2.1 SSP-100 Client Driver for DOS

In order to use the SSP-100 Client Driver, the system must be configured with Card and Socket
Services software. Card and Socket Services software is not provided with the SSP-100 but is
available from Quatech.
IMPORTANT:
Some versions of Card and Socket Services dated before 1993
do not support general purpose I/O cards.
installation of the Client Driver the adapter does not configure
or operate properly, an updated version of Card and Socket
Services may be required.

2.1.1 Client Driver Installation

The following procedure is used to install the SSP-100 Client Driver:
1. Copy the Client Driver from the SSP-100 distribution diskette onto the system's hard
drive.
2. Using an ASCII text editor, open the system's CONFIG.SYS file located in the root
directory of the boot drive.
3. Locate the line(s) in the CONFIG.SYS file where the Card and Socket Services
software is installed.
4. AFTER the line(s) installing the Card and Socket Services software, add the
following line to the CONFIG.SYS file:
SSP130CL.SYS options
command line options discussed on the following pages.
5. Save the CONFIG.SYS file and exit the text editor.
6. Insert the SSP-100 into one of the system's PCMCIA slots.
NOTE: Since the SSP-100 Client Driver supports "Hot Swapping", it is not necessary to
have the SSP-100 installed when booting the system. By inserting the card before
booting, however, the Client Driver will report the adapter configuration during the boot
process thereby verifying the changes made to the CONFIG.SYS.
2-3
If after careful
DEVICE
where options are the SSP-100 Client Driver
SSP-100
= drive:\path\
User's Manual
(Rev. G and later)
