Wiring the ICAD actuator
continued
Connections
upper level
AKS 4100/4100U
+
–
© Danfoss | DCS (MWA) | 2016.07
Wiring diagram showing ICAD wired to a Danfoss EKE controller
Note: For instructions on completely wiring an EKE controller, please see the relevant EKE controller manual.
AKS 41
24 V DC
2 3
4-20 mA
1 2 3 4 5 6 7 8
15 16 17 18 19 20 21 22
CAN RJ
plug for
remote display
CANbus connection
ModBUS
to other EKE controllers
24 V AC
L
N
orange
blue
9 10 11 12 13 14
23 24
orange
yellow
Upper level
ICAD 2 gen
nd
Optional ICAD/ICM
Valve Position
Feedback
DI1 - main switch
ICAD 2 gen (2010 +)
nd
brown
24 V DC
white
