Vega VEGACAL 65 Operating Instructions Manual

Capacitive cable electrode for continuous level measurement
Hide thumbs Also See for VEGACAL 65:
Table of Contents

Advertisement

Quick Links

Download this manual

Operating Instructions

Capacitive cable electrode for
continuous level measurement
VEGACAL 65
Foundation Fieldbus
Document ID: 30035

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VEGACAL 65 and is the answer not in the manual?

Questions and answers

Related Manuals for Vega VEGACAL 65

Summary of Contents for Vega VEGACAL 65

  • Page 1: Operating Instructions

    Operating Instructions Capacitive cable electrode for continuous level measurement VEGACAL 65 Foundation Fieldbus Document ID: 30035...

  • Page 2: Table Of Contents

    Set up with PACTware and other adjustment programs Connect the PC ......................31 Parameter adjustment with PACTware ................32 7.3 Parameter adjustment with AMS™ and PDM ..............32 Saving the parameter adjustment data ................32 8 Maintenance and fault rectification 8.1 Maintenance ........................33 8.2 Rectify faults ........................33 VEGACAL 65 • Foundation Fieldbus...
  • Page 3 Instructions manuals for accessories and replacement parts Tip: To ensure reliable setup and operation of your VEGACAL 65, we offer accessories and replacement parts. The corresponding documenta- tions are: • 27720 - VEGADIS 61 • 30531 - Electronics module VEGACAL series 60 • 34296 - Protective cover • 31088 - Flanges according to DIN-EN-ASME-JIS Editing status: 2013-08-21 VEGACAL 65 • Foundation Fieldbus...

  • Page 4: About This Document

    Action This arrow indicates a single action. Sequence of actions Numbers set in front indicate successive steps in a procedure. Battery disposal This symbol indicates special information about the disposal of bat- teries and accumulators. VEGACAL 65 • Foundation Fieldbus...

  • Page 5: For Your Safety

    During work on and with the device the required personal protective equipment must always be worn. Appropriate use VEGACAL 65 is a sensor for continuous level measurement. You can find detailed information on the application range in chapter "Product description". Operational reliability is ensured only if the instrument is properly used according to the specifications in the operating instructions manual as well as possible supplementary instructions.

  • Page 6: Safety Label On The Instrument

    That is why we have introduced an environment management system with the goal of continuously improving company environmental pro- tection. The environment management system is certified according to DIN EN ISO 14001. Please help us fulfill this obligation by observing the environmental instructions in this manual: • Chapter "Packaging, transport and storage" • Chapter "Disposal" VEGACAL 65 • Foundation Fieldbus...

  • Page 7: Product Description

    Housing with electronics • Housing cover, optionally available with display and adjustment module Fig. 1: VEGACAL 65 - cable version with plastic housing Housing cover with integrated display and adjustment module (optional) Housing with electronics 3 Process fitting VEGACAL 65 • Foundation Fieldbus...

  • Page 8: Principle Of Operation

    In addition to the type label outside, you can also find the serial num- ber on the inside of the instrument. Principle of operation Area of application VEGACAL 65 is a level sensor with partly insulated probe for continu- ous level measurement. The electronics functions according to the admittance principle (phase-selective admittance processing). It is designed for industrial use in all areas of process technology and can be applied in all areas of industrial process measurement.

  • Page 9: Operation

    IEC 61158-2 DD/CFF The DD (Device Descriptions) and CFF (capability files) necessary for planning and configuration of your FF (Foundation Fieldbus) com- munication network are available in the download area of the VEGA homepage www.vega.com under "Services - Downloads - Software - Foundation Fieldbus". The appropriate certificates are also available there. A CD with the appropriate files and certificates can be ordered via e-mail under info@de.vega.com or by phone from one of the VEGA agencies under the order number "DRIVER.S".

