Detroit Radiant Products ACS-40P-120V Manual

Acs series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Detroit Radiant Products Co.
ACS Series
Installation, Operation
Maintenance and Parts
The ACS Series heater is a gas-fired radiant brooder. This manual provides specific information related
to the ACS Series models. All persons involved with the installation, operation and maintenance of the
heater system must read and understand the information in this manual.
Improper installation, adjustment, alteration, service or maintenance can cause
property damage, injury or death. Read the installation, operation and maintenance
instructions thoroughly before installing or servicing this equipment.
This heater must be installed and serviced by trained gas installation and service
personnel only. Failure to comply could result in personal injury, asphyxiation, death,
fire or property damage.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other appliance.
Do not use this heater in indoor living or sleeping quarters! Installation of a
commercial brooder in residential indoor spaces may result in property damage,
serious injury, asphyxiation or death.
If you smell gas:
1. Open windows. Do not touch electrical switches.
2. Extinguish any flame.
3. If odor continues, keep away from the appliance and immediately call your gas supplier or fire
department.
INSTALLER: Present this manual to the end user.
Keep these instructions in a clean and dry place for future reference.
Model#: ___________________ Serial #: _________________________
Manual
!
WARNING
!
DANGER
!
(located on rating label)
LIOACS-Rev. 01917
Print: LIOACS-2M-09/17_r1-01/18 (CDS)
Replaces:
