Waddress specifies the base address of the memory window required to configure theSSP-100.
Set address = D0 for a memory window at segment D000, address = D8 for a
memory window at segment D800, etc. Valid settings for address are C8, CC, D0,
D4, D8, and DC. If this option is omitted, a memory window at segment D000 will
be used.
Before removing a SSP-100 from its PCMCIA socket, the Enabler should be executed to free the
system resources allocated when the card was installed. For this operation the Enabler provides
on additional command line option:
R instructs the enabler to release the resources previously allocated to the SSP-100.
When the 'R' option is used, any settings specified by the 'B' and 'I' options are
ignored.
2.2.1.1 Example 1
SSP130EN.EXE
In example 1, no command line argument is specified. The Enabler will report an error and
display the proper usage of the command.
2.2.1.2 Example 2
SSP130EN.EXE (s0,b300,i5)
In example 2, the Enabler will configure the SSP-100 in socket 0 with a base address of 300H
and IRQ 5 using a configuration memory window at segment D000.
2.2.1.3 Example 3
SSP130EN.EXE (i10,h,b340,s1)
In example 3, the Enabler will configure the SSP-100 in socket 1 with a base address of 340H
and IRQ 10 using a configuration memory window at segment D000.
2.2.1.4 Example 4
SSP130EN.EXE (s0,b300,i3,wd8)
In example 4, the Enabler will configure the SSP-100 in socket 0 with a base address of 300H
and IRQ 3 using a configuration memory window at segment D800.