  • Page 10: Packaging, Transport And Storage

    You can find further information in the operating instructions "Display and adjustment module PLICSCOM" (Document-ID 27835). VEGACONNECT The interface adapter VEGACONNECT enables the connection of communication-capable instruments to the USB interface of a PC. For parameter adjustment of these instruments, the adjustment software PACTware with VEGA-DTM is required. VEGACAL 65 • Foundation Fieldbus...
  • Page 11 The protective cover protects the sensor housing against soiling and intense heat from solar radiation. You will find additional information in the supplementary instructions manual "Protective cover" (Document-ID 34296). Flanges Screwed flanges are available in different versions according to the following standards: DIN 2501, EN 1092-1, BS 10, ANSI B 16.5, JIS B 2210-1984, GOST 12821-80. You can find additional information in the supplementary instructions manual "Flanges according to DIN-EN-ASME-JIS" (Document-ID 31088). VEGACAL 65 • Foundation Fieldbus...

  • Page 12: Mounting

    Fig. 4: Measures against moisture penetration Pressure/Vacuum The process fitting must be sealed if there is gauge or low pressure in the vessel. Before use, check if the seal material is resistant against the measured product and the process temperature. VEGACAL 65 • Foundation Fieldbus...

  • Page 13: Mounting Instructions

    During operation, the probe must not touch any installations or the vessel wall. The measured value can also change if the distance to the vessel wall changes considerably. If necessary, secure the end of the probe (insulated). In the gravity weight there is a thread (M12), e.g. for a ring bolt (article no. 2.27424). The thread is already insulated in the gravity weight with an adapter. Make sure that the probe cable is not completely taut. Avoid tensile loads on the cable. VEGACAL 65 • Foundation Fieldbus...
  • Page 14 If the instrument is mounted in the filling stream, unwanted false measurement signals can be generated. For this reason, mount the instrument at a position in the vessel where no disturbances, e.g. from filling openings, agitators, etc., can occur. This applies particularly to instrument versions with a longer probe. Fig. 6: Inflowing medium VEGACAL 65 • Foundation Fieldbus...

  • Page 15: Connecting To Power Supply

    • Connect only in the complete absence of line voltage • If overvoltage surges are expected, overvoltage arresters should be installed according to Foundation Fieldbus specification Tip: We recommend VEGA overvoltage arrester B63-32. In hazardous areas you must take note of the respective regulations, conformity and type approval certificates of the sensors and power supply units. Voltage supply The instrument requires a operating voltage of 9 … 32 V DC. Operat- ing voltage and the digital bus signal are carried on the same two-wire connection cable.

  • Page 16: Connection Procedure

    Fig. 7: Connection steps 6 and 7 8. Press down the opening levers of the terminals, you will hear the terminal spring closing 9. Check the hold of the wires in the terminals by lightly pulling on them VEGACAL 65 • Foundation Fieldbus...

  • Page 17: Wiring Plan, Single Chamber Housing

    Fig. 8: Material versions, single chamber housing Plastic Aluminium Stainless steel, investment casting Stainless steel, electro-polished Filter element for air pressure compensation of all material versions. Blind plug with version IP 66/IP 68, 1 bar for Aluminium and stainless steel VEGACAL 65 • Foundation Fieldbus...

  • Page 18: Wiring Plan, Double Chamber Housing

    Fig. 10: Wiring plan, single chamber housing Voltage supply, signal output Wiring plan, double chamber housing The following illustration apply to non-Ex as well as Ex ia versions. The Exd version is described in the next subchapter. VEGACAL 65 • Foundation Fieldbus...
  • Page 19 Electronics compartment Typ: Display I ² C 5 6 7 8 Fig. 12: Electronics compartment, double chamber housing Simulation switch ("on" = simulation mode) Connection for VEGACONNECT (I²C interface) Internal connection cable to the connection compartment VEGACAL 65 • Foundation Fieldbus...

  • Page 20: Wiring Plan, Double Chamber Housing Ex D

    Wiring plan, double chamber housing Ex d Housing overview Fig. 15: Double chamber housing Housing cover, connection compartment Blind plug or plug M12 x 1 for VEGADIS 61 (optional) Housing cover, electronics compartment Filter element for air pressure compensation Cable gland VEGACAL 65 • Foundation Fieldbus...
  • Page 21 Internal connection cable to the connection compartment Terminals for VEGADIS 61 Connection compartment Fig. 17: Connection compartment, Ex-d double chamber housing Spring-loaded terminals for power supply and cable screen Ground terminal for connection of the cable screen VEGACAL 65 • Foundation Fieldbus...

