1. Introduction

The SSP-100 is a single channel RS-232 asynchronous serial adapter for systems

equipped with PCMCIA Type II and/or Type III expansion sockets. The SSP-100 is a

PCMCIA Type II (5 mm) card and is PCMCIA PC Card Standard Specification 2.1

compliant.

The SSP-100's serial port is implemented using a 16C750 Universal Asynchronous

Receiver/Transmitter (UART), which is the recommended communications interface for

multitasking environments and with applications involving high data transfer rates.

PCMCIA Card

Cable Assembly

Standard D-9 Male

Figure 1. SSP-100 Card and Cable Assembly

SSP-100

User's Manual

1-1

(Rev. G and later)
