connec- tion room and/or boiler room) remains freely accessible and that there is no heat accumulation. There must be a free space of 500mm for the dismantling of the heating flange.
-
Page 15: Dimensions Sketch
DIMENSIONS SKETCH Cold water Hot water Thinwall suspension Dimensions in mm Nominal capacity Weight in Type B adjustable in litres from - to Hanging storage tank 400 - 550 Hanging storage tank 400 - 700 Hanging storage tank 1019 550 - 850 Hanging storage tank 1219 750 - 1000 Id. -
Page 16: Product Data Erp
PRODUCT DATA ERP ECO CLEVER Model Storage tank volume Mixed water volume Load profile Energy efficiency grade Energy efficiency 39.8 38.9 38.3 38.7 Daily electricity consumption 6.039 6.220 6.330 6.248 elec Annual electricity consumption 1316 1347 1366 1352 Power consumption with smart 30.195 31.100 31.650... - Page 17 The following must be observed: In order to ensure the faultless functioning of the connection fittings these may only be installed in frost-pro- tected spaces. The outlet of the safety valve must be open and observable and/or the outlet pipe from the drip tray (water overflow funnel) must not terminate outside so that neither frost nor blockages due to dirt and the like can result in a malfunction.
-
Page 18: Electrical Connection
In order to allow repairs to be carried out easily and to allow the device to be removed or replaced, it is necessary to establish the connection to the tank by means of a detachable connection (union). Storage tank leaks as a result of an improper connection and resulting damage and consequential damage are excluded from the warranty and product liability. -
Page 19: Initial Commissioning
INITIAL COMMISSIONING Before switching on the electrical power the storage tank must be filled with water. During the heating up process the expansion water generated in the inner boiler must drip out of the safety valve in the case of a pressure resistant connection and out of the mixer unit in the case of a non-pressure connection. -
Page 20: Inspection, Maintenance, Servicing
INSPECTION, MAINTENANCE, SERVICING a) During heating-up excess water must be seen to drip out of the safety valve outlet (in the case of non-pressure connections the excess water will drip out of the mixer unit valve). When fully heated up (approx. -
Page 21: Guarantee, Warranty And Product Liability
GUARANTEE, WARRANTY AND PRODUCT LIABILITY The warranty will be fulfilled in accordance with the current legal provisions of the Republic of Austria as well as with those of the EU. A condition for the operation of guarantee services by the product manufacturer (hereinafter referred to as the PM) is the presentation of the paid invoice for the purchase of the device for which the guarantee service is being invoked, whereby the identity of the device in terms of type and serial number must be taken from the invoice and must be produced by the claimant. - Page 22 In case of third-party interference without our express instruction, any and all claims shall be null and void, even if this is done by a licensed installation technician. The acceptance of costs arising from repairs carried out by third-parties shall be subject to the PM having been requested to fix the fault and having either failed to meet their exchange or repair obligations or not having done so within a reasonable period.
- Page 23 NOTES Id. no.: 242440-7...
- Page 24 A-8720 Knittelfeld, Austriastraße 6 Tel.: (03512) 700-0, Fax: (03512) 700-239 Internet: www.austria-email.at E-mail: office@austria-email.at Austria Email in your area? For addresses and telephone numbers of our subsidiaries, visit our homepage at www.austria-email.at Print errors and changes of all kinds are reserved.