  • Page 22: Wiring Plan - Version Ip 66/Ip 68, 1 Bar

    Fig. 18: Wiring plan, Ex-d double chamber housing Voltage supply, signal output 5.6 Wiring plan - version IP 66/IP 68, 1 bar Wire assignment, con- nection cable Fig. 19: Wire assignment, connection cable brown (+) and blue (-) to power supply or to the processing system Shielding VEGACAL 65 • Foundation Fieldbus...

  • Page 23: Set Up With The Display And Adjustment Module Plicscom

    4. Screw housing cover with inspection window tightly back on Removal is carried out in reverse order. The display and adjustment module is powered by the sensor, an ad- ditional connection is not necessary. VEGACAL 65 • Foundation Fieldbus...

  • Page 24: Adjustment System

    Adjustment system Fig. 21: Display and adjustment elements LC display Indication of the menu item number Adjustment keys • Key functions [OK] key: – Move to the menu overview – Confirm selected menu – Edit parameter VEGACAL 65 • Foundation Fieldbus...

  • Page 25: Setup Steps

    The actual level can then be calculated on the basis of these settings. VEGACAL 65 must be installed. A change of level is necessary for this adjustment. In the main menu item "Basic adjustment", the individual submenu items should be selected one after the other and provided with the correct parameter values.
  • Page 26 54.5 pF 3. Prepare the adjustment value for editing with [OK]. Move to the selection window with [OK]. Min. adjustment Accept current measured value? Accept? Edit? 4. Accept the current measured value or move to the editing window with "Edit". To edit, set the cursor to the requested position with VEGACAL 65 • Foundation Fieldbus...
  • Page 27 Linearization curve A linearisation is necessary for all vessels in which the vessel volume does not increase linearly with the level - e.g. in a horizontal cylindri- cal or spherical tank - and the indication or output of the volume is required. Corresponding linearisation curves are preprogrammed for VEGACAL 65 • Foundation Fieldbus...
  • Page 28 Min. adjustment 0 pF Damping ti Linearization Linear Sensor-TAG Sensor Display AI-Out 1 Special parameters All special parameters are reset to delivery status. Peak value The min. and max. values are reset to the actual value. VEGACAL 65 • Foundation Fieldbus...

  • Page 29: Menu Schematic

    Service Info Displayed value Backlight ▼ Al-Out Switched off Diagnostics Basic adjustment Display ▶ Diagnostics Service Info Peak value Sensor status Trend recording Capacit. min.: 65.7 pF Presentation of the trend curve Capacit. max.: 782.4 pF VEGACAL 65 • Foundation Fieldbus...

  • Page 30: Saving The Parameter Adjustment Data

    They are thus available for multiple use or service purposes. If VEGACAL 65 is equipped with a display and adjustment module, the most important data can be read out of the sensor into the display and adjustment module.

  • Page 31: Set Up With Pactware And Other Adjustment Programs

    Fig. 23: Connection via VEGACONNECT externally I²C bus (com.) interface on the sensor I²C connection cable of VEGACONNECT VEGACONNECT USB cable to the PC Necessary components: • VEGACAL 65 • PC with PACTware and suitable VEGA DTM • VEGACONNECT • Power supply unit or processing system VEGACAL 65 • Foundation Fieldbus...

  • Page 32: Parameter Adjustment With Pactware

    Note: Keep in mind that for setup of VEGACAL 65, DTM-Collection in the actual version must be used. All currently available VEGA DTMs are included as a DTM Collection on a CD. They can be purchased for a token fee from the responsible VEGA agency. In addition, the actual PACTware version is also avail- able on this CD. In addition, this DTM Collection incl. the basic version of PACT- ware can be downloaded free of charge from the Internet. Move via www.vega.com and "Downloads" to "Software".

