12. Verify that the following are true in the specified tile or area:
Setting
Tile 1
Tile 2
Tile 3
Tile 4
Status Bar
13. On the signal generator, check that HDVG7 is displayed and then press the
down arrow button to select Sample Structure/Depth. Next, press the right
arrow button to change the HDVG7 color space from YPbPr to GBR 4:4:4
10 bit.
14. Press the ENTER button.
15. Verify the following are true for the specified tile or area:
Setting
Tile 1
Tile 2
Tile 3
Tile 4
16. Record Pass or fail in the test record.
Incoming Inspection
Display
YPbPrA parade waveform displayed
Format indicates Auto 1080i 59.94-YCbCrA
4444 10 bit
Color bars picture displayed
Endpoints of Lightning display land within
targets
SDI Input DL-AB is displayed
Display
YPbPr parade waveform displayed and
automatically converted from RGB input
signal
Format indicates GBR 4:4:4 10 bit
Color bars picture displayed
Endpoints of Lightning display land within
targets
