Networking
LAN
Wireless
Connectivity
USB
Serial
SD
Special I/O
Expansion
Advanced Technologies
CPU Virtualization
Special Functionality
Operating System
Supported
Operating Conditions
Input Voltage
Power Consumption
Operating Temperature
Relative Humidity
MTTF
Enclosure
Material
Cooling
Dimensions
Weight
Package
Warranty
Notes
fitlet-H/T owner's manual
2x GbE LAN ports
LAN1: Intel I211 GbE controller (RJ-45)
LAN2: Intel I211 GbE controller (RJ-45)
Intel 2.4/5GHz dual band 7260HMW
WLAN 802.11ac
Bluetooth 4.0
2x USB 3.0
6x USB 2.0
1x Serial communication port
COM1: RS232 via mini serial connector
Micro-SD slot support SD/SDHC/SDXC cards
Transfer rates up to 25 MB/s
1x micro SIM slot (6 pins)
Half/Full-size mini-PCIe socket
Half/Full-size mini-PCIe/mSATA socket
Yes
Auto-On
Wake-on-LAN
Wake-on-Timer
PXE Boot
Watchdog
Windows 7/8/10, 32-bit and 64-bit
Linux 32-bit and 64-bit
Embedded OS
Fitlet-H
Unregulated 10 – 15VDC input
4.5W – 10.5W
1. Commercial
HDD models: 0°C – 50°C
SSD models: 0°C – 70°C
2. Extended (TE)
SSD models only: -20°C – 70°C
3. Industrial (TI)
SSD models only: -40°C – 70°C
10% to 90% (operation)
5% to 95% (storage)
> 100,000 hours
Fitlet-H
Die Cast Aluminum
Passive Cooling Fanless Design
19cm x 16cm x 2.5cm
1067gr
5 years
3
1. Nominal input voltage: 12V
2. Shared with mSATA
3. For products purchased since 1-Jan-2013
4. For use with mini PCIe Cellular Modem module
4
2
Fitlet-T
1
5W – 25W
Fitlet-T
19cm x 16cm x 4cm
1100gr