  • Page 33: Maintenance And Fault Rectification

    24 hour service hotline Should these measures not be successful, please call in urgent cases the VEGA service hotline under the phone no. +49 1805 858550. The hotline is available to you 7 days a week round-the-clock. Since we offer this service world-wide, the support is only available in the English language.

  • Page 34: Exchanging The Electronics Module

    Ex approval may be used. If there is no electronics module available on site, one can be ordered from the VEGA agency serving you. The new electronics module must be loaded with the order data of the Sensor serial number sensor.

  • Page 35: Shortening The Electrode

    3. To avoid splicing of the steel cable, tin the cable before shortening with a soldering iron and tighten the wire. 4. Shorten the cable with a cut-off wheel or metal saw at the lower end. Make sure the length is correct before shortening. Fig. 24: Take the gravity weight into account and shorten the cable respectively VEGACAL 65 • Foundation Fieldbus...

  • Page 36: How To Proceed In Case Of Repair

    Clean the instrument and pack it damage-proof • Attach the completed form and, if need be, also a safety data sheet outside on the packaging • Please contact for the return shipment the agency serving you. You can find the agency on our home page www.vega.com. VEGACAL 65 • Foundation Fieldbus...

  • Page 37: Dismounting

    These may be used only for privately used products according to the WEEE directive. Correct disposal avoids negative effects on humans and the environ- ment and ensures recycling of useful raw materials. Materials: see chapter "Technical data" If you have no way to dispose of the old instrument properly, please contact us concerning return and disposal. VEGACAL 65 • Foundation Fieldbus...

  • Page 38: Supplement

    1 NPT, 1½ NPT (ASME B1.20.1) Ʋ Flanges DIN from DN 50, ANSI from 2" Weight Ʋ Instrument weight (depending on 0.8 … 4 kg (0.18 … 8.82 lbs) process fitting) Ʋ Gravity weight 900 g (32 oz) Ʋ Cable weight: ø 6 mm (0.236 in) 180 g/m (1.9 oz/ft) Ʋ Cable weight: ø 8 mm (0.315 in) 220 g/m (2.4 oz/ft) Sensor length (L) 0.2 … 32 m (0.656 … 105 ft) Length screening tube (L) 0.07 … 4 m (0.23 … 13.12 ft) Max. tensile load (cable) Ʋ PTFE partly insulated: ø 6 mm 10 KN (2248 lbf) (0.236 in) VEGACAL 65 • Foundation Fieldbus...
  • Page 39 Ʋ > 120 pF 1 % of the current measured value Linearity error < 0.25 % of the complete measuring range Ambient conditions Ambient, storage and transport tempera- -40 … +80 °C (-40 … +176 °F) ture Process conditions Process pressure Ʋ Standard -1 … +64 bar/-100 … 6400 kPa (-14.5 … 928 psig) Ʋ with screening tube adapter (PN1) 0 … +1 bar/0 … 100 kPa (0 … 14.5 psig) Process temperature (thread or flange temperature) Ʋ VEGACAL 65 of 316L with cable PT- -50 … +150 °C (-58 … +302 °F) FE partly insulated ø 6 mm (0.236 in) VEGACAL 65 • Foundation Fieldbus...
  • Page 40 – 1 x closing cap ½ NPT, 1 x blind plug ½ NPT, 1 x blind plug M16 x 1.5 or optionally 1 x plug M12 x 1 for exter- nal display and adjustment unit – 1 x plug (depending on the version), 1 x blind plug M20 x 1.5; 1 x blind plug M16 x 1.5 or optionally avail- able with 1 x plug M12 x 1 for external display and adjustment unit Spring-loaded terminals for wire cross- < 2.5 mm² (AWG 14) section Depending on the version M12 x 1, according to DIN 43650, Harting, 7/8" FF. VEGACAL 65 • Foundation Fieldbus...
  • Page 41 Operating voltage with illuminated display and adjustment module Ʋ Non-Ex instrument 12 … 32 V DC Ʋ Ex-ia instrument 12 … 24 V DC Ʋ Ex-d instrument 20 … 32 V DC Power supply by/max. number of sensors Ʋ Fieldbus max. 32 (max. 10 with Ex) Electrical protective measures Protection, depending on housing version VEGACAL 65 • Foundation Fieldbus...

  • Page 42: Foundation Fieldbus

    Approvals Instruments with approvals can have different technical data depending on the version. For that reason the associated approval documents of these instruments have to be carefully noted. They are part of the delivery or can be downloaded under www.vega.com via "VEGA Tools" and "serial number search" as well as via "Downloads" and "Approvals". 10.2 Foundation Fieldbus Block diagram, measured value processing The following illustration shows the Transducer Block (TB) and Function block (FB) in simplified form.
  • Page 43 Channel = 1: Primary Value AI 2 Channel = 2: Secondary Value 1 Channel = 3: Secondary Value 2 Fig. 26: VEGACAL 65 measured value processing Diagram, adjustment The following illustration shows the function of the adjustment: VEGACAL 65 • Foundation Fieldbus...
  • Page 44 Sensor reference plane cal_level_hi [%] Calibration Highest Point cal_level_lo [%] Calibration Lowest Point Fig. 27: Adjustment VEGACAL 65 Parameter list The following list contains the most important parameters and their meaning: • primary_value – This is the process value after adjustment and Linearization with the status of the transducer block – It is the input for the AIFB when CHANNEL = 1 is selected –...
  • Page 45 • level_offset • sensor_offset • phase_angle_select – set up to suit the process conditions • epsilon_r – set up to suit the process conditions • product_type – set up to suit the process conditions VEGACAL 65 • Foundation Fieldbus...

  • Page 46: Dimensions

    Fig. 28: Housing versions in protection IP 66/IP 68 (0.2 bar) - with integrated display and adjustment module the housing is 9 mm/0.35 in higher Plastic housing Aluminium housing Aluminium double chamber housing Stainless steel housing, electropolished Stainless steel housing - precision casting Stainless steel double chamber housing - precision casting VEGACAL 65 • Foundation Fieldbus...
  • Page 47 ø 84 mm (3.31") (3.03") M16x1,5 M20x1,5 M20x1,5 M20x1,5 M20x1,5/ ½ NPT Fig. 29: Housing versions in protection IP 66/IP 68 (1 bar) - with integrated display and adjustment module the housing is 9 mm/0.35 in higher Aluminium housing Stainless steel housing - precision casting Stainless steel double chamber housing - precision casting VEGACAL 65 • Foundation Fieldbus...
  • Page 48 G1 1 / 2 A ø 6 mm (0.24") ø 30 mm (1.18") Fig. 30: VEGACAL 65, cable version with ø 6 mm, threaded version G1 (ISO 228 T1) = Sensor length, see chapter "Technical data" VEGACAL 65 • Foundation Fieldbus...
  • Page 49 G1 1 / 2 A ø 8 mm (0.32") ø 30 mm (1.18") Fig. 31: VEGACAL 65, cable version with ø 8 mm, threaded version G1 (ISO 228 T1) = Sensor length, see chapter "Technical data" VEGACAL 65 • Foundation Fieldbus...
  • Page 50 10 Supplement ø 40 mm (1.58") Fig. 32: Temperature adapter ø 16 mm (0.63") Fig. 33: VEGACAL 65, screening tube, for example against strong condensation Length of the screening tube, see chapter "Technical data" VEGACAL 65 • Foundation Fieldbus...

  • Page 51: Information

    Les lignes de produits VEGA sont globalement protégées par des droits de propriété intellec- tuelle. Pour plus d'informations, on pourra se référer au site www.vega.com. VEGA lineas de productos están protegidas por los derechos en el campo de la propiedad indus- trial. Para mayor información revise la pagina web www.vega.com.

  • Page 52: Information

    Subject to change without prior notice © VEGA Grieshaber KG, Schiltach/Germany 2013 VEGA Grieshaber KG Phone +49 7836 50-0 Am Hohenstein 113...
